PowerVision PowerRay User manual

PowerRay Quick Start Guide
PowerVision

01 02 03
PowerRay
PowerRay Introduction
PowerRay Vehicle
Base Station
Bait Drop
Remote control
Diving Preparation
5-7
8-11
1-3
4
Diving safety 15
Diving and Safety
Remote Control Modes
Using the FishFinder Sonar
12Locking and Unlocking
PowerRay
Prepare PowerRay
Prepare Remote Controller
Prepare App
Prepare VR
Battery and Charging
Check Battery Levels
Charging
Vision+ App Functions
13
14
FishFinder

01
The PowerVision PowerRay can dive as deep as 98 feet underwater in either fresh water or salt
water. It can be used for underwater photography, fish detecting, and fish luring. Users can operate
the PowerRay through the PowerVision Edition of ZEISS VR ONE Plus Goggles, transmitter, or app to
stream real-time video. Its integrated 4K UHD camera has 12 million pixels for underwater
photography and videography.
PowerRay Introduction: PowerRay Vehicle
LED Lights
Vertical Motor
Charging Port
LED Tail Light
Horizontal Motor
4K UHD Camera
Precision Bait Drop
Place for PowerSeeker

The PowerRay base station connects to the submersible through the tether cable. By connecting to
the base station, the user can control the PowerRay camera with the remote controller, VR goggles,
or a cell phone. The base station battery is 3000mAh and can work for up to 3 hours. Users can
check the battery level through the battery indicator. The base station has a rubber belt that helps
prevent the unit from slipping into the water.
Base Station
Rubber Belt
Rubber Belt Knob
Power Switch
Battery Indicator
WiFi Indicator
Cable/Charging Port Cable
Reset
02

PowerRay’s remote controller connects with the base station wirelessly. Functions include operating
the vehicle, LED lighting adjustment, speed adjustment, underwater photography, underwater
videography, precision remote bait drop, fixed depth settings and more. Users can operate
PowerRay easily through the remote control. The built-in rechargeable battery’s capacity is 3000mAh
and can operate continuously for up to 20 hours. Users can check the battery level through the
battery indicator.
Remote Controller
H
M
L
Speed Switch
Battery Indicator
Camera/FishFinder Button
Right Joystick
Left Joystick
Bait Drop Release
Depth Maintenance/
Manual Switch
Take a Photo/Video
Right Dial:
Front LED Light Adjuster
Left Shoulder Button
Left Dial
Charging Port Power Switch
03

PowerRay FishFinder sonar can detect fish and underwater landscapes up to 130 feet below the
surface and sends real-time images to the app. The sonar is equipped with a fish luring light, and can
be attached to the PowerRay or used as a stand-alone sonar device.
FishFinder
Fish Line Position
Charging Port
Fish Luring Light
Bait Drop
Please put the fish line on the hook, and operate the PowerRay
to drop the bait with the remote controller or the Vision+ App.
Charging Port
04

Remote Controller
3.5 hours to fully charge
1
2
3
2 3
1
All-in-one charger: The PowerVision charging adaptor can charge the PowerRay, remote control,
and the base station at the same time. You can also charge your cell phone with the USB port on
the adaptor.
Charging
Base Station
2.5 hours to fully charge
PowerRay Vehicle
2.5 hours to fully charge
05

Vehicle: PowerRay vehicle battery level is displayed on the Vision+ App interface.
FishFinder: The FishFinder will automatically turn on when the charging port touches the water. It will
turn off 1 minute after leaving the water. Battery level is displayed on the Vision+ App inferface.
Battery Levels
Vehicle Battery Level FishFinder Battery Level
06

H
M
L
Remote Controller and Base Station: Check battery indicator, marked in red below.
Battery Levels
Above 30% 30% - 10% Below 10% Above 60% 60% - 20% Below 20%
07

PRA_Station_xxx
WIFI
1. Turn on the base station by pressing and holding the
power button for 3 seconds.
2. Plug the cable into the base station.
3. Open the vehicle power port protector.
4. Plug the other side of the cable tightly into PowerRay.
Note: Make sure to dry the port immediately after use!
5. Use a mobile device to turn on the WiFi, connect to
“PRA_Station_xxx” (default password: 123456780)
Prepare PowerRay
08

H
M
L
Cell phones or tablets can be mounted on the bracket of the remote control. Turn on the remote
controller. It will start searching for the base station, so make sure that unit is powered on. The
remote controller light will turn green when it is connected. You will hear a notification sound when
connection is complete. Make sure you connect to the Wi-Fi to (PRA Station). Launch the Vision+ App
and switch to PowerRay. When it shows “Device is connected,” click on “Start Diving” and
you’re ready to explore!
Prepare the Remote Controller and the App
Device is connected
09

Vehicle Battery
Base Station Battery
“Vision+” App Functions
Connection Status
Master/Slave Mode
Front Light Control
Speed Mode
Album
Camera Parameters
Depth Maintenance Switch
Water Depth
Switch Photo/
Video Mode
Take Photo/Video
Prompt Message
Right Joystick
Left Joystick
Bait Drop
Sonar Mode Switch
VR Mode Switch
Base Station Signal
10

Switch to VR mode in the App and slide your mobile device into the VR glasses.
Put your phone into the bracket and push back the bottom cover.
Insert the bracket into the PowerVision Edition of ZEISS VR ONE Plus goggles.
Head gesture function activation: Press down on the left shutter button to enable this function.
You will now be able to guide the PowerRay through head gesture commands. Once you’re done,
push the left shutter button again to release this feature.
Prepare PowerVision Edition of ZEISS VR ONE Plus
11

H
M
E
H
M
E
11
To prevent users from spinning the propellers accidently outside the water, PowerRay pilots need
to unlock the PowerRay to enable the motors.
Unlock: Dial the left finger wheel to the right and press
camera/fish finder button for 1 second until it vibrates.
Lock: Dial the left finger wheel to the left and press
camera/fish finder button for 1 second until it vibrates.
Locking and Unlocking PowerRay
H
M
L
Speed Controls: Speed of the vehicle can be adjusted by toggling the
switch between the two joysticks (High, Medium, and Low speed).
12

Forward
Backward
Forward
Backward
Rotate
Left
LEFT JOYSTICK
Rotate
Right
MODE 1 / JAPANESE
Ascend
Descend
RIGHT JOYSTICK
Ascend
Descend
Rotate
Left
LEFT JOYSTICK
Rotate
Right
MODE 2 / AMERICAN
Forward
Backward
RIGHT JOYSTICK
Ascend
Descend
Rotate
Left
LEFT JOYSTICK
Rotate
Right
MODE 3 / CHINESE
RIGHT JOYSTICK
Ascend
Descend
Forward
Backward
Rotate
Left
LEFT JOYSTICK
Rotate
Right
MODE 4
RIGHT JOYSTICK
PowerRay has 4 modes in which to control the submersible. The remote control’s default mode is
“MODE 4.” Users can choose the mode that best fits their control of the PowerRay through the App.
Remote Control Modes
13

Speed Controls: Speed of the vehicle can be adjusted by toggling the
switch between the two joysticks (High, Medium, and Low speed).
1. The FishFinder must be installed on the PowerRay before connecting the power cable to the Ray.
2. Once the PowerRay is powered on, the FishFinder will start to work when it enters the water.
3. The FishFinder will automatically connect to the PowerRay. You can also connect to the FishFinder
Wi-Fi, “PSE_xxx”. No password is needed when the FishFinder is bobbing on the water surface.
4. You can also click on Vision+ App icon to switch to the FishFinder interface.
Note: Display parameters can be adjusted to change the display effect. You can also turn on/off
the fish detection notification.
Using the FishFinder Sonar
14

Dive in
open water
Avoid waterweeds
Do not throw
into water
Avoid hot
environments
Keep base station
away from water
Keep within
visual range
Do not exceed
30M depth
Turn off the base
station to save battery
Do not pull the cable
with strong force
Do not touch
spinning propellers
Do not spin motors
in the air outside of
the water
15
