Landa MVC3-30321 User manual

PRESSURE WASHERS
®
OPERATOR’S MANUAL
LANDA, INC. ■ 4275 N.W. Pacific Rim Blvd. ■ Camas, WA 98607 ■ USA
For technical assistance or the Landa Dealer nearest you, call 800-LANDA-4-U (800-526-3248) or [phone]
or consult our web page at www.landa.com
■MVC3-30321 ■MVC4-30321 ■MVC4-30321E
■MVC4-30321E/S ■MVC4-35321E
MVC
L
I
S
T
E
D
®

Model Number ______________________________
Serial Number ______________________________
Date of Purchase ____________________________
The model and serial numbers will be found on a decal attached to
the pressure washer. You should record both serial number and
date of purchase and keep in a safe place for future reference.
CONTENTS
3
MVC Manual •Form #96-61836 •Revised 5/03
Introduction ................................................................................................................................... 4
Important Safety Instructions ........................................................................................................ 4
Component Identification .............................................................................................................. 5
Pre-Operation Checklist ................................................................................................................ 6
Set-Up Procedures ....................................................................................................................... 7
Operating Instructions ................................................................................................................... 7
General Washing Techniques ........................................................................................................ 7
Shut-Down Procedures ................................................................................................................. 7
How to Use the Detergent Injector ................................................................................................ 8
Preventative Maintenance ............................................................................................................. 9
Maintenance and Service ........................................................................................................ 9-11
Exploded View (All Models) ....................................................................................................12-13
Exploded View Parts List (All Models) .................................................................................... 14-15
MVC Control Box Exploded View ................................................................................................ 16
MVC Control Box Exploded View Parts List ................................................................................ 17
Hose & Spray Gun Assembly (All Models) .................................................................................. 18
Hose Reel Option Breakdown.................................................................................................19
Downstream Injector Assembly #4-011184 (All Models) .............................................................. 19
Preventative Maintenance Schedule ........................................................................................... 20
Oil Change Record ...................................................................................................................... 20
Troubleshooting ...................................................................................................................... 21-23
Warranty ...................................................................................................................................... 24
Spanish Translations .............................................................................................................. 25-32

4 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 • REV. 5/03
INTRODUCTION
Thank you for purchasing a Landa Pressure Washer.
This manual covers the operation and maintenance of
the MVC3-30321, MVC4-30321, MVC4-30321E/S, and
MVC4-35321E washers. All information in this manual is
based on the latest product information available at the
time of printing.
Landa, Inc. reserves the right to make changes at any
time without incurring any obligation.
The MVC Series was designed for maximum
use of 4 hours per day, 5 days per week.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this Landa pressure washer.Warning infor-
mation should be emphasized and understood. If the op-
erator is not fluent in English, the manufacturer’s instruc-
tions and warnings shall be read to and discussed with
the operator in the operator’s native language by the pur-
chaser/owner, making sure that the operator compre-
hends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number.
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: When using this machine basic precau-
tions should always be followed, including the fol-
lowing:
CAUTION:To reduce the risk of in-
jury, read operating instructions
carefully before using.
1.Read the owner's manual thor-
oughly. Failure to follow instruc-
tions could cause malfunction
and result in death, serious
bodily injury and/or property
damage.
2. Know how to stop the machine and bleed pressures
quickly. Be thoroughly familiar with the controls.
3. Stay alert - watch what you are doing.
4. All installations must comply with local codes. Con-
tact your electrician, plumber, utility company or the
selling distributor for specific details.
WARNING: Flammable liquids
can create fumes which can ignite
causing property damage or se-
vere injury.
5. Risk of explosion - do not spray
flammable liquids or operate in
an explosive location. Operate
only where open flame or torch
is permitted.
WARNING: Do not place machine
near flammable objects when the
engine is hot.
WARNING: Keep water spray
away from electrical wiring or fa-
tal electric shock may result. Read
warning tag on electrical cord.
WARNING: Spray gun kicks back.
Hold with both hands.
6. Grip cleaning wand securely with both hands before
starting the cleaner. Failure to do this could result in
injury from a whipping wand.
WARNING:Risk of fire. Do not add
fuel when the machine is operat-
ing.
7. Allow engine to cool for 2 min-
utes before refueling. If any fuel
is spilled, make sure area is dry
before testing spark plug or
starting the engine. (Fire and/
or explosion may occur if this
is not done.)
Gasoline engines on mobile or portable equipment
shall be refueled:
a. Outdoors;
b. With the engine on the equipment stopped;
c. With no source of ignition within 10 feet of the
dispensing point;
d. With an allowance made for expansion of the fuel
should the equipment be exposed to a higher am-
bient temperature.
In an overfilling situation, additional precautions are
necessary to ensure that the situation is handled in
a safe manner.
WARNING
KEEP WATER SPRAY
AWAY FROM
ELECTRICAL WIRING.
WARNING
RISK OF EXPLOSION:
USE CAUTION WHEN
REFUELLING.
READ OPERATOR’S
MANUAL THOROUGHLY
PRIOR TO USE.
CAUTION
WARNING
RISK OF EXPLOSION:
DO NOT SPRAY
FLAMMABLE LIQUIDS.

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
5
LANDA MVC •#96-61836 • REV. 5/03
COMPONENT IDENTIFICATION
Water Supply Hose
(not included)
Variable Pressure
Control Wand
Trigger
Control Wand
Handle
Nozzle
Quick
Coupler
Wand
Coupler
Brass Soap
Nozzle
Spray Gun
High Pressure
Hose
High Limit
Thermostat
Gasoline
Tank
Detergent
Injector
Detergent
Nipple
Quick
Coupler
Fuel Oil Tank

6 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
WARNING: Risk of injection or se-
vere injury to persons - Keep clear
of nozzle - Do not touch or direct
discharge stream at persons.This
machine is to be used only by
trained operators.
CAUTION: Hot discharge fluid. Do
not touch or direct discharge
stream at persons.
8. High pressure developed by these machines can
cause personal injury or equipment damage. Use
caution when operating. Do not direct discharge
stream at people, or severe injury and/ or death may
result.
WARNING: High pressure can
cause paint chips or other par-
ticles to become airborne and fly
at high speeds.
9. Eye safety devices and foot pro-
tection must be worn when us-
ing this equipment.
10. Never make adjustments on
machine while in operation.
WARNING: Use only in well ven-
tilated areas. Failure to observe
this warning could cause a loss
of consciousness or death.
11. Avoid installing in small areas
or near exhaust fans. Exhaust
contains poisonous carbon
monoxide gas; exposure may
cause loss of consciousness
and may lead to death. It also
contains chemicals known, in certain quantities, to
cause cancer, birth defects or other reproductive
harm.
12. Do not operate with the spray gun in the off position
for extensive periods of time as this may cause dam-
age to the pump.
13. The best insurance against an accident is precau-
tion and knowledge of the machine.
14. Landa will not be liable for any changes made to our
standard machines, or any components not pur-
chased from Landa.
15. Read engine safety instructions provided.
16. Never run pump dry or leave spray gun closed longer
than 5 minutes.
17. Inlet water must be from a cold, clean fresh city wa-
ter supply.
WARNING: Only use recom-
mended fuel. Using other fuels
may result in a serious explosion
causing personal injury, property
damage or loss of life.
18. Use No. 1 or No. 2 heating oil
(ASTM D306) only. NEVER use
gasoline in your fuel oil tank.
Gasoline is more combustible
than fuel oil and could result in a serious explosion.
NEVER use crankcase or waste oil in your burner
assembly. Fuel unit malfunction could result from con-
tamination.
19. Do not confuse gasoline and fuel oil tanks. Keep
proper fuel in proper tank.
20. Protect machine from freezing.
21. Be certain all quick coupler fittings are secured be-
fore using pressure washer.
22. Do not allow acids, caustic or abrasive fluids to pass
through the pump.
23. To reduce the risk of injury, close supervision is nec-
essary when a product is used near children. Do not
allow children to operate the pressure washer. This
machine must be attended during operation.
24. Do not operate this product when fatigued or under
the influence of alcohol or drugs. Keep operating area
clear of all persons.
25. Protect high pressure hose from vehicle traffic and
sharp objects.
26. Before disconnecting high pressure hose from wa-
ter outlet, turn burner off and pull the trigger on the
spray gun allowing water to cool to below 100°F
before stopping machine. Then open the spray gun
to relieve pressure. Failure to properly cool down or
maintain the heating coil may result in a steam ex-
plosion.
27. Do not overreach or stand on unstable support. Keep
good footing and balance at all times.
28. This machine must be attended during operation.
29.
CAUTION: Risk of injury. Disconnect battery
ground terminal before servicing.
PRE-OPERATION CHECK
❑Pump oil (SAE 30W non-detergent oil)
❑ Cold water supply (6 gpm •5/8" •20 psi)
❑Hose, wand, nozzle (nozzle size per serial plate)
❑Water filter (intact, nonrestrictive)
❑Engine fuel (unleaded 86 or higher)
❑Engine oil (SAE 10W40)
❑Burner fuel (No. 1 home heating fuel or diesel)
WARNING
HIGH PRESSURE
STREAM CAN
PIERCE SKIN AND
TISSUES.
WARNING
USE PROTECTIVE
EYEWEAR WHEN
OPERATING.
WARNING
RISK OF
ASPHYXIATION.
USE THIS PRODUCT
ONLY IN A WELL
VENTILATED AREA.
WARNING
RISK OF FIRE OR
EXPLOSION: USE
VAPOR FUEL ONLY.

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
7
LANDA MVC •#96-61836 •REV. 5/03
SET-UP PROCEDURES
This machine is intended for outdoor use only.
Machine must be stored indoors when not in use.
1. Attach a 5/8" water supply hose to inlet connector.
Minimum flow should be 5 gpm.
2. Attach high pressure hose to discharge nipple using
quick coupler.Lock coupler securely into place by pull-
ing back coupler collar and inserting it onto discharge
nipple and then pushing collar forward to lock in place.
3. Attach variable pressure control wand to spray gun
using teflon tape on threads to prevent leakage.
4. Attach swivel connector on high pressure hose to
spray gun using teflon tape on threads.
5. Check oil level on sight glass on side of pump. Oil
should be visible one-half way up sight glass (SAE
30W non-detergent). The oil level can also be
checked by using the dipstick on the top of the pump.
6. Fill gasoline tank and check engine oil.
7. Fill fuel tank. Do not confuse gasoline and fuel oil
(diesel) tanks. Keep proper fuel in proper tanks.
8. Install proper battery making sure that the red cable
is attached to the positive terminal. Use only a group
24 marine type deep cell battery with a 90 amp hour
rating (battery not included). This is for electric start
models only.
9. These machines are intended to be protected from
outside environments.
OPERATING INSTRUCTIONS
(See Component Identification on page 5.)
1. STOP! Read operator’s manual before operating this
machine.Failure to read operation and warning instruc-
tions may result in personal injury or property damage.
2. Turn on water at faucet and pull trigger on spray gun
allowing water to flow until all air has discharged from
system. Check for water leaks; tighten as needed.
3. Pull wand coupler collar back and insert desired pres-
sure nozzle into coupler then secure by pushing col-
lar forward.
NOTE: Variable pressure control wand handle must
be turned clockwise to enable water to flow out of
the high pressure nozzle.
4. Read engine manual, turn on gas valve and choke.
Turn the engine switch to the START position and
hold it there until the engine starts. NOTE: Do not
use the electric starter for more than five seconds at
a time. If the engine fails to start, release the switch
and wait ten seconds before operating the starter
again. When the engine starts, allow the engine
switch to return to the ON position. If the engine is to
be started without the battery, turn switch to start
position and pull rope to start. Turn off choke.
CAUTION: Small engines may kick back. Do not hold
pull rope tightly in hand.
5. With spray nozzle pointed away from you or anyone
else, press trigger on spray gun to obtain pressur-
ized cold water spray.
6. For hot water, turn the burner switch ON when a
steady stream of water flows out of the spray gun.
Burner will light automatically.
NOTE: Do not start machine with burner switch on.
7. To apply detergent, see “How to Use the Detergent
Injector”(page 8).
GENERAL WASHING
TECHNIQUES
1. Hold spray nozzle approximately one foot from the
surface being cleaned. Spray at an angle to get un-
der the material being removed.
2. When washing large objects, use detergent injector to
apply detergent. Start washing from the bottom and
work up. Better detergent economy and faster results
will be obtained by allowing the detergent to set 5 - 10
minutes. After washing, rinse from the top down.
3. Cleaning heavy dirt or material away with a hard
stream of clear water is recommended before using
a cleaning agent.
SHUT DOWN PROCEDURES
1. Rinse all lines (and injector) with clean water to re-
move any soap residue.
2. Turn burner switch off and continue spraying, allow-
ing the water to cool below 100°F.
3. Turn engine off.
4. Turn off water supply.
5. Open spray gun to relieve remaining pressure.
6. Remove water supply hose.
7. In freezing conditions, disconnect water supply and
open spray gun to allow water to drain.Then turn off
the engine. See winterizing procedure under Main-
tenance and Service.
CAUTION: Do not allow pump to run longer than 5
minutes without water. Disconnect all hoses to al-
low water to drain.
CAUTION: With the machine off, open spray gun to
release pressure before removing discharge hose.
CAUTION: Burner switch must be turned off when
the engine is off or damage to the battery and the
12vDC burner will result.

8 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
HOW TO USE THE
DETERGENT INJECTOR
WARNING:Some detergents may
be harmful if inhaled or ingested
causing severe nausea, fainting
or poisoning. The harmful ele-
ments may cause property dam-
age or severe injury.
The machine can siphon and mix de-
tergents with the use of Landa's de-
tergent injector kit.
1. Pull injector quick coupler collar back and secure on
discharge nipple. Injector valve body arrow should
point in direction of flow.
2. Connect high pressure hose to injector nipple se-
curing quick coupler.
3. Start machine as outlined in Operating Instructions.
4. Place detergent pick-up tube into container of deter-
gent solution.
5. Turn pressure control handle counterclockwise on
the variable pressure wand. This lowers the pres-
sure by directing the water flow through the soap
nozzle and allows the detergent injector to siphon
soap.
6. Open trigger spray gun. Water detergent ratio is ap-
proximately 15 to 1.
7. When you finish washing, rinse by simply turning
the variable pressure wand control handle clockwise
to increase pressure.
NOTE: The detergent injector will not siphon with
water flowing through the high pressure nozzle at
the end of the wand.
8. For clean up, place detergent pick-up tube into con-
tainer of clear water and follow steps 5 and 8 to pre-
vent detergent deposits from damaging the injector.
WARNING
SOME DETERGENTS
MAY BE HARMFUL IF
INHALED OR
INGESTED.
Detergent
Injector
High Limit
Thermostat
Detergent
Pickup Tube
Brass Soap
Nozzle
Nozzle
Quick
Coupler
Variable Pressure
Wand (VP)
Variable Pressure
Control Handle
Spray Gun
Injector
Discharge
Nipple
Trigger
High Pressure Hose
Discharge
Nipple
Quick Coupler
Rupture Disk
High Pressure
Nozzle

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
9
LANDA MVC •#96-61836 •REV. 5/03
PREVENTATIVE MAINTENANCE
1. Check to see that the water pump is properly lubri-
cated.
2. Follow winterizing instructions to prevent freeze dam-
age to the pump and coils.
3. Always neutralize and flush detergent from system
after use.
4. If water is known to be high in mineral content, use a
water softener in your water system or de-scale as
needed.
5. Do not allow acidic, caustic or abrasive fluids to be
pumped through system.
6. Always use high grade quality Landa cleaning prod-
ucts.
7. Never run pump dry for extended periods of time.
8. Use clean fuel-kerosene, No. 1 fuel oil or diesel. Re-
place fuel filter every 100 hours of operation. Avoid
water contaminated fuel as it will seize up the fuel
pump.
9. If machine is operated with smoking or eye burning
exhaust, coils will soot up, not letting water reach
maximum operating temperature. (See section on
Air Adjustments.)
10. Never allow water to be sprayed on or near engine
or burner assembly or any electrical component.
11. Periodically delime coils as per instructions.
12. Check to see that engine is properly lubricated.
It is advisable, periodically, to visually inspect the burner.
Check air inlet to make sure it is not clogged or blocked.
Wipe off any oil spills and keep this equipment clean
and dry.
The areas around the Landa washer should be kept clean
and free of combustible materials, gasoline and other
flammable vapors and liquids.
The flow of combustion and ventilating air to the burner
must not be blocked or obstructed in any manner.
MAINTENANCE AND SERVICE
Unloader Valves:
Unloader valves are preset and tested at the factory be-
fore shipping.Occasional adjustment of the unloader may
be necessary to maintain correct pressure. Call your
local dealer for assistance.
Winterizing Procedure:
Damage due to freezing is not covered by warranty. Ad-
here to the following cold weather procedures whenever
the washer must be stored or operated outdoors under
freezing conditions.
During winter months, when temperatures drop below
32°F, protecting your machine against freezing is nec-
essary. Store the machine in a heated room. If this is not
possible then mix a 50/50 solution of anti-freeze/water
into a 5 gallon bucket. Place a short section of garden
hose into the bucket and connect it to the machine. El-
evate the bucket and turn the pump on to siphon the
anti-freeze through the machine. If compressed air is
available, an air fitting can be screwed into the inlet con-
nector and, by injecting compressed air, all water will be
blown out of the system.
High Limit Hot Water Thermostat:
For safety, each machine is equipped with a high limit
control switch. In the event that the temperature of the
water should exceed its operating temperature, the high
limit control will turn the burner off until the water cools.
Pumps:
Use only SAE 30W non-detergent oil. Change oil after
the first 50 hours of use.Thereafter, change the oil every
three months or at 500 hour intervals. Oil level should be
checked by using the dipstick found on top of the pump
or the red dot visible through the oil gauge window. Oil
should be maintained at that level.
Cleaning of Coils:
In alkaline water areas, lime deposits can accumulate
rapidly inside the coil pipes. This growth is increased by
the extreme heat build up in the coil.The best prevention
for liming conditions is to use high quality cleaning de-
tergents. In areas where alkaline water is an extreme
problem, periodic use of Landa Deliming Powder (part
#9-028008) will remove lime and other deposits before
coil becomes plugged. (See Deliming Instructions for use
of Landa Deliming Powder.)
Deliming Coils:
Periodic flushing of coils is recommended.
1. Fill a container or optional float tank with 4 gallons of
water, then add 1 lb. of deliming powder. Mix thor-
oughly.
2. Remove wand assembly from spray gun and put
spray gun into container. Secure the trigger on the
spray gun into the open position.
3. Attach a short section (3-5 ft.) of garden hose to
machine to siphon solution from an elevated con-
tainer. Turn pump switch on, allowing solution to be
pumped through coils back into the container. Solu-
tion should be allowed to circulate 2-4 hours.
4. After circulating solution flush entire system with
fresh water. Reinstall wand assembly to spray gun.

10 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
Rupture Disk:
If pressure from pump or thermal expansion should ex-
ceed safe limits, the rupture disk will burst allowing high
pressure to be discharged through hose to ground.When
disk ruptures it will need to be replaced.
Fuel:
Use clean fuel oil that is not contaminated with water
and debris. Replace fuel filter and drain tank every 100
hours of operation.
Use No. 1 or No. 2 Heating Oil (ASTM D306) only.
NEVER use gasoline in your burner tank. Gasoline is
more combustible than fuel oil and a serious explosion
could result. NEVER use crankcase or waste oil in your
burner. Fuel unit malfunction could result from contami-
nation.
Fuel Control System:
These machines utilize a fuel solenoid valve located on
the fuel pump to control the flow of fuel to the combus-
tion chamber. This solenoid valve, which is normally
closed, is activated by a flow switch when water is flow-
ing through it. When an operator releases the trigger on
the spray gun, the flow of water through the flow switch
stops, turning off the current to the fuel solenoid. The
solenoid then closes, shutting off the supply of fuel to
the combustion chamber. Controlling the flow of fuel in
this way allows for an instantaneous burn or no burn
situation, thereby eliminating high and low water tem-
peratures, and combustion smoke normally associated
with machines incorporating a spray gun.
CAUTION: Periodic inspection is recommended to in-
sure that the fuel solenoid valve functions properly. This
can be done by operating the machine and checking to
see that when the trigger on the spray gun is in the off
position, the burner is not firing.
Electrode Setting:
(See illustration below.)
Burner Nozzle:
Keep the tip free of surface deposits by wiping it with a
clean, solvent-saturated cloth, being careful not to plug
or enlarge the nozzle. For maximum efficiency, replace
the nozzle each season.
Air Adjustment:
Machines are preset and performance tested at the fac-
tory - elevation 100 feet. A one-time initial correction for
your location will pay off in economy, performance and
extended service life. If a smoking or eye-burning ex-
haust is being emitted from the stack, two things should
be checked. First, check the fuel to be certain that kero-
sene or No. 1 home heating fuel is being used. Next,
check the air adjustment on the burner.
Initial Air Adjustments:
Allow sufficient air to obtain a clean burning flame by
loosening the lock screws and moving the air shutter
and if necessary the bulk air band.
Reduce the air supply until the flame tips appear slightly
smoky then increase the air just enough to cause the
flame tips to appear absolutely clean.
Periodically check wiring connections. If necessary to
adjust electrodes, use diagram.
Air Band
Adjustment
Bolt
Air Band
Pressure
Gauge Port
Pressure
Adjustment
Screw
Return
Line
Fuel
Pump
5/32"
Electrodes
Nozzle Adapter
1/4"
1/2"
5/32" 2-7/8"
5/32" Gap
Top View Side View
In Line Filter

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
11
LANDA MVC •#96-61836 •REV. 5/03
Fuel Pressure Adjustment:
To adjust fuel pressure, turn the adjusting screw clock-
wise to increase, counterclockwise to decrease. Do not
exceed 200 psi. NOTE: When changing the fuel pump, a
bypass plug must be installed in the return port or the
fuel pump will not prime.
Removal of Soot and Heating Coil:
In the heating process, fuel residue in the form of soot
deposits may develop on the heating coil and block air
flow which will affect burner combustion.When soot has
been detected on visual observation, the soot on the coil
must be washed off after following the coil removal steps.
1. Remove the tank head assembly by unscrewing the
three Tek screws and lifting the tank head off.
2. Remove the two pipe nipples and associated fittings.
3. Lift the coil out of the outer wrap.
CAUTION:The coil weighs about 80 lbs. Use proper
lifting techniques.
4. Clean, repair and replace the coil by reversing the
above steps.
Coil Reinstallation:
Reinstall by reversing the above steps 4 through 1.
Final Note:
The 12 VDC burner systems can draw as much as 18
amps! For such motors to run properly, the battery and
engine charging system must be kept in good condition,
and the engine must run fast enough to adequately
charge the battery. Do not throttle down the engine for
any length of time.

12 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
21
2
30
47
23
46
20
19
18
18
19
54
30
22
65
96
60
28
71 24
72
91
63
31
70
29
29
57
26
25
49
31
27
ALL MODELS
EXPLODED VIEW LEFT SIDE
90
64

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
13
LANDA MVC •#96-61836 •REV. 5/03
2
6
81
14
1
59
85
48
13
12
11
62
85
101
76
60
4
52
54
37
39
73
37
36
78
50
38
15
92
69 82
18
19
20
42
80
43
45
89 31
88
31
19
18
20
93
82
83
51
50
55
33
33
16
20
46
81
86
85
41
54
53
66
67
68
68
61
84
34
35
58
31 87
56
79
31
32
40
31
77
31
51
10
9
7
44
Rectifier
(Reversed
View)
ALL MODELS
EXPLODED VIEW RIGHT SIDE
95
98
99
94
100
3
For
Detail See
Control
Box Illus.
103
102
14
85
97
74
17

14 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
ALL MODELS
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 95-07290029 Tank Head Assembly,
16" Dia. x 8" Stack 1
2 10-02025A Label, Hot/Caliente w/Arrows
Warning 3
3 90-50045 Clip, Retaining, U-Type 3
4 95-07290053 Retainer, Burner Insulation 1
5 95-07121218 Coil, Dura, 14.5" Dia., Sch. 80 1
6 95-07290013 Wrap, Outer Coil 1
7 6-05134 Cable Ty, 48" 2
8 95-07101225 Block, Discharge,
Brass 3/8" x 1/2" 1
9 2-0031 Elbow, 3/8" Street 1
10 2-2007 Nipple, 3/8" x 3/8" NPT ST Male1
11 2-3408 Disk, Rupture Assy, 8000 PSI 1
12 2-90041 Clamp, Screw, #16 1
13 4-02130050 Hose, 7/8" Push-On,
Conduit 2.5 ft.
14 90-19710 Screw, 1/4" x 3/4" HH NC 15
15 7-01482 Insulation, Tank Bottom,
1" Blanket 1
16 95-073901000 Assy Frame, MVC 1
17 10-03013 Label, MVC, Coil Logo 1
18 4-0307 Wheel & Tire, 6" Steel Rim 4
19 90-20041 Collar, 5/8" Bore Shaft 4
20 90-4005 Washer, 5/8", Flat, SAE 4
21 5-01021 Engine, Honda, GX270
9 HP, 18 AMP (3-30321) 1
5-01072 Engine, Honda, GX340
11 HP E/S, 18 AMP (4-30321E) 1
5-01070 Engine, Honda, GX340
11 HP, 18 AMP (4-30321) 1
5-010720 Engine, Honda, GX390
13 HP E/S, 18 Amp (4-30321E/S,
4-35321E) 1
22 5-23125 Pump, General, TX1506GB
(3-3000) 1
5-2313 Pump, General, EZ-3040G
(4-3000) 1
5-23161 Pump, General, EZ-4035G
(4-3500) 1
23 4-02047714 Hose, 3/8" x 14", 2 Wire,
Pressure Loop 1
ITEM PART NO. DESCRIPTION QTY
24 2-30082 Pump Protector, 1/2" PTP 1
25 6-021730 Switch, Flow, MV60 1
6-021740 Switch, Reed Repleacement,
MV60 1
26 2-0053 Elbow, 1/2" JIC, 3/8", 90°1
27 5-3025 Unloader, PA 8 GPM @3650 PSI,
VB75K47L 1
28 2-1024 Elbow, 1/2" Street, Brass 1
29 2-10942 Swivel, 1/2" MP x 3/4" GHF
w/Strainer 1
30 2-1088 Hose Barb, 1/4" Barb x 1/8" ML
Pipe, 90°2
31 2-9040 Clamp, Hose, UNI .46 - .54 8
32 4-02100000 Hose, 1/4", Push-On, Fuel Line
(17 inches) 1
33 2-0115 Box, Battery, M-100
(Electric Start Only) 1
2-011500 ▲ Plate, Battery Box, Large,
PolyPro (Electric Start Only) 1
34 2-01154 Tank, Fuel 1
35 2-01167 Cap, Fuel Tank, Plastic H60-AV 1
36 2-01053 Mount, Rubber Vibration, 40 Duro
(Blue Dot) 2
37 2-01052 Mount, Rubber Vibration,
30 Duro 2
38 95-07290008 Tab, Outer Wrap 4
39 2-0103 Grommet, Rubber,
Nozzle Holder 4
40 2-99031 Filter, Diesel Fuel, Disposable 1
41 7-00031 Beckett Burner 1
42 90-2025 Nut, 5/16" Wing (Electric Start) 4
43 90-20040 Nut, 3/8" Flange Whiz Loc 4
44 2-1089 Hose Barb, 1/4" Barb x 1/4" Pipe,
90°1
45 2-1085 Hose Barb, 1/4" Barb x 1/4" ML
Pipe 1
46 95-07390001 Axle, 27.5" 2
47 10-02029 Label, Danger Cool Engine 1
48 2-00602 Elbow 1
49 2-3100544 Valve, E-Z Start,
3/8" MPT x 1/8" FPT 1
50 90-2020 Nut, Cage, 3/8" x 12 GA 12

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
15
LANDA MVC •#96-61836 •REV. 5/03
ALL MODELS
EXPLODED VIEW PARTS LIST CONTINUED
ITEM PART NO. DESCRIPTION QTY
51 6-0615 Regulator, Voltage, 15 V
(Pull Start) 1
77-31620-ZG5-003
Regulator/Rectifier, 18 AMP
(Electric Start) 1
90-1999 Screw, 10/32" x 3/4", Black 3
90-1994 Screw, 10/32" x 1-1/4", Black
(Electric Start) 2
90-017 Nut, 10/32" Keps 3
90-017 Nut, 10/32" Keps
(Electric Start) 2
52 90-1006 Bolt, 5/16" x 3/4" NC 8
53 90-2001 Nut, 5/16" ESNA 8
54 90-4001 Washer, 5/16" Flat 20
55 90-19715 Screw, 5/16" x 1-1/4" Whiz 4
56 2-010061 Bushing, Rubber, Nitrate 2
57 2-00270 Elbow, 3/8", Male 1
58 2-010062 Diptube Assy, Plastic,
7.50" Long 1
59 7-014832 Insulation, Tank Head 1
60 90-19960 Screw, 3/8" x 1-1/4" Whiz Loc 8
61 90-2022 Nut, Cage, 1/4" x 16 GA 5
62 10-09004 Label, Hot Water Outlet 1
63 2-11063 Plug, Push-On, Oil Drain,
Honda 1
64 2-11062 Swivel, 1/4" JIC FEM, Push-On 1
65 2-10491 Plug, 1/4" JIC 1
66 6-0117 Wire, THWN, 6 GA, Red
(Electric Start) 4 ft.
67 6-0118 Wire, THWN, 6 GA, Black
(Electric Start) 4 ft.
68 6-05101 Connector, Battery Post,
Universal (Electric Start) 2
69 90-20012 Nut, Whiz Loc, 5/16" Flange
(Electric Start) 4
70 2-30062 Valve, Anti-Siphon, Watts 8B 1
71 95-07141121 Key, 0.247 SQR x 2.125 1
ITEM PART NO. DESCRIPTION QTY
72 90-4008 Lock Washer 4
73 90-1996 Screw, 1/2" x 3/4" HH NC,
Whiz Loc 8
74 2-01403 Bushing, Snap, 5/8" 1
75 10-03014 ▲Label, MVC Frame Logo 1
76 11-1043 Label, Warning, Text 1
77 10-020110 Label, Use Only Kerosene 1
78 2-01037 Grommet, 1-5/16", Rubber 1
79 2-010066 Elbow, Fuel Tank 1
80 90-1992 Bolt, 3/8" x 3/8" Socket 1
81 2-000891 Nipple, Galv, 1/2" x 2-1/2" 2
82 90-4002 Washer, 3/8", Flat 4
83 95-07290085 Bracket, Wheel Brake 1
84 90-1995 Screw, 1/4" x 1/2" 4
85 90-200012 Nut, 1/4" Flange 12
86 90-2001 Nut, 5/16" ESNA 1
87 4-02100000 Fuel Line, 1/4" (25" Long) 1
88 4-02100000 Fuel Line, 1/4" (4" Long) 1
89 2-1103 Adapter, 1/4" x 1/4" 1
90 4-02100000 Hose, 1/4" (14.50 inches) 1
91 90-1009 Bolt, 5/16" 4
92 90-4008 Lock Washer, 5/16" Elec Start 4
93 2-01212 Cap, Vinyl (Yellow) 1
94 95-07390106 Lever, Break, MVC 1
95 7-01215 ▲ Nozzle, Burner 1.25, 90°B
(3-3000) 1
7-0102 ▲ Nozzle, Burner 2.00, 90°B
(4-3000, 4-3500) 1
96 4-02100000 Hose, 1/4" (7") 1
97 7-21699 Motor, 12V 1
98 7-00098 Fuel, Pump w/12V Solenoid 1
99 7-21754U Solenoid Coil, 12V 1
100 7-578727 ▲Electrode Kit 1
101 95-07390101 Bracket, Coil Support 1
102 2-9015 Clamp 4
103 90-19711 Screw, 1/4" x 1/2" HH, NC 2
104 10-99027 ▲Label, Stripe 2
▲ Not Shown

16 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
9
19
10 3
26
6
14
5
7
21
4
2
1
11
18
16
MVC
CONTROL BOX EXPLODED VIEW
17
8
22
15
13
20
12
Grounding Screw
(Reversed
View)
25
28
14
19
24
27
29
23

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
17
LANDA MVC •#96-61836 •REV. 5/03
ITEM PART NO. DESCRIPTION QTY
1 4-05088 Thermostat, Adjustable, 302°F1
2 95-07390018 Cover, Elec. Box, MVC 1
3 90-19942 Screw, 10/32" x 3/4", Black 6
4 6-041250 Breaker, 1658-G41-02-P10-25A1
5 6-05181A Locknut, 1/2" 1
6 6-020590 Light, Indicator, Green 12V 1
7 90-2018 Cage, Nut, 10/32" x 16 GA 6
8 10-990245 Label, Control Panel 1
9 4-050820 Meter, Tach/Hour, 12vDC,
Sentec 1
90-200430 ▲ Nut, 6/32" Keps 2
90-14 ▲ Screw, 6/32" x 5/8" 2
10 6-020251 Switch, Curvette RA901VB-B-1-V,
Carling 1
11 6-0516 Strain Relief, 1/2" Metal,
Two Screw 2
12 6-05152 Strain Relief 1
13 95-07390101 Box, Electric, MVC 1
14 90-200012 Nut, Whiz 2
15 6-0611 Rectifier, Bridge (Electric Start) 1
16 6-03671 Relay, P & B, VF4-41F11, 12VDC,
40AMP 1
17 6-06070 Capacitor (3-3000) 1
18 6-06071 Bracket, Capacitor (3-3000) 1
19 90-017 Nut, 10/32" Keps 6
20 90-14 Screw, 6/32" x 3/8", RND HD
MCH 2
21 90-200430 Nut, 6/32" Keps 2
22 90-1999 Screw, 10/32" x 3/4" BH SOC
CS (Elec. Start) 1
23 6-01270 Conduit, Split, 1/4" 4 ft.
24 2-01403 Bushing Snap, 5/8" 3
25 90-19710 Screw 1/4" x 1/2" NN NC 2
26 90-1991 Screw, 10/32" x 1/2" Black 1
27 90-1994 Screw, 10/32" x 1-1/4"
(Ground) 1
28 11-1042 Label, Ground 1
29 2-011681 Cap, Capacitor, 1.37 x 1.50 x
.060, Blk, w/o Hole 1
MVC
CONTROL BOX EXPLODED VIEW

18 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
HOSE AND SPRAY GUN ASSEMBLY
ALL MODELS
ITEM PART NO. DESCRIPTION QTY
1 2-2002 Coupler, 3/8" Female 1
2-0121 ▲Quick Coupler O-Ring LG 1
2 4-02033450C Hose, 50' x 3/8"
(3-3000, 4-3000) 1
4-02083450C Hose Only, 50' x 3/8", 4000 PSI
(4-3500) 1
3 4-01212 Spray Gun, Shutoff,
Series 2000 1
4 4-0111351A Wand, VP Zinc 1/4" (AL344)
w/ Coupler w/ Soap Nozzle 1
83-SSVPKIT ▲AR Wand Repair Kit,
Stainless Seat 1
5 4-06540 Brass Soap Nozzle Only, 1/8" 1
6 2-2001 Coupler, 1/4" Male 1
2-0119 ▲Quick Coupler O-Ring Sm 1
ITEM PART NO. DESCRIPTION QTY
7 4-12804015 Nozzle, SAQMEG 1504, Yellow
(4-3000) 1
4-12804000 Nozzle, SAQCMEG 0004, Red,
(4-3000) 1
4-12804025 Nozzle, SAQCMEG 2504, Green,
(4-3000) 1
4-12804040 Nozzle, SAQCMEG 4004, White,
(4-3000) 1
4-12803515 Nozzle, SAQMEG 1535, Yellow
(4-3500) 1
4-12803500 Nozzle, SAQMEG 003.5, Red,
(4-3500) 1
4-12803525 Nozzle, SAQMEG 2503.5, Green,
(4-3500) 1
4-12803540 Nozzle, SAQMEG 4003.5, White,
(4-3500) 1
4-12803015 Nozzle, SAQMEG 1530, Yellow
(3-3000) 1
4-12803000 Nozzle, SAQMEG 0003, Red,
(3-3000) 1
4-12803025 Nozzle, SAQMEG 2503, Green,
(3-3000) 1
4-12803040 Nozzle, SAQMEG 4003, White,
(3-3000) 1
▲ Not Shown
3
2
1
7
6
5
4

MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
19
LANDA MVC •#96-61836 •REV. 5/03
MVC
HOSE REEL OPTION BREAKDOWN
ITEM PART NO. DESCRIPTION QTY
1 2-0052 ▲ Nipple, 1/2" JIC x 1/2" Pipe 1
2 2-0054 Elbow, 1/2" JIC x 1/2", 90°1
3 2-2002 Coupler, 3/8" Femal, Brass 1
4 4-02047736 Hose, 3/8" x 36",
2 Wire Pressure Loop 1
DOWNSTREAM INJECTOR ASSEMBLY #4-011184
ALL MODELS
ITEM PART NO. DESCRIPTION QTY
8 3-12021 Injector, Det, Non-Adjust #3 1
9 2-9040 Clamp, Hose, UNI .46 - .54 2
10 4-02080000 Tube, 1/4" x 1/2", Clear Vinyl 6 ft.
11 2-1904 Strainer, 1/4", Hose Barb 1
11
10
98
To Coil Outlet
4
7
8
5
6
2
3
ITEM PART NO. DESCRIPTION QTY
5 4-02755030 Hose Reel, 100' Non-Pivot,
E-ZEE w/Pin Lock 1
6 90-1996 Screw, 3/8" x 3/4" HH NC,
Whiz Loc 4
7 90-20040 Nut, 3/8", Flange Whiz Loc, NC 4
8 95-07290090 Bracket, E-ZEE Hose Reel Left,
Wrinkle Black 1
▲ Not Shown

20 MVC SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA MVC •#96-61836 •REV. 5/03
PREVENTATIVE MAINTENANCE
This pressure washer was produced with the best available materials and quality craftsmanship. However, you as the
owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative mainte-
nance procedures will assist in preserving the performance of your equipment. Contact your Landa, Inc. dealer for
maintenance. Regular preventative maintenance will add many hours to the life of your pressure washer. Perform
maintenance more often under severe conditions.
MAINTENANCE SCHEDULE
Engine Oil Inspect Daily
Change Every 25 hours
Filter Every 50 hours
Air Cleaner Inspect Every 50 hours or monthly
Clean Every 3 months
Battery Level Check monthly
Engine Fuel Filter 500 hours or 6 months
Spark Plug Maintenance 500 hours or 6 months
Clean Fuel Tank(s) Annually
Replace Fuel Lines Annually
Pump Oil Inspect Oil level daily
Change After first 50 hours, then every 500 hours or annually
Clean Burner Filter Monthly (More often if fuel quality is poor)
Remove Burner Soot Annually
Burner Adjustment/Cleaning Annually
Replace Burner Nozzle Annually
Descale Coil Annually (More often if required)
Replace High Pressure Nozzle Every 6 months
Replace Quick Couplers Annually
Clean Water Screen/Filter Weekly
Replace HP Hose Annually (If there are any signs of wear)
OIL CHANGE RECORD
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
