JVC CA-D5T User manual

JVC MW:
COMPACT
COMPONENT
SYSTEM
KOMPACTES KOMPONENTENSYSTEM
SYSTEME DE COMPOSANTS COMPACT
KOMPACTO KOMPONENTEN-SYSTEEM
SISTEMA DE COMPONENTES COMPACT
IMPIANTO A COMPONENTI COMPATTO
CA-D5T
OS
DIGITAL AUDIO
INSTRUCTIONS
BEDIENUNGSANLEITUNG
INSTRUCTIONES
GEBRUIKSAANWIJZING
INSTRUCCIONES
ISTRUZIONI
E30580-2465A «
[ EF, G, Gl]

Warnings,
Cautions
and
Others
/
Warnung,
Achtung
und
sonstige
Hinweise
/Mises
en
garde,
précautions
et
indications
diverses
/Waarschuwingen,
voorzorgen
en
andere
mededelingen/
Avisos,
precauciones
y
otras notas /
Avvertenze
e
precauzioni
da
osservare
IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If the
plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point,
then obtain an appropriate safety approved extension
lead or consult your dealer.
BE SURE to replace the fuse only with an identical
approved type, as originally fitted.
If nontheless the mains plug is cut off ensure to remove
the fuse and dispose of the plug immediately, to avoid a
possible shock hazard by inadvertent connection to the
mains supply.
If this product is not supplied fitted with a mains plug then
follow the instructions given below:
IMPORTANT:
DO NOT make any connection to the terminal which is
marked with the letter E or by the safety earth symbol or
coloured green or green-and-yellow.
The wires in the mains lead on this product are coloured
in accordance with the following code:
Blue : Neutral
Brown: Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured
black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or coloured
red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRI-
CIAN.
Per I'ltalia:
"Si dichiara che il questo prodotto di marca JVC é conforme
alle prescrizioni del Decreto Ministeriale n.548 dei 28/08/95
pubblicato sulla Gazzetta Ufficiale della Repubblica Italiana
n.301 del 28/12/95."
Caution — POWER switch!
Disconnect the mains plug to shut the power off completely. The
POWER switch in any position does not disconnect the mains
line. The power can be remote controlled.
Achtung — POWER-Schaliter!
Den Netzstecker aus der Steckdose ziehen, um die
Stromversorgung vollkommen zu unterbrechen. Der Schalter
POWER unterbrichet in keiner Stellung die Stromversorgung
vollkommen. Die Stromversorgung kann mit der Fernbedienung
ein- und ausgeschaltet werden.
Attention — Commutateur POWER!
Déconnecter la fiche de secteur pour couper complétement le
courant. Le commutateur POWER ne coupe jamais complétement
la ligne de secteur, quelle que soit sa position. Le courant peut
étre télécommandeé.
Opgelet — POWER schakelaar!
Om de stroomtoevoer geheel uit te schakelen, trekt u de stekker
uit het stopkontakt. Anders zal er altijd een geringe hoeveetheid
stroom naar het apparaat lopen, ongeacht de stand van de
POWER schakelaar. U kunt het apparaat ook met de
afstandsbediening aan- en uitschakelen.
jAtenclén — Interruptor POWER!
Desconectar el cable de alimentacién para desactivar |a
alimentacién totalmente. Cualquier que sea la posicion de ajuste
del interruptor POWER, la alimentacién no es cortada
completamente. La alimentacién puede ser controlada
remotamente.
Attenzione — L’Interruttore POWER!
Disinserire 1a spina del cavo di alimentazione dalla presa della
rete elettrica per staccare completamente |’alimentazione.
L’interruttore POWER in nessuna posizione stacca la linea di
alimentazione elettrica principale. E possibile il controllo remoto
dell’alimentazione.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ACHTUNG
Zur Verhinderung von elektrischen Schiagen, Brandgefahr, usw:
1. Keine Schrauben lésen oder Abdeckungen enifernen
und das Gehause nicht 6ffnen.
2. Dieses Gerat weder Regen noch Feuchtigkeit
aussetzen.
ATTENTION
Afin d'éviter tout risque d'électrocution, d'incendie, etc.:
j. Ne pas enlever les vis ni les panneaux et ne pas
ouvrir le coffret de l'appareil.
2. Ne pas exposer l'appareil a la pluie ni a I'humidité.
G-1
VOORZICHTIG
Ter vermindering van gevaar voor brand, elektrische schokken,
enz.:
1. Verwijder geen schroeven, panelen of de behuizing.
2. Stel het toestel niet bloot aan regen of vocht.
PRECAUCION
Para reducir riesgos de choques eléctricos, incendio, etc.:
1. No extraiga los tornillos, los cubiertas ni la caja.
2. No exponga este aparato a la Iluviao ala
humedad.
ATTENZIONE
Per ridurre il rischio di shock elettrici, incendi, ecc...
1. Non togliete viti, coperchi o la scatola.
2. Non esponete l'apparecchio alla piogggia e
alfumidita.

Caution: Proper Ventilation
To
avoid
risk
of
electric
shock
and
fire,
and
to
prevent
dam-
age, locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No
obstructions
should
be
placed
in
the
areas
shown
by the dimensions below.
3 Bottom:
Place
on
the
level
surface.
Maintain
an
adequate
air
path
for
ventilation
by
placing
on
a
table
with
a
height
of 10 cm or more.
Wichtig: Ausreichende Beliftung
Zur
Vermeidung
von
elektrischen
Schlagen,
Feuer
und
sonstigen
Beschadigungen
gilt
flr
die
Gerateseiten
folgendes:
1 davor:
Hindernisfrei und gut zuganglich.
2 daneben/dariiber/dahinter:
Hindernisfrei
in
allen
angegebenen
Abstanden
(s. Abbildung).
3 darunter:
Absolut ebene Stellflache; ausreichende Beliiftung
durch Aufstetlen auf einem Tischchen von mindestens
10 cm Hohe.
Attention: Aération correcte
Pour
prévenir
tout
risque
électrique
ou
d’incendie
et
éviter
toute détérioration, placez |'appareil de la maniére suivante:
1 Avant:
Bien dégagé de tout objet.
2 Cétés/dessus/dos:
Ne laissez rien aux endroits indiqués dans les figures
ci-dessous.
3 Dessous:
Posez l'appareil sur une surface plane et
horizontale. Veillez 4 ce que sa ventilation correcte
puisse se faire en le plagant sur une table d’au moins
dix centimétres de hauteur.
Front view
Vorderansicht
Face
Vooraanzicht
Vista frontal
Vista frontale 15cm
Let op: Goede verluchting vereist
Om
brand,
elektrische
schokken
en
beschadiging
te
voorkomen, moet u het toeste! als volgt opstellen:
1 Voorkant:
Geen belemmeringen en open ruimte.
2 Zijkanten/boven-/onderkant:
Geen belemmeringen plaatsen in de hieronder
aangegeven zones.
3 Onderkant:
Op viakke ondergrond plaatsen. Voldoende
ventilatieruimte voorzien door het toestel op een tafeltje
met een hoogte van 10 cm of meer te plaatsen.
Precauci6n: ventilacién correcta
Para
evitar
el
riesgo
de
descargas
eléctricas
e
incendio
y
prevenir posibles dafios, instale el equipo en un lugar que
cumpla los siguientes requisitos:
1 Parte frontal:
Sin obstrucciones, espacio abierto.
2 Lados/parte superior/parte posterior:
No debe haber ninguna obstruccién en las areas
mostradas por las dimensiones de ia siguiente figura.
3 Parte inferior:
Situe el equipo sobre una superficie nivelada. Mantenga
un espacio adecuado para permitir el paso del aire y
una correcta ventilaci6n, situando el equipo sobre una
mesa de 10 0 mas cm de altura.
Attenzione: Per una corretta ventilazione
Per
prevenire
il
rischio
di
folgorazione
e
incendio
e
per
evitare danni, posizionare le apparecchiature come segue:
1 Parte anteriore:
Nessun ostacolo e spazio libero.
2 Lati/Parte superiore/Retro:
Lasciare liberi gli spazi indicati dalle dimensioni.
3 Base:
Posizionare su una superficie piana. Consentire ja
circolazione dell’aria mettendo l'impianto su un tavolo
alto almeno 10 cm.
Side view
Seltenansicht
Cété
Zijaanzicht
Vista lateral
Vista laterale 15cm

IMPORTANT FOR LASER PRODUCTS/ WICHTIGER HINWEIS FUR LASER-PRODUKTE / IMPORTANT POUR LES
PRODUITS LASER /BELANGRIJKE INFORMATIE VOOR LASERPRODUKTEN / IMPORTANTE PARA LOS
PRODUCTOS LASER / IMPORTANTE PER | PRODOTTI LASER
REPRODUCTION OF LABELS/ANBRINGUNGSORTE FUR LASER-PRODUKTE/REPRODUCTION DES ETIQUETTES/
VERKLARING VAN DE LABELS/REPRODUCCION DE ETIQUETAS/RIPRODUZIONE DELLE ETICHETTE
®
Go Oo 8 8 OS
—
G-3
CLASSIFICATION LABEL, PLACED ON REAR
ENCLOSURE
KLASSIFIKATIONSETIKETTE AN DER RUCKSEITE
ETIQUETTE DE CLASSIFICATION, PLACEE A
L'ARRIERE DU COFFRET
KLASSIFIKATIELABEL, OP DE ACHTERZIJDE VAN
HET APPARAAT
ETIQUETA DE CLASIFICACION, PEGADA EN LA
PARTE POSTERIOR DE LA CAJA
ETICHETTA Di CLASSIFICAZIONE, SITUATA SUL
RIVESTIMENTO POSTERIORE
CLASS 1
LASER PRODUCT
CLASS 1 LASER PRODUCT
DANGER: Invisible laser radiation when open and
interlock failed or defeated. Avoid direct exposure to
beam.
CAUTION: Do not open the top cover. There are no
user serviceable parts inside the Unit; leave ali
servicing to qualified service personnel.
LASER-PRODUKT DER KLASSE 1 7
GEFAHR: Unsichtbare Laserstrahiung bei Offnung
und fehlerhafter oder beschadigter Spre. Direkten
Kontakt mit dem Strah! vermeiden!
ACHTUNG: Das Gehdause nicht offnen. Das Gerat
enthalt keinerlei Teile, die vom Benutzer gewartet
werden k6énnen. Uberlassen Sie Wartungsarbeiten
bitte qualifizierten Kundendienst-Fachleuten.
PRODUIT LASER CLASSE 1
ATTENTION: Radiation laser invisible quand l'appareil
est ouvert ou que le verrouillage est en panne ou
désactivé. Eviter une exposition directe au rayon.
ATTENTION: Ne pas ouvrir le couvercle du dessus. II
n'y a aucune piéce utilisable a 'intérieur. Laisser a un
personnel qualifié le soin de réparer votre appareil.
®
© © © 88
DANGER: Invisible laser
radiation when open and
interlock failed or defeated,
AVOID DIRECT EXPOSURE
TO BEAM.
WARNING LABEL, PLACED INSIDE THE UNIT
WARNETIKETTE IM GERATEINNEREN
ETIQUETTE D'AVERTISSEMENT PLACEE A
L'INTERIEUR DE L'APPAREIL
WAARSCHUWINGSLABEL, IN HET APPARAAT
ETIQUETA DE ADVERTENCIA, PEGADA EN EL
INTERIOR DE LA UNIDAD
ETICHETTA DI AVVERTENZA, SITUATA
ALL'INTERNO DELL'APPARECCHIO
VARNING: Osynlig laser.
straining nar denna del ar
Oppnad och sparen a
utkopplad. Betrakta ¢j
(e) | | stalen. {3}
ADVARSEL: Usyniig laser-
straling ved abning, nar
sikkerhedsalbrydere er ude
af funktion. Undga udseet-
telse for straing (
alttina
sdteeseen.
KLAS 1 LASERPRODUKT
GEVAARLIJK: Onzichtbare laserstraling wanneer
open en de beveiliging faalt of uitgeschakeld is.
Voorkom het direkt blootstaan aan de straal.
VOORZICHTIG: De bovenkap niet openen. Binnenin
het toestel bevinden zich geen door de gebruiker te
repareren onderdelen: laat onderhoud over aan
bekwaam vakpersoneel.
PRODUCTO LASER CLASE 1
PELIGRO: En el interior hay radiacién laser invisible.
Evite el contacto directo con el haz.
PRECAUCION: No abra la tapa superior. En el
interior de la unidad no existen piezas reparables por
el usuario; deje todo servicio técnico en manos de
personal calificado.
PRODOTTO LASER CLASSE 1
PERICOLO: Radiazione laser invisibile quando
lapparecchio € aperto ed il dispositivo di sicurezza é
guasto 0 disattivato. Evitare I'esposizione diretta ai raggi.
ATTENZIONE: Non aprire il coperchio superiore. Non vi
sono parti adoperabili dall'utente all'interno di questo
apparecchio; lasciare tutti i controlli a personale qualificato.
VARO: Avattaessa ja suo-
jalukius ohitettaessa olet
nakymattémalla
lasersatelylle. Ala katso

HiumiMagic
COMPU" PLAY
Great sound
Triple Tray
Three timers
Thank you for purchasing the JVC Compact Component System.
We hope it will be a valued addition to your home, giving you years of enjoyment.
Be sure to read this instruction manual carefully before operating your new stereo system.
Here you will find all the information you need to set up and use the system.
For questions that are not be answered in the manual, please contact your dealer.
=
2.
r=)
=
boded
Features
With IflumiMagic COMPU PLAY, there is no mistake of which buttons to press for instant power on
and playback. If you approach the system, the sensor detects your action, illuminates the function
buttons and makes them blink. Once you’ve chosen the source — CD, for instance — everything
else happens automatically: power to the system is turned on, the input is set to CD, and CD
playback begins. That’s IllumiMagic COMPU PLAY, and it makes music just a touch away.
Messages appear on the display to guide you through the quick and easy operation of the functions
that apply to a blinking IllumiMagic COMPU PLAY button.
Pre-programmed live surround effects like D-CLUB (Dance Club), HALL, STADIUM as well as S.E.A.
effects like ROCK, POPS, and CLASSIC so you don’t have to be a sound engineer to get treat effects.
CD changer function can operate 3 discs.
¢ Discs can be changed during play using the TRIPLE TRAY.
* Continuous, program or random play of 3 discs.
The three timers, DAILY Timer, ONCE REC (Recording ) Timer, and SLEEP Timer are extremely easy to set.
How This Manual Is Organized
In this manual we have incorporated some special features:
¢ Basic information that is the same for many different functions is grouped in one place, and
not repeated in each procedure. For instance, in the section on playing a CD, we do not
repeat the information about setting the volume and the sound conditioning, which are
talked about in the Using the Amplifier section.
* Name of buttons and controls are written in all capital letters like this: POWER.
¢ When we are talking about the Function, rather than the BUTTON or DISPLAY, only the
first letter is capitalized.
The manual has a table of contents to help you easily look up what you want to know.
We’ ve enjoyed making this manual for you, and hope you will use it to enjoy the sound and many
features built into your CA-DST.
IMPORTANT CAUTIONS
1. Installation of the Unit
¢ Select a place which is level, dry and neither too hot nor too cold (Between 5°C and 35°C or
41°F - 95°F).
¢ Leave sufficient distance between the Unit and a TV.
* Do not use the Unit in a place subject to vibrations.
2. Power cord
* Donot handle the power cord with wet hands!
* Some power (17 watts) is always consumed as long as the power cord is connected to the
wall outlet.
« When unplugging the Unit from the wall outlet, always pull the plug, not the power cord.
3. Malfunctions, etc.
¢ There are no user serviceable parts inside. If anything goes wrong, unplug the power cord
and consult your dealer.
¢ Do not insert any metallic object into the Unit.
=,

Table of Contents
Getting Started ...........scsssscscccsssssssssesessosssssesssnssseseessceeessesnenseess
ACCESSOMIES f.i65s555 505.25, Sadivs asiccvesssesctdestaséavensversea covets,
Using the Remote Control ..........cccccscsssseseeee
Connecting the FM Antenna ...........cccccscssssssesessesserenceee
Connecting the AM (MW/LW) Antenna ...........0...0000
Connecting the Speakers .........ccccscceseeeeees
Connecting Auxiliary Equipment
DEMO Mode uu... eescscessseseseseseesscsssesessscsesessacsens
Turning the DEMO Display ON and Off
COMPU PLAY... fe .cneeiectek cedeencabiasdiiicrstcvesitosesvtshads
Stopping the IllumiMagic COMPU PLAY buttons
blinking and turning the guide display off ........... 7
Using the Amplifier ............-ssccssssssssssssseessssseessssssssssssesseessee
Turning Power ........cccccssessseeseeees
Turning the CA-D5T On
Turning the CA-DST Off .o....cccceescscceeseseeereesees
Adjusting the Volume .0........c.cccccsecssessesesesesessescsesusseseaes
FADE MUTING Function
Reinforcing the Bass Sound ...........ccceccscessessessssessesteeees
SOUN MOdeS .0.....essecsseseseescesesecsecsesesneseeesecscsssessesneaves
Preset S.E.A. (Sound Effect Amplifier) Effects ..... 10
Listening To Optional Equipment ...............ccccceeeee 10
Using the Tuner............sssssssssssesssssssssrsessssseessssscsuesserseeessennesens
One Touch Radio...
Tuning In a Station ccc cccsccecsessecsescsessecsssestevseses
Switching between Frequency Bands ...
Three ways to select a Station ........cccccseeeseesesseees
Presetting Stations oo... ssseseseceeseeeseecteeseeeesecseessees
To Change the FM Reception Mode ...........ccccsseeeeee
Using the CD Player ...........ss.ssssssssssscsssssssessssessssssessessseersssen 13
The Quickest Way To Start a CD Is With
the One Touch Operation .........cccccssseseteescstseees 14
Basics of Using the CD Player — Continuous Play..... 14
To Insert Discs 0.0... cscseseesecseeseseseseeseeesesseecesseseceees
To Change Discs While Playing
To Select a Disc, Track Or Passage
Within 4, Tack: .ccsiscsdics arse deecd eeecacvenn 16
Locating a Track With the Remote Control
Dirty scssccsdteseexces xcereseteesisisi int nidesves weds 16
Programming the Playing Order of the Tracks ............. 16
Random Play oo... cceccccessssesesssenseseseeesesesecssessrseas wae 18
Repeating a Selection Or the Discs ..... wa 19
Tray Lock Function o....cccccsccscscsescscseesscscsesesescssnavaees 19
Locking the Electronic LOcKk ........ccccccsssssseeseeeee 19
Unlocking the Electronic Lock ........ccccsceseeeeees 19
Using the Cassette Deck (Listening to a Tape)............... 20
One Touch Play
Regular Play ........cccccceeeees
Fast Left And Fast Right
MUSIC Scat ist scsisk descevsnanbonarvanietl ets taansva cea scstsedisieees
To Find the Beginning of the Current Song ........... 22
To Find the Beginning of the Next Song Bs
Other Useful Features of the Cassette Deck .................
Using the Cassette Deck (Recording) .............ssssessssees 23
Things To Know Before You Start Recording ....... 23
Standard Recording ......c.cccecccccssesssssssescsvsvevensnsveseesnees 24
To Record Any Sound Source To Tape .... 4
CD Direct Recording 00.0... eececesesesssssseseesssesesseeeeesees
Auto Edit Recording .........ccccessesesssesseescscscscsenseenseeees
Tape To Tape Recording (Dubbing) ...........0.c eee
How To Use the DUBBING Button
Recording With the Timer .0....cccccecsseseeseeseceees
Using the Timers. ............ssccssscssssssssssessssvssssccssessscessssnsessseesene
Clock Setting 00.0... eecceeeteestensneaees
Setting the DAILY Timer
Turning the DAILY Timer On and Off ..... ... 30
Setting the ONCE REC (Recording) Timer .......... ww 31
Turning the ONCE REC Timer On and Off........... 32
Setting the SLEEP Timer ..........cceccscsccccesece cesses teees 32
Timer: Priority ssisce.ccsiesscsesnctiissisiaxsecssiaceeasscvesasvsooiinte 33
Care And Maintenance ..........ssssssssssssssssssusessssecsssterssen 34
Troubleshooting ............cccsssssssssssssssessssssssssssessscecsesenesesseneneess 35
Specifications ..........scsssssssssssssssssssssssesccssssssussssserseneesees 3%

ferladiate mj elacete|
Accessories
=
a)
=
c
Lu)
Check to be sure you have all of the following things, which are supplied with the CA-DST.
AM (MW/LW) Loop Antenna (1)
Remote Control (1)
Batteries (2)
FM Wire Antenna (1)
If any are missing, contact your dealer immediately.
How To Put Batteries In the Remote Control
Match the polarity (+ and —) on the batteries with the + and — markings in the battery compartment.
R6P (SUM-3)/AA (15F)
CAUTION: Handle batteries properly.
To avoid battery leakage or explosion:
¢ Remove batteries when the Remote Control will not be used for a long time.
* When you need to replace the batteries, replace both batteries at the same time with new ones.
* Don’t use an old battery with a new one.
¢ Don’t use different types of batteries together.
Using the Remote Control
The Remote Control makes it easy to use many of the functions of the CA-DST from a distance of
up to 23 feet away.
You need to point the Remote Control at the remote sensor on the CA-D5ST’s front panel.
Remote sensor
fe Sea |
Ee
———— » Di
OG Pitter Ss
a

<=
as
i)
c
Lid -
CAUTION: Make all connections before plugging the Unit into an AC power outlet.
Connecting the FM Antenna
A. Using the Supplied Wire Antenna
The FM Wire Antenna provided can be connected to a
FM 75-ohm COAXIAL as temporary measure.
Extend the supplied wire antenna horizontally.
For Germany
B. Using the Coaxial Type Connector (Not Supplied)
A 75-ohm antenna with coaxial type connector (DIN
45 332) should be connected to the FM 75-ohm
COAXIAL terminal.
For Other Countries
C. Using an FM 75-Ohm Antenna Cable (Not Supplied)
Connect the FM connector on the FM 75-ohm
COAXIAL terminal.
FM Wire Antenna
If reception is poor,
connect the outside
antenna.
Before attaching a 75 ohm coaxial lead
(the kind with a round wire going to an
outside antenna), disconnect the supplied
FM Wire Antenna.
CAUTION:
To
avoid
noise,
keep
antennas
away
from
metallic
parts
of
the
CA-D5T,
connecting
cord
and
the
AC
power
cord.

CAUTION: Make all connections before plugging the Unit into an AC power outlet.
Connecting the AM (MW/LW) Antenna
=
4
=
Cc
Libel
AM antenna wire If reception is poor, connect the outside antenna.
Note: Even when connecting
an outside AM antenna,
keep the indoor AM loop
connected.
AM Loop Antenna
Turn the loop until you
have the best reception
Snap the tabs on the loop
into the slots of the base to
attach the AM Loop.
Connecting the Speakers (Please refer to instructions for speakers as will when you connect speakers.)
pct ciate Ce a A A AAAS AACR RS i rm ai ep
For each speaker connect one end of the speaker wire to the speaker terminals on the back of the
CA-DST and one end to the speaker.
1. Open each of the terminals and insert the speaker wires firmly (be sure to remove the insulation
at the end of each wire first), then close the terminals.
2. Connect the red (+) and black (—) terminals of the right side speaker to the red (+) and black
(—) terminals marked RIGHT on the CA-DS5T.
Connect the red (+) and black (—) terminals of the left side speaker to the red (+) and black (—)
terminals marked LEFT on the CA-DST.
Left speaker
Right speaker -
IMPORTANT: Use speakers with the correct impedance only. The correct impedance is indicated on
the back panel.
CAUTION:
If
a
TV
is
installed
near
speakers,
the
TV
may
display
irregular
colors.
In
this
case,
set
the
speakers
away
from
the
TV.

CAUTION: Make all connections before plugging the Unit into an AC power outlet.
Connecting Auxiliary Equipment
=
BL
=
fat
Li
AUX
RIGHT LEFT
VCR or other equipment
To listen to these sources, press
the AUX button
Now you can plug the AC power cord into the wall outlet, and your CA-D5T is at your command!
DEMO Mode
When the CA-DST is connected to an AC power outlet, a DEMO mode displaying some of the
system’s features starts.
The DEMO display cycles through the following items repeatedly.
* Scrolling display of “DEMO MODE”.
* Demo of IllumiMagic COMPU PLAY buttons.
¢ Source Indicator.
« DISC-1 to DISC-3 Indicator.
¢« Demo of Live Surround effects and S.E.A effects.
¢ Demo of CD RANDOM PLAY.
* Demo of ACTIVE BASS EXTENSION.
*« Demo of pre-setting of up to 40 FM/AM channels.
The DEMO display stops when the power is turned on. ;
The DEMO display will start again about one minute after the CA-DST is set to STANDBY mode
(the red STANDBY indicator is on).
Turning the DEMO Display ON and Off
The DEMO display can be turned on and off when the system is in STANDBY mode.
To turn the DEMO display off, press the DEMO button while in DEMO mode. The display changes
from the DEMO display to the clock display after “DEMO OFF” light up on the display.
To turn the DEMO display on, press the DEMO button. The display changes from the clock display
to the DEMO display.
Note: The DEMO display automatically starts when the power cord is inserted into a wall outlet. To
stop the DEMO display when the power cord is inserted into the wall outlet, press the DEMO button
to turn the DEMO display off.

COMPU PLAY
COMPU PLAY is JVC’s feature that lets you control the most used functions of the CA-DS5T with a
single touch.
What
COMPU
PLAY
does
is
to
automatically
turn
on
the
power
and
start
the
function
you
have
specified.
With
IllumiMagic
COMPU
PLAY,
when
you
approach
the
system
to
use
a
function,
the
sensor
detects
your
action,
illuminates
the
function
buttons
and
displays
“PRESS
ANY
BLINKING
KEY”
on
the
display.
Not
all
COMPU
PLAY
buttons
blink
with
the
IllumiMagic
COMPU
PLAY
function.
=
2
=)
J
Ll
IltumiMagic COMPU PLAY buttons
The CD, FM/AM, TAPE, AUX, DISC-1, DISC-2 and DISC-3 buttons on the Unit.
Buttons that do not blink
On the Unit
CD Player & buttons.
On the Remote Control
AUX button
TUNER button
CD player Play (®) button
CD Player DISC-1 to DISC-3 buttons.
CD player Open/Close (4) button
Cassette player Play (<4 or >) buttons
The
functions
performed
when
the
you
use
the
IllumiMagic
COMPU
PLAY
buttons
are
explained
in
the
relevant
section
for
each
function.
Stopping
the
IllumiMagic
COMPU
PLAY
buttons
blinking
and
turning
the
guide
display
off
When
the
system
is
in
STANDBY
mode,
press
the
POWER
button
on
the
CA-DST
while
holding
down
the
STOP/CANCEL
@
button.
“GUIDE OFF” appears in the display.
aes Ay sia Sie | oe ane as a
out peur]
To start IlumiMagic COMPU PLAY blinking again, repeat this operation.
“GUIDE ON” appears in the display.
T TI |
Lt il Li
el
Lan)
ja,
|
J
a)
Cc
Note:
IliumiMagic
COMPU
PLAY
buttons
may
interfere
with
the
remote
control
operation
of
TV's
and
other
remote
controlled
equipment.
If
this
occurs,
turn
off
the
IlumiMagic
COMPU
PLAY
blink
function

Using the Amplifier
=
o
>
Lh
SOUND
MODE
VOLUME
PHONES AUX
POWER
Source, Sound Mode etc. Volume Level
VOLUME
-,+
Sound Mode frequency line
SOUND FADE
MODE MUTING
When the CA-DST is being used, the display shows other items as well.
However, we have only shown the items described in this section.
Turning Power
Turning the CA-D5T On
Saber Press the POWER button.
The displays come on and the Standby indicator goes out.
(=) The CA-DST comes on ready to do whatever it was doing when the power was last shut off.
If the last thing you were doing was listening to a tape in Deck B, you are now ready to listen to
a tape again in Deck B, or you can change to another source.
1 If you were listening to the Tuner last, the Tuner comes on playing the station it was last set to.
Turning the CA-D5T Off
b—4 Press the POWER button again.
The Standby indicator lights up and the displays blank, except for the clock display.
(=) { Some power (17 watts) is always consumed even though power is turned off (called Standby
Mode).
Q) To switch off the Unit completely, unplug the AC power cord from the AC outlet. When you
unplug the AC power cord, the clock will reset to 0:00 right away, and preset Tuner stations will
be erased after a few days.

Adjusting the Volume
ae
Turn
the
VOLUME
control
clockwise
to
increase
the
volume
or
counterclockwise
to
decrease
it.
Turning
the
VOLUME
control
quickly
also
adjusts
the
volume
level
quickly.
When
use
the
Remote
Control,
press
the
VOLUME
+
button
to
increase
the
volume
or
press
the
VOLUME
-
button
to
decrease
it.
rn
an
yn
oF
.
eee
ee
o
es...
u
VOLUME
VOLUME VOLUME
Cc)
Cy)
Display
when
the
volume
Display
when
the
volume
Display
when
the
volume
level
is
set
to
0
level
is
set
to
20
level
is
set
to
its
maximum
level
=
@
a
Lt
For private listening
Connect
a
pair
of
headphones
to
the
PHONES
jack.
No
sound
comes
out
of
the
speakers.
Be
sure
to
turn
down
the
volume
before
connecting
or
putting
headphones.
CAUTION:
The
Volume
cannot
be
adjusted
while
the
Unit
is
in
STANDBY
mode.
DO
NOT
turn
on
the
Unit
and/or
start
playing
any
source
without
setting
the
VOLUME
control
to
0;
otherwise,
the
sudden
blast
of
sound
can
damage
your
hearing,
speakers
and/or
headphones.
are FADE MUTING Function
C5
Set
the
Volume
Level
to
0
by
pressing
the
FADE
MUTING
button
on
the
Remote
Control.
Press
this
button
again
to
restore
the
Volume
Level
to
its
previous
level.
Reinforcing the Bass Sound
The
richness
and
fullness
of
the
bass
sound
is
maintained
regardless
of
how
low
you
set
the
volume.
You
can
use
this
effect
only
for
playback.
ansg
ex
To
get
the
effect,
press
the
ACTIVE
BASS
EX.
(Active
Bass
Extension)
button.
“ACT-BASS”
appears
in
the
display
and
the
ACTIVE
BASS
EX.
indicator
lights
up.
gar T zt] E.
| = ASS
To
cancel
the
effect,
press
the
button
again.
The
message
“OFF”
appears
in
the
display
and
the
ACTIVE
BASS
EX.
indicator
goes
out.
ge
ae
Lil
J
Sound Modes
The
CA-DST
has
some
preset
sound
effects
that
give
you
control
of
the
way
your
music
sounds,
so
_
you
can
tailor
it
for
your
room
and
for
the
quality
of
the
source.
We
can
give
you
some
idea
of
how
each
one
affects
the
music,
but
the
only
way
to
really
tell
is
to
try
them
yourself.
You
can
use
only
one
effect
at
a
time,
selecting
from
the
Live
Surround
or
S.E.A.
effects
is
only
possible
for
playback
mode.
Live Surround Effects
With
these
effects,
the
sound
coming
from
only
two
speakers
approaches
the
quality
of
sound
from
four speakers.
D-CLUB
(Dance
Club)
Increases
resonance
and
bass.
HALL
Adds
depth
and
brilliance
to
the
sound,
like
in
a
concert
hall.
STADIUM
Adds
clarity
and
spreads
the
sound,
like
in
an
outdoor
stadium.

SOUND MODE
or
SOUND
Preset S.E.A. (Sound Effect Amplifier) Effects
Adjustments
of
frequency
range
levels
have
been
preset
as
three
S.E.A.
effects.
ROCK Boosts low and high frequencies.
POPS Good for vocal music.
CLASSIC
Set
for
wide
and
dynamic
sound
stereo
systems.
To
get
an
effect,
press
the
SOUND
MODE
button
repeatedly
until
the
Sound
Mode
you
want
appears
in
the
display.
Each
time
you
press
the
button,
the
modes
change
as
follows:
[
D,
CLUB—>HALL——>
STADIUM
——>
ROCK
——>POPS
—>
CLASSIC
—>
OFF
"1
{1
The
display
changes
to
display
appropriate
information
for
the
Sound
Mode
you
have
selected.
When D-CLUB, HALL or STADIUM SOUND) [LIVE
(Live Surround effects) are selected. Mone sureoNo)
When ROCK, POPS or CLASSIC
{S.E.A. effects) are selected.
When Sound Mode OFF is selected.
To
cancel
an
effect,
press
the
Sound
Mode
button
until
“OFF”
appears
in
the
display.
Listening To Optional Equipment
cone
10
©
By
playing
the
sound
from
auxiliary
equipment
through
the
CA-DST,
you
can
gain
control
over
how
the
music
or
program
sounds.
Once
the
connected
equipment
is
playing
through
the
CA-DST,
you
can
apply
the
sound
effects,
make
recordings,
or
listen
with
the
headphones.
Q
First
make
sure
that
the
optional
equipment
is
properly
connected
to
the
CA-DST.
(See
page
6).
7. Set the VOLUME control to 0.
2. Press the AUX button.
The Unit automatically turns on and “AUX” lights up on the display.
3. Start playing the selected equipment.
4, Adjust the VOLUME control to the desired listening level.
5. Select a sound effect mode, if you wish.
To Cancel the Setting
Change
the
source
by
starting
any
one
of
the
CA-D5T’s
built-in
sound
sources,
such
as
the
Tuner
or
CD
Player.

Using the Tuner
FM/AM TUNING <<, >>
Display
Band
display,
Frequency
display
Preset
channel
When
the
CA-DST
is
being
used,
the
display
shows
other
items
as
well.
However,
we
have
only
shown
the
items
described
in
this
section.
You
can
listen
to
both
FM
and
AM
(MW/LW)
stations.
Stations
can
be
tuned
in
manually,
automati-
cally,
or
from
preset
memory
storage.
Q
Before
listening
to
the
radio:
«
Check
that
both
the
FM
and
AM
(MW/LW)
antennas
are
firmly
connected.
(See
page
4
and
5).
One Touch Radio
Just
press
the
FM/AM
button
(or
the
TUNER
button
on
the
Remote
Control)
to
turn
on
the
Unit
and
Start playing the most recent station tuned in.
Q
You
can
switch
from
any
other
sound
source
to
the
radio
by
pressing
the
FM/AM
button
(or
the
TUNER
button
on
the
Remote
Control).
Tuning In a Station
TUNER
Of:
Press
the
FM/AM
button
(or
the
TUNER
button
on
the
Remote
Control)
to
turn
on
the
radio.
The
frequency
of
the
previously
selected
channel
appears
on
the
display.
Switching between Frequency Bands
Press the FM/AM button.
Each
time
you
press
the
button,
the
band
alternates
between
FM
and
AM
(MW/LW).
117
=
w
>)
=
uw

Three ways to select a station
CHJuiiSenf=7 Press the TUNING << or bP button on the Unit repeatedly to move from frequency to
frequency until you find the one you want. (Manual Tuning).
OR
Hold down the TUNING <¢ or ® button on the Uint, the frequency starts changing on the
display. When a station is tuned in, “TUNED” lights up on the display and the frequency stops
changing. (Auto Tuning).
OR
{) (Possible only after presetting stations.)
Press once and release the <4 or >i button on the Unit to go to the next preset station, or
hold the k¢<4 or >i button on the Unit to cycle through the preset stations: release the button
when the preset station you want shows on the display.
You can also use the Remote Control to tune in preset channels:
1. Press the TUNER button so that you can receive the most recent station tuned in.
2. Select the station by entering the preset number in the numeric keys of the Remote Control.
Q Example: for channel 5, press 5. For channel 15, press +10 then 5. For channel 20, press
+10, then 10. For channel 32, press +10 three times, then 2.
Presetting Stations
You can store up to 40 of your favorite radio stations (FM and AM (MW/LW)) in memory, giving
you quick, easy access to the stations.
7. Select a band by pressing the FM/AM button.
2 2. Press the TUNING << or >> button on the Unit to tune in a station.
Geto) 3. Press the SET button.
The SET button indicator comes on, the preset number and “MEMORY” appears in the display
and blinks for five seconds.
3 = { During these five seconds while blinking, you can assign a channel number to the station
: and enter it into the memory.
4. Select a channel number by pressing the <4 or >> button on the Unit until you find the
channel number you want.
4.
5. Press the SET button and the station will be assigned to the channel number showing on the
display.
“MEMORY” appears in the display.
ha fo pd TE CT
oxo Pik Vice |
QO Ifa station has been previously stored using the same channel number, this will be erased
and the newly selected station will be stored.
QO If the “MEMORY” indicator goes off, start again from step 3.
5.
6. Repeat steps 1 - 5 for each station you want to store in memory with a preset number.
CAUTION: If the Unit is unplugged or if a power failure occurs, the preset stations will be erased in
a few days. If this happens, preset the stations again.
To Change the FM Reception Mode
When an FM stereo broadcast is hard to receive or noisy, press the FM MODE/MUTE button (or
FM MODE button on the Remote Control) so that the “AUTO” indiactor goes off in the display.
Reception improves, but there are no stereo effects, In this monaural mode, noisy comes out while
tuning in stations (since muting is also canceled).
oe ae To restore the stereo effect, press the FM MODE/MUTE button (or the FM MODE button on the
Remote Control) so that the “AUTO” indicator lights up. In this stereo mode, no noise comes out
while tuning in stations, and you can hear stereo sounds when a program is broadcast in stereo.

Using the CD Player
REPEAT
4 £ PROGRAM/RANDOM
5 Oo
toi Oh
L@ i= @4 Disc buttons
Lice ox
ed
|
OAR
a a |
CD MANUAL SEARCH <<, >>
Numeric keys
Display
Disc display Track number, Playing time, step number
cD1OKEY | [ows STAT Nd fl fil Ra Nd fi AY,
| Se a
het Gaeta @ ‘
®
All track numbers of the loaded CD
CD Player control buttons When the CA-DST is being used, the display shows other items as well.
However, we have only shown the items described in this section.
Disc indicator
Each Disc button has a disc indicator. This indicator is off when the CD Player is checking that there
is no disc in the disc tray for the corresponding disc number.
Pressing the & button turns the indicator on.
a Disc display
3
A red marker lights on the disc display for the disc number you have selected. This disc display
&. blinks while a CD is being played.
The center of the disc display is not lit while CD Player is checking that there is no disc in the disc
1 tray for the corresponding disc number.
Disc marker
13

=
wo
=
=
uw
The CA-DST’s CD Player has an Automatic Changer with 3 disc trays. You can use Continuous,
Random,
Program
or
Repeat
Play
for the
discs
in
DISC-1,
DISC-2
and
DISC-3.
Repeat
Play
can
repeat all the tracks on all the CD’s, the tracks on one of the CD’s or one track on one CD.
There is also the Tray Lock function, which safely keeps discs in the trays.
Here are the basic things you need to know to play a CD and locate the different selections on it.
Each selection is called a track, so when we are talking about locating a track, we are also talking
about how you find a certain song or performance.
The Quickest Way To Start a CD Is With the One Touch Operation
The power comes on, and operations are done automatically.
Q Press the CD button (or the ® button on the Remote Control).
¢ If there is a CD in the disc tray of the selected (lit) disc number, playback continues from the
track where it was interrupted.
*
If
there
is
no
CD
in
any
of
the
disc
trays,
the
message
“OPEN”
appears
in
the
display
after
a
few seconds and the disc tray for the marked disc opens.
QO Press a DISC button (1 to 3).
¢ If there is a CD in the disc tray for the disc number you have selected, playback begins from
the first track of that disc. If there is no CD in the disc tray, the message “OPEN” appears in
the display after a few seconds and the disc tray opens.
Q Press the & button.
¢ The power turns on, and the tray opens automatically.
Basics of Using the CD Player — Continuous Play
14
eels
or
0-0-0:
You can play the discs continuously in the DISC 1 to DISC 3 trays.
,
To Insert Discs
7. Press the 4 button on the right of the tray you want to insert the disc into.
The disc tray slides out automatically.
2. Puta CD, with its label side up, into the tray.
ATTENTION: To avoid malfunctions when you play a CD, please set the CD in the right place at
the center of the tray.
CD
CORRECT INCORRECT
3. Press the & button to close the tray.
Tray
4. Repeat steps 1 to 3 to insert other discs into other trays.
Q1 To continue putting discs into other trays, even if a tray is open, by pressing the & button of
another disc tray, the open tray will close automatically, and the new disc tray will slide out.
Q To put an 8 cm CD into a tray, insert it so that it is aligned with the groove in the tray’s center.
OQ) “OPEN” appears in the display when a tray opens, and “CLOSE” when a tray closes.
Note: When the CD Player is reading a disc, “- - - -” appears in the display. While this is being
displayed, the 4 button or DISC button cannot be used. Once the display changes from “- - - -” to
another display, the & button and DISC button can be used.

To Play a Disc
This function plays the disc in the Unit continuously.
1. Prepare the discs.
Z. Press the DISC button (1-3) of the disc to play.
The first track of the selected disc will begin playing.
When the selected disc finishes playing, the next disc will begin playing automatically.
When the last disc has finished playing, the Unit will stop automatically.
=
”n
m
=
Lid
(1) When a DISC button is pressed while a tray is open, the open tray will close automatically and
Continuous Play playback begins from the first track of the disc.
To use Continuous Play from the first track of the disc selected by the disc marker, you do not need
to press a DISC button (1-3), just press the CD button (or > button on the Remote Control).
Playing order of discs
Q When playback starts from DISC-1, the playing order is DISC-1 -* DISC-2 + DISC-3. When
DISC-3 has finished, the CD Player selects DISC-1 (the disc marker is on) and stops.
Q When playback starts from DISC-2, the playing order is DISC-2 > DISC-3 + DISC-1. When
DISC-1 has finished, the CD Player selects DISC-2 (the disc marker is on) and stops.
{When playback starts from DISC-3, the playing order is DISC-3 > DISC-1 + DISC-2. When
DISC-2 has finished, the CD Player selects DISC-3 (the disc marker is on) and stops.
¢ If any of the disc trays are empty, the CD Player skips that disc tray and continues through
the remaining disc trays in the order shown above.
Note: If there is no CD in disc tray for the DISC button you pressed, the message “OPEN” appears
in the display and the disc tray automatically opens.
If there is no disc in the disc tray for the selected disc number, when the CD button (or the ® button
on the Remote Control) is pressed, playback begins from the next disc.
To stop play the disc, press the ll button (or the ™ button on the Remote Control) for the disc
number being played.
To stop play and remove the disc, press the & button (or the & button on the Remote Control) for
the disc being played.
To pause, press the CD button. The CD button and the Disc display will blink. (The Pause function
cannot be used with the button on the Remote Control.)
To cancel pause, press the CD button again. Play continues from the point where it was paused.
RESUME
When the STOP/CANCEL @ button (or the @ button on the Remote Control) is pressed during
playback, and the source is changed, the track number is memorized even when the power is turned
off. The next time the CD button (or the > button on the Remote Control) is pressed, play resumes
from the track where it was interrupted.
(2 To start playback from the first track, press the DISC button.
To Change Discs While Playing
You can replace a CD in a tray not being used, while another CD is playing.
7. Press the 4 button of the tray not being used.
The tray opens.
2. Replace the disc in the tray.
3. Press the 4 button to close the tray.
15

Rel
cD
10KEY
To Select a Disc, Track Or Passage Within a Track
7. Press the DISC button (1-3) for the disc tray containing the track you want to listen to.
Q Example: for the third disc, press 3.
2. Press the 4< or >> button to select the track.
The selected track starts playing.
Q Each time you briefly press and release the Kd or > button, the track changes by one.
¢ Press and release the 1 button to go ahead one track at a time.
¢ Press and release the ké<4 button to go back one track at a time.
* Holding down the k¢<4 or ®P1 button allows you to change tracks continuously.
QO Holding down the MANUAL SEARCH <4 or > buttons, during playback, will fast
forward/backwards the CD so you can quickly find a particular passage in the selection you
are listening to. (The fast forward/backwards function cannot be used from the Remote
Control.)
Locating a Track With the Remote Control Directly
Using the numeric keys on the Remote Control allows you to go directly to the beginning of any
track.
7. Press the DISC button (1-3) for the disc tray containing the track you want to listen to.
Q Example: for the third disc, press 3.
Z. Press the CD 10KEY button.
3. Enter the number of the track you want to listen to with the numeric keys.
The selected track starts playing.
Q Example: for track 5, press 5. For track 15, press +10 then 5. For track 20, press +10, then
10. For track 32, press +10 three times, then 2.
Programming the Playing Order of the Tracks
PLAY MODE
16
You can change the order in which the discs and tracks play, and select only the discs and tracks you
want from among those loaded in the CD Player.
By using the Remote Control, you can easily program tracks.
Q You can program up to 32 steps in any desired order from among the discs in the player.
Q You can only make or change a program when the CD Player is stopped.
Using the Remote Control
1. Press the PLAY MODE button.
The message “PROGRAM” appears in the display and the PROGRAM indicator comes on.
If a program is already running, the track number blinks.
(2 The display changes with each press of the PLAY MODE button, as shown below.
— PROGRAM ~ RANDOM > Off (Continuous Play) -> (back to the beginning)
