Precision Pro RL1836 User manual

RL1836
Precision Pro Steel Lawn Roller
RL2436
SAFETY GUIDELINES FOR USE OF PRODUCT
*The most important information is knowing how to stop your riding mower or lawn tractor, read your equipment’s owner’s manual
for horse power and towing weights
*With increased towing weight, your stopping distance increases also
*Do not tow the roller up or down steep ditches or hills. Be extremely cautious around steep grades
*Watch for holes, uneven terrain and other possible obstacles
*Inspect roller and all hardware periodically. Be sure all parts are secure before and during operation
*Never carry any passengers with you
*Do not operate lawn roller on slopes greater than 10 - 12 degrees
USING YOUR LAWN ROLLER
*Remove the expansion plug by loosening the wing nut.
*Fill your roller with water or sand to recommended weight for your towing equipment (mower or lawn tractor). DO NOT GO
OVER YOUR TOWING EQUIPMENT’S WEIGHT LIMIT. Failure to do so can result in damage to the towing equipment and/or
personal injury.
*Replace the expansion plug and tighten the wing nut. Make sure the plug is tight enough to stop any leakage.
*Your lawn should be moist for best rolling conditions. Excessive water or muddy conditions are not recommended.
*Keep your mower or lawn tractor at a safe and steady speed. 3 - 4 MPH is a good speed for proper operation.
*Damage to your mower, lawn tractor and/or personal injury can occur if you start or stop the roller (filled) abruptly.
*When finished using the roller, drain and let the interior fully dry. Never leave water in the lawn roller during cold weather. Freezing
can occur, damaging the welded seams causing leaks and/or structural failure.
MAINTENANCE
*Always check all the hardware before use. Make sure all hardware and components are tight and secure.
*Always keep moving joints lubricated. Lubricate the Clevis Assembly and Axle/Bearings when needed.
*Keeping the roller clean and dry will prolong the unit’s life.
*Sand off any rust that might occur, and paint exposed metal with a quality enamel paint.
LIMITED WARRANTY
This unit is warranted against defects in materials and workmanship to the original purchaser, under normal use and
service, for a period of ninety (90) days from date of sale. During the Warranty Period, we will repair or replace
at our option free of charge to the original purchaser, any part of the Unit that our examination shows to be defective
in workmanship or materials. This Warranty Does Not apply to damage caused by transit, misuse, abuse, neglect, accident,
normal wear, or alterations by unauthorized persons.
1981
01/04
RL2448
WEIGHT CAPACITIES PER MODEL
It is extremely important to know how much your mower or lawn equipment is designed to tow. Below are approximate weight
capacities for individual models.
Model Weight filled with water Weight filled with sand
RL1836
RL2436
RL2448
331 lbs.
588 lbs.
784 lbs.
530 lbs
942 lbs.
1,257 lbs.

PARTS LIST FOR LAWN ROLLERS:
PLEASE DO NOT RETURN THIS MERCHANDISE TO THE STORE. CALL US AND WE
WILL TAKE CARE OF ANY PROBLEM YOU MIGHT HAVE WITH THIS PRODUCT.
Phone (800) 225 - 5891 EXT. #204
HOW TO ORDER
REPLACEMENT PARTS:
When ordering parts always
give model number, part
number and part description.
Send To: Parts Division
316 Limit Street
Lincoln, IL 62656
TIP: Many of these
hardware parts can be
purchased at your local
hardware store.
Qty
1
2
4
2
2
4
4
1
1
1
2
1
1
1
1
1
Ref
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Parts
No
1961A
2576
2351
1955
1964
1974
3039
1966
1968
1988
1264
4279
1989
1042
1972
1956
Description
Roller Body
3/16” x 2” Cotter Pin
1” Flat Washer
Roller Bearing
Hitch Side Bar
3/8” x 1” Hex Head Bolt
3/8” Reverse Lock Nut
Long Brace
Short Brace
3/4” x 4” Hex Head Bolt
3/4” Flat Washer
Clevis Pin 5/8” x 3-1/2”
3/4”Lock Nut
#14 Hitch Pin Clip
Clevis Assembly
Expansion Plug
1
2
3
4
5
3
6
7
8
7
6
33
5
4
2
9
10 11
11
12
13
14
16
15
Qty
1
2
4
2
2
4
4
1
1
1
2
1
1
1
1
1
Ref
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Parts
No
1960A
2576
2351
1955
1965
1974
3039
1967
1969
1988
1264
4279
1989
1042
1972
1956
Description
Roller Body
3/16” x 2” Cotter Pin
1” Flat Washer
Roller Bearing
Hitch Side Bar
3/8” x 1” Hex Head Bolt
3/8” Reverse Lock Nut
Long Brace
Short Brace
3/4” x 4” Hex Head Bolt
3/4” Flat Washer
Clevis Pin 5/8” x 3-1/2”
3/4”Lock Nut
#14 Hitch Pin Clip
Clevis Assembly
Expansion Plug
RL1836 Parts List RL2448 Parts List
Phone [phone]
[phone] Ext. 204
FAX [phone]
Qty
1
2
4
2
2
4
4
1
1
1
2
1
1
1
1
1
Ref
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Parts
No
2003A
2576
2351
1955
1964
1974
3039
1966
1968
1988
1264
4279
1989
1042
1972
1956
Description
Roller Body
3/16” x 2” Cotter Pin
1” Flat Washer
Roller Bearing
Hitch Side Bar
3/8” x 1” Hex Head Bolt
3/8” Reverse Lock Nut
Long Brace
Short Brace
3/4” x 4” Hex Head Bolt
3/4” Flat Washer
Clevis Pin 5/8” x 3-1/2”
3/4”Lock Nut
#14 Hitch Pin Clip
Clevis Assembly
Expansion Plug
RL2436 Parts List
RL1836
RL2436
RL2448
