IMPORTANT MANUAL Do Not Throw Away
/an
OWNER'S MANUAL
MODEL:
PPR20H42STB
LAWN TRACTOR
WARNING:
Read this Owner's Manual and follow
all Warnings and Safety Instructions.
Failure to do so can result in serious
injury.
ALWAYS WEAR EYE PROTECTION DURING OPERATION
183255 3.4.02 RD
Printed in U.S.A.
I!
SAFETY RULES
'_ Safe Operation Practices for Ride-On Mowers _
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS.
FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
I. GENERAL OPERATION
• Read,understand,andfollow allinstructionsinthemanual
and on the machinebeforestarting.
•Only allow responsibleadults, who are familiar with the
instructions,to operate the machine.
• Clear the area ofobjectssuch as rocks,toys,wire, etc.,
whichcould be pickedupand thrownbythe blade.
•Besure thearea isclear ofother people beforemowing.
Stop machine ifanyone enters the area.
•Never carrypassengers.
•Do not mow in reverse unless absolutely necessary.
Always lookdownand behindbeforeand whilebacking.
•Beawareofthemowerdischargedirectionanddonotpoint
itat anyone. Donotoperatethemowerwithouteitherthe
entire grass catcheror the guard inplace.
•Slow downbeforeturning.
•Never leavea runningmachineunattended. Alwaysturn
off blades, set parkingbrake, stop engine, and remove
keys beforedismounting.
•Turn offbladeswhen notmowing.
• Stopenginebeforeremovinggrasscatcherorunclogging
chute.
•Mow onlyin daylightor good artificiallight.
•Do notoperate the machinewhileunder the influenceof
alcoholordrugs.
•Watch for traffic when operating near or crossingroad-
ways.
• Useextracarewhen loading orunloading the machine into
a trailer or truck.
• Data indicates that operators, age 60 years and above, are
involved in a large percentage of riding mower-related
injuries. These operators should evaluate their ability to
operate the riding mower safely enough to protect them-
selves and others from serious injury.
• Keep machine free ofgrass, leaves or other debris build-
up which can touch hot exhaust /engine parts and burn.
Do not allow the mower deck to plow leaves
or other debris which can cause build-up to occur. Clean
any oil or fuel spillage before operating or storing the
machine. Allow machine to cool before
storage.
I1.SLOPE OPERATION
Slopes are a major factor related to loss-of-control and tipover
accidents, which can result in severe injury or death. All slopes
requireextra caution. Ifyoucannot backup theslopeor ifyoufeel
uneasy on it, do not mow it.
DO:
• Mow up and down slopes, not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine. Tall grass can hide obstacles.
• Use slow speed. Choose a low gear so that you will not
have to stop or shift while on the slope.
• Follow the manufacturer's recommendations for wheel
weights or counterweights to improve stability.
• Use extra care with grass catchers or other attachments.
These can change the stability of the machine.
• Keep all movement on the slopes slowand gradual Do
not make sudden changes in speed or direction.
2
• Avoid starting or stopping on a slope. Iftires lose traction,
disengage the blades and proceed slowly straight down
the slope.
DO NOT:
•Do not turn on slopes unless necessary, and then, turn
slowly and gradually downhill, if possible.
•Do not mow near drop-offs, ditches, or embankments.
The mower could suddenly turn over ifawheel is overthe
edge of a cliff or ditch, or if an edge caves in.
•Do notmow on wet grass. Reduced traction could cause
sliding.
•Do not try to stabilize the machine by putting your foot on
theground.
•Do not use grass catcher on steep slopes.
III. CHILDREN
Tragic accidents can occur if the operator is not alert to the
presence of children. Children are often attracted to the
machine and the mowing activity. Neverassumethat children
will remain where you last saw them.
• Keep children out of the mowing area and under the
watchful care of another responsible adult.
• Be alert and turn machine off if children enter the area.
• Before and when backing, look behind and downforsmall
children.
• Never carry children. They may fall off and be seriously
injured or interfere with safe machine operation.
• Never allow children to operate the machine.
• Use extra care when approaching blind corners, shrubs,
trees, or other objects that may obscure vision.
IV. SERVICE
• Use extra care in handling gasoline and other fuels. They
are flammable and vapors are explosive.
- Use only an approved container.
- Never remove gas cap or add fuel with the engine
running. Allow engine to cool before refueling. Do not
smoke.
- Never refuel the machine indoors.
- Never store the machine or fuel container inside where
there is an open flame, such as a water heater.
• Never run a machine inside a closed area.
• Keep nuts and bolts, especially blade attachment bolts,
tight and keep equipment in good condition.
• Never tamper with safety devices. Check their proper
operation regularly.
• Keep machine free ofgrass, leaves, orother debris build-
up. Clean oilor fuel spillage. Allow machineto cool before
storing.
• Stop and inspect the equipment if you strike an object.
Repair, ifnecessary, before restarting.
• Never make adjustments or repairs with the engine
running.
• Grass catcher components are subject towear, damage,
and deterioration, which could expose moving parts or
allow objects to bethrown. Frequently check components
and replace with manufacturer's recommended parts,
when necessary.
• Mower blades are sharp and can cut. Wrapthe blade(s)
or wear gloves, and use extra caution when servicing
them.
• Check brake operation frequently. Adjust and service
as required.
SAFETY RULES
&Safe Operation Practices for Ride-On Mowers &
• Be sure the area is clear of other people before mowing.
Stop machine if anyone enters the area.
• Never carry passengers or children even with the blades
off.
• Do not mow in reverse unless absolutely necessary. Al-
ways look down and behind before and while backing.
• Never carry children. They may fall off and be seriously
injured or interfere with safe machine operation.
• Keep children out of the mowing area and under the
watchful care of another responsible adult.
• Be alert and turn machine off if children enter the area.
• Before and when backing, look behind and down for small
children.
• Mow up and down slopes (15 ° Max), not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine. Tall grass can hide obstacles.
• Use slow speed. Choose a low gear so that you will not have
to stop or shift while on the slope.
• Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly straight down
the slope.
• If machine stops while going uphill, disengage blades, shift
into reverse and back down slowly.
• Do not turn on slopes unless necessary, and then, turn
slowly and gradually downhill, if possible.
Look for this symbol to point out im-
portant safety precautions. It means
CAUTION!!! BECOMEALERT!!! YOUR
SAFETY IS INVOLVED.
CAUTION: In order to prevent acciden-
tal starting when setting up, transport-
ing, adjusting or making repairs, al-
ways disconnect spark plug wire and
place wire where itcannot contact spark
plug.
CAUTION: Do not coast down a hill in
neutral, you may lose control of the
tractor.
CAUTION: Tow only the attachments
that are recommended by and comply
with specifications ofthe manufacturer
of your tractor. Use common sense
when towing. Operate only at the low-
est possible speed when on a slope.
Too heavy of a load, while on a slope,
is dangerous. Tires can lose traction
with the ground and cause you to lose
control of your tractor.
WARNING
Engine exhaust, some of its constituents, and cer-
tain vehicle components contain or emit chemicals
known to the State of Californ ia to cause cancer and
birth defects or other reproductive harm.
WARNING
Battery posts, terminals and related accessories
contain lead and lead compounds, chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
3
PRODUCT SPECIFICATIONS
GASOLINE CAPACITY 2.0 GALLONS
AND TYPE: UNLEADED REGULAR
OILTYPE (API-SF-SJ): SAE 30 (above 32°F)
SAE 5W-30 (below 32°F)
OIL CAPACITY: W/FILTER 4.0 PINTS
W/OFILTER 3.75 PINTS
SPARK PLUG: CHAMPION RC12YC
(GAP: .040")
GROUND SPEED (MPH): Forward: 0-5.5
Reverse 0-2.4
TIRE PRESSURE: FRONT: 14 PSI
REAR: 10 PSI
CHARGING SYSTEM: 3 AMPS BATTERY
5 AMPS HEADLIGHTS
BATTERY: AMP/HR: 28
MIN. CCA: 230
CASE SIZE: UIR
BLADEBOLTTORQUE: 27-35 FT. LBS.
CONGRATULATIONS on your purchase ofa new Tractor.
It has been designed, engineered and manufactured togive
you the best possible dependability and performance.
Should you experience any problem you cannot easily
remedy, please contact your nearest authorized service
center. We have competent, well-trained technicians and
the proper tools to service or repair this tractor.
Please read and retain this manual. The instructions will
enable you to assemble and maintain your tractor properly.
Always observe the "SAFETY RULES".
CUSTOMER RESPONSIBILITIES
•Read and observe the safety rules.
• Follow a regular schedule in maintaining, caring for and
using your tractor.
• Follow the instructions under the "Customer Responsi-
bilities" and "Storage" sections of this owner's manual.
WARNING: This tractor is equipped with an internal com-
bustion engine and should not be used on or near any
unimproved forest-covered, brush-covered or grass-cov-
ered land unless the engine's exhaust system is equipped
with a spark arrester meeting applicable local or state laws
(if any). If a spark arrester is used, it should be maintained
in effective working order by the operator.
A spark arrester for the muffler is available through your
nearest authorized service center/department (See REPAl R
PARTS section of this manual).
Inthe state ofCaliforniathe above is required by law (Section
4442 ofthe California Public Resources Code). Other states
may have similar laws. Federal laws apply on federal lands.
TABLE OF CONTENTS
SAFETY RULES ........................................................ 2-3
PRODUCT SPECIFICATIONS ....................................... 4
CUSTOMER RESPONSIBILITIES ...................... 4, 16-19
ASSEMBLY ................................................................ 6-8
OPERATION ............................................................. 9-15
MAINTENANCE SCHEDULE ....................................... 16
SERVICE AND ADJUSTMENTS ............................. 20-25
STORAGE ................................................................... 26
TROU BLESHOOTING ............................................. 27-28
REPAIR PARTS - TRACTOR .................................. 30.45
WARRANTY ................................................................ 46
4
UNASSEMBLED PARTS
Steering Wheel
Steering
Wheel Insert
Steering
Sleeve
Steering
Extension
Shaft
Steering Adapter
(1) Large Flat
Washer
(1) Locknut 1/4-28
(1) Hex Bolt 1/4-28 x 1-1/4 (1) Locknut 1/2-20
Seat
(1) Washer @
17/32 x 1-3/16 x 12 Gauge
(1) Knob
Slope Sheet
(2) Keys
For Future Use
5
ASSEMBLY
Your new tractor has been assembled at thefactory with exception of those parts left unassembled for shipping purposes. To
ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the
correct tools as necessary to insure proper tightness.
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly easier. Standard
wrench sizes are listed.
Utility knife Pliers
(1) 3/4" wrenches Tire pressure gauge
(2) 7/16" wrenches
When rightorlefthand ismentionedinthis manual, itmeans
when you are in the operating position (seated behind the
steering wheel).
TO REMOVE TRACTOR FROM CARTON
UNPACK CARTON
•Remove all accessible loose parts and parts cartons
from carton.
• Cut, from top to bottom, along lines on all four corners
of carton, and lay panels flat.
• Check for any additional loose parts or cartons and
remove.
BEFORE REMOVING TRACTOR FROM
SKID
ATTACH STEERING WHEEL (See Fig. 1)
ASSEMBLE EXTENSION SHAFT AND BOOT
•Slideextension shaftontolowersteering shaft. Align mount-
ing holes in extension and lower shafts and install
1/4 hex bolt and Iocknut. Tighten securely.
IMPORTANT: TIGHTEN BOLT AND NUT SECURELY TO
10-12 FT. LBS TORQUE.
• Placetabs of steering boot over tab slots in dash and push
down to secure.
INSTALL STEERING WHEEL
• Position front wheels of the tractor so they are pointing
straight forward.
• Remove steering wheel adapter from steering wheel and
slide adapter onto steering shaft extension.
• Position steering wheel so cross barsare horizontal (left to
right) and slide inside boot and onto adapter.
• Assemblelargeflat washer,1/2hexnutandtighten securely.
• Snap steering wheel insert into center of steering wheel.
• Remove protective materials from tractor hood and grill.
IMPORTANT: CHECK FOR AND REMOVE ANY STAPLES
IN SKIDTHAT MAY PUNCTURE TIRES WHERE TRACTOR
IS TO ROLL OFF SKID.
INSERT
112 HEX NUT
LARGE FLAT
WASHER
STEERING
BOOT
ABS
EXTENSION SHAFT
114 HEX BOLT
114 LOCKNUT t
I
LOWER
STEERING
SHAFT
FIG. 1
HOW TO SET UP YOUR TRACTOR
CHECK BATTERY (See Fig. 2)
•Lift seat pan to raised position.
•If this battery is put into service after month and year
indicated on label (label located between terminals)
charge battery for minimum of one hour at 6-10 amps.
(See"BATTERY" inCUSTOMER RESPONSIBILITIES
section ofthis manual for charging instructions).
6
ASSEMBLY
SEAT PAN _I
FIG. 2
INSTALL SEAT (See Fig. 3)
Adjustseat before tighteningadjustment knob.
•Remove adjustment knobandflat washer securingseat
tocardboard packing andset aside for assembly ofseat
to tractor.
• Pivot seat upward and remove from the cardboard
packing. Remove the cardboard packing and discard.
• Place seat on seat pan so head of shoulder bolt is
positioned over large slotted hole in pan.
• Push down on seat to engage shoulder bolt in slot and
pull seat towards rear of tractor.
• Pivot seat and pan forward and assemble adjustment
knob and flat washer loosely. Do not tighten.
• Lower seat into operating position and sit on seat.
• Slide seat until a comfortable position is reached which
allows you to press clutch/brake pedal all the way down.
• Get off seat without moving its adjusted position.
• Raise seat and tighten adjustment knob securely.
_EAT
SEAT P_ SHOULDER
BOLT
FLAT _HER
ADJUSTMENT
KNOB
NOTE: You may now roll or drive your tractor off the skid.
Follow the appropriate instruction below to remove the
tractor from the skid.
TO ROLL TRACTOR OFF SKID (See Operation
section, page 10, for location and function of
controls)
• Press lift lever plunger and raise attachment lift lever to
its highest position.
• Release parking brake bydepressing clutch/brake pedal.
• Place freewheel control in freewheeling position to
disengage transmission (See'qO TRANSPORT" in the
Operation section of this manual).
Roll tractor forward off skid.
Remove banding holding deflector shield up against
tractor.
TO DRIVE TRACTOR OFF SKID (See Opera-
tion section, page 10, for location and func-
tion of controls)
_WARNING: Beforestarting, read,understand and follow
all instructionsin the Operation section ofthis manual. Be
sure tractor isin a well-ventilated area. Be sure the area in
front of tractor isclear of other people and objects.
•Be sure all the above assembly steps have been
completed.
• Check engine oil level and fill fuel tank with gasoline.
•Place freewheel controlin "transmission engaged" po-
sition.
• Sit on seat in operating position,depress clutch/brake
pedal and set the parking brake.
•Place motion control lever in neutral (N) position.
•Press liftlever plunger and raiseattachment liftlever to
its highest position.
• Start theengine. After engine hasstarted, rnove throttle
controlto idle position.
•Release parkingbrake.
• Slowly movethemotioncontrolleverforward and slowly
drive tractor off skid.
• Apply brake tostop tractor,set parking brake and place
motion controllever in neutral position.
•Turn ignitionkey to "OFF" position.
Continue with the instructionsthat follow.
FIG. 3
7
ASSEMBLY
IMPORTANT: FOR SHIPPING PURPOSES, THE
MULCHER PLATE WAS PREATTACHED TO YOUR
MOWER. THE MULCHER PLATE MUST ONLY BE USED
WITH THE MULCHING BLADES THAT CAME PACKED
SEPARATELY IN THE CARTON.
YOUR MOWER CAME FACTORY EQUIPPED WITH HIGH
PERFORMANCE BLADES, WHICH ARE THE BEST
BLADES FOR BAGGING AND DISCHARGING. TO USE
YOUR MOWER WITH THE HIGH PERFORMANCE BLADES
THE MULCHER PLATE MUST BE REMOVED FROM THE
MOWER (SEE FIG. 4).
TO SET UP YOUR MOWER FOR MULCHING
•Remove high performance blades and install mulcher
blades, (see BLADE REMOVAL in the CUSTOMER
RESPONSABILITY section of this manual).
TO INSTALL MULCHER PLATE (See Fig. 4)
NOTE: Ifyou installedthemulching bladesyouwillneedtoinstall
themulcher plate.
• Raise and hold deflector shield in upright position.
• Place front of mulcher plate over front of mower deck
opening and slide into place, as shown.
• Hook front latch into hole on front of mower deck.
• Hook rear latch into hole on back of mower deck.
CAUTION: Donot remove deflector shield
from mower. Raise and hold shield when
attaching mulcher plate and allow it to
rest on plate while in operation.
DEFLECTOR MULCHER
SHIELD PLATE
LATCH
HOOKS
FIG. 4
TO CONVERT TO BAGGING OR
DISCHARGING
NOTE: The mulcher blades will discharge and bag grass, but
forbest bagging and discharging install the high performance
blades.
• Remove mulcher plate and mulcher blades and install
high performance blades, (see BLADE REMOVAL in the
CUSTOMER RESPONSABILITY section ofthis manual).
• Store mulcher blades and mulcher plate in a safe place.
Your mower is now ready for discharging or installation
of optional grass catcher accessory.
CHECK TIRE PRESSURE
The tires on your tractor were overinflated at the factory for
shipping purposes. Correct tire pressure is important for
best cutting performance.
• Reduce tire pressure to PSI shown in "PRODUCT
SPECIFICATIONS" section of this manual.
CHECK DECK LEVELNESS
For best cutting results, mower housing should be properly
leveled. See"TO LEVEL MOWER HOUSING"in the Service
and Adjustments section of this manual.
CHECK FOR PROPER POSITION OF ALL
BELTS
See the figures that are shown for replacing motion and
mower blade drive belts in the Service and Adjustments
section of this manual. Verify that the belts are routed
correctly.
8
CHECK BRAKE SYSTEM
After you learn how to operate your tractor, checkto see that
the brake is properly adjusted. See "TO ADJUST BRAKE"
in the Service and Adjustments section of this manual.
,/CHECKLIST
BEFORE YOUOPERA TEAND ENJOY YOUR NEW TRAC-
TOR, WE WISH TO ASSURE THAT YOU RECEIVE THE
BEST PERFORMANCE AND SATISFACTION FROM THIS
QUALITYPRODUCT.
PLEASE REVIEW THE FOLLOWING CHECKLIST:
,/ All assembly instructions have been completed.
,/ No remaining loose parts in carton.
,/ Batteryis properly prepared and charged. (Minimum 1
hour at 6 amps).
,/ Seat is adjusted comfortably and tightened securely.
,/ All tires are properly inflated. (For shipping purposes,
the tires were overinflated at the factory).
,/ Be sure mower deck is properly leveled side-to-side/
front-to-rear for best cutting results. (Tires must be
properly inflated for leveling).
,/ Check mower and drive belts. Be sure they are routed
properly around pulleys and inside all belt keepers.
,/ Check wiring. See that all connections are still secure
and wires are properly clamped.
,/ Before driving tractor, be sure freewheel control is in
drive position.
WHILE LEARNING HOW TO USE YOUR TRACTOR, PAY
EXTRA ATTENTION TO THE FOLLOWING IMPORTANT
ITEMS:
,/ Engine oil is at proper level.
,/ Fuel tank is filled with fresh, clean, regular unleaded
gasoline.
,/ Become familiar with all controls - their location and
function. Operate them before you start the engine.
,/ Be sure brake system is in safe operating condition.
,/ Itis importantto purgethetransmission before operating
yourtractorforthefirsttime. Follow proper starting and
transmission purging instructions (See "TO START
ENGINE"and"PURGE TRANSMISSION"in the Opera-
tion section of this manual).
OPERATION
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning.
At
BATTERY CAUTION OR REVERSE FORWARD FAST SLOW
WARNING I
ENGINE ON ENGINE OFF OIL PRESSURE LIGHTS ON OVER TEMP
LIGHT
FUEL CHOKE MOWER HEIGHT PARKING BRAKE UNLOCKED
LOCKED
L
!
MOWER LIFT
R N H L
ATTACHMENT REVERSE NEUTRAL HIGH LOW
CLUTCH ENGAGED
IGNITION ATTACHMENT
CLUTCH DISENGAGED
PARKING BRAKE
KEEP AREA CLEAR SLOPE HAZARDS
(SEE SAFETY RULES SECTION)
DANGER, KEEP HANDS AND FEET AWAY FREE WHEEL
(Automatic Models only)
9
OPERATION
KNOW YOUR TRACTOR
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR
Compare the illustrationswith yourtractortofamiliarize yourself with thelocationsofvarious controlsand adjustments. Save
this manual for future reference.
CHOKE
THROTTLE
CLUTCH/BRAKE
PEDAL
AMMETER
IGNITION LIGHT
ATTACHMENT SWITCH SWITCH
CLUTCH LEVER POSITION
LIFT LEVER
PLUNGER
CHMENT
LIFT LEVER
oHEIGHT
ADJUSTMENT
INDICATOR
FREE WHEEL
CONTROL'
PARKING
BRAKE
3TION
CONTROL
LEVER
FIG. 5
Our tractors conform to the safety standards of the American National Standards Institute.
ATTACHMENT CLUTCH LEVER: Used to engage the
mower blades, orother attachments mounted toyourtractor.
LIGHT SWITCH POSITION: Turns the headlights on and
off.
AMMETER - Indicates charging (+) or discharging (-) of
battery.
CHOKE CONTROL- Used when starting a cold engine.
THROTTLE CONTROL: Used for controlling engine speed.
CLUTCH/BRAKE PEDAL: Used for declutching and brak-
ing the tractor and starting the engine.
PARKING BRAKE: Locks clutch/brake pedal intothe brake
position.
FREEWHEEL CONTROL: Disengages transmission for
pushing or slowly towing the tractor with the engine off.
MOTION CONTROL LEVER: Selects the speed and
direction of tractor.
ATTACHMENT LIFT LEVER: Used to raise, lower, and
adjust the mower deck or other attachments mounted to your
tractor.
LIFT LEVER PLUNGER: Used to release attachment lift
lever when changing its position.
IGNITION SWITCH: Used for starting and stopping the
engine.
10
