PRICE PUMP XJ Series Installation guide

Price® Pump Co. Model XJ & JB Series Page 1of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
IN-164
PRICE PUMP
Installation,
Operating, and
Maintenance
Manual
Type XJ/JB Series
Caution:
Before installing,
repairing or performing
maintenance on this
pump, read these
instructions completely.
Installation
Electrical
WARNING!
Ground motor before
connecting to electrical
power supply! Failure to
ground motor can cause
severe or fatal electrical
shock hazard!
Do not ground to gas
supply line!
Disconnect power to
motor before working on
motor or pump!
Match voltage to
nameplate voltage on
motor. Incorrect voltage
can cause fire or seriously
damage motor, voiding
warranty.
Close Coupled -
Motor Pumps
These pumps require no special
care in mounting, although it is
suggested that they be firmly
bolted to a level surface.
Adequate air movement over
motor will help prevent
overloads.
Power Frame Mounted
Pumps
These pumps must be mounted
on a rigid steel base that will not
warp or flex. Each pump must
be mounted such that the pump
shaft centerline is on center
with the driver shaft center-
line. Pads and/or shims will be
required on either pump, driver
or both. The two shafts should
not touch each other and the
distance between them depends
on the coupling used to connect
them. Misalignment will cause
bearing failure and void
warranty. Pumps are rough
aligned at the factory but
must be realigned after
shipment and installation.
Pulley driven pumps must have
pulleys in line and good belt
tightness practices followed.
I & O Manual

Price® Pump Co. Model XJ & JB Series Page 2of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
Direction of Rotation
Note: Motor shaft rotation is
viewed from the suction end of
pump. A rotational arrow is
shown on the front of the pump
volute casing. Incorrect rotation
can cause pump damage, failure
or reduced performance, voiding
warranty. It is best to check
rotation by momentarily
energizing or jogging the motor
prior to filling pump with liquid.
Warning! Do not operate
pump without liquid for more
than a few seconds, as damage
will result to mechanical seal.
PLUMBING
All piping should be supported
independently of the pump.
Piping should not exert any
stress on the pump connections.
1. Suction Piping-Horizontal
Pumps.
Suction line must provide
adequate suction pressure and
smooth liquid flow for proper
pump operation. Air entrapment
in the suction line because of
leaks or improper design may
cause the pump to lose prime
and fail. This pump is not self-
priming, therefore the suction
must be flooded at start up.
Also, the suction line must
provide sufficient pressure and
smooth flow to pump inlet to
prevent pump cavitation. A
length of straight pipe a
minimum of 5 times the pump
inlet diameter and preferably 10
times the diameter should be
installed in the suction line
where it enters the pump.
Elbows, fittings or valves
installed close to the suction can
disrupt liquid flow and cause
malfunction. Suction lines must
be at least the same size as the
pump inlet or larger if possible.
Price Pump Company
recommends against using foot
valves in the suction line to
maintain liquid in the pump
when it’s not operating. If foot
valves are used due to suction
lift conditions they must be
properly maintained to avoid
leaks resulting from wear or
fouling. Suction piping must be
designed to prevent air from
being trapped in high spots in
the piping. This condition may
cause the pump to vapor lock as
the air bubble moves into the
pump.
2. Discharge Piping.
For flow and discharge head
control it is advisable to install a
valve (globe, ball, or other
adjustable and non-leak type) in
the discharge line close to the
pump. The valve may be closed
during system repairs to prevent
backflow. By installing a check
valve in the discharge line
backflow can also be prevented
during maintenance or during
periods of pump stoppage.
OPERATION
Priming. All centrifugal pumps
must be filled with liquid prior to
start up. For the pump
illustrated in this manual
completely fill the volute and
suction lines prior to operation.
It is suggested that during initial
start up the discharge valve be
closed and then opened as the
motor develops full rpm’s. If
pump does not build up pressure
as motor speed increases, shut
down and reprime pump.
Ensure that liquid flow into
pump is not restricted (see
“Troubleshooting”).
Note: A centrifugal pump’s
flow and head (pressure) will
vary with the amount of
resistance (friction and flow
restrictions) in the discharge
line. As a valve on the discharge
line opens the flow and motor
amp draw will increase and head
will drop. As a valve on the
discharge is closed the flow and
amp draw will decrease and the
head will increase. If resistance
in the discharge line is not
sufficient the pump will operate
at a condition of maximum (or
“choked”) flow, also sometimes
called “end of performance
curve.” Maximum horsepower
is required to operate at this
point and motor overload may
result. If excessive amp draw
and motor overload is recurring,
reduce the system flow by

Price® Pump Co. Model XJ & JB Series Page 3of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
installing a valve on the
discharge line and restricting
flow. Alternatively, reduce
pump head by trimming impeller
to a smaller diameter. Consult
local Price Pump dealer for
assistance.
CAUTION
Disconnect power to pump
before servicing to avoid
dangerous or fatal electrical
shock hazards.
If pump has been used to
pump hazardous materials be
certain that all materials have
been removed prior to
working on the pump.
Inverting pump with liquid in
it could cause liquid to get
into motor bearings and cause
damage. Before disassembling
be certain all liquid is
removed from the pump.
TROUBLESHOOTING
1. Pump fails to build pressure:
Check for:
a. Pump not primed.
b. Incorrect rotation.
c. Driver speed too low.
d. Suction line restricted.
e. Driver failure.
f. Plugged or damaged
impeller.
g. Pump or impeller
undersized.
h. Pump cavitation.
i. Impeller rubbing volute.
2. Pump fails to provide
enough flow.
Check for:
a. System resistance too high.
b. Pump undersized.
c. Pump not primed.
d. Driver speed too low.
e. Poor suction conditions
f. Impeller rubbing volute due
to improper installation.
g. Pump cavitation.
h. Plugged or damaged
impeller.
3. Excessive noise or vibration
during operation.
Check for:
a. Motor bearing failing.
b. Pump cavitating.
c. Impeller rubbing volute.
4. Leaking mechanical seal.
Check for:
a. Improper assembly.
b. Worn or cracked seal
faces.
c. Abrasive material build up
around seal.
d. Liquid flashing at seal faces
(temp too high).
e. Seal pressure rating too
low for the service.
f. Chemical attack of seal
parts.
g. Seal operated dry or with a
liquid having poor
lubricating properties.
5. Pump gradually loses
pressure and head.
Check for:
a. Increasing temperature
causing cavitation or liquid
vaporization.
b. Driver failure.
c. Suction lift too high.
d. Air entering suction line.
6. Motor/pump overheating.
Check for:
a. Excessive flow and amp
draw. (Throttle discharge)
b. Low voltage or frequency.
c. Flow too low with
resulting heat rise.
d. Bearing failure.
e. System temperature too
high.

Price® Pump Co. Model XJ & JB Series Page 4of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
TYPE XJ/JB Series MAINTENANCE AND REPAIR I&O IN 164
Before attempting any repairs under warranty, contact Distributor to obtain factory authorization.
Repairs carried out without authorization may void warranty. Many causes of pump system failure
are due to improper system design. Refer to the Trouble Shooting List in this manual before
carrying out pump inspection.
DISASSEMBLY
1. Disconnect power source
from motor.
2. Disconnect electrical
connections, tagging wires
carefully to preserve correct
rotation. Loosen pump
base.
3. Remove pump and motor
assembly to repair area.
Observe position of all parts
prior to disassembly.
(Note: volute may be left in
piping.)
4. Remove 8 volute bolts and
remove volute from pump.
5. Remove impeller. Remove
impeller lockdown by
turning CCW. Slide
impeller off of the shaft.
Save shaft key.
6. Remove seal head from the
shaft. On type 9 seal, loosen
set screws and slide seal
from shaft. On type 21,
remove seal by sliding it off
of the shaft.
7. Remove the four motor
bolts and remove bracket
from motor.
8. Remove seal seat from
bracket. Use wooden or
plastic dowel to tap the seat
from the bracket.
9. Remove shaft or shaft
sleeve. Heat shaft sleeve to
approximately 300oF and
use a bearing puller to
remove the sleeve.
REASSEMBLY
1. Clean seal cavity of the
bracket thoroughly.
2. Thoroughly clean pump
shaft. Assure that the shaft
is not grooved and that there
is no evidence of pitting or
fretting. Polish the shaft
with extra fine emery cloth
and clean the keyway.
3a. On 56C motors, (stub
shaft pumps only), ensure
all debris and burrs are
removed from the motor
shaft. Align halfdog
setscrew with motor
keyway while sliding stub
shaft over the motor
shaft. Set height
(diagram A). Tighten all
set screws.
3b. On JM style motors,
apply Loctite RC/609 to
inside diameter of shaft
sleeve. Install shaft sleeve
onto motor shaft making
sure that the groove for
the Teflon® sleeve gasket
is facing the pump end.
Clean excess Loctite from
shaft. Ensure sleeve is
seated against motor
shaft shoulder.
4. For Type 21, 8, and 9 seals:
Place the bracket on a firm
surface with the seat cavity
(pump end) up. Then place
a small amount of vegetable
oil on the seat cup or “O”
ring seat. Place the seat in
the seal cavity with the
polished face up toward the
pump end. Evenly push seat
into seat cavity with fingers,
then gently tap seat into
place with a wooden dowel
or plastic rod (2” outside
diameter). To help ensure
the seat is not damaged,
place the cardboard disk
supplied with the seal under
the end of the dowel to
prevent damaging the seat
face.
Diagram A

Price® Pump Co. Model XJ & JB Series Page 5of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
5. Place bracket on motor
(aligning the base if
applicable). Secure bracket
to motor with four motor
bolts and washers.
6. Install seal head assembly:
For Type 21:
a. Lubricate shaft and
elastomer with vegetable
oil.
b. Install rotary seal head
onto pump shaft and slide
toward seat using a
twisting motion until
carbon face touches seal
seat.
c. For 145JM through
215JM frame pumps,
install new sleeve gasket
into shaft sleeve. For
254JM through 256JM,
install new gasket into
hub of impeller.
d. Install seal spring and
retainer over shaft sleeve.
e. Install impeller onto
motor shaft being careful
to align keyway of
impeller with keyway in
motor shaft. Push
impeller on until impeller
bottoms out on shaft
sleeve. Install key in
keyway.
f. Install impeller lockdown
gasket and impeller
lockdown. Tighten
securely.
For Type 8 or Type 9:
a. Do not remove metal
clips from seal head
assembly. Place seal on
shaft sleeve sliding gently
past shoulder.
b. Slide seal head toward
seat until carbon face
contacts ceramic seat.
Tighten seal head
setscrews to shaft sleeve
using short arm allen
wrench supplied with seal
or repair kit. Remove
clips in seal head and
discard.
c. For 145JM through
215JM frame pumps,
install new sleeve gasket
into shaft sleeve. for
254JM through 256JM,
install new gasket into
hub of impeller.
d. Install impeller onto
motor shaft, being careful
to align keyway of
impeller with keyway in
motor shaft. Push
impeller on until impeller
bottoms out on shaft
sleeve. Install key in
keyway.
e. Install impeller lockdown
gasket and impeller
lockdown. Tighten
securely.
7. Install new volute gasket.
Ensure that all of the mating
surfaces of the gasket joint
are cleaned to bare metal.
8. Install volute and secure
with 8 bolts and tighten
evenly.
9. Rotate pump shaft by
hand to ensure impeller
does not rub against
volute.
10. Return pump to
installation, reconnect
electric connections.
11. Start pump momentarily
to observe shaft rotation.
If rotation corresponds to
the rotation arrow on the
pump, it may be put into
service. If rotation is
incorrect, switch any two
leads on 3-phase motors
to change rotation.
Check wiring diagram of
motor for single phase
rotation correction.
12. Remove top pipe plug (if
applicable) from the front
of volute and prime pump
thoroughly, making sure
all air is purged. Turn
shaft one revolution and
then refill. Replace the
pipe plug.
13. Start pump allowing
adequate time to purge all
air from system. Observe
any gauges, flow meters,
etc., to see if pump
performs properly.

Price® Pump Co. Model XJ & JB Series Page 6of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
XJ /JB PARTS LIST
Effective: June 26, 1997
For Sizes:
1 x 1½-8
1½ x 2-8 (Threaded Only)
1½ x 3-8 (Flanged Only)
2 x 3 -8
Note: All wetted parts are 316 Stainless Steel
A
1
.Volute (Flanged) (316SS) XJ/JB
1 x 1½-8(XJ100) 2620 B. 1/8” Pipe Plug (1 rqd std, 3 others opt)(316SS) 0559
1½ x 3-8( (XJ150) 2622 C. Volute Gasket, Teflon® 4035
2 x 3 -8(XJ200) 2624 D. Volute Bolts (8 rqd) (316SS) 0724
A2.Volute (Threaded Opt) (316SS) E. Bracket (316SS)
1 x 1½-8(JB100) 4002 Single Seal (std) 4010
1½ x 2-8(JB150) 4003 Double Seal 4010-1
2 x 3 -8(JB200) 4000 Single Flush 4010-2
Quench & Flush 4010-3
Internal Flush 4010-4

Price® Pump Co. Model XJ & JB Series Page 7of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
Continued on Back

Price® Pump Co. Model XJ & JB Series Page 8of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
XJ/JB Parts List -Continued
XJ/JB
F1.T.21 Viton® Single Seal/Seat (std) 0122
F2.T.9 Teflon® Single Seal/Seat (opt) 0123
Seat Pin for T.9 (not shown) 0890
F3.T.21 Viton® Double Seal/Seat (opt) 1024
Double Seal Plate T.21 (2 rqd) 0309
Plate Gasket, Teflon® (2 rqd) 0505
Seal Plate Bolts (6 rqd) 0977
F4.T.9 Teflon® Double Seal/Seat (opt) 0670
Double Seal Plate T.9 (2 rqd) 0309-1
Plate Gasket, Teflon® (2 rqd) 0505
Plate Bolts (6 rqd) 0977
Seat Pin for T.9 (2 rqd, not shown) 0890
143JM-215JM 254/256JM
G. Impeller lockdown 0978 4050
H. Lockdown Gasket, Teflon® 0245 4060
J. Impeller for Flanged Volute **
1 x 1½-8(XJ100) 2621-dia N/A
1½ x 3-8( (XJ150) 4024-dia 4026-dia
2 x 3 -8(XJ200) 2628-dia 2625-dia
Impeller for Threaded Volute (opt) **
1 x 1½-8(JB100) 4022-dia N/A
1½ x 2-8(JB150) 4024-dia 4026-dia
2 x 3 -8(JB200) 4020-dia 4025-dia
** For Double Seal Impellers (add “DS” to Impeller P/N. For Example: 2621DS or 4022DS)
K. Sleeve Gasket, Teflon® 0245 4045
L. Shaft Sleeve 0127 4040
M. Impeller Shaft Key 0135 0136
N. Bracket Bolts (4 rqd) 0595
143-184JM 0588
213JM/215JM 1189
O. Bracket Bolt Washers (4 rqd)
143-184JM 1137
213JM/215JM 1199
254JM/256JM 1199
P. Spacer (Bracket to Motor) N/A 4055
Only rqd for 254/256 JM Motors
Q. Seal Quench (opt) Any Frame
Lip Seal Plate 0309-2
Buna Lip Seal 0756
Viton® Lip Seal 0757
Teflon® Lip Seal 0758
Plate Gasket, Teflon® (1 rqd) 0505
Plate Bolts (3 rqd) 0977
R1.Motor Specify P/N
R2.Power Frame 0502
XJ/JB Repair Parts Kits
Includes: Teflon® Gasket, SS Shaft Sleeve, Sleeve Gasket, Impeller lockdown Gasket, Loctite
P/N 4095 Kit for 143/215JM
P/N 4096 Kit for 254/256JM
Note: Seal/seat must be ordered in addition to repair kit.
Options: 1½” T.21 & T.9 Single & Double
(XJ-JBPR7 Parts 97 12/14/01)

Price® Pump Co. Model XJ & JB Series Page 9of 8 I&O IN164 12/14/01
21775 8th Street East wP.O. Box Q wSonoma, CA 95476-0329 w(707) 938-8441 wFax [phone]
GENERAL TERMS OF SALE FOR PRODUCTS Effective: January 1, 1993
1. GENERAL
A. Seller's price is based on these sales terms and (i)
this document together with any additional writings
signed by Seller shall represent the final, complete and
exclusive statement of the agreement between the
parties and may not be modified, supplemented,
explained or waived by parol evidence, Buyer's purchase
order, a course of dealing, Seller's performance or
delivery, or in any other way except in writing signed by
an authorized representative of Seller, and (ii) these
terms are intended to cover all activity of Seller and
Buyer hereunder, including sales and use of products,
parts and work and all related matters (references to
products include parts and references to work include
construction, installation and start-up). Any reference by
Seller to Buyer's specifications and similar requirements
are only to describe the products and work covered
hereby and no warranties or other terms therein shall
have any force of effect. Catalogs, circulars and similar
pamphlets of the Seller are issued for general
information purposes only and shall not be deemed to
modify the provisions hereof.
B. The agreement formed hereby and the language
herein shall be construed and enforced under the
Uniform Commercial Code as in effect in the State of
California on the date hereof.
2. TAXES
Any sales, use or other similar type taxes imposed on
this sale or on this transaction are not included in the
price. Such taxes shall be billed separately to the Buyer.
Seller will accept a valid exemption certificate from the
Buyer if applicable; however, if an exemption certificate
previously accepted is not recognized by the
governmental taxing authority involved and the Seller is
required to pay the tax covered by such exemption
certificate. Buyer agrees to promptly reimburse Seller
for the taxes paid.
3. PERFORMANCE, INSPECTION AND
ACCEPTANCE
A. Unless Seller specifically assumes installation,
construction or start-up responsibility, all products shall
be finally inspected and accepted within thirty (30) days
after arrival at point of delivery. Products not covered
by the foregoing and all work shall be finally inspected
and accepted with thirty (30) days after completion of
the applicable work by Seller. All claims whatsoever by
Buyer (including claims for shortages) excepting only
those provided for under the WARRANTY AND
LIMITATION OF LIABILITY and PATENTS Clauses
hereof must be asserted in writing by Buyer within said
thirty (30) day period or they are waived. If this contract
involves partial performance, all such claims must be
asserted within said thirty (30) day period for each
partial performance. There shall be no revocation of
acceptance. Rejection may be only for defects
substantially impairing the value of products or work and
Buyer's remedy for lesser defects shall be those provided
for under the WARRANTY AND LIMITATION OF
LIABILITY Clause.
B. Seller shall not be responsible for non-performance
or for delays in performance occasioned by any causes
beyond Seller's reasonable control, including, but not
limited to, labor difficulties, delays of vendors or
carriers, fires, governmental actions, or shortages of
material, components, labor, or manufacturing facilities.
Any delays so occasioned shall affect a corresponding
extension of Seller's performance dates which are, in any
event, understood to be approximate. In no event shall
Buyer be entitled to incidental or consequential damages
for late performance or for a failure to perform. Seller
reserves the right to make partial shipments and to ship
products, parts or work which may be completed prior to
the scheduled performance date.
C. In the event that Seller has agreed to mount motors,
turbines, gears, or other products which are not
manufactured by Seller and which are not an integral
part of Seller's manufactured product, and a delay in the
delivery of such products to Seller occurs that will cause
a delay in Seller's performance date, Seller reserves the
right to ship its product upon completion of manufacture
and to refund an equitable portion of the amount
originally included in the purchase price for mounting
without incurring liability for non-performance.
D. Seller reserves to itself the right to change its
specifications, drawings and standards if such changes
will not impair the performance of its products, and
parts, and further that such products, and parts, will meet
any of Buyer's specifications and other specific product
requirements which are a part of this agreement.
E. The manufacture and inspection of products and
parts shall be to Seller's Engineering and Quality
Assurance standards plus such other inspections, tests of
documentation as are specifically agreed to by Seller.
Requirements for any additional inspection, tests,
documentation, or Buyer witness of manufacture, test,
and/or inspection shall be subject to additional charges.
4. TITLE AND RISK OF LOSS
Title and risk of loss shall pass to buyer upon delivery of
products at the designated Ex Works place (Incoterms
1990) unless other wise agreed by the parties.
5. EROSION AND CORROSION
It is specifically understood that products and parts sold
hereunder are not warranted for operation with erosive
or corrosive fluids. No product or part shall be deemed
to be defective by reason of failure to resist erosive or
corrosive action of any fluid and Buyer shall have no
claim whatsoever against Seller therefore.
6. WARRANTY AND LIMITATION OF
LIABILITY.
A. Seller warrants only that its product and parts, when
shipped, and its work (including installation,
construction and start-up), when performed will meet all
applicable specifications and other specific product and
work requirements (including those of performance), if
any, of this agreement, and will be free from defects in
materials and workmanship. With respect to products,
parts and work not manufactured or performed by Seller,
Seller's only obligation shall be to assign to Buyer, to the
extent possible, whatever warranty Seller requires from
the manufacturer. All claims for defective products or
parts under this warranty must be made in writing
immediately upon discovery and, in any event, within
one (1) year after initial start-up or eighteen (18) months
after shipment, whichever first occurs, and all claims for
defective work must be made in writing immediately
upon discovery and in any event, within one (1) year of
completion thereof by Seller. Defective items must be
held for Seller's inspection and returned to the original
f.o.b. point upon request. THE FOREGOING IS
EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES WHATSOEVER, EXPRESS,
IMPLIED AND STATUTORY, INCLUDING
WITHOUT LIMITATION, THE IMPLIED,
WARRANTIES OF MERCHANTABILITY AND
FITNESS.
B. Upon Buyer's submission of a claim as provided
above and its substantiation, Seller shall at its option
either (i) repair or replace its product, part or work at the
original place of delivery, or (ii) refund an equitable
portion of the purchase price.
C. THE FOREGOING IS SELLER'S ONLY
OBLIGATION AND BUYER'S EXCLUSIVE
REMEDY FOR BREACH OF WARRANTY AND,
EXCEPT FOR GROSS NEGLIGENCE, WILLFUL
MISCONDUCT, AND REMEDIES PERMITTED
UNDER THE PERFORMANCE, INSPECTION AND
ACCEPTANCE AND THE PATENTS CLAUSES
HEREOF, THE FOREGOING IS BUYER
EXCLUSIVE REMEDY AGAINST SELLER FOR
ALL CLAIMS ARISING HEREUNDER OR
RELATING HERETO WHETHER SUCH CLAIMS
ARE BASED ON BREACH OF CONTRACT. TORT
(INCLUDING NEGLIGENCE) OR OTHER
THEORIES. BUYER'S FAILURE TO SUBMIT A
CLAIM AS PROVIDED ABOVE SHALL
SPECIFICALLY WAIVE ALL CLAIMS FOR
DAMAGES OR OTHER RELIEF, INCLUDING BUT
NOT LIMITED TO CLAIMS BASED ON LATENT
DEFECTS. IN NO EVENT SHALL BUYER BE
ENTITLED TO INDIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES,
NOR FOR DAMAGES FOR LOSS OF USE, LOST
PROFITS OR REVENUE, INTEREST, LOST
GOODWILL, WORK OR PRODUCTION
STOPPAGE, IMPAIRMENT OF OTHER GOODS,
INCREASED EXPENSES OF OPERATION, OR
THE COST OF PURCHASING REPLACEMENT
POWER OR OTHER SERVICES BECAUSE OF
SERVICE INTERRUPTIONS. FURTHERMORE, IN
NO EVENT SHALL SELLER'S TOTAL LIABILITY
FOR DAMAGES OF BUYER EXCEED THE
PURCHASE PRICE OF THE PRODUCTS OR
PARTS MANUFACTURED BY SELLER AND
UPON WHICH SUCH LIABILITY IS BASED. ANY
ACTION ARISING HERE-UNDER OR RELATED
HERETO, WHETHER BASED ON BREACH OF
CONTRACT, TORT (INCLUDING NEGLIGENCE)
OR OTHER THEORIES, MUST BE COMMENCED
WITHIN ONE (1) YEAR AFTER THE CAUSE OF
ACTION ACCRUES OR IT SHALL BE BARRED.
7. PATENTS
Seller agrees to assume the defense of any suit for
infringement of any Canadian patents brought against
Buyer to the extent of such suit charges infringement of
an apparatus or product claim by Seller's product in an of
itself, provided (i) said product is built entirely to
Seller's design, (ii) Buyer notifies Seller in writing of
the filing of such suit within ten (10) days after the
service of process thereof, and (iii) Seller is given
complete control of the defense of such suit, including
the right to defend, settle and make changes in the
product for the purpose of avoiding infringement of any
process or method claims, unless infringement of such
claims is the result of following specific instruction
furnished by Seller.
8. EXTENT OF SUPPLY
Only products and listed in Seller's proposal are included
in this agreement. It must not be assumed that Seller
has included anything beyond same.
9. MANUFACTURING SOURCES
To maintain delivery schedules, Seller reserves the right
to have all or any part of the Buyer's order manufactured
at any of Seller's or its licensee's plants on a world-wide
basis.
