Pro's Kit PT-1136 User manual

PT-1136
CORDLESS LIGHTED SCREWDRIVER 3.6V
User’s Manual
1st Edition,2015
©2015 Copy Right by Prokit’s Industrial Co., Ltd.

PT-1136 User’s Manual
www.prokits.com.tw
Please read this instruction manual carefully before using the tool
General Safety Rules
WARNING Read all safety warnings and all instructions Failure to follow all warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
The term “power tool” in the warnings refer to your mains operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tools in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs,
alcohol or medication. Amoment of inattention while operating power tools may result
in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
1

PT-1136 User’s Manual
www.prokits.com.tw
2
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in
moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of these devices can reduce dust
related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not(use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tools operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control;
g) Use the power tool, accessories and tool bits etc., in accordance with these instructions
and in the manner intended for the particular type of power tool, taking into account the
working conditions and the work to be performed. Use of the power tool for operations
different from intended could result in a hazardous situation.
5. Battery tool use and care
a) Recharge only with the adaptor specified by the manufacturer. A charter that is suitable
for one type of battery pack may create a risk of fire when used with another battery
pack.
b) Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected form the battery may cause irritation or burns.
d) For ensure the maximum life out of a new battery, always charge the battery before use.
e) Always discharge battery completely when long time no use or not often to use power
tool before use
f) Battery will auto discharge when long time no use, .please charge the battery 50 days
per time
g) Please keep ambience dry and opportune temperature where storage power tool. It will
quicken auto discharge where environment too high or too low temperature.
Hi-humidity will damage the battery and will make power tool rust

PT-1136 User’s Manual
www.prokits.com.tw
6. Service
Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
Safety Advice for Rechargeable Battery
Use only the battery provided with the replacement rechargeable battery from Pro’sKit and the
provided adaptor. Protect battery and adaptor from humidity. Do not operate the adaptor outdoors.
When it is not in use and before cleaning and servicing, disconnect the adaptor from the power
supply. Do not open or attempt to repair the battery or the adaptor. If any parts are defective, have
them repaired by a qualified technician or send them to our service department for repair. Only
charge the battery at an ambient (surrounding air) temperature between 10ºC and 40ºC. A
charged battery can be used to power the machine under ambient temperature conditions
between 0ºC and 50ºC.When not in use, store the battery in a dry place between 10ºC and 30ºC.
Important! Danger! Never short-circuit the battery or expose it to moisture. Do not store it
together with any metal parts which could short-circuit the contacts. The battery could overheat,
start burning or explode.
If any person comes into contact with acid or similar internal fluids or substances
contained in the battery, wash off these substances immediately with plenty of water. If
these substances make contact with the eyes, rinse with plenty of water and visit a doctor
immediately.
Do not place the rechargeable batteryinto fire or water. It can explode. The Rechargeable Battery
should not be discarded to domestic refuse, regardless of whether used or unused. You should
return it to a local battery collection point in accordance with Battery Regulations or return them to
us suitably marked “Used Battery”.
3

PT-1136 User’s Manual
www.prokits.com.tw
Technical Data
Model No PT-1136A PT-1136F PT-1136G
Rated voltage DC 3.6 V DC 3.6 V DC 3.6 V
No-load
speed 200 rpm 200 rpm 200 rpm
Output torque 2.5N.m 2.5N.m 2.5N.m
Dirver(collect) 6.35mm (1/4") Hex Bit
Shank 6.35mm (1/4") Hex Bit Shank 6.35mm (1/4") Hex Bit Shank
Overall
Length:
Straight 270mm (10-13/16") 270mm
(10-13/16") 270mm (10-13/16")
Overall
Length:
Angled 210×140mm
(7-23/32") 210×140mm (7-23/32") 210×140mm (7-23/32")
Battery Ni-Mh 3.6V 1000
mAh Ni-Mh 3.6V 1000 mAh Ni-Mh 3.6V 1000 mAh
Charging time 5~7 hours 5~7 hours 5~7 hours
Free running
time 30-35 min. (unload speed) 30-35 min. (unload speed) 30-35 min. (unload speed)
Weight 365g 365g 365g
Adaptor 120V AC 60Hz
6V DC 300mA 230V AC 50Hz 6V DC 300mA 220V AC 50Hz 6V DC 300mA
Protection Class II
Complied with EN60335-2-29
Indoor operation only
4
Accessory
Screwdriver bits in plastic holding set 11pcs bits
2pcs bits holder
Bit size SL 3/4/5/6/7mm T10/15/20
PH#1/2/3
Environmental Proection
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your local authority or retailer for
recycling advice

PT-1136 User’s Manual
www.prokits.com.tw
Product Introduction
Froward&
Reverse Switch
Angle Lock
Charging light indication
LED Light switch
LED Light
Initial operation
Charging the Battery
The rechargeable battery must be charged before the first use. Only recharge the battery once it
is has been fully discharged, i.e. the performance clearly decreases. Otherwise the battery may
not achieve its full capacity at the subsequent charge.
Important! Only use the provided adaptor for charging the battery. When the speed
became slowly, charging the battery immediately. The red LED light will light up during the power
tool was charging. Please remove the adaptor from the power tool after 5-7 hours.
Inserting Tool Bits
The machine has a magnet in the slot. You can insert or remove screw bit quickly and easily
without any auxiliary tool.
Forward / Reverse Switch
Use the Forward / Reverse Switch to start the machine and keep holding it for continuous
operation. To switch the machine off, release the Forward / Reverse Switch
Important! Do not switch quickly. Wait for operating stop, then switch to desire
operation, to avoid switch damaged
5

PT-1136 User’s Manual
www.prokits.com.tw
6
LED Light
The machine has a built in LED light; it is convenience for working in dark environments. The
LED light switch is at the top of handgrip. Simply slide the switch on and off as required when
needed. Turn off when not needed so as to save battery life.
Operation for working
Only use tool bits which can be securely fastened in the chuck and for which the bits has been
designed.
Before using the machine check whether the screw-bit is inserted correctly.Avoid over-tightening
screws, otherwise the screw head may be damaged or stripping of the threads may occur.
Screw-bit Insertion
Insert the screw-bit into the slot in the head of the screw. Hold the screw bit perpendicular to the
head of the screw, otherwise the screw or the screw head may be damaged. Press the forward
button, the screw bit against the screw and driving in the screw into work-piece. When the screw
is completely screwed in, hold the machine firmly and release switch, otherwise the screw or the
screw head may be damaged.
Screw-bit Removal
Insert the screw-bit into the slot in the head of the screw. Hold the screw-bit perpendicular to the
head of the screw, otherwise the screw or the screw head may be damaged. Press the reverse
bottom, screw bit against the screw and removing the screw.
Maintenance and Clean
To clean the power tool, always use a dry or moist, but not wet towel. Many cleaning agents
contain chemical substances which may cause damage to the plastic parts of the machine.
Therefore do not use any strong or inflammable cleaners such as petrol, paint thinner, turpentine
or similar cleaning agents.
Always keep air ventilation holes free of dust deposits to prevent overheating.
Service
For more information on PT-1136A/ PT-1136F and other products, please visit
www.prokits.com.tw

PT-1136 User’s Manual
www.prokits.com.tw
PT-1136A/F/G 鎳氫充電起子 3.6V
使用說明書
使用前請先詳讀本份操作手冊
基本安全規則
警告：沒有按照以下安全注意事項及使用說明操作，將導致觸電、火災或其它嚴重傷害。
請將本份文件加以保存以供日後所須參考使用。
1. 工作區域
a) 請保持工作環境整潔明亮，混亂昏暗的環境將引發事故。
b) 請不要在易爆環境中使用電動工具，例如在易燃的液體、瓦斯或者粉塵環境中。
電動工具使用時所產生的火花可能點燃粉塵或氣體。
c) 工作環境中請勿有孩童及旁觀者，以免分心造成失誤。
2. 電器安全
a) 電動工具插頭請與相配的插座使用。請不要以任何方式拆解並改裝插頭，需接地的電
動工具不可使用轉接插頭。使用未拆解過的插頭和匹配的插座將減少觸電的風險。
b) 請避免讓人體接觸接地表面,像是管道、散熱器、爐灶及冰箱等，如果你的身體接地將
會有觸電的風險。
c) 請避免讓電動工具暴露在雨中或是潮濕的環境中.雨水滲入電動工具中會增加觸電的風
險
d) 請勿濫用電線。絕不用電線搬運、拉動電動工具或將插頭拉出；電線必須遠離高溫、
油膩、尖銳或可移動的物體，受損或纏繞的電線會增加觸電風險。
e) 當在戶外操作電動工具時，請搭配適合戶外使用的外接電線，以減少觸電風險。
f) 如果無法避免在潮濕的環境中使用電動工具，請使用漏電斷路器（RCD），以減少觸
電風險。
3. 個人安全
a) 請保持高度警覺，操作電動工具須有基本常識並保持專心，請勿在身體疲勞、服用藥
物、飲酒及醫事治療後使用電動工具，否則會導致嚴重的人身傷害。
b) 請使用安全裝備。永遠配戴護目鏡。在適當的狀況下使用安全設備，如防塵面罩、防
滑安全鞋，安全帽，聽力保護裝置等，以避免造成人體傷害。
c) 為避免電動工具突然啟動，插電前請先確認開關處於 “ OFF”位置，移動電動工具或
插電前手指請勿放在開關處，以免誤觸開關導致事故發生。
d) 啟動前務必先移除調整電動工具的鑰匙或扳手，遺留在電動工具上的鑰匙或扳手在啟
動時可能導致人身傷害。
e) 操作電動工具時請保持適當距離，以便在突如其來的狀況發生時能有足夠時間反應及
處理。
f) 穿著適宜，請不要穿寬鬆衣服或佩戴首飾。請讓您的頭髮，衣服和手套遠離電動工具。
寬鬆衣服、珠寶或長髮可能會捲入或卡住電動工具。.
g) 如果有提供排屑和集塵的設備，請確保他們連接完好且使用得當。使用這些裝置可減
少粉塵導致的危險。
7

PT-1136 User’s Manual
www.prokits.com.tw
4. 電動工具的使用及維護
a) 請選擇適當的電動工具。請依據您的工作狀況使用正確的電動工具，可使工作更有效率、
更安全，並使電動工具發揮最大效益。
b) 當電動工具的啟動開關不能開啟或關閉電源時請停止使用，請送回原廠修理以免發生危
險。
c) 當電動工具要進行調整、更換配件或儲存不用時，請先將插頭拔下，此預防安全措施可
降低電動工具意外啟動的風險。
d) 電動工具請貯存在兒童無法接觸的地方。請不要讓不熟悉或對操作說明不瞭解的人員使
用。未經訓練的人員操作電動工具會造成危險。
e) 電動工具維護：請檢查電動工具可調的部位是否到位，零件是否有破損或是有其它任何
可能影響電動工具操作的情形。如有損壞，請先進行修理後才能使用。許多事故都是因
為電動工具未作好維護而造成的。.
f) 保持鑽頭（或批頭）鋒利和清潔，適當的維持在鋒利狀態可減少卡住的狀況且易於使用。
g) 依據本操作說明及操作方法，考量工作環境及需完成的工作，選用適當的電動工具、配
件及批頭進行作業。選擇不適合的電動工具會產生危險狀況。
5. 電池的使用及維護
a) 請使用製造商原裝的變壓器充電，不適合的變壓器可能會造成火災。
b) 請使用製造商原裝的電池包，使用非製造商原裝的電池包可能造成人身傷害和火災。
c) 當電池遭到濫用時，電池裏的液體可能會滲出，請勿觸摸。如果意外接觸電池液，請用
大量清水沖洗。如果眼睛接觸液體，請立即就醫。皮膚接觸噴出的電池液會造成疼痛或
燙傷。.
d) 為確保電動工具電池壽命及效能充分發揮，請務必充飽電後再使用。
e) 非經常性及長時間使用電動工具，使用時請先確認電池是否有電，電動工具能正常使用
情況下，建議先使用直至電動工具無法運轉再進行充電。
f) 長時間存放電動工具不使用須注意電池自放電情況，建議每50天取出進行一次完全充電
g) 存放電動工具請注意環境溫濕度，過高/過低的溫度將使電池自放電情況加速，濕度過高
容易使電動工具及電池生鏽短路而造成損壞。
6. 服務
本電動工具的維修或更換零件需由原廠專業維修人員服務，以確保電動工具的使用安全性。
關於可充電電池的安全公告
請使用原廠所提供的電池及變壓器，並存放於乾燥區域。請勿在戶外使用變壓器。當變壓器使用
完畢或是在清潔維修前，請先拔下插頭。請勿試圖打開修理電池或變壓器。如果任何部件有缺陷，
請由合格的維修技術人員維修或送回原廠維修。電池充電的環境溫度為10℃到40℃之間，已充電
的電池可以在0℃到50℃環境溫度下提供電動工具電力進行作業。如不使用時，請儲存在10℃到30
℃之間的乾燥環境。
重要! 危險! 請勿讓電池短路或接觸水氣。請勿將電池與金屬物品存放在一起以免造成短路，
電池將產生過熱、發燙或爆炸。
8

PT-1136 User’s Manual
www.prokits.com.tw
如果任何人接觸到電池內部液體或物質，請立即用大量清水沖洗。如果這些物質接觸眼睛，請立
即用清水沖洗後立刻就醫。
請勿將將充電電池放入水中或火中，以免發生爆炸。無論充電電池是否使用，均不可當作家用垃
圾丟棄。您應該按照電池回收條例送到當地國家的電池回收站或是交回給我們並標示為“使用過
電池”。
規格
型號 PT-1136A PT-1136F PT-1136G
額定電壓 DC 3.6V DC 3.6V DC 3.6V
無負載轉速 200rpm 200rpm 200rpm
輸出扭力 2.5 N.M (MAX) 2.5 N.M (MAX) 2.5 N.M (MAX)
工作夾頭 6.35mm( 1/4”) 內六
角插孔
6.35mm( 1/4”) 內六角
插孔
6.35mm( 1/4”) 內六角
插孔
電池 鎳氫電池 3.6V
1000mAh
鎳氫電池 3.6V
1000mAh
鎳氫電池 3.6V
1000mAh
充電時間 5-7 小時 5-7 小時 5-7 小時
可使用時間 30~35 分鐘. (無負載) 30~35 分鐘. (無負載) 30~35 分鐘. (無負載)
長度 270mm 270mm 270mm
重量 365g 365g 365g
變壓器 輸入：120V AC 60Hz
輸出：6V DC 300mA
輸入：230V AC 50Hz
輸出：6V DC 300mA
輸入：220V AC 50Hz
輸出：6V DC 300mA
防護等級： II 級
符合標準： EN60335-2-29
適用於室內操作
配件
批頭 2pcs 延長杆
11pcs 25mm 批頭
批頭規格
一字 SL : 3.0 / 4.0 / 5.0 / 6.0 / 7.0mm
星型 : T10 / T15 / T20
十字 PH : #1 / #2 / #3
環境保護
廢棄的電器產品請勿當作家用垃圾處理。
請依當地國家的回收條例送到回收站或是零售商進行回收。
9

PT-1136 User’s Manual
www.prokits.com.tw
產品功能
10
操作說明
充電指示燈
LED 照明燈開關
角度調節按鈕
正反轉切換按鈕
LED 照明燈
基本說明
充電
首次使用前請先將可充電電池充飽電。每次電池完整放電後才能再次進行充電，以避免電池效率
降低。除此之外還會造成之後每次充電都無法充飽電的情況發生。
重要! 請使用原廠所提供的變壓器為電池充電。當電力耗盡時請盡快充電，充電時紅色充電指
示燈會亮起，請控制充電時間在5～7小時內，充電完成請移除變壓器。
過度消耗電力及過長時間充電都會對電池造成傷害。
插入批頭
本產品夾頭內有磁鐵可吸附批頭，使用時可直接插入或拔出批頭，不需特別對準且快速方便。
正反轉切換按鈕
當正反轉按鈕往上按時批頭會向右轉(旋緊)，往下按則是向左轉(鬆開)，鬆開開關後即停止運轉。
特别注意 ! 切換時請待旋轉動作停止後，再切換下一個動作，旋轉中直接切換將容易造成機
器損傷，請適當控制切換速度，以保護開關。
LED照明燈
本產品內建LED照明燈可提供於昏暗環境進行作業，照明燈開關位於電動工具上方，不使用時請
隨手關燈以節省電力。
操作使用
請使用合格的批頭產品, 并確認規格符合本產品的裝配尺寸。
開始操作前請先確認批頭插入是否牢固。避免螺絲鎖附過緊造成螺絲頭損傷或滑牙。
●螺絲鎖入
請將批頭放入本機夾頭內，批頭與螺絲對準呈垂直方向，否則螺絲將造成損壞。將批頭對著螺絲
按下正轉開關將螺絲鎖緊。當螺絲完全鎖緊後，鬆開正反轉切換按鈕即可。

PT-1136 User’s Manual
www.prokits.com.tw
螺絲旋出
請將批頭放入本機夾頭內，批頭與螺絲呈垂直方向，否則螺絲將造成損壞。將批頭對著螺絲按下
反轉開關將螺絲旋出。
維護和清潔
請使用乾的或是微濕的毛巾進行清潔。許多清潔劑含有化學物質，可能會使機器的塑膠部位造成
損壞。因此請勿使用其它較強烈或易燃的清洗劑像是汽油、松香水，松節油及其它類似的清潔劑。
本機通風孔請防止灰塵沉積以免過熱。
服務
更多關於 PT-1136A / PT-1136F 的資訊及其它產品, 請上本公司網站www.prokits.com.tw
©2015 Prokit’s Industries Co., LTD. All rights reserved 2015001(C)
11
