PowerBase B0P-SP07-20-ZJ User manual
53cm Self Propelled Petrol
Rotary Lawn Mower
These instructions contain important information that will help you get the best
from your product, ensuring it is assembled correctly and safely. If you need help
or have damaged or missing parts, call the Customer Helpline on 01904 727 509.
IMPORTANT!
Please read these
instructions fully before
starting assembly.
Instruction
Manual
20V 2.5Ah Battery 620672
2
Contents
Intended use 03
In the box 03
Symbols 04
General safety warnings 05
Charging the battery 07
Capacity display 09
Technical data 09
Cleaning, maintenance and storage 10
Disposal 10
Troubleshooting 11
Getting help 12
Warranty 12
3
Intended Use
This battery should only be used for Powerbase 20V and 40V
range products. It is for domestic use only, not for commercial,
industrial or trade use.
In the Box
Contents
1 x Battery pack
1 x Instruction manual
Parts
1. Battery pack
2. Release button
3. Display button
4. Capacity display (3 LED lights)
1
2
3
4
4
Symbols
Before use, carefully read through the user manual.
The battery is for indoor use only.
Do not throw into water.
Do not dispose of batteries in a fire. They will explode and
cause injury.
Do not subject the battery to strong sunlight over long
periods of time. Do not leave on a heater (max. 45°C).
Batteries contain Li-ion. Do not dispose of exhausted
batteries in domestic waste. Contact your local authority
to find out how to dispose of batteries safely.
WEEE symbol. Waste electrical products should not be
disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or local store
for recycling advice.
The product complies with the applicable European
Directives, and an evaluation method of conformity for
these directives was done.
The product complies with the applicable UK Directives,
and an evaluation method of conformity for these
directives was done.
5
General Safety Warnings
Safety instructions for the battery
WARNING! Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result in
an electric shock, fire and/or injury.
Save all warnings and instructions for future
reference!
a) Do not dismantle, open or shred secondary
cells or batteries.
b) Do not expose cells or batteries to heat or
fire. Avoid storing in direct sunlight.
c) Do not short-circuit a cell or a battery. Do
not store cells or batteries haphazardly in a
box or drawer where they may short circuit
each other or be short-circuited by other
metal objects.
d) Do not remove a cell or battery from its
original packaging until required for use.
e) Do not subject cells or batteries to
mechanical shock.
f) In the event of a cell leaking, do not allow
the liquid to come in contact with the skin
or eyes. If contact has been made, wash
the affected area with copious amounts of
water and seek medical advice.
g) Do not use any charger other than that
specifically provided for use with the
equipment.
6
h) Observe the plus (+) and minus (–) marks
on the cell, battery, equipment and ensure
correct use.
i) Do not use any cell or battery which is not
designed for use with the equipment.
j) Do not mix cells of different manufacture,
capacity, size or type within a device.
k) Battery usage by children should be
supervised.
l) Seek medical advice immediately if a cell or
a battery has been swallowed.
m) Always purchase the battery
recommended for the device by the
manufacturer of the equipment.
n) Keep cells and batteries clean and dry.
o) Wipe the cell or battery terminals with a
clean dry cloth if they become dirty.
p) Secondary cells and batteries need to be
charged before use. Always use the correct
charger and refer to the manufacturer’s
instructions or equipment manual for
proper charging instructions.
q) Do not leave a battery on prolonged charge
when not in use.
r) After extended periods of storage, it may
be necessary to charge and discharge the
cells or batteries several times to obtain
maximum performance.
7
s) Retain the original product literature for
future reference.
t) Use only the cell or battery in the
application for which it was intended.
u) When possible, remove the battery from
the equipment when not in use.
v) Dispose of properly.
w) The charging temperature is between the
range of 5°C to 45°C.
Charging the Battery
If the battery cannot fit into the charger properly, remove it
from the charger. Only charge a Powerbase battery in the
correct charger. If the battery is hot after use in the tool, let
it cool down before charging.
a) Connect the charger to the mains.
b) Insert the battery (1) into the charger, until it clicks into the
locked position (Fig.1).
c) Frequently monitor the charger and battery (1) while charging.
d) It takes about 1 hour to charge a fully discharged 2.5Ah battery
with a Powerbase 2.4A charger B0Q-SP06-20ZB.
e) Remove the battery (1) from the charger when it is fully
charged and unplug the charger from the mains.
f) To remove the battery (1) from the charger, press the release
button (2) on the battery (1) and push the battery (1) out.
g) Let the battery (1) cool down before use.
(1)
8
Charging status LEDs
1. Connect the charger to a power supply. The left red light will
illuminate.
2. Slide the battery pack into the charger; make sure the battery
pack is fully seated in position. The left red right is on and the
right green light is flashing to indicate the charging is ongoing.
3. When charging is complete, the left light is off and the right
green light is on.
4. Once the battery is fully charged, disconnect the charger from
the mains and remove the battery pack from the charger.
Fig.1
Fig.2
Red light
Green light
Diagram 1
9
Capacity Display
The level of capacity will be displayed on the 3 LED lights (4) when
the display button (3) is pressed.
Technical Data
Model number B0P-SP07-20-ZJ
Battery type Li-ion
Voltage 20V max.
Capacity 2.5Ah/50Wh
Battery charging time 60 mins
Temperature limit 45oC
Suitable charger (charger sold separately）
Model B0Q-SP07-2040ZB
Input 220-240V~ 50/60Hz 120W
Output 21V/4A
3
4
10
Cleaning, Maintenance and Storage
Cleaning
a) Regularly clean the battery with a soft cloth, preferably after
each use.
b) If the dirt does not come off, use a soft cloth moistened with
soapy water.
c) Never use solvents such as petrol, alcohol and ammonia water,
etc., to clean the battery. These solvents may damage the
plastic parts.
Maintenance
The battery has been designed to operate over a long period
of time with minimal maintenance. Continuous satisfactory
operation depends upon care and regular cleaning.
Storage
Store the battery out of the reach of children in a stable and
secure place. Avoid storage in direct sunlight.
Disposal
Do not dispose battery with your household refuse.
Dispose battery according to the regulation and
requirement of local council.
11
Troubleshooting
Fault Possible cause Possible solution
Battery fails to
charge.
1. Battery not
properly inserted
into battery
charger.
2. Battery is too hot.
3. Battery is
defective.
4. Charger is
defective.
1. Ensure battery and
charger are firmly
connected.
2. If the battery is hot
after continuous use
in charger, allow it to
cool down to room
temperature before
charging.
3. Contact the service
centre.
4. Contact the service
centre.
Battery has re-
duced run time. Battery is too old. Purchase a new battery
pack.
12
Getting Help
Our dedicated UK-based customer helpline is open 7 days a week
to assist you with assembly, parts queries and technical support.
We are open during office hours but you can always send an email
back enjoying your garden in no time.
For useful assembly, starting and maintenance videos, and for
ordering spares, please visit www.coreservice.co.uk.
Using our service does not affect your statutory rights.
Warranty
This product is covered by a 2 year warranty.
The warranty covers any manufacturing defect in materials,
workmanship and finish.
Any claim under this warranty must be made by going to your
nearest Homebase store, taking your proof of purchase with you,
and claims must be made within 2 years of the date of purchase.
We will offer you a free repair of the item where this is possible,
or a replacement or a refund. Your statutory rights remain
unaffected; in particular, any rights you may have under the
Consumer Rights Act 2015.
This warranty is given by HHGL Limited, MK9 1BA; HHGL (ROI)
Limited, D02 X576.
Please note: This warranty does not apply to products misused
or neglected and only covers domestic use. It does not apply to
commercial use of the product.
September 2021
