Procool SP480 Series User manual

procool AV Cooling Solutions SP480 series
PROCOOL LLC – 115 E South St Suite C, Plano, IL 60545 – P: 630-552-9999 F. 630-552-9996 – www.procool.com
PROCOOL SP480 SERIES TEMPERATURE CONTROLLED COOLING SYSTEMS
Intake Models: SP480X, SP480XT, SP480TV, SP480T
Exhaust Models: SP480X-E, SP480XT-E, SP480TV-E, SP480T-E
Model No.
SP480X, SP480X-E
SP480XT, SP480XT-E
SP480TV, SP480TV-E
SP480T, SP480T-E
Silent Operation
Silent Variable Speed
High Airflow
Ultra High Airflow
Panel Size:
2U (19"w x 3.5"h x 2”d)
2U (19"w x 3.5"h x 2”d)
2U (19"w x 3.5"h x 2”d)
2U (19"w x 3.5"h x 2.5”d)
Panel color/material:
Black/metal
Black/metal
Black/metal
Black/metal
Fan Size:
80mm x 80mm x 25mm
80mm x 80mm x 25mm
80mm x 80mm x 25mm
80mm x 80mm x 38mm
Number of Fans:
4
4
4
4
Fan Speed (per fan):
1600 RPM
1200-2400 RPM
4200 RPM
5700 RPM
Air Flow Direction
INTAKE (*E = EXHAUST)
INTAKE (*E = EXHAUST)
INTAKE (*E = EXHAUST)
INTAKE (*E = EXHAUST)
Air Flow (combined):
128 CFM
56-128 CFM
212 CFM
336 CFM
Static Pressure (per fan):
2.89 mm H²O
2.52mm H²O
0.260 in H²O
0.740 in H²O
Noise (combined):
20 dBA
12-20 dBA
45 dBA
61 dBA
Thermistor Probe length
n/a
n/a
n/a
n/a
Grills/Guards:
Black Wire
Black Wire
Black Wire
Black Wire
Bearings:
Fluid Dynamic
Fluid Dynamic
Dual Ball Bearings
Precision Ball Bearings
Power Supply:
100-240 VAC - 12 VDC
100-240 VAC - 12 VDC
100-240 VAC - 12 VDC
100-240 VAC - 12 VDC
Power Supply Plug:
NEMA 1-15 – 2.1mm
NEMA 1-15 – 2.1mm
NEMA 1-15 – 2.1mm
NEMA 1-15 – 2.1mm
Power Supply Cable:
36"
36"
36"
36"
Current draw:
0.36A
0.68A
1.92A
3.04A
Power consumption:
4.32w
8.16w
23.04w
36.4w
Weight
2 lbs.
2 lbs.
2 lbs.
2 lbs.
Operating Temperature
14 ~ 158°F (-10 ~ 70°C)
14 ~ 158°F (-10 ~ 70°C)
14 ~ 158°F (-10 ~ 70°C)
14 ~ 158°F (-10 ~ 70°C)
Storage Temperature:
-40 ~ 158°F (-40 ~ 70°C)
-40 ~ 158°F (-40 ~ 70°C)
-40 ~ 158°F (-40 ~ 70°C)
-40 ~ 158°F (-40 ~ 70°C)
Fan Model
SX80
SXT80
TV80
T80

procool AV Cooling Solutions SP480 series
PROCOOL LLC – 115 E South St Suite C, Plano, IL 60545 – P: 630-552-9999 F. 630-552-9996 – www.procool.com
Instructions:
THERMAL PROBE:
Place the temperature probe where you want it to detect the temperature. It can be left as is on the panel for
an ambient temp. Or it can be placed at the top of a cabinet or above a hot component. Try to avoid placing
the probe where the fans will blow directly on it. For best results, locate the probe where it will detect the
most heat.
PROGRAM:
Press the PROGRAM button to set the on and off temperatures for each of the 4 zones. Press the PROGRAM
button to begin. All LED’s will blink indicating programming for Global Mode. All Zones will operate with the
same temperature. Press PROGRAM again to toggle between Zones 1 through 4. The LED for the selected zone
will blink. To exit program mode press PROGRAM until all LED’s stop blinking. Settings will be automatically
saved.
START / STOP:
While in the selected PROGRAM mode, press the START button to set the temperature where the fans should
start. Use the UP and DOWN buttons to change the temperature. Then press the DOWN button to set the
temperature where the fans should stop.
Hold START and STOP together for 3 seconds to switch to Always On mode which bypasses temperature
control. The screen will display bp for bypass mode. The fans will continue to run until switched back to
temperature mode or powered off.
UP - C/F - Display:
Press the UP button to toggle between Celsius “C” or Fahrenheit “F” (when NOT in Programming mode)
Press and hold the UP button for 3 seconds to enter DARK mode. The indicator lights and display will shut off.
The controller will still function as normal. Repeat to turn the display back on.
DOWN:
Used only for setting temperature in programming mode.
HEATING FUNCTION:
Set the START temperature lower than the STOP temperature. The controller will run until the stop
temperature is reached and the environment is heated to the set temperature.
Features:
* Control 4 fans individually with 4 temp zones
* Large Temperature display (Switchable- on or off)
* Switch between Fahrenheit and Celsius easily.
* Switches from thermal control to always on mode
* Programmable from 32-212°F (0-100 Celsius)
* 32” thermal probe (48” Extensions are available separately)
Temperature probe
