Powerwerks PW100T User manual





10. Subwoofer Out
9. POWERLINK Out
8. POWERLINK In
7. Master Volume
6. High
5. Low
4. Volume
3. Aux In
2. Line Inputs
1. Mic Inputs
12. AC Power Cord Receptacle
11. Power

2. LINE Inputs: These ¼-inch inputs may be used to connect high-impedance microphones or
keyboards, drum machines and other audio devices.
3. AUX IN: Use this stereo input to connect an external audio device such as an MP3, CD player or
computer for playback. Note: Right and Left channels are summed to mono on this input.
1. MIC Inputs: These XLR inputs are designed for low-impedance microphones or equipment that
has a Mic-level, balanced output (often called a Direct Out). Note: These inputs receive 15-volt
phantom power. This is used to provide power to condenser microphones. Phantom power will not
damage any dynamic or non-condenser microphone.
CONTROLS & FEATURES OVERVIEW
INPUT SECTION:
This is where you may plug in microphones, instruments, keyboards, drum machines or other audio
devices and adjust the volume, bass and treble.
4. Volume: Use these controls to adjust the volume level of each channel and the relative balance
between them.
5.Low: Determines the emphasis of Low frequencies. Turning this knob clockwise creates a deeper,
warmer tone. If you need a brighter sound, reduce the Low by turning counterclockwise.
6. High: Turned clockwise, this control accents High frequencies to produce clearer, crisper sound.
Turn counterclockwise to make the sound softer and less bright.
11. Power: This switch activates AC power to the powered PA.
12. AC Power Cord Receptacle: Insert the PW100T’s AC cord rmly into the AC receptacle. Be
sure to use the cable provided with your PW100T. The power cord can be removed for storage or
replacement if damaged. Note: Replace the AC cord if its protective jacket is damaged or ground pin
is damaged or removed.
7. Master Volume: Controls the overall volume of all channels and input on POWERLINK Note: Does
not affect POWERLINK Output level.
8. POWERLINK IN: This balanced XLR Jack accepts the POWERLINK output from another PW100T
using a standard Mic cable. Channels from both PW100T’s are summed together. Use the channel
volume controls to get the mix of the 6 channels (If a channel is not used turn the volume all the way
down). MASTER volume controls the loudness of the mix through its PW100T. It does not affect
volume of linked PW100T. Note: The shield connection (pin 1) on this jack is connected to chassis
ground. It is not lifted.
9. POWERLINK OUT: This balanced XLR Jack accepts the POWERLINK input from another PW100T
using a standard Mic cable. Channels from both PW100T’s are summed together. Use the channel
volume controls to get the mix of the 6 channels (If a channel is not used turn the volume all the way
down). MASTER volume controls the loudness of the mix through its PW100T. It does not affect
volume of linked PW100T. This jack may also be used to connect the PW100T to a power amp with
a balanced line input. Note: The shield connection (pin 1) on this jack does not connect to chassis
ground. It is lifted.
10. Subwoofer Out: This line level un-balanced output is optimized to send low frequency signal
to PW112S powered subwoofer but will work with any powered subwoofer that accepts a line level
input. A crossover is activated when plugging a standard ¼” mono (tip/Sleeve) plug into this jack.
The crossover point is 150Hz. Frequencies 150 and below go to subwoofer output jack at all times
Frequencies 150Hz and above go to PW100T speakers. PW100T speakers are full range when jack
is not used. Note: It is recommended to connect use a standard ¼” mono (tip/sleeve) SHIELDED
instrument cable because the sleeve connection to ground is what activates crossover on PW100T
speakers.
12. AC Power Cord Receptacle
11. Power

Output Power 1% 100W 4 Ohm load
CH 1 and 2 Mic XLR Balanced, Line level 1/4" Un-balanced
onom
dexim
,oeretS
leveL
enil/enohpdaeH
"8/13HC
-56dB Residual Noise, all level controls 0% (minimum)
-48dB Nominal System Noise, all level controls at 50%
+70dB Mic to Speaker Output (CH 1 & 2)
+56dB Line to Speaker Output (CH 1 & 2)
+42dB AUX IN to Speaker Output
Channel EQ (high, low)
Subwoofer Out Line Out 20Hz-150Hz.
Phantom Power +15V Mic inputs (Ch 1 & 2)
USA/Canada 120VAC/60Hz, 160W nominal
Europe 230VAC/50Hz, 160W nominal
lanimon
W061
,zH05/CAV032KU
Australia 240VAC/50Hz, 160W nominal
Japan 100VAC/50-60Hz, 160W nominal
Speakers Four 4½" 50W 4 Ohm each
revird
ozeip
"½
3
nroH
Power Capacity 100W RMS
60HZ-20kHz Full range (subwoofer jack not used)
150HZ-20kHz Crossover Active (1/4" mono plug in subwoofer jack)
Nominal Impedance 4 Ohms Not designed for external speakers
mm/kg 190 (width), 715 (height), 165 (depth), 10.57 kg
Inches/Pounds 7½ (width), 28 (height), 6½ (depth), 23.3 lb
Hum & Noise
Frequency Response
Dimensions & Weight
PW100T Powered PA Specifications
4kHz and above , 800Hz and below.
Power Requirements
SYNC (IN and OUT) Both jacks accept a balanced input and sends a pre-master volume output mix of
channels. Recommended use: Linking two PW100T's together.
System Gain
(Measurements made at
1kHz)
Frequency Response 20HZ-20kHz Actual response is tailored to speaker cabinet for
accurate acoustical response.
Accepted Inputs

1
GAIN
volume
MAIN BUS
MIC
LINE
lowhigh
Phantom Power 15V
2
GAIN
volume
MIC
LINE
lowhigh
Phantom Power 15V
3
volume lowhigh
AUX
CHANNELS
MASTER
Conditioning
LINKING BUS
IN
OUT
SYNC
MASTER
+
_
+
_
+
_
PASSIVE CROSSOVER
SPEAKERS
Crossover
SUBWOOFER OUT
Crossover
CROSSOVER BYPASS
POWER AMP
100W
+
_
+
_
HF COMPENSATION
Inserting 1/4"
mono (tip/sleeve)
SHIELDED
instrument cable
into subwoofer out
j
ack activates
crossover.
BLOCK DIAGRAM

EC Declaration of Conformity
We: Kustom Musical Amplification INC.
3015 Kustom Drive
Hebron, Ky 41048-0568
Tel: 1-859-817-7100 Fax: 1-859-817-7150
Declare that the product
Product name: Powerwerks
Product model number: PW100T
to which this declaration relates is in conformity with the following standards;
EN55013: 2001/+A1:
2003+A2: 2006 Limits and methods of measurement of radio disturbance characteristics of broadcast
receivers and associated equipment.
EN55020: 2007 Electromagnetic immunity of broadcast receivers and associated equipment.
EN61000-3-2: 2006 Limits for harmonic current emissions (equipment input current < 16A per phase).
EN61000-3-3: 2008 Limitation of voltage fluctuations and flicker in low voltage supply systems for
equipment with rated currents < 16A.
EN60065: 2002+A1:
2006+A11: 2008 Safety requirements for main operated electronic and related apparatus for household and
similar general use.
Following the provisions of EU Council Directive(s): 72/73 EEC and 89/336/EEC.
We the undersigned, hereby declare that the equipment specified above conforms to the aforementioned directive(s).
Name of authorized person: James Brown, Chief Engineer
Signature:______________________ Date: 14 January, 2011
Kustom Musical Amplification INC.
3015 Kustom Drive
Hebron, Ky 41048-0568
Tel: 1-859-817-7100 Fax: 1-859-817-7150
Signature:______________________
Date: 14 January, 2011
