INSTRUCTION MANUAL
Electric Pole Saw
Model # PS6108
Have product questions or need technical support? Please feel free to contact us!
Website: www.Amerisuninc.com
Toll free: 1-800-791-9458 Mon-Fri 9-5 EST
Email: [email protected]

2

3
CONTENTS
Technical data…...………………………………………………………... 3
General safety rules…….………………………………………………... 4
Specific safety rules for pole saw ……....………………………………. 5
Electrical information…………………………………………………... 6
Knowing your pole saw……....………………………………………… 8
Assembly and adjustments……………………………………………… 9
Operation………………………………………………………………... 10
Maintenance……………………………………………………………... 11
Exploded view & parts list……………………………………………… 14
Warranty………………………………………………………………… 16
TECHNICAL DATA
Electric Pole Saw Model # PS6108
Motor: 120V, 60 Hz, 6A
Motor speed: 4500 RPM
Saw chain: Oregon 91PJ033X, 3/8” Pitch
Chain gauge: 0.050”
Chain drive link amount: 33
Bar length: Oregon 8 inch
Chain speed: 11m/s (no load)
Lubrication of chain: Automatic lubrication
Chain oil required: Yes
Overall length: 7.8 feet
Weight: 11 lb.
Warning! We strongly recommend that this item not be modified and/or used for any application
other than that for which it was designed. If you have any questions relative to its application, do not
use the equipment until you have consulted us and we have advised you.
Contact Power Smart at [phone] Mon-Fri 9am-5pm EST

4
GENERAL SAFETY RULES
Warning –When using an electric pole saw, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons, including the
following:
READ ALL INSTRUCTIONS
Make sure you read and understand all instructions. Improper use of this pole saw can cause severe injury
or death from fire, electrical shock, and body contact with moving chain, on falling wood.
BEFORE OPERATING SAW
1. Read and understand this owner’s manual before operating pole saw.
2. Watch what you are doing. Use common sense. Do not operate saw when you are tired.
3. Use pole saw for cutting wood only. Do not use pole saw for purpose not intended. Do not use for
cutting plastic, masonry, etc.
4. Only well-instructed adults should operate pole saw. Never allow children to operate pole saw.
5. Use only electrical voltage noted on model plate of pole saw.
6. Use only extension cords marked for outdoor use.
7. Do not operate pole saw
•While under the influence of alcohol, medication, or drugs
•In rain or in damp or wet areas
•Where highly flammable liquids or gases are present
•If saw is damaged, adjusted wrong, or not fully and securely assembled
•If trigger does not turn saw on and off. Chain must stop moving when you release trigger. Have
faulty switch replaced by authorized service center.
•While in a hurry
•While in tree or on a ladder unless trained to do so
8. Wear snug-fitting clothes when operating pole saw. Do not wear loose clothing or jewelry. They can
get caught in moving saw chain.
9. Wear the following safety gear when operating pole saw.
•Heavy-duty gloves (wear rubber gloves when working outdoors)
•Steel-toed safety footwear with non-skid soles
•Eye protection such as safety glasses, goggles, or face screen
•Hard hat
•Ear mufflers or ear plugs
•Hair covering to contain long hair
•Face or dust mask (if working in dusty areas)
10. Before cutting, always provide the following:
•Clear work area
•Secure footing
•Planned retreat path from falling tree
11. Inspect tree before cutting down. Make sure there are no dead limbs or branches that may fall on you.
12. To reduce the risk of electric shock, this saw has a polarized plug (one blade is wider than the other).
This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet of your
extension cord, reverse the plug. If it still does not fit, a polarized extension cord will be necessary.
Do not change the plug in any way.
WHILE OPERATING SAW

5
Stay alert. Use common sense while operating pole saw.
Keep work area clean. Cluttered areas invite injuries.
Be aware of extension cord while operating pole saw. Be careful not to trip over cord. Keep cord
away from chain and operator at all times.
Keep children, animals, and bystanders away from pole saw and extension cord. Only pole saw user
should be in work area.
Do not cut down a tree unless you are trained or have expert help.
If two or more persons perform bucking and felling operations at the same time, provide plenty of
distance between operations. Provide distance of at least twice the height of tree being felled.
Grip pole saw firmly with both hands. Never operate pole saw with one hand. Never use hand guard
as handle.
Keep finger off trigger until ready to make cut.
Before starting pole saw, make sure chain is not touching anything.
To guard against electrical shock, avoid body contact with grounded objects such as pipes, fences,
and metal posts.
Keep all parts of body away from chain when saw is running.
Do not force pole saw while cutting. Apply light pressure. It will do the job better and safer at the rate
for which it was intended.
Cut small brush and saplings with extreme care. Slender material may catch in chain and be whipped
toward you. This could also pull you off balance.
When cutting limb or tree trunk that is under tension, use extreme caution. Be alert for wood
springing back. When wood tension is released, limb could spring back and strike operator causing
severe injury or death.
Carry pole saw from one place to another
•With saw stopped and unplugged
•By holding front handle (never use hand guard as handle)
•With finger off trigger
•With guide bar and chain to rear
KICKBACK SAFETY PRECAUTIONS
Warning –Kickback may occur when the nose or tip of the guide bar touches on object, or
when the wood closes in the cut. Tip contact in some cases may cause a lightning fast reverse
reaction, kicking the guide bar up and back towards the operation. Pinching the saw chain
along the top of the guide bar may push the guide bar rapidly back towards the operator. Either of these
reactions may cause you to lose control of the saw which could result in serious injury to user.
Kickback is the name given to a sudden, rapid upward movement of the saw cutting mechanism in an
upward arc towards the operator. Kickback occurs when the upper quadrant of the bar nose comes in
contact with a solid object or is pinched. The rotational force of the chainsaw can be reversed in the
opposite direction of the chain movement. This may fling the bar up and back in an arc towards the
operator. Serious injury or even death can result from contact between the moving saw chain and the
operator.
The best protection against injury due to kickback is to avoid situations that can cause kickback:
Hold the chainsaw firmly with both hands and maintain a secure grip.
Be aware of the location of the bar nose at all times while cutting.

6
Never bring the nose of the guide bar in contact with any object. Never cut limbs with the nose of the
guide bar. Be especially careful when cutting saplings, brush and small hard limbs that may easily
pinch the cutting chain.
Don’t cut above shoulder height. Don’t overreach or use the chainsaw while standing on a ladder or
tree.
Never use the chainsaw one-handed.
Use extreme caution when entering a previous cut.
Do not attempt plunge cuts if you are not familiar with this cutting technique.
Stand to the side of the cutting path of the chainsaw.
Cut with a correctly sharpened, properly tensioned chain at all times.
Save these instructions. It is your guide to safe and proper operation of this pole saw.
ELECTRICAL INFORMATION
DOUBLE INSULATION
Double insulation is a concept in safety in electric power tools that eliminates the need for the usual
three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor
components with protecting insulation. Double insulated tools do not need to be grounded.
WARNING: The double insulated system is intended to protect the user from shock resulting
from a break in the tool’s internal insulation. Observe all normal safety precautions to avoid
electrical shock.
NOTE: Servicing a product with double insulation requires extreme care and knowledge of the system.
This should be performed only by a qualified service technician. For service, we suggest you return the
product to your nearest authorized service center for repair. Always use original replacement parts
intended for your particular model of tool when servicing.
WARNING: This tool is for outdoor use only. Do not expose to rain or use in damp locations.
Guidelines for using extension cords
Make sure your extension cord is in good condition. When using an extension cord, be sure to use one
heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating. The table below shows the correct size to be used
according to cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.

7
Minimum Gauge for Extension Cords (AWG)
(When using 120 V only)
Ampere Rating
Total Length of Cord in feet
More Than
Not More Than
25
50
100
150
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Recommended
Make sure your extension cord is properly wired and in good condition. Always replace a damaged
extension cord or have it repaired by a qualified person before using it.
Protect your extension cords from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be
protected with a 15 Amp time-delayed fuse. Before connecting the motor to the power line, make sure the
switch is in the OFF position and the electric current is rated the same as the current stamped on the motor
nameplate. Running at a lower voltage will damage the motor.
WARNING: This tool must be grounded while in use to protect the operator from electric shock.

8
KNOWING YOUR POLE SAW
Saw chain
Oregon guide bar
Sprocket locking knob
Lubrication oil tank cap
Inner tube
Adjusting knob
Outer tube
Adjusting knob
Inner tube
Trigger switch lock-out
Trigger switch
Handle
Power cord

9
ASSEMBLY AND ADJUSTMENTS
Unpacking
Unpack the Pole Saw and all its parts, and compare against the list below. Do not discard the carton or
any packaging until the Pole Saw is completely assembled.
1
Pole saw
1
Saw chain (assembled)
1
Guide bar (assembled)
1
Scabbard
1
Wrench
1
Owner’s manual
Install the pole saw
1. Loosen the adjusting knob near to the handle and slide the inner and outer tube.
2. Loosen the adjusting knob near motor head and insert the inner tube of motor head until heard “click”
sound. Then tighten the adjusting knob.
3. Pull inner tube out to desired length of extension then tighten the adjust knob near the handle.
Chain Lubricating Oil
Use high quality chain lubricating oil to minimize wear between the saw chain and guide bar while in use.
We recommend using SAE No. 30 in the summer and SAE No. 10 in the winter or when cutting resinous
wood. Check the oil level prior to each use.
WARNING - The chain saw is not supplied filled with oil. It is essential to fill with oil before
use. Never operate the chain saw without chain oil or at an empty oil tank level, as this will
result in extensive damage to the product.
Adjusting Knob
Adjusting Knob

10
WARNING - Never use waste or reclaimed oil. This results in damage to the oil pump, saw
chain and guide bar.
Filling oil tank
1. Set chain saw on any suitable surface with Oil Tank Cap facing upward.
2. Clean area around the Oil Tank Cap with cloth and unscrew the cap by turning it counter clockwise.
3. Add chain oil until reservoir is full.
4. Avoid dirt or debris entering oil tank, refit Oil Tank Cap and tighten by turning clockwise until hand
tight.
OPERATION
Adjusting pole length
The pole saw has a telescoping pole assembly that will extend from 71 inches (fully retracted) to 94.5
inches (fully extended).
An adjusting knob near handle is used to hold the pole in
position at any extended length.
1. To extend the pole, loosen the adjusting knob. Pole
will slide freely.
2. Pull inner tube out to desired length of extension.
Note: only extend pole to minimum length required to reach limb
that is being cut.
3. To lock pole in position, tighten adjusting knob.
Turn on the pole saw
1. Use both hands to grip Pole Saw. Use only designated grip areas when operating Pole Saw. Use firm
grip. Thumbs and fingers must wrap around Pole Saw handle and pole.
2. Make sure your footing is firm. Keep feet apart. Divide your weight evenly on both feet.
3. When ready to make a cut, press in trigger switch lock-out and squeeze trigger switch. This will turn
pole saw on.
Warning - Never stand directly under the limb you are trimming. Always position yourself
out of the path of falling debris.
Warning - Never stand on a ladder or other type of unstable support while using the pole saw.
Warning - Do not use pole saw near cable, electric power or telephone lines. Maintain a
minimum clearance of 10 feet from all power lines.
Warning - Keep other persons from cutting end of pole saw an d at a safe distance from work
area.
Adjusting Knob

11
MAINTENANCE
Change saw chain
1. Remove the screw and turn Sprocket Locking Knob counterclockwise to remove the guide bar cover.
2. Move the chain tensioning pin fully back towards the sprocket
using the chain tension screw. (See direction arrow)
3. Place the guide bar onto the bar studs so that the chain tensioning pin fits into the hole in the guide
bar.
4. Install chain over clutch and place around the sprocket and guide bar.
5. Make sure the chain cutters on top of the guide bar face in the direction that the chain runs.
6. Install guide bar cover. Tighten the sprocket locking knob finger tight.
7. Adjust saw chain tension by first holding the bar nose up and turning the chain tension screw
clockwise until saw chain touches the bottom of the guide bar.
8. Tighten the sprocket cover locking nut using the wrench provided, keeping the guide bar nose up
while tightening the nut.
9. Pull the saw chain around the guide bar by hand to check for tight spots. Saw chain should move
freely but not sag. If too tight loosen the guide bar nuts and adjust using the chain tension screw.
10. Tighten the guide bar cover by turning the sprocket locking knob and using a screwdriver to tighten
screw.
WARNING - Never try to run the chainsaw without sprocket cover securely tightened.
Screw
Sprocket Locking Knob
Guide Bar Cover
Tension Pin

12
Caution: Proper saw chain tension is extremely important. If saw chain is too tight, the guide bar and saw
chain will be quickly damaged. If the saw chain is too loose, it may get out of the guide bar groove and
cause an injury.
Note: A new chain will stretch so adjust the tension after a few cuts. Watch saw chain tension carefully
for the first half hour of cutting.
Guide bar and oil holes
Clean guide bar before use. Follow instructions for removing and
installing guide bar and saw chain. Remove guide bar and clean
groove of the guide bar with a small screwdriver. Clean oil holes
with a wire. Check the sprocket and the clutch and clean the bar
mount area before installing the bar. Guide bar with sprocket nose
should be lubricated with grease using a lubricating syringe. Invert
the symmetrically shaped guide bar every 8 working hours or each
time the chain is removed to ensure uniform wear. Check the bar
rails frequently for wear and remove burs and square up the rails
using a flat file. Clean the Oiler port on the saw every time the saw
chain and guide bar are removed.
Sprocket
A damaged drive sprocket will cause premature wear or damage of the chainsaw.
Check the sprocket when installing a new chain. When outer diameter of sprocket is worn 0.5mm (0.020”)
or more, replace it. Always clean sprocket, clutch and bar mount area before installing guide bar.
Saw chain sharpening
It is advisable to have professional shops sharpen saw chains. It is beyond the expertise of the typical
home owner to sharpen saw chains. An improperly sharpened saw chain will not cut effectively, require
more physical effort, and cause high vibrations and a higher rate of wear.

13
Maintenance chart
Before
Work
After
work
Weekly
Monthly
If
faulty
If
damaged
As
required
Complete
Machine
Visual inspection
x
Clean
x
Switch
Check operation
x
Oil tank
Clean
x
Chain
lubrication
Check
x
Saw chain
Inspect and check the
sharpness
x
Check chain tension
x
Sharpen
x
Guide bar
Check (wear, damage)
x
Clean and turn over
x
x
Deburr
x
Replace
x
x
Chain
sprocket
Check
x
Screws
and Nuts
Retighten
x
Power
cord
Check
x
Replace
x

14
EXPLODED VIEW & PARTS LIST
Item
Stock #
Description
Item
Stock #
Description
1
PS6108-101
Sprocket locking knob
30
PS6108-130
Worm shaft
2
PS6108-102
Screw ST4.2x14
31
PS6108-131
Bearing 606
3
PS6108-103
Guide bar cover
32
PS6108-132
O-ring
4
PS6108-104
Gasket
33
PS6108-133
Pipe connector
5
PS6108-105
Seal
34
PS6108-134
Oil tank
6
PS6108-106
Tension screw M5x30
35
PS6108-135
Oil tank seal
7
PS6108-107
Tension nut
36
PS6108-136
Oil tank cap
8
PS6108-108
Right side
36-1
PS6108-136-1
filter cover
9
PS6108-109
Bolt M8x20
36-2
PS6108-136-2
Filter
10
PS6108-110
Snap ring
37
PS6108-137
Valve
11
PS6108-111
Washer
38
PS6108-138
Pipe seal
12
PS6108-112
Sprocket
39
PS6108-139
Pipe 70mm
13
PS6108-113
Bearing cover
40
PS6108-140
Screw ST4.2x10
14
PS6108-114
Right motor cover
41
PS6108-141
Pipe 65mm
15
PS6108-115
Bearing 627
42
PS6108-142
Oil pump
16
PS6108-116
Stator
43
PS6108-143
Carbon brush
17
PS6108-117
Rotor
44
PS6108-144
Brush holder
18
PS6108-118
Key 2.5x10
45
PS6108-145
Screw ST2.9x16
19
PS6108-119
Bearing 608
46
PS6108-146
ST2.9x10
20
PS6108-120
Gear
47
PS6108-147
Right switch box
21
PS6108-121
Locknut M5
48
PS6108-148
Plug
22
PS6108-122
Rubber bracket
49
PS6108-149
Left switch box
23
PS6108-123
bracket
50
PS6108-150
Left motor cover
24
PS6108-124
Washer 4
51
PS6108-151
Knob
25
PS6108-125
Spring washer 4
52
PS6108-152
Guide bar
26
PS6108-126
Screw M4x10
53
PS6108-153
Saw chain
27
PS6108-127
Bearing 6900
54
PS6108-154
Scabbard
28
PS6108-128
Shaft
55
PS6108-155
Wrench
29
PS6108-129
Worm gear

15
Item
Stock #
Description
Item
Stock #
Description
1
PS6108-201
Screw ST4.2x14
16
PS6108-216
Screw M4x5
2
PS6108-202
Right handle
17
PS6108-217
Ring
3
PS6108-203
Handle grip
18
PS6108-218
Tube connector
4
PS6108-204
Cable holder
19
PS6108-219
Spring pin
5
PS6108-205
Cable sleeve
20
PS6108-220
Stop bracket
6
PS6108-206
Power cord
21
PS6108-221
Spring
7
PS6108-207
Switch lever
22
PS6108-222
Outer tube
8
PS6108-208
Spring
23
PS6108-223
Cable
9
PS6108-209
Switch lock-out
24
PS6108-224
Inner tube B
10
PS6108-210
Spring
25
PS6108-225
Screw ST2.9x8
11
PS6108-211
Switch
26
PS6108-226
Left bracket
12
PS6108-212
Left handle
27
PS6108-227
Plug
13
PS6108-213
Inner tube A
28
PS6108-228
Screw ST4.2x8
14
PS6108-214
Tube spring
29
PS6108-229
Right bracket
15
PS6108-215
Adjusting knob

16
TWO (2) YEARS LIMITED WARRANTY
PowerSmart®is committed to building tools that are dependable for years. Our warranties are consistent with our
commitment and dedication to quality.
TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE.
Power Smart (“Seller") warrants to the original purchaser only, that all Power Smart consumer power tools will be
free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days
for all Power Smart®Products, if the tool is used for professional or commercial use.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Two (2) Years Limited
Warranty and, to the extent permitted by law, any warranty or condition implied by law, shall be the repair or
replacement of parts, without charge, which are defective in material or workmanship and which have not been
misused, carelessly handled, or misrepaired by persons other than Seller or Authorized Service Center. To make a
claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to Power
Smart Include a legible copy of the original receipt, which lists the date of purchase (month and year) and the name
of the company purchased from.
THIS LIMITED WARRANTY DOES NOT APPLY TO ANY ACCESSORY ITEMS INCLUDED WITH THE
TOOL SUCH AS CIRCULAR SAW BLADES OTHER RELATED ITEMS OR TO ANY REPLACEMENT
PARTS LISTED UNDER MAINTENANCE.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO TWO (2) YEARS FROM DATE OF
PURCHASE. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE
OR USE OF THIS PRODUCT. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN
CANADA AND FROM COUNTRY TO COUNTRY.
For questions / comments, technical assistance or repair parts –
Please call toll free at: 1-800-791-9458 (Mon-Fri 9am –5pm EST)
Email: [email protected]m
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
