Poulan Pro PR600Y22RHP Owner's manual

419261 Rev. 1 06.30.09 BY Printed in U.S.A.
REPAIR PARTS MANUAL
MODEL NO. PR600Y22RHP
(MFG. ID. NO. 96142004601)
Rotary Lawn Mower
For Parts and Service, contact our authorized distributor: call 1-800-849-1297
For Technical Assistance: call 1-800-829-5886

2
ROTARY LAWN MOWER - - MODEL NUMBER PR600Y22RHP (MFG. ID. NO. 96142004601)
4
5
9
10
11
12
12 12
14
15
16
17
20
21
24
25
26
26
27
28 29
30
31
32 33
34 35
36
37
38
39
4060
41
42
43
44
45
46
47
48
49
50
51
52
53
53
54
55
55
56
56
57
58
59
60
35
62
63
64
65
25
27
13
13
28
29
30
31
32
34
37
54
65
69
71
1
3
6
6
7
8
2
19 18
7
SERVICE NOTES

6
LIMITED WARRANTY
The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and workmanship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will re- pair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship. This
Warranty is subject to the following limitations and exclusions. 1. This warranty does not apply to the engine, transaxle/transmission components,
battery (except as noted below) or components parts thereof. Please refer to the
applicable manufacturer's warranty on these items.
2. Transportation charges for the movement of any power equipment unit or at-
tachment are the responsibility of the purchaser. Transportation charges for any parts submitted for replacement under this warranty must be paid by the pur- chaser unless such return is requested by the manufacturer.
3. Battery Warranty: On products equipped with a Battery, we will replace, without
charge to you, any battery which we find to be defective in manufacture, during the first ninety (90) days of ownership. After ninety (90) days, we will exchange the Battery, charging you 1/12 of the price of a new Battery for each full month from the date of the original sale. Battery must be maintained in accordance with the instructions furnished.
4. The Warranty period for any products used for rental or commercial purposes is
limited to 45 days from the date of original purchase.
5. This Warranty applies only to products which have been properly assembled,
adjusted, operated, and maintained in accordance with the instructions furnished. This Warranty does not apply to any product which has been subjected to al- teration, misuse, abuse, improper assembly or installation, delivery damage, or to
normal wear of the product.
6. Exclusions: Excluded from this Warranty are belts, blades, blade adapters, nor-
mal wear, normal adjustments, standard hardware and normal maintenance.
7. In the event you have a claim under this Warranty, you must return the product to
an authorized service dealer.
Should you have any unanswered questions concerning this Warranty, contact: giving the model number, serial number and date of purchase of your product and the name and address of the authorized dealer from whom it was purchased. THIS WARRANTY DOES NOT APPLY TO INCIDENTAL OR CONSEQUENTIAL DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME PERIODS STATED HEREIN FOR OUR EXPRESSED WARRANTIES. Some areas do not allow the limitation of consequential damages or limitations of how long an implied Warranty may last, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights which vary from locale to locale. This is a limited Warranty within the meaning of that term as defined in the Mag- nuson-Moss Act of 1975.
In Canada contact: Poulan Pro Customer Service Department 5855 Terry Fox Way Mississauga, Ontario L5V 3E4
Poulan Pro Customer Service Department 1030 Stevens Creek Road Augusta, GA 30907 USA
3
ROTARY LAWN MOWER - - MODEL NUMBER PR600Y22RHP (MFG. ID. NO. 96142004601)
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm.
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty.
KEY PART
NO. NO. DESCRIPTION KEY PART NO. NO. DESCRIPTION
1 194203X479 Upper Handle
2 183567 Cable, Operator Presence
3 850733X004 Bracket, Upstop
4 166649 Mulcher Plug
5 66426 Wire Tie
6 189713X428 Handle Knob
7 750634 Screw
8 194199X421 Control Bar
9 401813X428 Rear Door Assembly
10 128415 Pop Rivet
11 150050 Screw, Self-Tapping
#10-24 x 5/8
12 54583 Screw, Hex Hex Head,
Sems 1/4-20 x 1/2
13 407794X421 Hubcap
14 195622X479 Back Plate
15 410545X479 Side Baffle
16 176655X479 Discharge Baffle
17 140661X479 Rear Baffle
18 132004 Keps Locknut 1/4-20
19 194788 Rope Guide
20 413160 Rear Skirt
21 405421 Spring, Rear Door, LH
24 405423 Spring, Rear Door, RH
25 409148 Nut, Hex, Flanged
26 184193 Bolt, Rear Door
27 408852X421 Wheel & Tire Assembly, Rear
28 142748 Bolt, Shoulder 3/8-16 x 1
29 401630 Washer, Curved, Cylindrical
30 401180X004 Axle Arm Assembly
31 701037X421 Selector Knob
32 401626X004 Selector Spring
33 189917X428 Mulcher Door
34 401629 Spacer
35 700325X005 Wheel Adjusting Bracket
36 175735 Hinge Bracket Assembly
37 150078 Screw, Sems, Thread Cutting
5/16-18 x 3/4
38 402574X428 Discharge Deflector
39 195915X479 Handle Bracket Assembly, LH
40 195914X479 Handle Bracket Assembly, RH
41 150406 Screw, Hex Head, Threaded,
Rolled 3/8-16 x 1-1/8
42 193000 Spring, Torsion
43 73800400 Nut, Hex, Nylock
44 417123 Kit, Mower Housing (Includes
Key Numbers 14, 15 and 51)
45 175650 Rod, Hinge
46 195963 Blade Adapter / Pulley
47 406713 Blade, 22"
48 851074 Washer, Hardened
49 850263 Washer, Helical
50 851084 Screw, Machine, Hex Head
3/8-24 x 1-3/8 Grade 8
51 170031 Kit, Front Baffle
(Includes Key Number 53)
52 404763 Danger Decal
53 17600406 Screw, Serrated, TT 1/4-20
54 88348 Washer, Flat
55 751592 Nut, Hex 3/8-16
56 88652 Hinge Screw 1/4-20 x 1-1/4
57 51793 Hairpin Cotter
58 151590X479 Lower Handle
59 191574 Handle Bolt
60 74760612 Bolt, Hex Head 3/8-16 x 3/4
62 405843 Debris Shield
63 192325 Screw, Debris Shield
64 - - - Engine, Briggs & Stratton,
Model Number 124T02
(For engine service and
replacement parts, call Briggs
& Stratton at 1-800-233-3723)
65 197480 O-Ring
69 197991 Clip, Cable
71 188839X004 Mounting Bracket,
Debris Shield
- - 404764 Warning Decal (not shown)
- - 193733 Operator’s Manual, English
- - 193736 Operator's Manual, French
- - 419261 Repair Parts Manual
KEY PART
NO. NO. DESCRIPTION

4
ROTARY LAWN MOWER - - MODEL NUMBER PR600Y22RHP (MFG. ID. NO. 96142004601)
54
57 33
18
18
35
16
17
13
14
11
29
29
56
56
38
38
41
7
1
12
16
17
13
14
12
27
28
11
15
15
19
36
40
60
61
62
63
64
65 66
67 68
69
70
71
72
72
73
74
74
75
76
77
78
79
5
ROTARY LAWN MOWER - - MODEL NUMBER PR600Y22RHP (MFG. ID. NO. 96142004601)
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm.
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty.
KEY PART
NO. NO. DESCRIPTION KEY PART NO. NO. DESCRIPTION
1 194653 Drive Control Assembly (Includes Cable)
6 150495 Retainer, Spring
7 194185X421 Bar, Drive Control
11 180775 Wheel & Tire Assembly, Front
12 12000058 E-Ring
13 403849 Pinion
14 189403 Dust Cover
15 404845 Pawl, Drive
16 67725 Washer, Flat 3/8
17 191039 Bearing, Wheel Adjuster
18 701037X421 Selector Knob
27 175262 Pan Head Tapping Screw #10-24 x 2-3/4
28 401271X428 Drive Cover
29 409149 Locknut, Hex
33 146527 V-Belt
35 408862 Kit, Wheel Adjuster, LH
(Includes Knob and Bearing)
36 415226 Gear Case Assembly, Complete
38 73800400 Locknut 1/4-20
40 137090 Spring
41 408861 Kit, Wheel Adjuster, RH
(Includes Knob and Bearing)
54 411062 Grassbag Assembly
56 407793X421 Hubcap
57 411952 Frame, Grassbag
60 183497 * Case, Lower
61 183498 * Case, Upper
62 183499 Gear, 27 Teeth
63 183500 Lever, Clutch
64 183501 Spring, Return
65 416988 Shaft, Input
66 183503 Dog, Movable
67 183504 Dog, Fixed
68 183505 Wire, Formed
69 183506 Bearing, Ball
70 183507 Fork, Shift
71 183508 Seal, Output Shaft
72 183509 Washer
73 183510 Seal, Case
74 183511 Bushing
75 196561 Shaft, Output
76 183513 Screw
77 183514 Seal, Input Shaft
78 416987 Pulley, Drive
79 416986 Locknut, Hex
* Use Dow Corning #709 to reseal Gear Case Halves.
