Procon Advantage Evo Manual
Hardware
InstallationGuide
AdvantageGPS.com l 1-800-553-7031
Welcome
Experience 4G LTE Evo,the nextevolutioninGPStracking. Advantage by
ProconAnalytics -where automotive telematics meetsgenuine analytics.
InstallationMade Easy
Toolsneededforinstall:screwdrivers,wirestrippersandcutters,crimping
tooland voltmeter.Plus,youmightwanttohavethe
followinghandy: connectors,velcro,and zipties.
Makesurethereisnotmetalabovethedeviceasitmayinterfere
withthesignal.
Keepit fromdirectexposure tothe sun,heat,rain,moisture,etc., and
away fromheaterventsorhot enginecompartments.
Do not tightlykinkorwrapexcesscable.
Mounting Evo
[ILLUSTRATIONS1 &2]
Install the Evodevice inaconcealedlocationunderthedash.
Holdit inplace.
Mark the locationforthevelcro.
Attachedvelcrotothebackofthedevice
and the othertothedash.
FACING DOWN!
EvoWiring
[POWER/SERIAL CABLEDIAGRAM]
We’veincludedadetachablewiringharness.Connecteverythingbefore
pluggingharness intotheEvodevice.
Black Wire:
Ground
Connectthegroundwiretothevehiclechassis(shouldalwaysbefirst
connection made.)
RedWire:
12VDCConstantPower Connecttoaconstantpowersource.Voltageshould
read 12Vwhen thevehicle’signitionline isin the off position.
WhiteWire:
Ignition input (optional unless
paymentreminder isused)
GreenWire:
Programming Input (notused)
YellowWire:
Output (Connectsto
starterinterruptor relay)
GREEN BLACKYELLOWRED
InputGroundOutput+12VBattery
OncethewiresareattachedandEvoismounted,plugtheharnessintoit
and powerup.
The LED indicators will show:
Asolidgreenlightindicatesagoodcellularcoverage.
Note:If thelightdoesnotlock onand go solid,you’renotgettingagoodsignal.
Unit willnot trackproperly.
A solidredlightindicatesgoodGPSsignal.
ECMStarterDisable
[DIAGRAM1]
If the starteris controlledby the ECM(Engine ControlModule),splicethe
wire that leadsdirectly fromtheECMtothe starter.
Note: Donotsplice intothewireleadingfromignition switchtothe ECM.
GREEN(NotInUse)
Note: Yellow wireconnectstoYellow relaywire.
Note: Groundshouldalwaysbethefirstconnectionmade
RED = Ignition
WHITE= Starter
YELLOW= Input
StarterInterrupter
[OPTIONAL FEATURE DIAGRAM 1]
Locateandcutthestarterwireofthevehicle.Thiswirewillonly
display12VDC while the vehicle isstarting.
Connectyellowwirefromthe harness tothe yellowwireofthe starter
interruptrelay.
Connect redwire from thestarterinterrupt relay tothe ignitionswitch
side ofthestarterwire.
Connect white wireofthestarterinterrupt relay tothe starterside of
the starterwire.
Payment Reminder
[OPTIONAL FEATURE]
Locateaswitchignitionpowerwirethatreads12Vwhenthevehicle’s
ignitionisinthe ON positionand 0 Voltswhenthe vehicle ignitionis
intheOFFposition.Theignitionwireretains12Vasthevehicle
isstarting.
Connectthewhitewirefromharness tothevehiclesignitionwire.
Ifthewhitewireisnotconnected,thepaymentreminderfeaturewill
activate uponthe changeofvehicle voltage,insteadofwhenthe
vehicle starts.
Note:If the whitewireis notconnected properly,the paymentreminderoption
will not function asdesigned.
LEDTroubleshooting
[TECHNICALDATA]
TechnicalData
OperatingVoltage
7V-28V
PowerConsumption
2.5 mA (standby), 50 mA (active)
Operating Temperature
-30
o
Cto+75
o
C
Storage Temperature
-40
o
Cto+85
o
C
OperationHumidity
20% to90% (non-condensing)
SolidGreen= CellularSignalisOK
FlashingGreen= Searching
SolidRed= GPSSignalisOK Flashing
FlashingRed= Searching
Note: Thefollowing LED behavioris indicativeofan over-the-air update:
•
Solid Red(15secs.)
•
GreenandRedflashingsimultaneously (about60secs.).
Installationmaycontinuewhiledevicereceivesupdates,however,al
waysconfirm bothLEDsare solidbefore finalizing.
8
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between theequipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning statements:
‐ English: This device complies with Industry Canada license‐exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause interference,
and (2) This device must accept any interference, including interference that may cause
undesired operation of the device. The digital apparatus complies with Canadian CAN ICES‐3
(B)/NMB‐3(B).
‐ French: Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux
appareils
radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil
ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout
brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le
fonctionnement.
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
● This device may not cause interference; and
● This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
● l’appareil ne doit pas produire de brouillage;
● l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Cet équipement est conforme Canada limites d'exposition aux radiations dans un
environnement non contrôlé. Cet équipement doit être installé et utilisé à distance minimum de
20cm entre le radiateur et votre corps.
