Professional Pool Products RC04 User manual

INSTALLATION
MANUAL
RC04
Step-Down Transformer
+ Reciever

INSTALLATION
AUX TERMINAL CONNECTION DETAILS:
1. Prior to commencing, make sure there is no
electricity passing through the wires and cables
to be connected.
2. Mount the transformer on a solid and secure
wall at a minimum distance of 2 meters from any
water source or pipes.
3. Connect the 220V input voltage into the
terminals clearly marked as 220V AC SUPPLY
4. Connect the lamp cables to the terminals clearly
marked as LAMP 12VAC
5. Connecter, and that it is functioning.
6. It is essential to make sure the connections are as
tight as possible in order to avoid sparking.
220VAC LINE VOLTAGE12VAC
AUX SWITCH 1 AUX SWITCH 2
LIVE
NEUTRAL
LIVE
NEUTRAL
Use these terminals to connect and
operate two aux electrical items (pump,
light, etc.) using the remote.
This will function as an on/off switch.
Refer to connection details.
AUX
