60cm Built In Electric Multifunction Oven and Grill
E60MF
User Guide & Installation Handbook
®
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 1

1
User’s Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 22
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Be Safe - Not Sorry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Using the Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cooking with a fan oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Slow cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooking frozen & chillled foods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Defrosting and cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Baking guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Traditional fruit cakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Roast turkey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Roasting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Automatic cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Programmer / Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 - 26
Step 1: Prepare installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 2: Connect to electricity supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Step 3: Check edging strip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Step 4: Secure appliance into housing unit . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Prestige® Customer Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Please keep this handbook for future reference, or for anyone else
who may use the appliance.
Contents
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 2

Thank you for choosing a Prestige®
appliance
We hope that the following information
will help you to familiarise yourself
with the features of the appliance, and
to use it successfully and safely.
Our policy is one of constant
development and improvement. Strict
accuracy of illustrations and specifications
is not guaranteed. Modification to
design and materials may be
necessary subsequent to publication.
Please read the instructions in this
handbook before using or installing
this appliance.
Your 1st Year Guarantee
To fulfil the conditions of your guarantee,
this appliance must be correctly
installed and operated, in accordance
with these instructions, and only be
used for normal domestic purposes.
Please note that the guarantee, and
Service availability, only apply to the
UK and Republic of Ireland.
Before using the appliance for
the first time, remove any protective
polythene film and wash the oven
shelves and furniture in hot soapy
water to remove their protective
covering of oil. Even so, when you
first switch on the oven or grill you
may notice a smell and some smoke.
This appliance is designed to fit into a
standard 600mm wide housing unit with
a minimum internal height of 580mm.
Electrical connection
Please refer to installation instructions
for electrical connection.
In your own interest, and that of safety,
make sure that the installation is carried
out by a competent person.
Disconnection of electric appliances
should always be carried out by a
competent person.
Warning: This appliance must be
earthed.
Condensation
When hot and cold air meet,
condensation forms. The outer door is air
cooled and the inner door gets hot, so some
condensation might form; this is normal
and will disappear within 10 - 15 minutes.
2
Introduction
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 3

Cooling fan
The cooling fan helps to keep the
exterior cool during normal use.
When an element is operated, you
should hear the cooling fan switch on
automatically and be able to feel air
evacuating from the appliance vents
just below the fascia.
The cooling fan will continue to operate
for approximately 10 minutes after
turning off the elements. This is normal.
If there is no such indication that the
fan is operating, the appliance will
require servicing. DO NOT USE THE
APPLIANCE UNTIL IT HAS BEEN SERVICED .
Switch the appliance off at the mains
and contact Customer Support.
Glass door panels
To meet the relevant standards of
Domestic cooking appliances, all the
glass panels on this appliance are
toughened to meet the fragmentation
requirements of BS 3193. This ensures
that, in the unlikely event that a panel
breaks, it does so into small fragments
to minimise the risk of injury.
Please take care when handling, using
or cleaning all glass panels as any
damage to the surfaces or edges may
result in the glass breaking without
warning or apparent cause at a later
date. Should any glass panel be
damaged, we strongly recommend
that it is replaced immediately.
To replace an oven light bulb
Caution: Switch off the electricity
supply to the appliance, to avoid the
risk of electric shock.
Wait until the oven is cool, then
remove the oven shelves.
Remove the loose oven back - unscrew
the 4 securing screws (one at each
corner). Unscrew the lens cover (turn
anticlockwise). Unscrew the bulb and
replace. Replace lens cover, and
replace oven back.
Please note that the oven light bulb is
not covered by the guarantee.
Environmental Protection
We are committed to protecting the
environment and operate an
Environmental Management System
which complies with BS EN ISO
14001.
Disposal of packaging
lAll our packaging materials are
recyclable and environmentally
friendly.
lPlease help us to protect our
environment by disposing of all
packaging in an environmentally
friendly manner.
lPlease contact your local authority
for the nearest recycling centre.
Caution: Packaging materials can
pose a risk of suffocation - keep away
from children.
3
Introduction
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 4

When you are cooking, keep
children away from the vicinity
of appliance.
This product is designed as a domestic
cooking appliance for the preparation
and cooking of domestic food
products, and should not be used for
any other purpose.
lRemove all packaging from the
appliance before using for the
first time.
lMake sure you read and
understand the instructions before
using the appliance.
lKeep electrical leads short so they
do not drape over the appliance
or the edge of the worktop.
lKeep all flammable materials (such
as curtains, furnishings & clothing)
away from the appliance.
lParts of the appliance may be hot
during or immediately after use. Care
should be taken to avoid touching
heating elements inside the oven.
Allow sufficient time for the appli-
ance to cool after switching off.
lSwitch off the electricity supply
before cleaning the appliance.
lDo not drape tea towels over the flue
vents as this creates a fire hazard.
lWhen opening the appliance
door, take care to avoid skin
contact with any steam which may
escape from the cooking.
lUsing aluminium foil to cover the
grill pan, or putting items wrapped
in foil under the grill creates a fire
hazard. The high reflectivity can
also damage the element.
lDo not use foil on oven shelves or
on the oven base, or allow it to
block the oven flue, as this creates
a fire hazard and prevents heat
circulation.
lDo not use the oven with the door
inner glass panel removed.
lUse oven gloves when removing
hot food / dishes from the oven or
grill. The oven / grill and utensils
will be very hot when in use.
lWhen cooking heavy items - eg;
turkeys - do not pull the oven shelf
out with the item still on the shelf.
lSwitch off the electricity supply
before replacing the oven light
bulb (if fitted), to avoid the risk of
electric shock.
lNever use the appliance for
heating a room.
lWarning: This appliance must
be earthed.
All installation, servicing and
maintenance work should be carried
out by a competent person who will
comply with current Regulations,
Standards and Requirements.
When you have finished
cooking check that all controls
are in the off position.
4
Be Safe - Not Sorry
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 5

Caution: Accessible parts may
be hot when the grill is used,
young children should be kept
away.
The grill is a single circuit fully variable
grill. It can be used for conventional
grilling, or as a fanned grill.
To switch on the grill
Turn the function selector control knob
to either the conventional grill
symbol, or the fanned grill symbol.
Turn the temperature selector control
knob clockwise to the desired grill
temperature setting.
To switch off the oven, return the
control knob to the “l” off position.
Preheating
For best results, preheat the grill for
3 - 5 minutes.
Aluminium foil
Using aluminium foil to cover the grill
pan, or putting items wrapped in foil
under the grill, can create a fire
hazard, and the high reflectivity can
damage the grill element.
Detachable grill pan handle
Place the handle over the edge of the
grill pan, at the narrow side edges.
Slide the handle to the centre, and
locate between the handle position
indicators.
The handle should be removed from
the pan during grilling, to prevent
overheating.
The handle is designed for removing /
inserting the grill pan under the grill
when grilling.
If cleaning the grill pan when it is hot,
use oven gloves to move it. Do not use
the handle to pour hot fats from the
grill pan.
Food for grilling should be positioned
centrally on the trivet.
5
Using the Grill
handle
grill pan
grid
handle position
indicators
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 6

Conventional grill
The door must be open when the
conventional grill function is used -
either fully open or using the door stop
position - open the door about 30˚
and it will hold open.
When using the door stop position for
grilling, you can remove the grill pan
handle by sliding it to the recess.
Thicker foods such as sausages and
chicken portions are suited to con-
ventional grilling.
Fanned grill
The door must be closed when the
fanned grill is used.
When opening the door, take care to
avoid skin contact with any steam
which may escape from the cooking.
Fanned grilling may be faster than
conventional grilling, because air is
being circulated around the food, and
thin portions of food such as bacon or
fish fillets may not need turning.
The fanned grill is particularly suited to
thinner foods such as bacon, gammon,
fish fillets etc.
Grilling
The temperature of the grill is variable,
and can be adjusted by turning the
temperature selector control knob to
the desired temperature setting.
The speed of grilling can also be
controlled by selecting a higher or
lower shelf position.
We recommend that the higher
temperature settings are used for
toasting and for cooking foods such as
bacon, sausages or steaks. Use a
higher shelf position.
For thicker foods such as chops or
chicken joint pieces, the temperature
may be reduced to a lower setting.
Use a middle to low shelf position.
Position the grill pan under the centre
of the grill.
The grill pan trivet, inside the grill
pan, can be inverted to give a high or
low position, or it may be removed.
6
Using the Grill
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 7

Oven functions are detailed below
with suggested uses.
Note: Please be aware that not all
appliances have all functions.
7
Oven Functions
Oven Function Recommended Uses
Base Heat Only Used to finish off the bases of food following cooking using the
conventional or fanned modes. The base heat can be used to pro-
vide additional browning for pizzas, pies and quiche. Use this
function towards the end of cooking.
Top Heat Only The heat is ideal from browning off the tops of food as it is not as
fierce as the grill following conventional or fanned cooking.
Provides additional browning for dishes like Lasagna or
Cauliflower cheese. Use this function towards the end of
cooking.
Conventional Oven This function works on the principle that heat rises. It is ideal for
traditional roasting. The meat is placed in the middle of the oven,
roast potatoes towards the top, and puddings towards the base
Fanned Grill The fan allows the heat to circulate around the food. Ideal for thin-
ner foods such as bacon, fish and gammon steaks. Foods do not
require turning. Use with the oven door closed.
Fanned Oven The even temperature in the oven makes this function suitable for
batch baking, or batch cooking foods. In addition it can be used
as a quick preheat boost.
Defrost To defrost foods, such as cream cakes/gateaux, use with the oven
door closed. For cooling dishes prior to refrigeration, leave the
door open.
Grill This function cooks food from the top and is ideal for a range of
food from toast to steaks.
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 8

When you are cooking, keep
children away from the vicinity
of the oven.
Your appliance may have a fanned
oven. When using the fanned oven,
please follow the instructions below:
To switch on the oven
Turn the function selector control knob
to the fan oven symbol.
Turn the temperature selector control
knob clockwise to the desired
temperature setting.
The red thermostat indicator will come
on until the selected temperature is
reached and then go off; it will turn on
and off periodically as the thermostat
operates to maintain the selected
temperature.
To switch off, return the control knob to
the “l” off position.
Preheating
The oven must be preheated when
cooking frozen or chilled food, and
we recommend preheating for yeast
mixtures, batters, soufflés and whisked
sponges, otherwise preheating is not
necessary as a fan oven warms up
quickly.
Preheat the oven until the indicator
light switches off for the first time;
this will take between 5 - 15 minutes,
depending on the temperature selected.
Aluminium foil
Use aluminium foil only to cover food
or cooking dishes. Do not foil to cover
the shelves or oven base, as this
creates a fire hazard.
Baking tray and roasting tins
For best cooked results and even
browning, the maximum size baking
trays and roasting tins that should be
used are as follows;
Baking tray 350mm x 280mm
This size of baking tray will hold up to
16 small cakes.
Roasting tin 370mm x 320mm
We recommend that you use good
quality cookware. Poor quality trays
and tins may warp when heated,
leading to uneven baking results.
Oven shelves
The oven shelf must be positioned with
the upstand at the rear of the oven and
facing upwards.
Position baking trays and roasting tins
on the middle of the shelves, and leave
one clear shelf position between
shelves, to allow for circulation of heat.
8
Using the Fanned Oven
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 9

Cooking with a fan oven
If you are used to cooking with a
conventional oven you will find a
number of differences to cooking with
a fan oven which will require a
different approach:
There are no zones of heat in a fan
oven, the convection fan at the back of
the oven ensures an even temperature
throughout the oven; this makes it ideal
for batch baking - eg; when planning
a party or stocking the freezer, as all
the items will be cooked within the
same length of time.
Cooking times will generally be shorter
by between 5 - 10 minutes per hour,
than those given in recipe books for
conventional cooking.
We recommend preheating the oven
for frozen or chilled food and also for
soufflés, batter mixtures & yeast mixtures.
Preheat the oven until the indicator
light switches off for the first time; this
will take between 5 - 15 minutes
depending on the temperature selected.
There is no flavour transference in a
fan oven, which means you can cook
strong smelling foods such as fish at
the same time as mild foods - eg; milk
puddings.
The fan oven may cook foods at a
lower temperature (between 10˚C and
20˚C lower) than a conventional oven,
so conventional recipe temperature
may have to be reduced.
To help the air circulate freely;
lPosition the shelves evenly within
the oven and maintain a clearance
from the oven roof and base.
lIf more than one cooking dish or
baking tray is to be used on a shelf
leave a gap of at least 25mm / 1”
between the items themselves and
the oven interior.
lAllow enough space between
shelves for food that will rise
during cooking.
lDo not place items on the oven
base as this will prevent air from
circulating freely.
9
Using the Fanned Oven
08 27355 00 - Prestige 60BI 5/10/07 12:01 Page 10
