PPG WAVE 2.2 Adjusting instructions
The PPG WAVE 2.2 has fully digital tone-generators which
need no tuning at all. Becaurse of the pich-wheel which is
an analog control there can be a total detuning of the
instrument. Follow these instruction for gettinq propper
function. 3 a ^ rr
Open the instrument as followes:
Remove the two screws on both sides of the WAVE 2.2 s case.
Loosen the two screws at both posterior sides, which work as
hinges. Lift the cover and remove the savety-plate of the
printed circuit boards. Now the instrument is ready for
service.
1- Adjusting the A/D Converter of the analog controls
av P any P ro 9 ramm and have a look into the ANALOG
DISPLAY. Move one control to the right-end position (full
clockwise) and notice the corresponding analog value. A
full clockwise turned control must show value *63'. If not.
you have to adjust the A/D Converter. The position of the
A/D trim control is shown in picture 1. Adjust the A/D trim
control to show value "63" even short before the
end-position of the analog control. Make this adjustment
before adjusting the Pitch Wheel (Bender).
2. Adjusting the Pitch Wheel
Call up any program, that uses keyb.mode "0". Make shure,
that no detunings work on the oszillators (DETUrO). Choose
Bender Intensity BI:”3". In the way the Bender spreads
from one limitation to the other, thare are parts with no
effect called "windows". A "window", for example, is at
the center position. The center position of the wheel
should be in the middle of this window. It can be adjusted
by loosening the screw of the plastic wheel fixed on the
potentiometer axis and adjusting the center position of the
wheel exactly to the centre of the window.

3. Adjusting the filters
3.1. Adjusting the resonance intensity
The instrument is opened and power is on. Call up program
74 group A (original PPG program). Tune the instrument to
440 Hz (TTUNE: 440)- Choose group A for adjusting the
resonance. After power ON. the voices of the WAVE 2.2 are
in the normal order. Each time you press a key the next
voice gets enabled. (in the sequence 1.2.3 4.5.6.7.8) Now
press the first key. in the centre of the keyboard, and
adjust the trim-pot so. that the filter resonance is
dirictly before self-osci11ation. Press the same key again
and trim the next voice. Go through all the 8 voices this
way. It is important that they are all trimmed to the same
intensity.
3.2. Adjusting the cutoff-frequency of the filters
Swith to group B (program 74). Press a key in the higher
range of the keyboard, and adjust the cutof.f-f r equency so
that it becomes equal to the fundamental frequency of the
tonegenerator. Do the same procedure for all the 8 voires.
The positiones of the trim-pot s you find in the drawing
below.

—
