Project Source PSWS-B7-20 User manual

1
VR20248
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-389-8827, 8 a.m. - 8 p.m., EST, Monday - Sunday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
MODEL #PSWS-B7-20
ITEM #2590044
7-in Wet
Tabletop Tile Saw
Español p. 27

2
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
2
3
4
5
11
17
23
24
25
26
Product Specifications.........................................................................................................
Package Contents ...............................................................................................................
Hardware Contents .............................................................................................................
Safety Information ...............................................................................................................
Assembly Instructions ........................................................................................................
Operating Instructions .......................................................................................................
Care and Maintenance .....................................................................................................
Troubleshooting ................................................................................................................
One Year Limited Warranty ..............................................................................................
Replacement Parts List .....................................................................................................
DESCRIPTION SPECIFICATIONS
Power Supply 120 V, 60 Hz
Motor 4,8 A
No Load Speed 3,450 RPM
Blade 7 in. x 5/8 in. (arbor)
Maximum Depth of Cut 1-1/4 in.
Rip Capacity (tile size) 18 in.
Diagonal Capacity (tile size) 10 in.
Bevel Cut Range 0°, 22.5°, 45°

3
EH
I
R
J
K
NM
B
F
L
A
O
P
Q
C
G
D
PACKAGE CONTENTS
A
B
C
D
E
G
I
Tile Saw 1
Miter Guide 1
Rip Guide Scale 1
Carry Handle 1
Rip Guide
Power Cord Stroage
1
1
Riving Knife 1
JCutting Wheel 1
FPower Cord 1
HBlade Guard Assembly 1
PART DESCRIPTION QUANTITY
L
M
N
Overflow Drain 1
Arbor Wrench 1
Arbor Nut Wrench 1
KExtension Table
(preassembled to tile saw)
1
OBevel Table
(preassembled to tile saw)
1
PMax Water Fill Line 1
QSwitch 1
RLower Guard 1
PART DESCRIPTION QUANTITY

4
AA
Locking Knob Assembly for Blade Guard
Replacement Part #259004409
Hardware for Riving Knife Assembly
Replacement Part #259004410
HARDWARE CONTENTS
Screw
(preassembled to
tile saw (A))
Qty. 2
Hex Bolt
Qty. 1
Lock Knob
Qty. 1
X
AA BB CC
Y
Blade Locking Assembly
Replacement Part #259004411
Arbor Nut
(preassembled
to tile saw (A))
Qty. 1
Outer Washer
(preassembled
to tile saw (A))
Qty. 1
Inner Washer
(preassembled
to tile saw (A))
Qty. 1
Z

5
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate, or install the
product.
This manual contains information that relates to PROTECTING PERSONALSAFETYand PREVENTING
EQUIPMENTPROBLEMS. It is very important to read this manual carefully and understand it thoroughly
before using the product. The symbols listed below are used to indicate this information.
DANGER
Potential hazard that will result in serious injury or loss of life.
WARNING
Hazard that could result in serious injury or loss of life.
CAUTION
Potential hazard that may result in moderate injury or damage to equipment.
SAFETY RECOMMENDATIONS
These precautions are intended for the personal safety of the operator and others working with the
operator. Failure to follow these instructions may result in a permanent loss of vision, serious personal
or even fatal injury, property damage and/or tool damage. Please take time to read and understand
them. Safety is a combination of common sense, staying alert and knowing how your saw works.
WARNING
To avoid mistakes that could cause serious injury, DO NOT plug in the saw until you have read and
understood the rules.
BEFORE USE
• For safe handling of this product, the user must have read and understood the instructions for use
before using it for the first time.
• Observe all safety instructions! If you DO NOT observe the safety instructions, you will endanger
yourself and others.
• Keep all instructions for use and safety instructions for future reference.
•Attach the instructions for use, if you pass on the product to someone else.
• KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
• All parts of the product, safety devices in particular, must be correctly installed to ensure faultless
operation.
OPERATION/WORKPLACE
• KEEP GUARDS IN PLACE and in working order.
• REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to see that keys and adjusting
wrenches are removed from tool before turning it on.
• KEEP CHILDREN AWAY. All visitors should be kept at a safe distance from work area.
• MAKE WORKSHOP CHILDPROOF with padlocks, master switches or by removing starter keys.
• DO NOT FORCE TOOL. It will do the job better and safer at the rate for which it was designed.
• USE THE RIGHT TOOL. DO NOT force tool or attachment to do a job for which it was not designed.
• DO NOT OVERREACH. Keep proper footing and balance at all times.

6
SAFETY INFORMATION
• REDUCE THE RISK OF UNINTENTIONALSTARTING. Make sure switch is in the off position before
plugging in.
• DIRECTION OF FEED. Feed work into a cutting disc against the direction of rotation of the blade or
cutter only.
• NEVER LEAVE TOOLRUNNING UNATTENDED. TURN POWER OFF. DO NOTleave tool until it
comes to a complete stop.
• The product may be used only when in a good working condition. If the product or part of the product
is defective, have it repaired by an expert.
• ALWAYS follow the applicable national and international safety, health and labor regulations.
• The product may only be used if no defects are found during the inspection. Ensure that any defective
parts are replaced before the product is used again.
• Position the product horizontally on a rigid, even surface with adequate load-bearing capacity.
• DO NOT leave any tools, objects, or cables lying in the working range of the device.
• Ensure that there is sufficient lighting during operation.
•Assume a natural and secure stance when working.
• Make sure that during operation, no body parts or clothing are caught and drawn in by rotating
components.
• The immediate environment must be free of combustible and other flammable or explosive substances.
• Young people under 18 years of age and users who are not sufficiently familiar with its operation
must not use the product.
• Persons unable to safely and carefully use the tool for physical, psychological, and neural reasons
must not use the product.
• Work with caution and only if you are physically fit. Working under the effects of fatigue, illness, alcohol,
medication and drugs is irresponsible, as you are unable to use the product safety.
SERVICE
• DISCONNECT TOOLS before servicing or when changing accessories, such as cutting discs.
• Have your electrical tool repaired only by qualified technicians, using only genuine spare parts. This
will maintain the safety of the electrical tool.
• DO NOTUSE IN A DANGEROUS ENVIRONMENT. DO NOTuse power tools in damp or wet locations,
or expose them to rain. Keep work area well lit.
• MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance.
• Follow instructions for lubricating and changing accessories.
• CHECK FOR DAMAGED PARTS. Before further use of the tool, a guard or other part that is damaged
should be carefully checked to determine that it will operate properly and perform its intended function.
Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting and any
other conditions that may affect operation. A guard or other part that is damaged should be properly
repaired or replaced.
• Only the maintenance work and troubleshooting activities described in these instructions may be carried
out. All other work must be carried out by an expert.
• Conversions, unauthorized modifications, and the use of non-approved parts are prohibited.
PRODUCT-SPECIFIC SAFETY WARNINGS
• Make sure that you ALWAYS stand to the side of the cutting disc.
• WEAR PROPER APPAREL. DO NOT wear loose clothing, gloves, neckties, rings, bracelets or other
jewelry that may get caught in moving parts. Nonslip footwear is recommended. Wear protective hair
covering to contain long hair.

7
SAFETY INFORMATION
• ALWAYS USE SAFETY GLASSES. Also use face or dust mask if cutting operation is dusty. Everyday
eyeglasses only have impact-resistant lenses; they are NOT safety glasses.
• USE RECOMMENDED ACCESSORIES. Consult the owner's manual for recommended accessories.
The use of improper accessories may cause risk of injury.
• NEVER STAND ON TOOL. Serious injury could occur if the tool is tipped or if the cutting
tool is unintentionally contacted.
• Use only cutting discs that are suitable for the product.
• Only use cutting discs in good working condition. Remove damaged or worn cutting discs immediately.
• NEVER use segmented cutting discs.
• Faults in the machine, including guards or diamond discs, should be reported as soon as they are
discovered. NEVER use the machine without the guard in position.
• DO NOT twist or bend workpieces.
• NEVER cut several workpieces simultaneously. DO NOT cut bundles made of several individual pieces.
A workpiece can get caught in the cutting disc and fly out of control.
• NEVER cut workpieces on which there are ropes, cords, bands, cables, or wires containing
such materials.
• Make regular checks to ensure that the cutting disc is correctly fastened.
• Make sure that during the cutting operation, an adequate quantity of cooling water reaches the cutting
surfaces of the disc at all times.
• NEVER cut wood or metal with this saw.
• ALWAYS maintain sufficient distance from the cutting disc. Switch off the product and wait until the
cutting disc stops before removing workpieces, residual material, etc., from the work area.
• ALWAYS pull out the main plug (disconnect the product from its power supply) before commencing
work on the product.
• A cutting disc can cause injuries, even when stationary! Use protective gloves to change the cutting
disc.
• NEVER use lateral counter pressure to bring the cutting disc to a standstill after switching off the drive.
• Replace table insert when worn.
• Use only diamond discs recommended by the manufacturer.
• NEVER use blades on this machine.
• Use only diamond discs for which the maximum possible speed is not less than the maximum spindle
speed of the tool and the material to be cut.
• Maximum size of working piece should be 10 sq. ft. (1 m2).
• This tile saw should only be used at temperatures between 59°F - 80°F.
• USE PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using
an extension cord, be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage, resulting in loss of power and overheating. page 10
shows the correct size to use depending on cord length and nameplate ampere rating. If in doubt, use
the next heavier gauge. The smaller the gauge number, the heavier the cord.
STORAGE AND TRANSPORT
• ALWAYS store the product in a dry place.
• Store the product in a frost-free place.
• Protect the product from damage during transport.
• Keep the product away from children. Store the product in a place where it is safe from children and
unauthorized persons.

8
SAFETY INFORMATION
RESIDUAL RISKS
Even when the product is used properly and in compliance with all the safety precautions in these
instructions for use, the following residual risks can arise:
• Touching the cutting disc in the exposed area.
• Reaching into the spinning cutting disc.
• Rebound from workpieces and workpiece parts.
• Cutting disc breaks.
• Faulty cutting disc diamond attachment being flung out.
• Hearing damage through failure to wear the requisite hearing protection.
WARNING
For your own safety, read instruction manual before operating saw.
• Wear eye protection.
• Use splash guard for every operation for which it can be used.
• Disconnect saw before servicing, when changing cutting wheels and cleaning.
• Use tool only with smooth edge cutting wheels free of openings and grooves.
• Replace damaged cutting wheel before operating.
• DO NOT fill water tank above water fill line.
WARNING
The tool is loud and the sound can cause hearing damage. ALWAYS wear ear protection to
help prevent hearing damage and loss. Failure to comply may result in moderate injury.
READ OPERATOR’S MANUAL
To reduce the risk of injury, user must read and understand operator’s manual before using this
product.
• USE SAFETY GOGGLES AND EAR PROTECTION
• ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CUL REQUIREMENTS.
FLYING DEBRIS can cause permanent eye damage.
USE DUST MASK
Some dust created by sawing contains chemicals that are known to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals come from lead-based paints, crystalline silica
from bricks, cement and other masonry products, arsenic and chromium from chemically treated lumber.
To reduce exposure to these chemicals, work in a well-ventilated area with approved safety equipment,
such as dust masks that are specially designed to filter out microscopic particles.

9
SAFETY INFORMATION
POSITION OF TILE SAW
• To avoid the possibility of the appliance plug or
receptacle getting wet, position tile saw to one side of
a wall-mounted receptacle to prevent water from dripping
onto the receptacle or plug. The user should arrange a
"drip loop" in the cord connecting the saw to a receptacle.
The "drip loop" is the part of the cord below the level of
the receptacle, or the connector if an extension cord is
used, to prevent water traveling along the cord and
coming into contact with the receptacle.
• If the plug or receptacle does get wet, DO NOT unplug
the cord. Disconnect the fuse or circuit breaker that
supplies power to the tool. Then unplug and examine
for presence of water in the receptacle.
ELECTRICAL SAFETY
CAUTION
In all cases, verify that the outlet in question is properly grounded. If you are not sure, have a licensed
electrician check the outlet.
GROUNDING INSTRUCTIONS
In the event of a malfunction or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of
electric shock. This tool is equipped with an electric cord that has
an equipment-grounding conductor and a grounding plug. The
plug must be plugged into a matching outlet that is properly installed
and grounded in accordance with all local codes and ordinances.
DO NOT modify the plug provided. If it will not fit the outlet, have
the proper outlet installed by a qualified electrician.
Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. The conductor with a green outer
surface, with or without yellow stripes, is the equipment-grounding
conductor. If repair or replacement of the electric cord or plug is
necessary, DO NOT connect the equipment-grounding conductor to a live terminal. Check with
a qualified electrician or service technician if the grounding instructions are not completely understood,
or if in doubt as to whether the tool is properly grounded. Use only three-wire extension cords that have
three-prong grounding plugs and three-pole receptacles that accept the tool’s plug, as shown. Repair
or replace a damaged or worn cord immediately.
Grounding pin
Grounded
outlet box
Drip loop

10
SAFETY INFORMATION
WARNING
• Use the proper extension cord. Make sure to use an extension cord that is heavy enough to carry the
current required by the tool. An undersized cord will cause a drop in line voltage, resulting in loss of
power and overheating of the tool.
• Use the extension cord only for intended purpose. DO NOT pull the extension cord to remove it from
the power socket.
Recommended size for extension cords
Amperage Rating of the Tool
(120 V Circuit Only)
Total Length of the Extension Cord
25' (7.6 m)
MINIMUM GAUGE FOR THE EXTENSION CORD (AWG)
18
MORE THAN
0
6
NOT MORE THAN
6
10
10 12
12 16
18
16
14
50' (15.2 m)
16
16
16
12
100' (30.5 m)
16
14
14
150' (45.7 m)
14
12
12
Not recommended
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE

11
ASSEMBLY INSTRUCTIONS
Unpacking
This product requires assembly.
• Carefully lift the saw from the carton and place on a level work surface.
WARNING
• DO NOT use this product if any parts in the Package Contents and Hardware Contents lists
are pre-assembled to your product when you unpack it (apart from those specified as being
pre-assembled).
Parts on this list are not assembled to the product by the manufacturer and require customer installation.
Use of a product that may have been improperly assembled could result in serious personal injury.
1. Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
2. DO NOT discard the packing material until you have carefully inspected and operated the tool.
3. The saw is factory set for accurate cutting. After assembling it, check for accuracy.
4. If any parts are damaged or missing, please call 1-866-389-8827 for assistance.
WARNING
• If any parts are damaged or missing, DO NOT operate this tool until the parts are replaced. Use of
this product with damaged or missing parts could result in serious personal injury.
• DO NOT attempt to modify this tool or create accessories not recommended for use with this tool.
Any such alteration or modification is misuse and could result in a hazardous condition leading to
possible serious personal injury.
• DO NOT connect to power supply until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
Tile Cutting Wheel
For maximum performance and safety, it is recommended that you use the 7 in. cutting wheel provided
with your saw. Additional cutting wheels are sold separately.
WARNING
• DO NOT use cutting wheels rated less than the no load speed of this tool. Failure to heed this warning
could result in personal injury. DO NOT use a wheel with cracks, gaps, or teeth.
Installing the Tile Cutting Wheel and Riving Knife
WARNING
• A 7 in. tile cutting wheel is the maximum wheel capacity of the saw. NEVER use a wheel that is too
thick to allow wheel washer to engage with the flats on the arbor. Larger wheels will come in contact
with the blade guard, while thicker wheels will prevent the arbor nut from securing the wheel on the
arbor. Either of these situations could result in serious accident and can cause serious personal injury.

12
ASSEMBLY INSTRUCTIONS
1
2
1. Unplug saw and remove bevel table (O).
2. Place arbor nut wrench (N) on arbor nut (AA), then
slide arbor wrench (M) onto arbor.
3. Holding arbor wrench (M) firmly to prevent the wheel
from moving, loosen arbor nut (AA) in counter-
clockwise direction) with arbor nut wrench (N).
1
3
AA
M
M
O
N
N
2

13
ASSEMBLY INSTRUCTIONS
4. Removearbor nut (AA) and outer washer (CC),
leaving the inner washer on the arbor.
WARNING
• ALWAYSinstall the inner wheel washer before placing
wheel on arbor. Failure to do so could cause an accident
since the wheel will not tighten properly.
NEVERuse wheels that have openings, grooves, or
teeth on this tool.
5. Place cutting wheel (J) onto arbor with arrows on
wheel goingin the counter-clockwise direction. Replace
the outer washer (CC). The double “D” flats on washers
align with flats on arbor. Replace arbor nut (AA) on
arbor. Make sure flat side of arbor nut touches outer
washer (CC).
6. Using arbor nut wrench (N)and arbor wrench (M),
tighten arbor nut securely.
AA
CC
CC
AA
J
N
M
4
5
6
Flats

14
2
2
22
1
11
ASSEMBLY INSTRUCTIONS
I
E
Z
Z
I
J
7
8
9
7. Loosen and remove screws (Z) with a Phillips
screwdriver (not included).
8. Place riving knife (I) onto the mounting area under-
neath the table. Reinstall screws (Z) through table and
into riving knife (I). Replace the bevel table.
9. To maximize cut quality align riving knife (I) with the
cutting wheel (J). Tighten screws (Z).
Note: Rip guide (E) can be used as alignment tool if
needed.
1
2
Z

15
21
ASSEMBLY INSTRUCTIONS
H
H
I
E
FF
Y
X
I
1
2
1
Installing the Blade Guard Assembly
1. Slide blade guard assembly (H) over riving knife (I)
and align holes in blade guard assembly (H) with slot
in the riving knife (I).
2. Insert hex bolt (Y) through blade guard assembly (H)
and riving knife (I). Thread the lock knob (X) onto hex
bolt (Y) and tighten to the desired height.
Note: ALWAYS adjust the blade guard horizontally to
the table and slightly above tile thickness. Blade guard
should not touch the tile.
Installing the Rip Guide
1. Lift locking lever on the rip guide (E) up and hook the
back of the rip guide (E) onto the back rim of the saw
table.
Lower front of the rip guide to the front of the saw table.
Use rip guide scales (C), located on front and rear of
table, to set rip guide to desired width of cut.
Push the locking lever down to secure to the saw table.
When securely locked, the locking lever should point
downward.
2
3
3
1

16
1
Installing the Miter Guide
1. Place slot on underside of the miter guide (B) on the
rip guide (E).
Adjust to desired angle using angle scale and tighten
securely with miter guide knob.
With rip guide at desired width, secure in place.
NOTE: The miter guide can only be used when the rip
guide is installed.
Installing the Overflow Drain
1. Remove bevel table.
Firmly push overflow drain (L) into hole in the bottom
of the water reservoir.
B
ASSEMBLY INSTRUCTIONS
1
1
L
E
2

17
OPERATING INSTRUCTIONS
WARNING
• DO NOT allow familiarity with the tools to make you careless. Remember that a careless fraction of a
second is sufficient to inflict serious injury.
• ALWAYS wear eye protection with side shields marked to comply with ANSI Z87.1. Failure to do so
could result in objects being thrown into your eyes, resulting in possible serious injury.
• DO NOT use any attachments or accessories not recommended by the manufacturer of this tool.
The use of attachments or accessories not recommended can result in serious injury.
Applications
You may use this tool for the purpose listed below:
• Straight line cutting operations such as cross cutting, mitering, ripping, and beveling.
Note: This saw is designed to cut man-made tile, pavers, and stone tile products only.
On/Off Switch
This saw is equipped with a switch that has a built-in
locking feature. This feature is intended to prevent
unauthorized and possible hazardous use by children
and others.
To Turn the Saw On
With the switch key inserted into the switch, lift the
switch to turn ON (I).
To Turn the Saw Off
Press the switch down to turn OFF (O).
Locking Saw
With the saw turned OFF, remove the safety key from
the switch. Store the key in a safe place.
WARNING
• In the event of a power failure or when the tool is not
in use, turn the switch OFF. This action will prevent
the tool from accidentally starting when power returns.
• ALWAYS make sure your workpiece is not in contact
with the cutting wheel before operating the switch to
start the tool. Failure to heed this warning may cause
the workpiece to be kicked back toward the operator
and result in serious personal injury.
• To reduce the risk of accidental starting, ALWAYS make
sure the switch is in the OFF position before plugging
tool into the power source.
ONON
LOCKED
OFFOFF
LOCKED

18
12
OPERATING INSTRUCTIONS
1
2
L
K
Filling the Reservoir Water
1. Fill the water reservoir with clean tap water to the max
fill line.
Note: The overflow drain prevents overfilling.
To Change Reservoir Water
1. Unplug the saw.
2. Remove the overflow drain and empty waste water
into a bucket. DO NOT allow the water to splash onto
the ground or around the machine.
3. Rinse the machine thoroughly.
Note: Make sure there is no debris inside the water level
component compartment.
4. Discard the waste water in accordance with local
regulations.
5. Replace with clean water.
Using the Extension Table
The extension table can be used on either side of the
tile saw to support large format tile.
• Simply slide extension table (K) out for the best support
for the size of the tile you are cutting.
• Return the extension table (K) to the inner position after
finishing the cutting.

19
2
2
Using the Rip Guide
The rip guide can be used on either the left or the right of side of the cutting wheel. Refer to the Installing
the Rip Guide section on Page 15 if necessary.
• Install the rip guide in the desired position using the rip guide scales (C) located on front and rear of
the saw table, refer to the Installing the Rip Guide section.
Using the Miter Guide
To adjust angles:
• Attach the miter guide (B) to the rip guide (E).
• Loosen the miter guide knob and rotate to the desired
angle by moving the guide left or right.
• Securely tighten the miter guide knob.
Making Cuts
WARNING
• ALWAYS put the tile saw on a clean, stable and flat surface.
• Maintain an adequate distance from the cutting wheel when cutting.
• Do not reach into the working range of the spinning cutting wheel while the product is operating.
• Carefully check the workpiece to be machined. There must not be objects, such as utility lines, nearby
that will present a hazard while working.
• This saw is designed to cut man-made tile, pavers, and stone tile products only.
• Wait until the cutting wheel has reached its maximum speed before commencing work.
• Before commencing work, check there is sufficient cooling water in the product.
• In the case of complex cuts (miter or bevel cuts) we recommend making a test cut beforehand.
• The cutting wheel will continue to rotate for a few seconds after the machine has been switched off.
Wait for the cutting wheel to stop before removing the workpiece, or making any adjustments.
• ALWAYS draw the line to be cut on the tile using a marker or grease pencil. If the tile is shiny and
hard-to-mark, place masking tape on the tile and mark the tape.
• A common problem when cutting tile is straying from the marked line. Once you’ve strayed from the
mark, you can not force the wheel back to the line by twisting the tile. Instead, back up and recut the
tile slicing off a small amount of tile until the wheel is back on track.
• To avoid this problem, use the rip guide or miter guide whenever possible.
• Another problem is cutting difficult material. To prevent chipping of the material at the end of the cut:
first cut 1-1/2 in. of the material, then turn off the saw; flip the material around 180° and make the cut.
• Clean the saw blade, rip and miter guides, and bevel table frequently during use. Debris from the cut
material can interfere with the function of the tool.
E
B
OPERATING INSTRUCTIONS
3
1

20
OPERATING INSTRUCTIONS
Making a Cross Cut
Cross cuts are straight 90° cuts. The material is fed into
the saw at a 90° angle to the wheel.
• Using a marker or grease pencil, mark the area to be
cut on material.
• Remove the miter gauge.
• Position the rip guide (E) the desired distance from the
wheel for the cut and securely locking lever.
• Place the material on the table, firmly against the rip
guide.
• Make sure the material is clear of the cutting wheel
before turning on the saw.
• Turn the on/off switch to the ON position.
• Let the cutting wheel build up to full speed and wait for
the wheel to get wet before moving the material into
the wheel.
• Hold the material firmly against the rip guide and feed
the material into the cutting wheel.
• When the cut is made, turn the saw OFF. Wait for the
cutting wheel to come to a complete stop before
removing any part of the material.
Making a Diagonal Cut
45° Diagonal cuts are also referred to as “long point-to-
long point cuts”.
• Using a marker or grease pencil, mark the area to be
cut on material.
• Install the miter guide (B).
• Adjust miter guide to 45° using angle scale and tighten
securely with miter guide knob.
• Place the material on the table and firmly against the
miter guide.
• Make sure the material is clear of the cutting wheel
before turning on the saw.
• Turn the on/off switch to the ON position.
• Let the cutting wheel build up to full speed and wait for
the wheel to get wet before moving the material into the
wheel.
• Hold the material firmly against the miter guide and
table fence. Feed the material into the cutting wheel.
• When the cut is made, turn the saw OFF. Wait for the
cutting wheel to come to a complete stop before
removing any part of the material.
