INSTALLATION INSTRUCTIONS
UNIVERSAL LED BATHROOM LIGHT 30CM | UN30L
UNIVERSAL LED BATHROOM LIGHT 60CM | UN60L
INSTALLER PLEASE NOTE
Read all installation instructions carefully before commencing installation. We reserve the right to change product
specications due to possible technical improvements.
This product must be used indoors only. The electricity connection and possible subsequent electric interventions must
only be done by a qualied electrician who will operate in accordance with current regulations in terms of electricity.
The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction.
Children should be supervised so that they do not to play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
Means for disconnection that must be incorporated in the xed wiring in accordance with AS/NZS wiring rules.
Model UN30L UN60L
Product Specications Plastic Mirror Lamp
Material Plastic
Dimensions L300 x W100mm x H35mm L600mm x W100mm x H35mm
Light Source: High Power LED
Operating Temperature: -20°C to 45°C - Indoors
Ingress Protection Grade: IP44
Voltage: 230-240V ~ 50Hz
Power: 5W 9W
Colour: 4000K
Luminous: 350 Lumens 700 Lumens
Lifespan: 20,000 Hours
www.plumbline.co.nz
Distributed by:
INSTALLATION INSTRUCTIONS
UNIVERSAL LED BATHROOM LIGHT 30CM | UN30L
UNIVERSAL LED BATHROOM LIGHT 60CM | UN60L
Three different xing methods:
Fixed directly on mirror
Fixed on wall
Fixed on cabinet
Mounted On Mirror:
12
3
INSTALLATION INSTRUCTIONS
UNIVERSAL LED BATHROOM LIGHT 30CM | UN30L
UNIVERSAL LED BATHROOM LIGHT 60CM | UN60L
Mounted On Wall:
12
3
Mounted On Cabinet:
1
2
3
INSTALLATION INSTRUCTIONS
UNIVERSAL LED BATHROOM LIGHT 30CM | UN30L
UNIVERSAL LED BATHROOM LIGHT 60CM | UN60L
Safety Instructions:
• Electrical installation must be carried out by a licenced electrician.
• In case of failure please switch off the power supply immidiately.
• The light source of this luminaire is not replaceable. When the light source reaches its end of life
the whole luminaire shall be replaced.
• Only use indoors.
Wiring of 60cm model only:
Only one ex lead needs to be connected to power the entire light.
The ex lead that is not connected is not required and can be cut off and insulated at the cable
entry.
Please Note: The lead that is cut and not used will not back feed any electrical current when the
opposing lead is connected to mains 230-240V ~ 50Hz.
