PR SOLO 575 User manual

SOLO 575
PR-2585
This product manual contains important information about the safe installation
and use of this projector. Please read and follow these instructions carefully and
keep this manual in a safe place for future reference.
PR LIGHTING LTD.
No. 5 1, Yingbin Road, Dashi, Panyu, Guangzhou, 511430 China
http://w w w . p r - lighting.c o m

SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
CONTROL CONNECTIONS 5
DMX TERMINATOR 6
SETUP OPTIONS-PROJECTOR CONFIGURATION 6
TO SET THE DMX START ADDRESS 6
FUNCTIONS DISPLAY
REPLACING GOBOS 9
REPLACING BELTS 9
DMX CONTROL CHANNEL FUNCTIONS 10
MAINTENANCE 15
LUBRICATION 15
KEEPING THE PROJECTOR CLEAN 15
TROUBLESHOOTING 15
TECHNICAL DATA 1
ELECTRICAL DIAGRAM 19
COMPONENT ORDER CODES 20
CHANGING THE OPERATION FREQUENCY 21
Please note that as part of our ongoing commitment to continuous product development, specifications are
subject to change without notice. Whilst every care is taken in the preparation of this manual we reserve the
right to change specifications in the course of product improvement. The publishers cannot be held responsible
for the accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and /
or the unit are in good condition before installation and use. Should there be any damage caused by
transportation, consult your dealer and do not use the unit. Any damage caused by improper use will not be
assumed by the manufacturer and / or dealer.
Solo 5 5 Manual_en.doc
2/24
ACCESSORIES
INDEX

THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
G clamps (2 PCS)
XLR cable with 3-pin plug and socket (1 PCS)
Safety cords (2 PCS)
Spare gobos (3 PCS)
This manual (1 PCS)
Ω clamps (Options) (2PCS)
Thank you for purchasing our product SOLO 5 5, PR-2585.
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place for
future reference.
SOLO 5 5 is an innovative projector with an elegant housing, which is of Pan’s and Tilt’s locks for
maintenance and high quality fans free from noise. The projector has 2 types of clamps for mounting
at any direction and position. Which complies to CE norms and standards and uses international
protocol DMX 512.
The projector uses MSR5 5 discharge lamp and high quality optical system, which produces bright
and beautiful light beam and has 60% output lumen more than the similar products with the same
power consumption. The projector features effects of strobe, frost light, mixed colours and rainbow, so
it is suitable for applications in TV station, disc, singing and dancing stage, nightclub, etc.
Solo 5 5 Manual_en.doc
3/24
INTRODUCTION

When unpacking and before disposing of the carton check there is no transportation damage before
using the projector. Should there be any damage caused by transportation, consult your dealer and
do not use the apparatus.
The projector is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain
and moisture, excessive heat, humidity and dust. Do not allow contact with water or any other liquids.
The projector is not designed or intended to be mounted directly on to inflammable surfaces.
The projector is only intended for installation, operation and maintenance by qualified personnel.
The projector must be installed in a location with adequate ventilation, at least 50cm from adjacent
wall surfaces. Be sure that no ventilation slots are blocked.
Do not project the beam onto inflammable surfaces, minimum distance is 5m. 5m
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle and/or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power
requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all
relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the power-
cord come into contact with other cables. Only handle the power-cord by the plug. Never pull out the
plug by tugging the power-cord.
Keep the lamp clean. Do not touch the lamp glass with bare hand.
The projector should always be installed with a secondary safety fixing. A safety cord is supplied for
this; it should be attached as shown in “installing the projector” section.
The lamp used in this projector is a Philips MSR 5 5 discharge lamp. After switching off don’t attempt
to restart the projector until lamp has cooled, this will require approx 15 minutes. Switching the lamp
on and off at short intervals will reduce the life of both the lamp and the projector. But occasional
breaks will prolong the life of the lamp and projector.
Never run the projector without a lamp.
There is no user serviceable parts inside the projector do not open the housing and never operate the
projector with the covers removed.
Always disconnec from he mains, when he device is no in use or before cleaning i or
before a emp ing any main enance work.
If you have any questions, don’t hesitate to consult your dealer or manufacturer.
Solo 5 5 Manual_en.doc
4/24
SAFE USAGE OF THE PROJECTOR

To pass 2 SAFETY CORDS
through 4 HOLES for safety!
WARNING
HOLE
SAFETY
CORD
106
256
To pass 2 SAFETY CORDS
through 4 HOLES for safety!
WARNING
HOLE
SAFETY
CORD
Take 2 clamps and 2 safety cords out from the package and mount 2 clamps on the underside of
fixture with 2 retainers attached to each clamp. Hang the fixture on the structure and fasten the
screws attached to each clamp. (Watch the WARNING on the underside of the base as shown above)
To pass 2 SAFETY CORDS hrough 4 HOLES for safe y! Always ensure that the projector is firmly
anchored to avoid vibration and slipping whilst functioning. Always ensure that the structure that you
are going to mount the projector is secure and is strong enough to support a weight of SOLO 5 5.
WARNING: 1. Unlock he PAN and TILT before he 1s applica ion of projec or for safe y.
2. The projec or MUST be lif ed or carried by he HANDLES ins ead of clamps.
LAMP
Lock tilt before fitting/replacing the lamp.
(Do the way as shown in the above figure)
Loosen 2 lampholder screws as shown in the above figure and take out the lampholder.
Free worn-out lamp from lampholder.
Fit a new lamp and insert it with lampholder into the fixture, then fasten 2 lampholder screws.
After the fitting is done, turn the projector on and 5 minutes later adjust 3 adjusting screws to focus for
the best light output.
No es: don’ ouch he bulb of he new lamp wi h bare hand so as no o influence he beam
ou pu .
WARNING: The MSR series are high-pressure lamps wi h ex ernal igni ers ( ). Care should
always be aken when handling hese lamps. Always read he manufac urers "Ins ruc ions for
use" enclosed wi h he lamp.
Solo 5 5 Manual_en.doc
5/24
FITTING THE LAMP
INSTALLING THE PROJECTOR

Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Use the plug provided to connect the mains power to the projector paying attention to the voltage and
frequency marked on the panel of the projector. It is recommended that each projector be supplied
separately so that they may be individually switched on and off.
IMPORTANT
I is essen ial ha each projec or is correc ly ear hed and he elec rical ins alla ion conforms o
all relevan s andards. Power consump ion of he SOLO 575 is 650W.
Connection between controller and projector and between one projector and another must be made
with 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to and from
the projector is via cannon 3 pin (which are included with the projector) or 5 pin XLR plugs and
sockets. The XLR's are connected as shown in the figure above.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each
other. The body of the plug is not connected in any way. The SOLO 5 5 accepts digital control signals
in protocol DMX512 (1990).
Connect the controller’s output to the first fixture’s input, and connect the first fixture’s output to the
second fixture’s input and connect the rest fixtures in the same way. Eventually connect the last
fixture’s output to a DMX terminator as shown in the figure below.
DMX IN FROM
CONTROLLER TERMINATOR
34.625334.625334.6253
DMX OUTDMX INDMX OUTDMX INDMX IN DMX OUT
Solo 5 5 Manual_en.doc
6/24
POWER SUPPLY - MAINS
CONTROL CONNECTIONS

In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a
DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals.
The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2
and 3, which is then plugged into the output socket on the last projector in the chain. The connections
are illustrated below.
UP
Projector configuration can be set conveniently via pressbutton switch and digital display. Turn the
projector on and the digital display will show DMX address you set and save last time and it can be
reset and saved again as you please.
Press button UP or DOWN if you want to browse through the various Setup Options.
Press button ENTER to save your settings or enter the next menu. Press button UP or DOWN to shift
the display between and or change the display of address.
Press button FUNC, it will return to the upper menu one by one. The display will return automatically
to the function of address display if you stay for about 60 seconds defaulted.
Each SOLO 5 5 must be given a DMX start address so that the correct projector responds to the
correct control signals. This DMX start address is the channel number from which the projector starts
to “listen” to the digital control information being sent out from the controller. The SOLO 5 5 has 14
channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 015, No. 3 projector’s
address 029, No. 4 projector’s address 043, and so on.
Solo 5 5 Manual_en.doc
DMX TERMINATOR CONNECTION
Connect a 120Ω(OHM) resistor across
pins 2 and 3 in an XLR plug and insert
into the DMX OUT socket on the last
unit in the chain.
/24
DMX TERMINATOR
SETUP OPTIONS - PROJECTOR CONFIGURATION
TO SET THE DMX START ADDRESS

Launch the projector. Press button ENTER more than 5 seconds to unlock panel.
Press button FUNC to ;
Press button ENTER, it will display address;
Press button UP and DOWN, you can set the address;
Press button ENTER to confirm;
Press button FUNC, it will return to the upper menu one by one.
Solo 5 5 Manual_en.doc
8/24
FUNCTIONS DISPLAY

RESERVED
RESERVED
SET ADDR. (Default: 001)
ADDR. 001
RESET MENU
RESET OR NOT
MODE MENU ( Defaut: dMX)
DMX CONTROLLER MODE
CONFIG. MENU
SET DMX EXT. CHANNEL (Default:ON)
DMX EXT. CHANNEL ENABLED
SET LAMP CONTROL MODE (Default:CTRL)
BY DMX SIGNAL EXISTING OR NOT
BY CONTROL CHANNEL
BY LAMP MENU
OPTION MENU
SET COLOUR FILTERS (Default:STEP)
LINEAR ROTATION ENABLED
LINEAR ROTATION DISABLED
SET ROTATION OF PAN (Default:OFF)
REVERSE ROTATION
FORWARD ROTATION
RESERVED
RESET (Default:OFF)
DISABLED
ENABLED AND LOAD ALL DEFAULTS
RESERVED
RESERVED
DMX EXT. CHANNEL DISABLED
DMX CONTROL CHANNEL DISABLED
DMX CONTROL CHANNEL ENABLED
SET DMX CONTROL CHANNEL (Default:ON)
FORWARD ROTATION
REVERSE ROTATION
SET ROTATION OF TILT (Default:OFF)
(CONTINUE)
Solo 5 5 Manual_en.doc
9/24

ACCESS SELF-TEST MODE
EXIT SELF-TEST MODE AND RESET
SELF-TEST MODE (Default:OFF)
INFORMATION MENU
DISPLAY LAMP'S USING TIME OR SET TO 0
DISPLAY TEMPERATURE
DISPLAY MAIN PCB'S TEMPERATUER
DISPLAY DRIVER PCB Ⅰ'S TEMPERATURE
DISPLAY PAN&TILT DRIVER PCB'S TEMPERATURE
TEST MENU
DEBUG MODE (Default:OFF)
EXIT DEBUG MODE AND RESET
ACCESS DEBUG MODE
LAMP MENU(Default:STAT)
DISPLAY STATE OF LAMP
ON
OFF
DISPLAY POWER PCB'S PROGRAM VER.
DISPLAY MOTOR DRIVER PCBⅠ'S PROGRAM VER.
DISPLAY MAIN PCB'S PROGRAM VER.
DISPLAY PROGRAM VERSION
DISPLAY PROJECTOR'S USING TIME
DISPLAY PAN&TILT DRIVER PCB'S PROGRAM VER.
(END)
SET 001-008 FAN SPEED
Solo 5 5 Manual_en.doc
10/24

ROTATING GOBO
ROTATED GOBO WHEEL
SPRING
ROTATED GOBO WHEEL
GOBO HOLDER
GOBO
RETAINING SPRING
Lock Tilt.
Free 2 latch catches on the cover and slip off the front cover. You could see the structure as shown in
the above figure.
For gobos replacement on the rotated gobo wheel: take an appropriate tool to tug up spring and take
out the rotating gobo with its holder; tug the head of retaining spring up and engage your another
hand to take the retaining spring out; take the gobo out; fit a new gobo and fit the retaining spring; fit
the gobo holder. Notes: the gobo cannot be touched with bare hand; be careful of the gobo when the
replacement is underway and don’t drop it.
Close the front cover and fasten 2 latch catches.
Pan’s bel s
Free 2 screws on Pan assembly’s maintenance
door and open the door; change the belts; close
the door and fasten the screws.
Til ’s bel s
The common users replacing the belts is not recommended.
Solo 5 5 Manual_en.doc
11/24
REPLACING GOBOS
CHANGING BELTS
Open the door
Screws
Base

The SOLO 5 5 uses 14 DMX channels. They are listed in the following table.
Channel Function DMX Value Description
1 Strobe 000-009 Blackout
010-020 Open
021-034 Strobe 1
035-048 Strobe 2
049-062 Strobe 3
063-0 6 Strobe 4
0 -090 Strobe 5
091-104 Strobe 6
105-118 Strobe
119-132 Strobe 8
133-146 Strobe 9
14 -160 Strobe 10
161-1 4 Strobe 11
1 5-188 Strobe 12
189-202 Strobe 13
203-216 Strobe 14
21 -230 Strobe 15
231-244 Strobe 16
245-255 Open
2 Dimmer 000-009 Blackout
010-255 0 to 100% dimming
3 Focus 000-255 Zoom from small to large
4 Zoom 000-255 Linear adjust
5 Pan rotation 000-255 Pan rotation from 0 to 540º
6 Tilt rotation 000-255 Tilt rotation from 0 to 2 0º
Solo 5 5 Manual_en.doc
12/24
DMX CONTROL CHANNEL FUNCTIONS

Colour Wheel 000-016 White. Note: stay 5 seconds while DMX value is 5, 6
or , the function reset perform
01 -024 White/colour filter 1
025-032 Colour filter 1
033-040 Colour filter 1/colour filter 2
041-048 Colour filter 2
049-056 Colour filter 2/colour filter 3
05 -064 Colour filter 3
065-0 2 Colour filter 3/colour filter 4
0 3-080 Colour filter 4
081-088 Colour filter 4/colour filter 5
089-096 Colour filter 5
09 -104 Colour filter 5/colour filter 6
105-112 Colour filter 6
113-120 Colour filter 6/white
121-12 White
128-133 Rotation speed 1 (slowest)
134-139 Rotation speed 2
140-145 Rotation speed 3
146-151 Rotation speed 4
152-15 Rotation speed 5
158-163 Rotation speed 6
164-169 Rotation speed
1 0-1 5 Rotation speed 8
1 6-181 Rotation speed 9
182-18 Rotation speed 10 (fastest)
188-195 Stop rotating
196-201 Reverse rotation speed 1 (slowest)
202-20 Reverse rotation speed 2
208-213 Reverse rotation speed 3
214-219 Reverse rotation speed 4
220-225 Reverse rotation speed 5
226-231 Reverse rotation speed 6
232-23 Reverse rotation speed
238-243 Reverse rotation speed 8
244-249 Reverse rotation speed 9
250-255 Reverse rotation speed 10 (fastest)
8 Rotating
Gobo Wheel
000-043 Clear
044-085 Gobo 1
086-128 Gobo 2
129-1 0 Gobo 3
1 1-212 Gobo 4
213-255 Gobo 5
Solo 5 5 Manual_en.doc
13/24

9 Gobo
Rotation
000-120 (Rotating gobo) 0~540º index
121-12 (Rotating gobo) Rotation speed 1(slowest)
128-135 (Rotating gobo) Rotation speed 2
136-143 (Rotating gobo) Rotation speed 3
144-151 (Rotating gobo) Rotation speed 4
152-159 (Rotating gobo) Rotation speed 5
160-16 (Rotating gobo) Rotation speed 6
168-1 5 (Rotating gobo) Rotation speed
1 6-183 (Rotating gobo) Rotation speed 8 (fastest)
184-191 (Rotating gobo) stop rotating
192-199 (Rotating gobo) reverse rotation speed 1(slowest)
200-20 (Rotating gobo) reverse rotation speed 2
208-215 (Rotating gobo) reverse rotation speed 3
216-223 (Rotating gobo) reverse rotation speed 4
224-231 (Rotating gobo) reverse rotation speed 5
232-239 (Rotating gobo) reverse rotation speed 6
240-24 (Rotating gobo) reverse rotation speed
248-255 (Rotating gobo) reverse rotation speed 8 (fastest)
10 Pan & Tilt
Speed
000-255 Adjust Pan&Tilt speed
11 Pan Fine
(16Bit)
000-255 Adjust Pan in 16Bit resolution
12 Tilt Fine
(16Bit)
000-255 Adjust Tilt in 16Bit resolution
13 Gobo
Rotation Fine
000-255 Adjust gobo rotation in 16Bit resolution
14 Control 000-048 Reserve
049-080 Reset
081-112 Reserve
113-144 Turn lamp off（stay 10 seconds）
145-223 Reserve
224-255 Turn lamp on（see remark below）
Remark:
If you intend to turn on/off the lamp via the 14th channel of the controller, don’t attempt to push the
handle of 14th channel to value 224-255 immediately after turning it off, or push the handle to value
224-255 to wait it cooling. Under these 2 circumstances, the lamp can not be turned on. The right
operation is: turn it off---cool down---push the handle to turn it on.
If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes
damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this
would normally indicate that it is reaching the end of its life and it should be changed at once, aged
lamps run to the extremity of their life might explode. If the projector does not function, check the
fuses on the power socket of the projector, they should only be replaced by fuses of the same
specification (200/220/230/240V: 6.35x32 T10A/250V; 100/120V: 6.35x32 T15A/250V). On
the PCBs inside the projector there are also 3 fuses. They are 1 fuse F2A／250V 5mmx20mm on Pan
and Tilt PCB and 1 fuse F2A／250V 5mmx20mm on SLAVE PCB. Should these be damaged call a
qualified technician before replacement. The projector has thermal protection device that will switch
off the projector in case of overheating, should either of these operation, check that the fans are not
blocked, and if they are dirty clean them before switching on the projector again. Check that the fans
are operational, if not call a qualified technician.
Solo 5 5 Manual_en.doc
14/24
MAINTENANCE

Any main enance work should only be carried ou by qualified echnicians.
To ensure the continuous rotation of the rotating gobos and linear motion of the lens for focusing, it is
recommended that the bearings for the rotating gobos and the 3 shafts for the focusing lens holder be
lubricated periodically, preferably every two months. Use only high quality, high-temperature resistant
grease instead of any type of oil. When lubricating the bearings, a syringe with a fine needle is the
easiest way to introduce the grease to the bearings around each gobo.
To ensure the reliability of the projector it should be kept clean. It is recommended that the fans
should be cleaned every 15 days. The lens and dichroic colour filters should also be regularly cleaned
to maintain an optimum light output. Do NOT use any ype of solven on dichroic colour fil ers.
Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or
particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics. A soft cloth
and typical glass cleaning products should be used in cleaning. It is recommended to clean the
external optics at least once every 20 days and clean the internal optics at least once every 30 / 60
days.
Do no use any organic solven , e.g. alcohol, o clean he reflec or mirror, dichroic colour
fil ers or housing of he appara us.
PROBLEM POSSIBLE CAUSE ACTION
The projector doesn’t switch
on
-The power supply is not
present
-The lamp doesn’t work
Check the fuse on the power
socket.
Replace the lamp.
The lamp comes on but the
projector doesn’t respond to
the controller
-Wrong DMX configuration
and/or start address
- Defective DMX cable
Make sure that the projector is
correctly configured.
Replace or repair the DMX cable.
The projector only functions
intermittently
-The fan has failed Make sure the fan is working and
not dirty.
Defective projection -The lens is broken
-Dust or grease on lenses
Check the lenses are not broken.
Remove dust or grease from the
lenses.
The projected image
appears to have a halo
-Installation of the lamp is not
correct
-Dust or grease
contamination on the optics.
Make sure the lamp is installed
correctly.
Carefully clean the optical group
lenses and the projector
components.
The beam appears dim -Dust or grease contamination
on the optics.
-The lamp is at the end of its
life
Check the optics is clean.
Replace with a new lamp of the
specified type and rating.
Solo 5 5 Manual_en.doc
15/24
TROUBLESHOOTING
KEEPING THE PROJECTOR CLEAN
LUBRICATION

LIGHT OUTPUT
2 ° DIAMETER (m)
10930
6020
1.2
5
2.40
4m
14° DIAMETER (m)
DISTANCE (m)
0
0
0
5m
14° （ lux）
2m
2m
0m
4m 3m
1m
3m
1m
5m
2 ° （ lux）
3.82
15
.20
2.54
4.80
10
5.09
9.60
20
6802 30 1210
6601500 3 0
25
12
.63
240
430
Solo 5 5 Manual_en.doc
16/24

VOLTAGES: 100/120/200/220/230/240V AC, 50Hz or 60Hz to order
POWER CONSUMPTION:
650W
LAMP: Type: Philips MSR 5 5/2 discharge lamp
Colour Temperature: 200ºK
Socket: GX9.5, single end
Manufacturers Rated Lamp Life: 1000 Hours
COLOURS:
1 colour wheels
6 dichroic colours plus white
Adjustable speed with rainbow effect
GOBOS:
Ro a ed gobo wheel
5 interchangeable gobos+white, indexical, bidirectionally rotatable in
adjustable speed respectively
Gobo diameter: 36.3mm
Gobo image diameter: 31.5mm
FOCUS:
DMX controlled focus
SHUTTER:
Double shutter blades, 0-100% linearly adjustable
STROBE:
0.3~6 F.P.S.
HEAD MOVEMENT:
Pan 540º, Tilt 2 0º
BEAM ANGLE:
14º-2 º linearly movement
CONTROL:
DMX512, 14 Channels
HOUSING:
Composite plastic (IP20)
NET WEIGHT:
Solo 5 5 Manual_en.doc
1 /24
TECHNICAL DATA

200/220/230/240V ：38.6Kg
100/120V ：
41.6Kg
SIZES:
Solo 5 5 Manual_en.doc
18/24

Solo 5 5 Manual_en.doc
19/24
ELECTRICAL DIAGRAM

FAN1
FAN2
FAN3
FAN4
FULL
FULL
3/4 POWER
1/2 POWER
GND
POWER
BOX FAN
GND
POWER
FEEDBACK
24VAC
GND GND VCC VCC DMX-SENS1 DMX-SENS2
H2
H3
H4
H5
H6
H
H8
H9
H10
TO BALLAST
FREQUENCY SELECT
LAMP
CAP
50
60
SEL
COM
50
60
POWER PCB
DISPLAY PCB
PLACE BACK
SW1 SW2 SW3 SW4
GND GND VCC VCC DMX-SENS1 DMX-SENS2
DISPLAY DRIVE PCB
DMX DMX
1
2
3
FEEDBACK
+
-
50Hz
60Hz
D L
N
Thermostat
Ignitor
LAMP
Ballast
CAP
0uF 3 0V
MSR 5 5/2
24VAC
Ph
3
1
2
DMX-IN
DMX-OUT
1
2
3
1
2
3
4
5
1
2
3
4
5
DMX-IN
DMX-OUT
+
+
-
-
AC Plug
Transformer
NL
24VAC
0V
Fuse
T A 250V
Filter
E
220V
230V
H1
230VAC L
N
HEAD FAN
HEAD FAN
+
+
-
-
HEAD FAN
HEAD FAN
+
+
-
-
HALL 1-3
View of mark side
HALL 1-1
GV
GV
SGV SGVSGV
SGVSGV
View of mark side
HALL 1-2
View of mark side
HALL 1-6
View side of no axletree
COLOR
M1-6
D B C A
D B C A
View side of no axletree
Z00M
M1-5
D B C A
D B C A
View side of no axletree
SHUTTER
M1-4
D B C A
D B C A
View side of no axletree
GOBO ROTATION
M1-3
D B C A
D B C A
View side of no axletree
ROT-GOBO WHEEL
M1-2
D B C A
D B C A
View side of no axletree
FOCUS
M1-1
D B C A
D B C A
View side of no axletree
No encoder motor
TILT2
D B C A
D B C A
View side of no axletree
Encoder motor
TILT1
D B C A
D B C A
View side of no axletree
No encoder motor
PAN2
D B C A
D B C A
View side of no axletree
Encoder motor
PAN1
D B C A
D B C A
SGV
Encoder Side
PAN ENCODE
-
+
TILT ENCODE
-
+
View of mark side
HALL 1-5
DMX-SENS2
DMX-SENS1
VCC
VCC
GND
GND
DMX-SENS2
DMX-SENS1
VCC
VCC
GND
GND
PAN & TILT PCB
TILT2TILT1PAN2PAN1
PAN-Encoder
TILT-Encoder
SLAVE #1 PCB
MOTOR6MOTOR5MOTOR4MOTOR3MOTOR2MOTOR1
SENS6
SENS5
SENS4
SENS3
SENS2
SENS1
Solo 5 5 Manual_en.doc
20/24
COMPONENT ORDER CODES
