Prem-I-Air EH1684 User manual

1
EH1684
1600W Pressure Washer

2
IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with the user of the product
for future reference.
BEFORE USE
You must inspect the appliance including its cable for any signs of damage. If the
product is damaged, DO NOT use it, and contact your supplier immediately.
PRODUCT SAFETY
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Do not use in close proximity to gas appliances
Do not use unless correctly installed.
Do not cover when in use.
Do not use the appliance in locations where paint, petrol or other flammable
liquids are used or stored.
Not suitable for use in boats, caravans or other similar areas.
The appliance is fitted with an overload cut-out which will operate if the motor
overheats or is stalled. If this happens, disconnect from the mains supply
immediately, and allow the motor to cool down.
SAFETY INSTRUCTIONS
The appliance you have purchased is a technologically advanced product. To
obtain the best performance from your unit, read this instruction manual carefully
and follow the instructions each time you use it.
SAFETY RULES
SAFETY “MUST NOTS”
DO NOT use the appliance with inflammable or toxic liquids,
or any products which are not compatible with the correct
operation of the appliance. EXPLOSION OR POISONING HAZARD
DO NOT direct the water jet towards people or animals.
INJURY HAZARD
DO NOT direct the water jet towards the unit itself, electrical
parts or towards other electrical equipment. ELECTRIC SHOCK
HAZARD

3
DO NOT use the appliance outdoors in case of rain. SHORT CIRCUIT
HAZARD
DO NOT allow children or incompetent persons to use the appliance.
INJURY HAZARD
DO NOT touch the plug and/or socket with wet hands. ELECTRIC
SHOCK HAZARD
DO NOT use the appliance if the electrical cable is
damaged. ELECTRIC SHOCK AND SHORT CIRCUIT HAZARD
DO NOT use the appliance if the high pressure hose is damaged.
EXPLOSION HAZARD
DO NOT jam the trigger in the operating position. ACCIDENT
HAZARD
Check that the data plates are affixed to the appliance, if not, inform
your dealer. Units without plates must NOT be used as they are
unidentifiable and potentially dangerous. ACCIDENT HAZARD
DO NOT leave the appliance unattended. ACCIDENT HAZARD
DO NOT move the appliance by pulling on the ELECTRICAL CABLE.
SHORT CIRCUIT HAZARD
Make sure that cars do not drive over the high pressure hose.
SAFETY “MUSTS”
All electrical conductors MUST BE PROTECTED against the water jet.
SHORT CIRCUIT HAZARD
The appliance MUST ONLY BE CONNECTED to an adequate power
supply in compliance with all applicable regulations. ELECTRIC SHOCK
HAZARD
Use of a safety residual current circuit-breaker (R.C.C.B.) will provide
additional protection for the operator (30 mA).
The high pressure may cause materials to
bounce of surfaces at speed; therefore protective clothing
and safety goggles MUST BE WORN. INJURY HAZARD
Before doing work on the appliance, REMOVE the plug. ACCIDENTAL
START-UP HAZARD
Before pressing the trigger, GRIP the gun firmly to counteract the
recoil. INJURY HAZARD
COMPLY WITH the requirements of the local water supply company.
According to DIN 1988, the appliance may only be connected to the mains
drinking water supply if a backflow preventer valve with drain facility is
installed in the supply hose. CONTAMINATION HAZARD
Maintenance and/or repair of electrical components MUST be carried
out by qualified and authorized Prem-i-Air engineers for the warranty to take
effect. If the supply cord is damaged, it must be replaced by a qualified person in
order to avoid a hazard.
DISCHARGE residual pressure before disconnecting the unit hose.
INJURY HAZARD

4
Before using the appliance, CHECK every time that the screws are
fully tightened and that there are no broken or worn parts. ACCIDENT
HAZARD
ONLY USE detergents which will not corrode the coating
materials of the high pressure hose/electrical cable.
EXPLOSION AND ELECTRIC SHOCK HAZARD
ENSURE that all people or animals keep a minimum
distance of 15m away. INJURY HAZARD
READ THE INSTRUCTION MANUAL AND RETAIN WITH PRODUCT FOR
FUTURE REFERANCE.
ASSEMBLY
1. Attach power lead onto the
side of the unit
2. Slot the lance / Spray bottle holder on
to the rear of the unit and align the
handle with the slots & holes on the top
of the base section. Fix the handle using
the two screws provided.
3. Slot the feet onto the base of the unit
ensuring they click into place.

5
OPERATION
To operate connect the water inlet to the mains water supply using a suitable hose
and connectors. If connecting to a mains drinking water supply a suitable back-flow
preventer must be fitted. Turn on the water. The water must be connected and
turned on before connecting the mains supply. Connect the power to the mains
supply using a RCCB 30ma circuit breaker. If using an extension lead the lead it
must be rated at 13 A, be fully unwound and suitable for outdoor use. Turn on the
pressure washer.
Connect either the lance attachment or the detergent bottle to the lance. The water
supply must be turned on before using the unit. The pressure washer is designed
to use only cold water. Never connect to hot water supply, this will reduce the life
of the Pressure washer and pump.
Assembled Parts List
1. Pressure Unit
2. Water supply hose.
3. Water Connection
4. Water inlet. (Back)
5. High pressure hose.
6. High pressure outlet.
7. Spray lance.
8 Power socket.
(Parts 2 & 3 are not supplied)
4. Connect the pressure hose to the lance with the screw connector and tighten
with a 17mm spanner. Connect the opposite end to the pressure outlet and
tighten the screw thread in a clockwise direction.
5. Connect the 2 sections of the lance together by aligning the slots on the lance
with those on the nozzle section or attach the detergent bottle as required.

6
Using the lance;
The lance nozzle can be adjusted to give a concentrated or wide fan spray pattern.
Care should be taken using the narrow spray pattern that the force of the spray
does not damage the surface being cleaned. Larger areas can be cleaned faster
using a wider fan pattern and the risk of damage to surfaces will be greatly reduced.
Optimal cleaning angle;
When using the lance the maximum effect is achieved by
spraying the water ‘head on’ to the surface but this can
cause dirt particles to become imbedded in the surface
and reducing the cleaning effect. Optimum cleaning is
achieved with an angle of approximately 45 degrees to
the surface being cleaned. This gives the best
combination of spray force and debris removal.
At all times care should be taken to avoid using concentrated spray patterns, steep
spray angles and spraying too close to the surface to reduce the chances of
damaging the cleaning surface.
Using the detergent bottle;
NOTE: Use only detergents formulated to be used with a pressure washer and test
on a small inconspicuous area prior to full cleaning.
Always follow the manufacturer’s guidelines on the detergent to water ratio. The
detergent bottle will mix at ratio of approximately 5.4% (1 to 19) and the detergent
should be mixed in the bottle taking this ration into account.
To use the detergent bottle attach to the lance and unscrew the bottle. Fill the bottle
with the correct concentration of detergent and replace bottle on applicator.
Apply the detergent according to the manufacturer’s instructions.
Nozzle

7
SHUTTING DOWN & STORAGE
Before turning off and storing the unit follow the procedure below;
1. Flush all detergent from the system
2. Turn off the pressure washer and unplug at the mains supply. Do not turn the
water off before this step. If the pressure washer is accidentally turned on with
the water off serious damage can be caused to the washer and pump.
3. Press the wand 2 or 3 times to release any pressure.
4. Turn off and disconnect from the water supply
5. Clean the unit as per the maintenance instructions.
6. Store in a dry place.
PAT TESTING
When used in a workplace, we recommend that this product should be safety-
tested yearly by a qualified electrician (PAT Tested)
We recommend that it is PAT tested regularly when used in a domestic
environment.
GENERAL SAFETY REQUIREMENTS
Domestic wiring must be tested periodically by a qualified electrician at least once
every 10 years or at every change of occupancy.
For office and retail premises, and buildings such as village halls, the wiring must
be inspected at least once every 5 years.
It is recommended that all buildings be fitted with smoke alarms (it is mandatory for
new buildings).
OPERATING COSTS
At time of going to press, the average cost of electricity is £0.13 per unit (kilowatt-
hour). The amount you are being charged will be shown on your electricity bill. At
this cost, the EH1684 will cost £0.20 per hour to run.
DISPOSAL AND RECYCLING
You must not dispose of this appliance with domestic household waste.
Most local authorities have specific collection system for appliances and disposal
is free of charge to the end-user.
When replacing an existing appliance with a similar new appliance your retailer may
take the old appliance for disposal.

8
MAINTENANCE
Before cleaning, turn the pressure washer off, and disconnect from the mains
supply. The unit may then be cleaned using a damp cloth with a drop of washing-
up liquid to remove any dust or dirt from the case. Do no use stronger detergents
or solvents as these may damage the case finish.
From time to time dirt or other objects may become trapped in the nozzle. To clean
you should turn off the unit and release any
pressure in the lance. Rotate the nozzle to
the narrow stream setting and using the
supplied Tip Cleaner you can slide back and
forth until the debris has been dislodged.
FAULT-FINDING
Symptom Possible cause(s) Corrective Action(s)
Tip Cleaner
Nozzle
Pressure
washer
does not
start up
1. Unit is Pressurized
2. Plug is not connected
3. Thermal safety switch
has tripped
1. Squeeze trigger on gun
2. Check plug socket and fuse
3. Switch off and allow to cool down
Pump does
not reach
necessary
pressure
1. Water inlet clogged
2. Pump is sucking air
from hose
connections
3. Nozzle is worn or not
fitted correctly
1. Clean water inlet
2. Check all hose connections and
check seals are fitted correctly
and tightened fully.
3. Check nozzle, if worn contact
dealer.
Motor
suddenly
Stops
1. Thermal safety switch
has tripped due to
overheating
1. Check water is on and allow unit
to cool, if it does not restart
contact your dealer
Fluctuating
Pressure
1. Clogged nozzle
2. Pump is sucking air
from hose
connections
1. Clean nozzle
2. Check all hose connections and
seals are fitted correctly and
tightened fully.

9
TECHNICAL SPECIFICATION
Dimensions: ................................................................415×265×300 mm
Weight:........................................................................6.3 kg
Power supply: .............................................................230 V ~
Power consumption: ...................................................1.6 kW
Operating current: .......................................................7 A
SERVICE WARRANTY
Prem-i-Air guarantees the product free from defects in materials and workmanship
for a period of two years.
Should this unit be operated under conditions other than those recommended, at
voltages other than the voltage indicated on the unit, or any attempts made to
service or modify the unit, then the warranty will be rendered void.
The product you buy may sometimes differ slightly from illustrations. This warranty
is in addition to, and does not affect, your statutory rights.
If you have any problems with this product, please call our Help Desk on (0845)
459 4816.
Prem-i-Air Appliances Ltd.,
Lancots Lane,
Sutton,
St. Helens,
Merseyside.
WA9 3EX
website: www.prem-i-air.com
