Installation, Operation & Maintenance Instructions for the
PRIER C-633 Mild Climate Commercial Wall Hydrant
*Please leave this sheet for the property owner*
Thank you for purchasing the PRIER C-633 Mild Climate Commercial Wall Hydrant, the nest quality commercial
hydrant available. Your C-633 will provide you years of dependable service with little or no maintenance.
Please note: Your C-633 hydrant has drain holes under the packing nut. After shutoff, the drain holes will allow water to
drain for a few moments to prevent freezing. This is normal and according to design.
Installation:
Installation procedures may vary slightly depending on the seat option purchased and the
installation inlet options. The C-633 wall hydrant is available with the following inlet options:
N1” MIP x 3/4” FIP
P1” Male SWT x 3/4” Female SWT
V3/4” ProPress Ready
Operation:
Operation of the C-633 Mild Climate Commercial Wall Hydrant is a simple process. Water ows through the hydrant after
turning the loose key one full turn counter-clockwise to the “on” position. The hydrant will achieve maximum ow at 2
1/2 full turns. Turn off the hydrant by turning the loose key clockwise to the “off” position. The hydrant will drain for a few
moments. If the dripping persists after a few moments, tighten the key slightly until the dripping stops. Be careful not to
overtighten the hydrant. The C-633 incorporates an integral atmospheric anti-siphon vacuum breaker that, in the rare
occurrence of a back siphonage, opens to the atmosphere preventing contamination of the water supply. As well as an
atmospheric vacuum breaker, the C-633 incorporates vacuum breaker check valve in the rare case that water is forced
backwards into the valve.
