Primacoustic FlexiFuser User manual

WWW.PRIMACOUSTIC.C O M
(QTY) Description:
(1) Top section
24” x 8” Black
(608mm x 200mm)
(1) Bottom section
24” x 8” Black
(608mm x 200mm)
(2) Side sections
46.75” x 8” Black
(1187mm x 200mm)
(1) Center divider
46.75” x 5” Black
(1187mm x 130mm)
(6) De ectors
46.75” x 3.5” Black
(1187mm x 88mm)
(1) Beveled upper
cross support
(1) Lower cross support
(1) Wall cleat
(1) Fabric wrapped
 berglass panel
(QTY) Description:
(18) Metal pins
(20) Wooden dowels
(10) Large  ush-mount
Phillips screws
(2) Heavy duty Phillips
screws
(2) Plastic drywall
anchors
TOOLS REQUIRED:
• Medium sized Phillips
screwdriver
• Bubble level
• Wall stud  nder
(recommended)
• Cordless drill and 1/8”
(3.5mm) drill bit
HARDWARE BAGBOX CONTENTS
OWNER’S MANUAL
Congratulations on purchasing the Primacoustic FlexiFuser™. The FlexiFuser is a 24” x 48”
x 8” high frequency diffuser that is placed behind the listener while spanning the width of the
listening area to scatter primary re ections, standing waves and  utter echo. A series of variable
pitch de ectors may be rotated to a desired position to dissipate sound energy and retain a
sense of air and ambiance in the room. Behind the slats, a 2” thick Broadway  berglass panel
eliminates internal re ections while augmenting mid and high frequency attenuation. Ideal for
studio and home theatre applications. Black frame with grey fabric panel.
Please take a few minutes to read this installation manual. It will give you step by step assembly
and mounting instructions. Please refer to www.primacoustic.com for various placement options
and bene ts. Should you have any questions or comments, we invite you to send an email to:
[email protected].
Before beginning assembly, please take a moment to familiarize yourself with the box contents.
It will include:
FLEXIFUSER™
Primacoustic is a division of Radial Engineering Ltd. • 1588 Kebet Way, Port Coquitlam, BC Canada V3C 5M5
Tel: [phone] • Fax [phone] • [email protected] • Copyright © 2017, All Rights Reserved Part # R870 2046 00 / 2017-08

21
ASSEMBLY INSTRUCTIONS
3 4
Insert four wooden dowels into the bottom section
Guide the side section onto the dowels and secure with
two large ush-mount Phillips screws from below.
Insert four dowels into the ends of the upper beveled rear
cross support and attach to the side section.
Insert four dowels into the ends of the lower rear cross
support and attach to the side section.
Guide the other side section onto the dowels and secure
with two large ush-mount Phillips screws from below.
Rest the berglass panel into the back of the frame. Insert two wooden dowels into the bottom section for the
center divider.
Guide the center divider onto the dowels and secure
with one large ush-mount Phillips screw from below.

ASSEMBLY INSTRUCTIONS
If the vertical deectors are to be xed in place insert
a second metal pin in the rear hole of each deector.
Skip this step if the deectors are to be movable and
continue to step-8.
REAR WALL: Angling the deectors in one
direction can prevent sound from bouncing
between parallel walls by redirecting sound.
Opposed and varied deectors distribute
sound in several directions helping to diffuse
reections.
5
7
6
8
Insert six metal pins into the bottom section.
Guide the six vertical deectors onto the pins.
Insert four wooden dowels into the side sections and
center divider.
Insert a metal pin into the middle hole of each
vertical deector.
Choose angles that work where the FlexiFuser will be
placed within the room.
Attach the top section. Ensure all the pins and
dowels are lined up correctly.
Secure the top section using ve large ush-mount
Phillips screws in the pre-drilled locations.
SIDE WALLS: Parallel deectors break up
primary reection when mounted to the rooms
side walls.
