Primal Vantage Field & Stream HEH00770 User manual

B
B
F
D
E
I
G
H
J
K
N
F
C
A
M
O
SAFETY MUST BE YOUR FIRST PRIORITY WITH THIS PRODUCT
*Blind not shown
Every year serious injury and even death occurs from hunting related falls. To ensure your safety, please COMPLETELY
read and follow this safety manual and ALL warning labels BEFORE assembling, installing or utilizing this product.
DO NOT USE THIS PRODUCT BEFORE FULLY UNDERSTANDING ALL SAFETY WARNINGS AND INSTRUCTIONS. IF YOU
HAVE QUESTIONS, ARE UNSURE ABOUT ANY INFORMATION OR NEED ADDITIONAL INFORMATION CONCERNING
YOUR PRODUCT, CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT 1-866-972-6168 OR VISIT
PRIMALVANTAGE.COM/FIELD-STREAM. KEEP AND MAINTAIN THIS SAFETY AND INSTRUCTION MANUAL IN A SAFE
LOCATION FOR FUTURE REFERENCE.
The Field & Stream trademark is owned by American Sports Licensing Inc., and is not associated with Field & Stream Licenses
Company, LLC or Field & Stream Magazine.
W A R N I N G
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120 ©2019 (rev. 1/19)
MODEL: HEH00770 • Tree Size: 9”-18” diameter
• NEVER Leave Roof Installed When Not In Use
OUTPOST 2X ROOF & BLIND

Roof/Blind Cover (1)
Right Frame Support (2)
Side Brace (2)
Spring Pins
Front Frame Corner (2)
Spring Pins
Rear Frame Corner (2)
Front Brace (1)
Bottom Tree
Brace (1)
Left Frame Support (1)
Top Tree Brace (1)
Pole (3)
J-Hook
Buckle (1)
Skirt (1)
1 Left Rail Support Brace...........Part # RK-1015
2 Front Frame Corners..............
2 Rear Frame Corners...............
Part # DFF-100
Part # DRF-100
2 Side Brace.............................. Part # DSB-770
Part # DVS-591
1 Right Rail Support Brace........ Part # RK-1020
1 Roof/Blind Cover.....................
Part # RK-1025
Part # DTB-510
1 Front Brace.............................
Part # DBC-583
1 TopTree Brace........................
1 Vertical Support......................
Part # DTB-500
1 Bottom Tree Brace.................
Part # WB-100
2 Bracket...................................
1 J-Hook Buckle Strap...............
2 M8x55mm Bolt........................Part # 1255
40 2 M6x40mm Bolt........................Part # 1040
1 M6 Knob................................. Part # 1600
55
Part # RK-9035
3 Poles.......................................Part # DTP-200
1 Skirt........................................ Part # DST-583
MODEL: HEH00770 • Tree Size: 9”-18” diameter
• NEVER Leave Roof Installed When Not In Use
OUTPOST 2X ROOF & BLIND
Vertical Support (1)
Two holes on side
1 M8x45mm Bolt........................Part # 1245
45
ROOF KIT HARDWARE BLISTER PACK
1255
O
1245
1040
B
C
D
E
F
G
H
J
K
M
N
O
P
A
I
PARTS LIST
AB
CD
Bracket (2)
H
N
G
P
KM
E
I
F
J
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream

Assembly Instructions Page 1 Model: HEH00770
Outpost 2x Roof And Blind
Slide each Side Brace F onto the other end of Front Frame Corner A .
There are three holes on each side brace that MUST be facing the inside
of the frame. SEE CLOSEUP
A
F
F
IA
Spring Pins
Slide Front Brace I onto Front Frame Corner A .
AA
I
Spring Pin Spring Pin
F
A
Spring Pin
1
2
1
2
Closeup
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream

E
B
Spring Pins
B
B
Spring Pin Spring Pin
BE
Slide each Rear Frame Corner B into Side Braces F .B
A
B
F
A
F
I
E
Assembly Instructions Page 2
3
4
4
3
Slide each Rear Frame Corner B into Top Tree Brace E .
The “U” part of the brace MUST be on top of the frame.
SEE CLOSEUP
Closeup
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream
Model: HEH00770
Outpost 2x Roof And Blind

NOTE: ALL WASHERS
ARE AGAINST THE
BOLT HEAD AND THE
NUT UNLESS STATED
OTHERWISE
Attach Left Frame Support Brace C to the left Side
Brace F using 1-M6x40mm bolt .
C
F
D
F
Attach Right Frame Support Brace D (the one with the nut
on it) on the Right Side Brace F using 1-M6x40mm bolt .
Assembly Instructions Page 3
5
5
6
6
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream
Model: HEH00770
Outpost 2x Roof And Blind
40
40
40
40

E
J
55
55
Attach Vertical Support J to Top Tree Brace E with
1-M8x55mm bolt .
Assembly Instructions Page 4
Attach both Brackets G to the center hole of Vertical Support J using
1-M8x45mm Bolt .
Attach Bottom Tree Brace H to Vertical Support J using 1-M8x55mm Bolt .
J
G
55 H
45
7
7
NOTE: ALL WASHERS
ARE AGAINST THE
BOLT HEAD AND THE
NUT UNLESS STATED
OTHERWISE
8
8
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream
Model: HEH00770
Outpost 2x Roof And Blind
45
55

C
DO
Attach Left and Right Frame Support Brace to
Vertical Support J using M6 Knob O . The Knob
will go through Left Frame Support Brace C then
through Vertical Post J then tightened through
Right Frame Support Brace D. SEE CLOSEUP
J
C
D
O
J
Assembly Instructions Page 5
NOTE: ALL WASHERS
ARE AGAINST THE
BOLT HEAD AND THE
NUT UNLESS STATED
OTHERWISE
9
9
Closeup
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream
Model: HEH00770
Outpost 2x Roof And Blind

M
B
A
F
M
A
F
B
10. Insert top Pole M into Front Frame Corner A .
Insert middle Pole M into Side Brace F .
Insert bottom Pole M into Rear Frame Corner B .
Attach Roof/Blind Cover K to the assembled roof
frame by using the self sticking fabric strips on the
front, rear and sides of the frame.
Turn the assembled Roof over so the frame is underneath. Pull
the Blind Sides out so the camo is on the outside.
Roll up the Blind Sides and tie them to the attached ties on the
Roof.
Assembly Instructions Page 6
10
11
12
10
11
12
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream
Model: HEH00770
Outpost 2x Roof And Blind

Raise the Roof Assembly to the tree using a safe
hoist/lift system to 3 feet above the shooting rail of your
treestand.
BUCKLE STRAP INSTRUCTIONS
Attach the Vertical Support to the tree by using J-Hook Buckle
Strap N .
Hook Buckle Strap N to Bracket G . Wrap the strap around the
tree once and attach the other end to the bracket. (See Buckle
Strap Instructions). Pull strap until it is tight against the tree.
Assembly Instructions Page 7
13
14
You MUST use a Hoist system to lift
the Roof to the Stand for installation
DO NOT climb the Ladder with the
Roof and Blind in Hand
NEVER stand on seat platform to
attach roof. Raise flip-up seat
platform to move closer to tree.
O
N
G
13
3Pull strap to desired
length.
Hold buckle as shown.
1
2Press down on latch and
insert strap underneath
teeth as shown.
4Pull slack to tighten.
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
©2019 (rev. 1/19)
primalvantage.com/field-stream
Model: HEH00770
Outpost 2x Roof And Blind

W A R N I N G
ALWAYS read and understand all warnings and instructions
before each use of this product. Failure to read and
understand all warnings and instructions may result in
serious injury or death.
NEVER exceed weight limit of 300 lbs. DO NOT use if your
combined weight with all your hunting gear and any
accessories exceeds 300 lbs. Use of tree stand over the
weight limit may result in serious injury or death.
ALWAYS inspect the tree stand for signs of wear or
damage BEFORE each use. Also inspect to ensure that
nuts and bolts are secure and straps are not frayed, worn,
or broken.
ALWAYS wear a Fall Arrest System (FAS) after leaving the
ground. If you are not wearing an FAS that meets ASTM
standards, DO NOT leave the ground. Failure to wear an
FAS may result in serious injury or death.
DO NOT use this tree stand while under the influence of
alcohol, medication, or illegal substances. Use of tree stand
while under the influence of any of these substances may
result in serious injury or death.
NEVER use this tree stand if you have a history of health problems
such as (but not limited to) heart problems, back problems,
impaired vision, equilibrium impairments are afraid of heights or
have been advised by a doctor not to do any strenuous activity. If
you are feeling ill, nauseous, or dizzy DO NOT use this tree stand
or If you are not physically fit, well rested and alert. Physical
ailments can reduce your ability to safely install, utilize and remove
your tree stand.
NEVER use this tree stand during inclement weather such as (but
not limited to) thunderstorms, snowstorms, hurricanes, icy
conditions, or high winds that could create slippery or dangerous
situations.
NEVER use this tree stand on a dead, leaning, loose barked tree or
on a utility pole as the tree may fall, break, or uproot and may result
in serious injury or death.
DO NOT modify or alter your tree stand.
NEVER leave the ground without checking every ladder
section connection to ensure they are firmly connected. If
ladder sections are separating, with the help of at least two
other people, remove the tree stand from the tree, tighten
all connections and reinstall on the tree.
NEVER remove or deface warning labels.
Installation Straps, Ratchet Straps, Quickclips,
Tiedown Ropes and Stabilizer Bars MUST be installed
and secured prior to climbing tree stand. Failure to
comply may result in serious injury or death.
Failure to follow all warnings listed below could result in serious injury or death.
Manufactured in the year 2019 Primal Vantage Company Inc. 2407 W. Euclid Ave., Littleton, CO 80120 1-866-972-6168
DO NOT climb ladder without Stabilizer Bar and
Installation Straps installed. These MUST be
correctly installed prior to use. Serious injury or
death may occur if Stabilizer Bar and Installation
Straps are not installed.
