Proaction A105QW Assembly Instructions

Washing Machine
Installation & User Instructions –Please keep for future reference
A105QW
A105QS
These instructions contain important information which will help you get the best from your
appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline:0845 600 4632
Important –
Please read these instructions fully before installing or using
52033000 – 27/04/11

Product codes
A105QW
A105QS
Contents
Customer Helpline: 0845 600 4632
Safety Information 2
Parts 3
Installation 4-5
Unpacking your washing machine 4
Removing the packing bolts 4
Water inlet hose connection 5
Drain hose connection 5
Electrical connection 6
Control Panel Functions 7-8
Program Selection Guide 9
User Instructions 10
Before first use 10
Preparing for a wash 10
Using your washing machine 11
Error Signals 12
Care and Maintenance 13-14
Water inlet filters 13
Pump filter 13
Detergent drawer 14
Siphon plug 14
Cabinet 14
Trouble Shooting 15
Technical Specifications 17
Guarantee 18
1

•This appliance is not to be used by children or
persons with reduced physical, sensory or
mental capabilities, Persons with lack of
experience and knowledge.
•Do not use a multiple socket or extension
cord.
•Do not use if the power lead is damaged. It
must be replaced by the manufacturer, their
approved service agent or similarly qualified
person. Customer Helpline: 0845 600 4632.
•Do not insert the plug into the power supply
with wet hands.
•Do not touch or use the appliance when
barefoot or with wet or damp hands.
•Do not open the detergent drawer during a
wash cycle.
•Do not touch the porthole (door) during the
washing cycle - it will get hot.
•Never force the machine door open while the
machine is running.
•Do not open the door if water is visible
through the porthole.
•Do not wash foam rubber or sponge like
materials on a hot wash.
•The machine can reach high temperatures
while running. Do not touch the drain hose or
waste water during draining.
•Do not forget that the packing material of your
machine may be hazardous for children.
•Keep your pet away from your machine.
•Do not use flammable detergent, sprays or dry
cleaning agents in or near to the appliance.
•Do not remove or insert the plug in the
presence of flammable gas.
•The appliance should not be put on a carpet
which can block the air ventilation on the bottom
side.
•Do not place heavy objects or sources of heat
or damp on top of the washing machine.
•Only use detergents which are suitable for
automatic washing machines and follow the
detergent manufacturers recommendations.
•Do not use this appliance if there are any
missing or damaged parts.
•Do not attempt to repair the appliance
yourself. Contact the manufacturer, their
approved service agent or the Customer
Helpline: 0845 600 4632.
Safety Information
Important –
Please read these instructions fully before installation
•The installation of this appliance is best
carried out by 2 people.
•Dispose of all packing carefully and
responsibly.
•This appliance is for indoor use only. Only
install in a dry indoor environment.
•The appliance MUST be positioned on a firm
level base.
•Do not position the appliance where it is
exposed to direct sunlight or heat sources as
this will age the plastic and rubber components.
•Warning: Ensure all 4 packing bolts have been
removed.
•Ensure the appliance is connected directly to
a domestic mains water supply.
•Warning: This washing machine MUST only
be connected to a cold water supply.
•Ensure all electrical connections are as stated
in this document.
•Ensure the appliance is plugged into a
separate earthed socket that is easily
accessible.
•Ensure the power lead is not trapped under
the appliance.
•Do not connect the appliance to the power
supply until installation is complete.
•This appliance is for domestic/household use
only and is not suitable for commercial use.
•Check that the water hose joints and
connections are secure and there are no leaks. If
the hoses leak, do not use until the leaks have
been stopped.
Before use During use
2

8 9
10
7 7
7 7
Back
7.Packing bolt x 4
8.Power lead
9.Drain hose
10.Water inlet
Plastic plug x 4
Parts
Please familiarise yourself with the parts and accessories listed below
23 4
1
5
6
Front
1.Detergent drawer
2.Top panel
3.Start / Pause button
4.Program selection dial
5.Door
6.Filter
Water inlet hose x 1
If you have damaged or missing parts,
call the
Customer Helpline: 0845 600 4632
Accessories included
3

1 2
34
5 6
Installation
Customer Helpline: 0845 600 4632
Unpacking your washing machine
Caution: 2 people are required
to unpack the washing machine,
it is recommended that gloves are
worn.
a:
Carefully remove all packaging materials
including the foam base, dispose of correctly.
Note: When opened, water droplets may be
visible in the drum etc. this is normal as each
appliance is factory tested.
Removing the packing bolts
Important: The packing bolts are
designed to support the internal
components during transit, these
MUST be removed before use.
a: Loosen the screws by rotating
counterclockwise with a suitable wrench.
(1 & 2)
b: Remove the bolts by pulling them. (3)
c: When the transport bolts have been removed,
insert the plastic transport screw taps found in
the accessories bag into the holes.(4)
Removing the packing bolts
a: For your machine to work efficiently with
minimum vibration it should be settled on flat,
non-slippery, firm ground.
b: You can adjust the balance of your machine
by changing the positioning of its feet.
c: First, loosen the plastic adjustment nut. (5)
d: Adjust by rotating the feet upwards or
downwards. (6)
e: After the desired position has been reached,
tighten the plastic adjustment nut again by
rotating it upwards.
Note: Never put cartons, wooden blocks or
similar materials to balance the machine on
uneven ground.
4

7
8
9
Installation
Customer Helpline: 0845 600 4632
Water inlet hose connections
Important:This washing machine
MUST only be connected to a
cold water supply.
a: Connect the water inlet hose, the angled
connection attaches to the water inlet on the
back of the washing machine.(7)
b: The straight connection attaches to the water
supply valve. (8)
c: Ensure all seals are in place before
connecting.
Important:Only tighten the hose
connection nut by hand - do not
overtighten.
Drain hose connections
Important:The height of the top
of the curve in the drain hose
MUST be between 60 - 100cm
from the floor.(9)
Important:The end of the water drain hose may
be fitted directly to the waste water outlet hole
or a special apparatus mounted on the outlet
bracket of the wash-stand.
Important:Never attempt to extend the water
drain hose by adding extra parts.
Continued on next page
Max.
100cm
Min.
60cm
5

Installation
Customer Helpline: 0845 600 4632
Electrical connections
Any electrical work that is
required to install this washing
machine MUST be carried out
by a qualified electrician.
Warning: THIS APPLIANCE
MUST BE EARTHED
Before making any electrical connections,
ensure that:
•Ensure the power socket is suitable for the
maximum power of the washing machine
(fuses in the power circuit must be 13 amp).
•The supply voltage should be the same as
that indicated in the technical specifications
(page 17) and the appliance rating plate
(located where shown).
•The appliance should be earthed and in
compliance with the applicable law.
•Additional earth cables should not be
necessary if the plug and socket are earthed.
If necessary, an additional earth cable
should be attached to the earth terminal on
the back of the washing machine and
earthed.
•When installed, the power socket must be
within easy reach.
•The use of adapters, multiple connectors or
extension cables are not recommended.
•The appliance must be connected to a 220-
240 volt 50 cycle AC supply by means of a
three pin socket, suitably earthed and
protected by a 13 amp fuse.
•Should the fuse need to be replaced, a 13
amp fuse approved to BS1363/A must be
used.
•The plug contains a removable fuse cover
that must be refitted when the fuse is
replaced. If the fuse cover is lost or
damaged, the plug must not be used until a
replacement cover has been fitted or the
plug is replaced.
•A damaged plug should be cut off as close
to the plug body as possible, the fuse should
be removed and the plug disposed of safely.
Plug replacement (UK & Ireland only)
Should you need to replace the plug; the wires
in the power cable are coloured in the following
way:
Blue – Neutral ‘N’
Brown – Live ‘L’
Green & Yellow – Earth ‘E’
As the colours of the wires in the power cable
may not correspond with the coloured markings
identifying the terminals in your plug, and
proceed as follows:
The green & yellow wire must be connected to
the terminal in the plug that is marked with the
letter E or by the earth symbol.
The blue wire must be connected to the terminal
that is marked with the letter N.
The brown wire must be connected to the
terminal that is marked with the letter L.
If the power lead is damaged, it must be
replaced by a qualified electrician.
6

1. Detergent drawer
2. Start / Pause button
3. No spin button
4. Cold wash button
5. Program ready light
6. Program end light
7. Program selection dial
2 3 4 5 6 7
1
Control Panel Functions
Customer Helpline: 0845 600 4632
a
b
c
d
e
2
3
4
1. Detergent drawer
a: Prewash detergent
b: Main wash detergent
c: Fabric softener
d: Siphon plug
e: Liquid level detergent plate ( in accessory bag)
2. Start / Pause button
Used to start a selected program or pause during
running.
3. No spin button
This program is recommended to be used for
your sensitive clothes on which no spinning
should be done. By pressing this function button,
you can cancel the spinning process which is
included in the program.
4. Cold wash button
When this button is pressed, your clothes are
washed with cold water. With this function, you
can wash your slightly dirty clothes using less
energy and water.
Continued on next page
7
1

Control Panel Functions
Customer Helpline: 0845 600 4632
6
7
8
5. Program ready light
Adjust the program knob to the program you
desire. The program ready light will be on.
6. Program end light
Your machine will automatically stop when the
program you have selected ends. The program
end light will be on.
7. Program selection dial
With the program knob, you can select the
program with which you desire to wash your
clothes. You must be careful that the adjustment
sign of the program knob is exactly on the
program you want to select. If you move the
program knob to 0 (off) position, while your
machine is running, your program will be
cancelled.
Note: If you want to activate an additional
function after the machine has started washing,
press the additional function button that you
want to use. If the additional function selected
can still be used at that program stage, the LED
of the function button will be turned on and the
function will be added to the program. If the LED
is not turned on, the function selected is not
possible at that stage of the current program
and will not be activated.
8

Program Selection Guide
Customer Helpline: 0845 600 4632
PROGRAM
PROG.
TIME
(mins)
DETERGENT
COMPART.
MAX LOAD
CAPACITY
(kg)
TYPE OF LAUNDRY
COTTON
1-90˚ 144 2 5 Dirty, boil, cotton and linen textile
2-60˚
(PREWASH) 155 1+2 5 Very dirty, cotton, coloured and linen
textile
3-60˚ 162 2 5 Dirty, cotton, coloured and linen textile
4-40˚ 132 2 5 Slightly dirty, cotton, coloured and linen
textile
5-40°
ECO WASH 109 2 5 Dirty, cotton, coloured and linen textile
6-30°
QUICK WASH 33 2 2,5 Slightly dirty, cotton, coloured and linen
textile
7-COLD 119 2 5
Slightly dirty cotton, coloured and linen
textile. Washed without heating the tap
water.
SYNTHETIC
1-60˚ 103 2 3 Dirty, synthetic or synthetic mixture
textile
2-40˚ 86 2 3 Slightly dirty, synthetic or synthetic
mixture textile
3-COLD 77 2 3
Slightly dirty, synthetic or synthetic
mixture sensitive laundry. Washed
without heating the tap water.
DELICATE
1-30˚ 85 2 2 Slightly dirty, cotton, coloured, synthetic
or synthetic mixture sensitive laundry
WOOL
2-30˚ 71 2 2 Dirty, hand and machine to wash wool
laundry
RINSING When your clothes need an additional rinse after the washing process. You can use this
program for all kinds of clothes.
SPINNING When your clothes need an additional spin after the washing process. You can use this
program for all kinds of clothes.
DRAINING
This program is used to drain the wastewater after the washing process of your
machine. Also if you want the water inside your machine to be drained before the
program ends, you can use this program.
(*) You can use softeners in all programs (except spinning and draining programs) optionally. When you arrange
the quantity of the softener, comply with the warning of the softener producer. Fill your softener in the (softener)
compartment of the detergent drawer.
Note:Durations vary according to wash load (weight and type), tap water, ambient temperature and selected extra
functions.
9

a: Plug in the machine.
b: Open the water tap.
c: There may be water left inside your machine
after factory tests and trials. It is recommended
that the first wash cycle be carried out with no
laundry, to remove this water; pour half a
measuring cup of normal laundry detergent into
compartment 2 and select cotton program at
90°C.
d: Adjust the program knob to a program you
desire.(Program number 1)
e: The program ready light will be on.
f: Run the program that you have selected by
pressing the Start/Pause button.
g: Your machine will automatically stop when
the program ends.
h: The program end light will be on.
User Instructions
Customer Helpline: 0845 600 4632
Before first use
Preparing for a wash
Laundry
•Sort your clothes according to their types
(cotton, synthetic, delicate, woolen, etc.),
washing temperatures and level of dirtiness.
•Never wash your white and coloured clothes
together.
•Since your new coloured clothes may
release dye on the first wash, wash them
separately.
•Remove any small objects from the pockets
of your clothes.
•Ensure that all zips and buttons on your
clothes are fastened.
•Remove the plastic or metal hooks of
curtains or place them inside a washing bag and
tie.
•Turn clothes such as trousers, knitted
fabrics, t-shirts and sweat shirts inside out.
•Wash your small clothes like socks and
handkerchiefs in a washing bag.
Placing clothes into the machine
•Open the door of your machine.
•Put your clothes into your machine in a
well-balanced manner.
•Place your clothes loosely in the machine.
•When you shut the door of your machine, be
careful that no cloth is jammed between the
cover and the gasket.
•Shut the door of your machine securely,
otherwise your machine will not start the
washing process.
Detergent
The quantity of detergent to be loaded into the
machine will depend on the following criteria:
•Your detergent consumption will change
depending on how dirty the clothes are. For your
slightly dirty clothes, do not pre-wash and put a
small amount of detergent in compartment 2 of
the detergent drawer.
•For your excessively dirty clothes, select a
program with pre-washing; fill ¼ portion of the
detergent in compartment 1 in the detergent
drawer and the remaining portion in
compartment 2.
•Use detergents developed especially for
automatic washing machines. The quantities
that will be used for your clothes are written on
the packaging of the detergents.
•As the hardness of your water increases, the
amount of the detergent to be consumed will
also increase.
•As the amount of clothing increases, the
amount of the detergent that will need to be
used will also increase.
•Fill your softener in the softener
compartment in your detergent drawer. Do not
exceed the MAX level. Otherwise, the softener
will diffuse in the washing water via the siphon.
•Concentrated softeners with high viscosity
should be diluted with water before loading in
the drawer. This is because high-viscosity
softeners obstruct the siphon and prevent the
flow of the softener.
•You can use liquid detergents in all
programs without pre-washing. For this, mount
the liquid detergent level plate in the second
compartment of the detergent drawer and
arrange the amount of liquid detergent
according to the levels on this plate.
10

1. Loading
a: Open the door, place laundry item by item
into the washing machine, firmly close the door.
b: Do not overload the washing machine (see the
program selection guide for maximum load
information, page 8).
2. Add detergent
Pull out the detergent drawer, add the detergent
and softener to the correct compartments.
3. Select a washing program
a: Adjust the program knob to a program you
desire.(Page 8)
b: The program ready light will be on.
4. Function buttons
Select the 'no spin' or 'cold wash' settings as
required (see page 6).
5. Start washing
Press the start/pause button and the washing
machine will start.
6. Finish washing
a: Your machine will automatically stop when the
program you have selected ends.
b: The program end light will be on.
c: Turn the program knob to O(off) position.
d: The door will be unlocked approximately two
minutes after the program ends.
e: You can open the door by pulling the handle
of the door towards yourself and take out your
clothes.
f: After you unload your clothes leave the door
open to dry the interior of your machine and to
prevent mould from developing.
g: Unplug your machine from the mains power
supply.
h: Close the water tap.
7. Changing a selected program
If you have selected a program and you do not
want it to continue:
a: Press the start/pause button.
b: Bring the program knob to O(off) status.
c: Adjust the program knob to the program you
desire.
d: The program ready light will be on.
e: By pressing the start/pause button, run the
program that you have selected.
Note: If you want to change running program, O
position should be used. Bringing the program
knob to another position will not change running
program.
8. Cancellation of a program
If you wish to end a running program early:
a: Press the start/pause button.
b: Turn the program knob to O(off) status.
c: Turn the program knob to “Draining” or
“Spinning” program.
d: The program ready light will be on.
e: Run the program you have selected by
pressing the start/pause button.
Note: If the power is interrupted at any stage of
the washing program, your machine will
continue the program from the point where it
was interrupted. Provided no changes have
been made to the program selected.
Child Lock
Child lock is used in order to protect the
washing cycle from the effects of unwanted
button activations during the cycle. Child lock is
activated by pressing the first and third button
on the control panel at the same time for more
than 3 sec. When child the lock is activated,
LED’s on the function buttons blink to indicate
that child lock is active. In order to deactive child
lock, the same buttons (1st and 3rd) should be
pressed again for more than 3 seconds.
Deactivation of child lock is shown by blinking of
LED on Start/Pause button.
User Instructions
Customer Helpline: 0845 600 4632
Using your washing machine
11

Error Signals
Customer Helpline: 0845 600 4632
Your machine is equipped with systems which will take the necessary precautions and warn you in
case of any. IMPORTANT: IT CAN TAKE UPTO 10 MINUTES FOR ERROR TO REGISTER.
FAILURE
CODE
FAILURE
INDICATOR
PROBABLE
FAILURE PROCESS TO BE FOLLOWED
Err 01
The start/pause
light blinks.
The door is not
shut properly.
Shut the door properly so that
you hear the click. If the
problem persists, turn off the
machine unplug and contact the
nearest authorised service agent
immediately.
Err 02
The program
ready light blinks.
The water level in
your machine is
below heater. The
pressure of your
water supply may
be low or water
supply may be
blocked.
Turn on the tap fully. The water
supply may be interrupted. If the
problem persists, your machine
will automatically stop after a
while.Unplug your machine, turn
off the tap and contact the
nearest authorised service agent
immediately.
Err 03
The start/pause
light and program
ready light blinks .
The pump has
failed or the
pump filter is
obstructed.
Clean the pump filter.If the
problem persists and contact
the nearest authorised service
agent immediately. (*)
Err 05
The start/pause
light and program
end light blink.
The heater of
your machine or
the heat sensor
has failed.
Shut down your machine and
unplug. Turn off your tap and
contact the nearest authorised
service agent immediately.
Err 06
The program
ready light and
program end light
blink.
The motor has
failed.
Shut down your machine and
unplug. Turn off the tap and
contact the nearest authorised
service agent immediately.
Err 07
The start/pause
light, program
ready light and
program end light
stays on
permanently.
Electronic
configuration
error.
Shut down your machine and
unplug. Turn off the tap and
contact the nearest authorised
service agent immediately.
Err 08
The start/pause
light, program
ready light and
program end light
blink.
The motor has
failed.
Shut down your machine and
unplug. Turn off the tap and
contact the nearest authorised
service agent immediately.
Err 09
The program
ready and
program end
lights stay on
permanently.
The network
voltage is too
high or too low.
If the network voltage is lower
than 150V or higher than 260V,
your machine will automatically
stop. When the network voltage
is recovered, your machine will
continue its operation.
(*) See the section regarding the care and maintenance of your machine.
12

Before cleaning your washing
machine.
a: Unplug your machine from the mains power
supply.
b: Close the water tap.
Water inlet filters
On the tap part of your machine’s water inlet
hose and at the ends of water inlet valves, there
are filters to prevent entrance of the dirt and
foreign materials in the water to the machine. If
the machine is unable to receive sufficient water
although your water tap is fully opened, these
filters should be cleaned.
•Remove the water inlet hose.
•Remove the filters found on the water inlet
valves by using a pincer and wash thoroughly
with a brush. (1)
•Clean the filters of the water inlet hoses
located on the tap side by removing manually
together with the seal. (2)
•After you clean the filters, you can fit them
the same way as you have removed them.
Pump filter
The pump filter system elongates the life of your
pump, which is used to drain the dirty water. It
prevents lint enter the pump. Cleaning of your
pump filter every 2-3 months is recommended.
To clean your pump filter:
•Open the kickplate’s cover, by pulling the
handle. (2-A & 3-A)
•Before opening the filter cover,place a cup in
front of the filter cover to prevent flow of the
remaining water in the machine.
•Loosen the filter cover by rotating it counter
clockwise and drain the water. (4-A)
•Remove the foreign materials from the filter.
•Check for the rotation of the pump manually.
•After you have cleaned the pump, fit the filter
cover by rotating clockwise.
•Put the kickplate cover into place.
•Do not forget that if you do not fit the filter
cover properly, it will leak water.
Danger of being scalded!
The water inside the pump
maybe hot- wait for it to cool.
1
2
Care and Maintenance
Customer Helpline: 0845 600 4632
13

Detergent drawer
Detergents may form sediments in your detergent
drawer or in the housing of the detergent drawer
over time. To clean the sediment, pull out the
detergent drawer from time to time. To pull out the
detergent drawer:
•Pull the detergent drawer to the end. (1)
•Keep pulling by pressing on the siphon lid
inside the drawer pulled to its end, and remove
the drawer from its place. (2)
•Wash with an old toothbrush and water.
•Remove the leftover disused detergent, avoid
dropping it back in to the machine.
•After drying the detergent drawer, replace it in
the housing by reversing the removal
operations.
Siphon plug
Pull out the detergent drawer. Remove the siphon
plug and clean the residues of the softener
thoroughly. Fit the cleaned siphon plug in its
location. Check it is placed properly.(3)
Cabinet
Clean the exterior surface of the cabinet of your
machine with lukewarm water and a cleaning
substance that will not damage the cabinet. After
rinsing with clean water, wipe it with a soft and dry
cloth.
Note:To get the best out of your machine. We
recomend that you periodically run a wash cycle
with limescale remover, especially in hard water
drear.
Note: After each wash leave the door to the
machine open to help air the drawer and
reduce any mould build up;
Note: Wipe the door seal ideally after each wash;
Note: Undertake a maintenance wash every 4-6
weeks with the drum empty. This wash should be
undertaken with lime scale and detergent remover;
1
2
3
Care and Maintenance
Customer Helpline: 0845 600 4632
14

Trouble Shooting
Customer Helpline: 0845 600 4632
All repairs to the machine must be carried out by an authorised repair agent. When a repair is required
or you are unable to eliminate the failure with the help of the information below:
a: Unplug the machine.
b: Close the water tap.
c: Contact the nearest authorised repair agent.
FAILURE PROBABLE CAUSE METHODS OF ELIMINATION
Your machine does
not operate.
It is unplugged. Insert the plug into the socket.
Your fuse is defective. Change your fuse.
The electric power is off. Check the electric power.
Start/pause button has not been
pressed. Press the start/pause button.
The programme knob is in the 0
(off) position.
Turn the programme knob to the
desired position.
The door is not shut properly. Shut the door properly. You should
hear the click.
Your machine does
not receive water.
Water tap is closed. Open water tap.
The water inlet hose may be bent.
Check the water inlet hose.
The water inlet hose is
obstructed. Clean the filters of water inlet hose. (*)
The valve inlet filter is obstructed. Clean the valve inlet filters. (*)
The door is not shut properly. Shut the door properly. You should
hear the click.
Your machine is not
draining water.
The drain hose is obstructed or
bent. Check the drain hose.
The pump filter is obstructed. Clean the pump filter. (*)
The clothes are not placed inside
the machine in a well-balanced
manner.
Spread the clothes inside the machine
in an orderly and well-balanced
manner.
Your machine is
vibrating.
The feet of your machine are not
adjusted. Adjust the feet. (**)
Transportation screws are not
removed. Remove transportation screws. (**)
Your machine is
vibrating.
There are only few clothes in the
device.
It does not prevent operation of the
machine.
Excessive amount of clothes are
filled in the machine or the clothes
are not placed in a well-balanced
manner.
Do not exceed the recommended
quantity of clothes and spread your
clothes in the machine in a well-
balanced manner.
Your machine is touching a rigid
object.
Ensure machine is not in contact with
hard objects.
(*) See the section concerning the care and maintenance of your machine.
(**) See the section concerning installation of your machine.
15

Trouble Shooting
Customer Helpline: 0845 600 4632
FAILURE PROBABLE CAUSE METHODS OF ELIMINATION
Excessive foam in
the detergent drawer.
Too much detergent has been
used.
Press the start/pause button.In order to
stop the foam,dilute one table-spoon of
softener in half liter of water and pour it
in the detergent drawer.Press the
start/pause button after 5-10
minutes.Arrange the amount of the
detergent properly in the next washing
process.
Wrong detergent has been used. Use only the detergents produced for
full automatic machines.
The washing result is
poor.
Your laundry is too dirty for the
programme you have selected.
Select a suitable programme. (see
page 8)
The amount of detergent used is
not sufficient. Use more detergent.
The washing result is
not good.
Clothes exceeding the maximum
capacity have been loaded in the
machine.
Put the clothes in your machine in a
manner not to exceed its maximum
capacity.
Your water may be hard.
Use the amount of detergent specified
by the detergent manufacturer.
Distribution of the clothes in your
machine is not well-balanced.
Spread the clothes inside the machine in
an orderly and well-balanced manner .
The water is drained
from the machine as
soon as it is filled.
The end of the water drain hose is
in a position too low according to
the machine.
Position the water drain at an
appropriate height.(**)
No water is seen in
the drum during
washing.
No failure. The water is in the
lower part of the drum. -
There are residues of
detergent on the
clothes.
Some detergents contain
ingredients which are not soluble
in water and which may form
white stains on your clothes.
By adjusting your machine, carry out an
additional rinse, or eliminate the stains
after drying, with a brush.
There are grey stains
on the clothes.
These stains may be caused by
oil,cream or ointment .
In the next washing operation, use the
maximum detergent amount declared by
the detergent producer.
The spinning process
is not done or starts
with delay .
No failure. The unbalanced load
control may work in that way.
The unbalanced load control system will
try to distribute your clothes in a
homogenous manner. After your clothes
are distributed, passage to spining
process will be realized. In the next
washing process,place your clothes into
the machine in a well-balanced manner.
(*) See the section concerning the care and maintenance of your machine.
(**) See the section concerning installation of your machine.
16

Technical Specifications
Customer Helpline: 0845 600
Model / Item
A105QW
A105QS
Power supply (220-240) V ~/50Hz (220-240) V ~/50Hz
Max working current 10 amp 10 amp
Water pressure Maximum : 1 Mpa
Minumum : 0.1 MPa
Maximum : 1 Mpa
Minumum : 0.1 MPa
Maximum power 2100 watt 2100 watt
Maximum washing load (dry) 5 kg 5 kg
Spinning speed 1000 rpm 1000 rpm
Washing programmes 15 15
Size 845 x 597 x 497 845 x 597 x 497
Net weight 65 kg 65 kg
The symbol on the product or its packaging indicates that this product may not be
treated as household waste. Instead it should be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about
recycling this product, please contact your local council office, your household waste
disposal service or the shop where the product was purchased.
Disposal information
17

18
