PowerPac PPT720WH User manual

MICROWAVE OVEN with 6 Power Level and Defrost function
PPT720WH
Comes in 2 colours
–Black and White

Parts & Description s
LIST OF COMPONENTS
1.
Viewing Window
2.
Outer Cover
3.
Door Lock
4.
Control Panel
5.
Power Dial
6.
Door Release Button
7.
Timer Dial
8.
Cavity
9.
Waveguide Cover
10.
Rotating Axis
11.
Rotating Ring
12.
Turntable
Door Release Button ⑥
Timer Dial ⑦
Viewing Window ① Door Lock ③ ④ Control Panel
Outer Cover ② ⑤ Power Dial

Cavity ⑧ Waveguide Cover ⑨
Rotating Axis ⑩ Rotating Ring ⑪ Turntable ⑫

Warnings s
ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
WARNINGS:
If the door or door seals are damaged, the oven must not be operated until it has been
repaired by a trained person.
It is hazardous for anyone other than a trained person to carry out any service or repair
operation which involves the removal of any cover, which gives protection against
exposure to microwave energy.
The following basic precautions should always be followed when using electrical
appliances:
1. Read all instructions before using the appliance.
The Appliance
2. This appliance must be used only for the purpose it was expressly designed, i.e.
heating food and beverages through microwaves; any use NOT complying with
the instructions contained in the manual (for example, drying of food or clothing
and heating of warming pads, slippers, sponges, damp cloth and similar) is
considered inappropriate and dangerous. The manufacturer is NOT responsible
for possible damages, including, risk of injury, ignition or fire, caused by the
inappropriate and/or unreasonable use.
3. The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to
persons, animals or objects, for which the manufacturer cannot be considered
responsible.
4. Before use, check the integrity of the appliance and power cable. DO NOT operate
the appliance when its housing is damaged. In case you are not sure, contact a
qualified person. If the power cable is damaged, it must be replaced by the
manufacturer or its service agent or a qualified technician in order to avoid a shock
hazard.
5. Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded. This appliance is fitted with an earth
wire for extra safety.

6. Avoid the use of adapters and/or extension cables; if their use is absolutely
necessary, use only materials in compliance with the current safety regulations
and according to the electrical parameters of the adapters.
7. The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
8. Only use original components & accessories (e.g. Turntable, Rotating Ring, etc.)
provided by the manufacturer. Any non-original component or accessory NOT
recommended by the manufacturer (including, but not limited to, Turntable,
Rotating Ring, etc. made by other manufacturers or by the same manufacturer but
for other models of the same capacity or otherwise) may cause injuries to persons
or damage to the appliance.
9. The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
Location
10. This appliance is NOT suitable to be used or stored near heat sources (open flame,
ovens, heaters, stoves, etc.) and/or in an explosive environment (in the presence
of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air). Items
containing these substances should never be placed in the appliance, and never
be used to clean the appliance in order to avert the risk of fire or explosion.
11. The appliance should NOT be placed on a surface, or in the vicinity of, objects
which can be damaged by heat, such as carpets or plastics. DO NOT locate
multiple portable socket outlets or power supplies at the bottom or rear of the
appliance. When using the appliance, the surface that the appliance is placed
upon as well the surface immediately above (e.g. a wooden cabinet above the
appliance), may become very hot. If the appliance is operated on wooden furniture,
use a protective pad to prevent damage to delicate finishes.
12. Place the appliance at a proper distance from the objects or surrounding walls
making sure that its functioning will NOT cause accidental damages. There should
be at least 10 cm of free space from the back, 5 cm from the left & right sides, and
at least 20 cm the top of the appliance. Never put things on top of the Outer Cover.
DO NOT use the appliance when placed in a closed cabinet.
13. To avoid electronic disturbance that may mar your listening or viewing pleasure
while the appliance is in operation, place the appliance at least 5 m from the TV,
radio or antenna.
14. Avoid placing the power cable on abrasive or sharp surfaces or in positions where
it can be damaged easily. The cable must NOT be placed under carpets, or
covered with throw rugs, runners or similar. Arrange the cable away from the high
traffic area, and where it will NOT be tripped over.
15. DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.

Operation
16. If you are using the appliance for the first time, you should:
a. Clean the exterior of the appliance – Outer Cover including the Control Panel,
Viewing Window, Rotating Axis, Rotating Ring, Turntable, the walls of the
Cavity and Waveguide Cover with a damp cloth and wipe dry. DO NOT use
metal scouring pads.
b. Place and use the appliance upright on a horizontal, stable, dry and heat-
resistant surface. Damage to the appliance may occur if it is placed on an
incline or decline.
c. Make sure to remove any label or protective sheet which may prevent its
proper functioning.
d. (First use)
•Fill a microwavable bowl with 2 inches of water and place the bowl on the
Turntable. Place a cover on top of the bowl loosely, but DO NOT seal the
bowl shut.
•Close the door and observe that it shuts tightly.
•Turn the Timer Dial anti-clockwise to ‘0’.
•Plug the power cable into the wall socket and switch it ON.
•Turn the Power Dial to the power level of ‘High’.
•Turn the Timer clockwise to ‘2’. The lamp will light and heating will
commence. You can view the Turntable rotating through the Viewing
Window. At any time, opening the door will cease operation and closing
the door will resume operation. The Timer countdown ceases during the
pause. Note that should you decide to discontinue heating before the
Timer runs out, make sure to set the Timer Dial back to ‘0’, this avoids the
appliance from operating with an empty load. After 2 minutes, heating will
stop, the bell will ring and the lamp will go out. Switch the wall socket off
and unplug the power cable. Thereafter the appliance is safe to use.
•Remove the bowl with great care. Be aware that heating of liquids can
result in delayed eruptive boiling, therefore care has to be taken when
handling containers of liquids.
•Care should be taken not to displace the Turntable when removing
containers from the appliance.
Switching the appliance ON
•Turn the Timer Dial anti-clockwise to ‘0’. Plug the power cable into the wall
socket and switch it ON. Turn the Power Dial to a suitable power level.
Turn the Timer clockwise to a suitable heating duration, up to 30 minutes.
The lamp will light and heating will commence.
(henceforth “switching the appliance on” is intended to include the steps
above)

Switching the appliance OFF
•Turn the Timer Dial anti-clockwise to ‘0’. Switch the wall switch off and
unplug the power cable from the wall socket.
(henceforth “switching the appliance off” is intended to include the steps
above)
DO NOT:
•cover the appliance during functioning;
•obstruct totally nor partially the Outer Cover;
•insert objects or body parts inside the Outer Cover of the appliance;
•switch the appliance on without any food or beverage in the Cavity - however,
should the Cavity be found empty during operation, immediately switch the
appliance off;
•place hot containers onto the Turntable;
•place the hot turntable onto running water directly after use to avoid cracking.
Leave to cool to room temperature first;
•heat food, especially liquids, in sealed containers as they are liable to explode;
•heat eggs in their shell and whole hard-boiled eggs as they may explode, even
after microwave heating has ended;
•use metal utensils as they are not allowed, or plastic or paper containers which
may ignite, during microwave cooking – use only microwave-safe utensils;
•use your bare hands when taking out food, use a pair of gloves, and be careful
not to touch the interior walls of the oven:
•turn the Timer Dial and Power Dial too hard so as to avoid any damage;
•leave the appliance unsupervised during operation.
17. During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
18. During the period of operation, high temperature steam may escape from the
container. To avoid scalding:
DO NOT
•fill the container with hot water;
•allow all of the water to be boiled away;
•overfill food or beverage to avoid overflow of hot liquids;
•use the appliance to heat oil or melt butter without any food present;
•add food with its packaging (plastic wrapper, paper, foil, metal can, etc.) still
attached without first removing the packaging;
•move the appliance whilst the appliance is in operation;

•touch any part of the appliance except the Handle, Power Dial, Timer Dial or
Door Release Button when in operation or just after switching it off as it will
still be very hot and may cause scalding. The container becomes increasingly
hot as the appliance operates. Do note that the food items and accompanying
liquids & gases inside the appliance, and the appliance itself would still be very
hot during heating, and for some time after the plug has been pulled out of the
wall socket. If you need to check on the progress of the food preparation, or
to turn over some food items, please use a utensil with a long handle;
•open the door of the appliance in front of any person or animal & one’s hands
and face should be angled away from the opening at all times.
19. DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock.
In case of accidental fall in water, DO NOT try to take it out, but first switch the
appliance off.
20. Plug and unplug the power cable firmly holding it with dry hands. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug
it or use it to drag the appliance to which is connected). Before unplugging the
appliance, turn the Timer Dial to ‘0’ and switch the wall switch off.
21. Switch the appliance off when not in use and before placing food items or
beverages inside the appliance. Before storing, cleaning or performing any
maintenance operation, leave to cool for at least 30 minutes.
22. In case of malfunction or anomaly during the functioning, switch the appliance off
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
23. If smoke is observed coming out of the appliance, switch the appliance off
immediately. Remove the food or beverage item and any other utensil placed in
the Cavity only after it has stopped smoking.
24. This appliance is NOT intended for commercial use but to be used in households
and similar applications, such as:
•Staff kitchen areas in shops, offices and other working environments;
•By clients in hotels, motels, dormitories and other residential environments;
•Bed and breakfast type environments.
25. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
NOT play with the appliance. Cleaning and user maintenance shall NOT be made
by children unless they are older than 8 and supervised. Keep the appliance and
its cable out of reach of children less than 8 years old.
26. Save these instructions.

How to Use s
1. Place the Rotating Ring onto the Cavity floor.
2. Place the Turntable securely onto the gears of the Rotating axis. The motor
underneath the Rotating axis drives the Turntable to rotate in either direction,
clockwise or anti-clockwise.
3. Place the food or beverage onto the Turntable and shut the Door. DO NOT operate
the appliance without any food or beverage inside the Cavity.
4. Turn the Timer Dial anti-clockwise to ‘0’.
5. Plug the power cable into the wall socket and switch it ON.
6. Turn the Power Dial to your desired power level.
7. Turn the Timer clockwise to your desired duration, up to 30 minutes.
8. The lamp will light and heating will commence. You can view the Turntable rotating
through the Viewing Window.
9. At any time, opening the door will cease operation and closing the door will resume
operation. The Timing ceases during the pause. Note that should you decide to
discontinue heating before the Timer runs out, make sure to set the Timer Dial
back to ‘0’, this avoids the appliance from operating with an empty load.
10. When the heating duration is over, the Timer will auto shut off, the bell will ring and
the lamp will go out.
11. Switch the wall socket off and unplug the power cable.
12. In the first use of this oven, there might be some light smoke coming out from the
oven. This is normal. After 5 minutes the smoke will disappear.
Note : The contents of feeding bottles and baby food jars are to be stirred or
shaken and the temperature is to be checked before consumption, in order to
avoid burns.
Six Microwave Power Levels

Average Defrosting Duration
No.
Weight
Defrost time
1
200 g
≈ 4 minutes
2
400 g
≈ 8 minutes
3
600 g
≈ 12 minutes
.Guide to choosing utensils
Depending on the cooking method, it is necessary to choose a microwave-safe
containers. It’s vital to use proper utensils in a microwave. Otherwise, it could produce
toxic substances in the heating process, and may even lead to an explosion.
Please refer to the table below.
Material of container
Microwave
Notes
Heat-resistant ceramic
Yes
Never use ceramics which are
decorated with metal rim or glazed
Heat-resistant plastic
Yes
Unsuitable for long duration microwave
cooking, except
#5 polypropylene (PP)
Heat-resistant glass
Yes
Ensure that the glass does not come
with metal lids or metal decorative paint
or glaze
Grill rack
No
Any item made of metal cannot be used
Plastic film
Yes
It should not be used when cooking
meat or chops with high fat content as
the heated meats may melt the film
Paper
Yes
Suitable only for a short duration
microwave cooking. DO NOT use wax
paper or those with printing.

COOKING TIPS…
The following factors may affect the cooking result:
Food arrangement
Place thicker cross-sections towards the outside, and thinner cross-sections at the
middle of the container. Spread them evenly. DO NOT overlap if possible.
Cooking duration
Start cooking with a shorter duration. Remove and evaluate it. Extend if necessary.
You can always extend the duration, but cannot uncook an overcooked or burnt dish.
Cooking food evenly
Food such as chicken, meat patties or steak should be turned once during cooking.
Depending on the type of food, if applicable, stir it from outside to centre of dish once
or twice during cooking
Allow standing time
After the Timer has gone off, leave the food in the oven for an extended period of
time. This not only allows the food to sizzle in its own gravy, but this allows it to
complete its cooking cycle and cooling it down in a gradual manner.
Whether the food is done
Colour and hardness of food help to determine if it is done, these include:
-Steam coming out from all parts of food, not just the edges;
-Joints of poultry can be moved easily;
-Pork or poultry shows no signs of blood;
-Fish is opaque and can be sliced easily with a fork.
Browning Dish
When using a Browning Dish or self-heating container, always place a heat-resistant
insulator such as a porcelain plate under it to prevent damage to the Turntable and
Rotating Ring.
Microwave safe plastic cookware
Some microwave-safe plastic cookware might not be suitable for cooking foods with
high fat and sugar content. Also, the preheating time specified in the dish instruction
manual must not be exceeded.

How to Clean s
WARNINGS:
The appliance should be cleaned regularly and any food deposits removed. Failure to
maintain the appliance in a clean condition could lead to deterioration of the surface
that could adversely affect the life of the appliance and possibly result in a hazardous
situation.
1. Turn the Timer Dial anti-clockwise to ‘0’. Switch the wall switch off and unplug the
power cable from the wall socket. Wait until the appliance has completely cooled
before cleaning or performing any maintenance operation.
2. Never immerse the appliance in water or other liquids.
3. Wipe the Outer Cover and internal walls of the Cavity (including the Waveguide
Cover), the Door, door seals and external and internal windows, using a soft, damp
cloth or sponge. Remove stubborn spots with a cloth moistened with mild liquid
detergent. DO NOT use abrasive scouring pads or powders. The appliance should
NOT be cleaned with a steam cleaner. DO NOT attempt to remove the Waveguide
Cover.
4. Wash the Turntable and the Rotating Ring with detergent with a non-abrasive
sponge. Rinse under running water. DO NOT use metal scouring pads. Dry the
Turntable and the Rotating Ring thoroughly and place them in their working
positions.
5. To remove persistent odours, place
a. several lemon slices onto the Turntable, then heat with power level at ‘High’ for
2 – 3 minutes, or
b. a cup of tea onto the Turntable, then heat with power level at ‘High’ for 2 – 3
minutes, or
c. several orange peel onto the Turntable, then heat with power level at ‘High’ for
1 minute.
Before you send this appliance for service, perform the following checklist:
1. Place one cup of water (approx.150 ml) in a glass in the oven and close the door
securely. Oven lamp should go off if the door is closed properly. Let the oven work
for 1 min.
2. Does the oven lamp light?
3. Does the cooling fan work? (Place your hand over the rear ventilation openings.)
4. Does the Turntable rotate? (The Turntable can rotate clockwise or anti- clockwise.
This is normal.)
5. Is the water inside the oven hot?
If the answer to any of the above questions is “NO”, check the wall socket and the fuse
in your circuit breaker. If both the wall socket and the fuse are functioning properly,
CONTACT OUR SERVICE CENTER.

ENVIRONMENTAL TIP s
This appliance, along with all other electronic appliances, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discard the
appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste as it contains
batteries and/or recyclable electric waste. Collection of such waste separately for
special treatment is necessary.
SPECIFICATIONS s
MODEL
PPT720WH
VOLTAGE
220 –240 V ~50 –60 Hz
POWER
700 W
CAPACITY
20 L
DIMENSIONS
L 451 x W 332 x H 258 mm

WARRANTY s
Warranty Conditions
1. This warranty provides against defective materials and manufacturing faults
throughout for two years from the date of purchase of the appliance. The warranty
on the Compressor is 10 years subject to the same conditions as above.
2. This warranty also does not cover normal wear and tear, replacement of
consumable materials and accessories, and the cost of maintenance of the
appliance.
3. This warranty does not cover the repair or replacement of part/s damaged by
misuse, accidents, negligence, alterations, or modifications in any way, or repairs
done by any repair organisation without the prior consent of PowerPac Electrical
Pte Ltd.
4. Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore
486045. A transport fee will be charged for personal doorstep service.
5. The original purchaser of the appliance must furnish proof of purchase to our
Service Centre with the email or number as registered during submission of
warranty when this appliance is sent for repair/service. Failure to do so may delay
the receipt of said repair/service by the customer.
6. Under no circumstances whatsoever shall the serial number be erased, defaced
or altered by the customer and/or his representatives, or the dealer and/or his
agents. Failure to ensure this shall invalidate the warranty.
7. This warranty is deemed to be void if the defect is cause by the attack of household
pests, fire, lightning, natural disasters, pollution, abnormal voltage or the usage of
generators.
8. This warranty is valid in Singapore only.
9. This warranty will be honoured subject to the customer’s registration of the
warranty inclusive of original invoice or valid purchase receipt. Failure to present
these documents will result in denial of service. However, if the customer still
requests that the defective appliance be repaired, PowerPac Electrical Pte Ltd
may, at its discretion, repair the appliance but impose a labour charge, as well as
the costs of the replacement parts, to be borne solely by the customer.
10. Please refer to the attached picture for the location of
one of our appliance’s serial number, as an example.

Please complete the on-line registration warranty form available on our website. There
is no further requirement to send us any hard copy as part of our efforts to save the
environment.
In accordance with the terms and conditions of this limited warranty as stated above,
PowerPac Electrical Pte Ltd, at its expense shall provide free services for the
appliance within the warranty period from its date of purchase from our Authorised
dealers.
