Projecta IS910E User manual

1
LITHIUM EMERGENCY
JUMPSTARTER
P/No. IS910E, IS1210E
AND PORTABLE POWER BANK

2
IMPORTANT SAFETY INFORMATION
Please read this manual thoroughly before use and store in a safe place for future
reference.
WARNINGS
• Risk of explosive gas. Working in the vicinity of a lead-acid battery can be dangerous.
Batteries release explosive gases during normal operation, charging and while
jumpstarting a battery. Before using this Jumpstarter, read and follow the instructions
carefully. Follow all manufacturer’s instructions and warnings on the vehicle’s battery and
other equipment being used.
• Jumpstart 12V lead-acid batteries only. Do not use to jumpstart dry-cell batteries
commonly found in household appliances. These batteries may burst and cause injury
and/or property damage.
• Do not smoke, use matches, use a cigarette lighter, or allow a spark or flame near the
battery.
• Do not allow metal to come in contact with the battery posts. It may spark or short circuit
the battery and cause an explosion/fire.
• Always wear eye protection when operating the Jumpstarter.
• Remove rings, bracelets, necklaces and watches when working with a lead-acid battery.
• Contains a Lithium Cobalt battery and must be disposed of properly.
• Ensure correct polarity when connecting to vehicle.
• Although the Jumpstarter is rain proof it is not designed to be left outside for extended
periods or submerge in water.
• Although the Jumpstarter has been designed to protect the battery it is best to not drop
the Jumpstarter or try and pierce the Jumpstarter in anyway, as this can result in a fire.
If the Jumpstarter is physically damaged in any way do not use.
• Do not store the Jumpstarter in temperatures above 40oCelsius or below -10oCelsius, as
this can affect the health of the battery and if the temperature is above 120oCelsius the
battery may catch fire.
• Not intended for people (including children) with reduced physical or mental capability.
• Once the vehicle is started disconnect the Jumpstarter immediately after starting.
• Do not try and charge via the USB output as this will damage the Jumpstarter and the
USB output.
IMPORTANT CHARGING INFORMATION
• Charge Jumpstarter prior to first use, this may take up to 4 to 8 hours depending on
the model.
• Fully recharge the Jumpstarter after every use to ensure your Jumpstarter is ready in
emergencies.
• To extend the life of your battery do not let the battery charge level fall below 20%.
• To extend the life of the Jumpstarter battery, do not charge above 45oC or below 0oC.

3
FEATURES
IS910E
The IS910E is suitable for starting most 12V Petrol vehicles up to 6 litres.
IS1210E
The IS1210E is suitable for starting most 12V Petrol vehicles up to 7 litres and diesel
vehicles up to 3.2 litres.
12V USB CHARGING – Allowing the Jumpstarter to be charged from your vehicle
cigarette socket.
LITHIUM BATTERY – Increased storage life and a much more compact lightweight unit.
PREMIUM SPARK FREE CLAMPS – Ensuring safe Jumpstarting.
INCORPORATING HIGHEST RATE OF DISCHARGE BATTERY – For increased
starting capacity.
POWER BANK WITH 2.1AMP USB PORT – Allowing charging of phones, tablets and
other small portable devices.
EASY TO READ BATTERY STATUS INDICATOR – Shows battery status and when
recharge is required.
CONNECTION INDICATION – Confirms clamp connectivity and status.
INBUILT LED FLOOD LIGHT – Inbuilt LED flood light provides illumination for safer,
more convenient operation at night.
ADDED PROTECTION, SAFETY AND RELIABILITY
TOTAL SAFEGUARD PROTECTION – Includes Over voltage Protection, Battery &
Switch Over-temperature Protection, Short Circuit Protection, Over Current Protection,
Over Cranking Protection, Under-voltage Protection, Low voltage indication, Battery Cell
Balancing to protect the user, vehicle and Jumpstarter.
SMART MODULE – A second layer of protection, preventing the unit from over charging.
REVERSE POLARITY PROTECTION & ALARM – Prevents sparking from accidental
reverse connection. The alarm sounds when the Jumpstarter clamps are connected
incorrectly.
SURGE PROTECTION – IS910E/IS1210E features built in surge protection so you
can safely Jumpstart vehicles with EFI (electronic fuel injection) and computer
management systems.

4
Part No. IS910E IS1210E
Battery
Battery Type Lithium Cobalt (LiCo)
Voltage 12 Volt only
Battery Capacity 6,600mAhr at 3.7V 13,500mAhr at 3.7V
24.4wHr at 3.7V 50.0wHr at 3.7V
2.2Ahr at 12.0V 4.5Ahr at 12.0V
Peak Amps 900A 1200A
Clamp Power 240A 330A
Number of Jumpstarts 7 Starts (Petrol) 14 Starts (Petrol)
(vehicle without a battery) 0 Starts (Diesel) 0 Starts (Diesel)
Number of Emergency Jumpstarts* 14 Starts (Petrol) 28 Starts (Petrol)
(with a flat vehicle battery) 0 Starts (Diesel) 5 Starts (Diesel)
Battery Cycles 500 500
USB Output
USB output 2.1A, 5.0V
USB low Voltage Disconnect Battery voltage at 9.0V
Jumpstarter Leads
Length Positive 23.5cm, Negative 16.5cm
Cable 8mm² 8(AWG)
Polarity Protection MCU controlled with Electronic Switch Smart Module
Overload Protection MCU controlled with Electronic Switch Smart Module
Recharging
Cable 1m long USB to Micro USB
Micro USB Charging port 2.1Amp micro USB charging port
3rd party 10W 240VAC USB adaptors can
be used. (Not Provided)
12V DC charging 12V to 5V 2.1Amp USB charger (provided)
Recharge time 4 hours 8 hours
Jumpstart Connection Voltages
Vehicle Voltage Range 0~15.0V
Dimensions, Weight & Environmental
Height 47mm
Width 178mm
Depth 91mm
Weight 0.61Kg 0.76Kg
Operating Temperature 0 to 45°C
Storage Temperature -20 to 40°C
Ingress Protection IP52 (Rain Proof) with covers over the ports
* Tested on a Ford Ranger 3.2L Diesel and Ford Territory 4.0L Petrol with a flat battery in good condition
SPECIFICATIONS

5
PRODUCT OVERVIEW
Battery
Clamps
Connection
Port
Premium Spark
Free Clamps
Durable Padded
Carry Case 2.1A USB
Accessory port
Battery Status
Indicator Clamp
Connection LED
2 x 0.5 Watt
LED Flood Light
with SOS Function
Micro USB
Charging Lead
Flood Light
On/Off 12V 2.1A USB Charging
Plug Adaptor
On/Off Jump Start
Button
Smart
Module
Jumpstarter
Charging Port

6
VEHICLE JUMPSTARTING INSTRUCTIONS
1. Your Jumpstarter should be charged for 8 hours prior to first use and as soon as
possible after each use.
2. Before making any connections, check the Jumpstarter battery status by turning on the
Jumpstarter. The Jumpstarters battery capacity should show at least 2 bars or 50%
charged.
3. Turn your vehicle’s ignition OFF before connecting the Jumpstarters clamps to
your vehicle.
4. Connect the Red Positive (+) clamp to the positive (+) terminal of the battery in the
vehicle and the Black Negative (-) clamp to the negative (-) terminal of the battery
or any non moving metal part of the engine block. DO NOT CONNECT TO FUEL LINE.
Always double check that you have the proper connections.
5. Press and hold the Jump Start button for 1 second. The Clamp LED should turn
on to Green.
6. Turn the vehicle’s ignition to ON and start the vehicle. After the engine has started,
turn the Jumpstarter off. If the Jumpstarter fails to start your vehicle refer to the
Clamp Connection LED table below for any error it may indicate & check that the
clamps are correctly connected with good contact.
7. Disconnect the Black clamp and then the Red clamp.
8. Recharge the Jumpstarter.
UNDERSTANDING YOUR JUMPSTARTER
CLAMP CONNECTION LED
Jumpstart Status LED State
Jumpstarter clamps connected to vehicle and ready to jumpstart Green Solid
Jumpstarting for more than 5 seconds 2 x Yellow Flash,
pause & repeat
Battery or Jumpstarter switch, Over-temperature Red/Green Alternate
flashing
Battery Charging in Temperatures >60°C or <0°C Red/Green Alternate
flashing and Siren
Short Circuit Red Flashing &
Beeping Siren
Clamps reverse connected to battery Red Solid and
Siren on
Jumpstarter is connected to vehicle battery and the Smart Red fast flash, Siren
Module has failed. Go to store to get P/n: ISECLAMP. Steady on
Jumpstarter is not connected to a vehicle battery. Red fast flash, Siren
Jumpstarter has an internal fault and can not be used. Steady on

7
BATTERY STATUS INDICATOR
When Jumpstarter is turned on battery gauge LED’s are displayed.
State of Charge Battery Gauge LED Display
<20% – Red Flashing
20–25% – Red
25–50% – Yellow
50–75% – Green
75–100% – Green
The Jumpstarter will beep if less than 10.0V until charged or turned off.
CHARGING THE JUMPSTARTER
The Jumpstarter can be charged with the provided 12V DC to USB charge adaptor or a via
3rd party 10 Watt USB 240VAC charger (tablet charger).
1. Plug the 12V to 2.1A USB charge adaptor into a 12V socket.
2. Use the provided USB to micro USB cable:
a. Connect the USB end into the 12V to USB socket.
b. Connect the micro USB end to the Jumpstarter.
The Jumpstarter will now turn on and start charging. The BATTERY STATUS INDICATOR
will now start to scroll in the following ways depending on its state of charge.
State of Charge Battery Gauge LED Display
<20% – All Flashing
20–50% – Red with Yellow & Green Flashing
50–75% – Yellow with Green Flashing
75–99% – Green with Green Flashing
100% – All Solid Green
3. When your Jumpstarts is fully changed after 4 hours for IS910E or 8 hours for
IS1210E, simply disconnect the leads and put the Jumpstarter away.

8
WHEN TO CHARGE
Your Jumpstarter is shipped partially charged. Therefore you should charge the Jumpstarter
before using it for the first time. It is recommended to charge fully after each use so the
Jumpstarter is ready in case it is required.
POWER BANK
The Jumpstarter has a USB output with 2.1A out. It is suitable to charge phones, tablets,
cameras and GPS devices. The Jumpstarter will turn off after 5 minutes of no activity or
the USB device has been fully charged.
If the USB output becomes overloaded, remove the device and check it. Turn the
Jumpstarter off and back on again, the USB output should work again
WARNING: Charging devices from the Jumpstarter will drain the battery and potentially
cause the Jumpstarter to fail to start your vehicle in an emergency. Recharge the
Jumpstarter as soon as possible.
FLOOD LIGHT
The Flood light has two functions, Flood light mode and SOS mode.
Flood light mode
Press and hold the light button for less than 3 seconds and the light will turn on. Press the
Light button again to turn the light off when you are finished.
Note: If the Jumpstarter is off and the light button is pressed, the button will need to be
pressed for at least ½ second before the light will turn on.
SOS mode
Press and hold the light button for more than 3 seconds and the work light will now
transmit SOS in Morse code. Press the light button again to turn off.
Note: The Flood light is not on a timer and will continue to operate until the battery is flat.

9
FREQUENTLY ASKED QUESTIONS
Q. Why didn’t my Jumpstarter start my vehicle?
A. There could be a number of reasons why the Jumpstarter did not start you vehicle.
Check the following:
1. Ensure the Jumpstarter battery is fully charged. Refer to page 7 (“BATTERY STATUS
INDICATOR”) for further information.
2. Ensure you have followed the correct operating procedure. Refer to page 5
(“Vehicle Jumpstarting Instructions”).
3. Ensure the vehicle operates on 12V DC
4. Ensure the vehicle being jumpstarted does not require a clamp output greater than
240 Amps (IS910E) or 330 Amps (IS1210E) in order to jumpstart the vehicle.
Q. Can I leave my Jumpstarter connected to car after it has started?
A. No. The Jumpstarter is not a replacement battery and should be disconnect from the
vehilce battery after the engine has started. Once the engine has started the jumpstarter
has already internally disconnected so the jumpstarter is not providing any benefit to
the vehicle and is best packed away so the jumpstarter does not fall into the engine or
moving parts.
Q. How often should I charge my Jumpstarter?
A. The Jumpstarter uses Lithium technology which self discharges only a very small amount.
To be safe the Jumpstarter should be charged at least every year to be sure it is ready in
case of an emergency.
Q. Can I charge the Jumpstarter and use the USB output at the same?
A. Yes that will not be a problem.
Q. What is Peak Amps?
A. Peak amps is the maximum current the battery in the Jumpstarter can produce.
Q. What is Clamp Power?
A. Clamp power is the maximum current available at the clamps.
Q. What is the Smart Module?
A. The Smart Module prevents the unit from overcharging and creates a second layer
of protection.

10
NOTES

11
NOTES

Distributed by
AUSTRALIA
Brown & Watson International Pty Ltd
Knoxfield, Victoria 3180
Telephone [phone]
Facsimile [phone]
National Toll Free 1800 113 443
NEW ZEALAND
Narva New Zealand Ltd
22–24 Olive Road
PO Box 12556 Penrose
Auckland, New Zealand
Telephone [phone]
Facsimile [phone] IS351
Issue 2 23.11.18
WARRANTY STATEMENT
Brown & Watson International Pty. Ltd. (“BWI”) of 1500 Ferntree Gully Road, Knoxfield,
Vic., telephone [phone], fax [phone], warrants that all products described
in its current catalogue will under normal use and service be free of failures in material
and workmanship for a period of one (1) year from the date of the original purchase by
the customer as marked on the invoice (see elsewhere for specific warranty period). This
warranty does not cover ordinary wear and tear, abuse, alteration of products or damage
caused by the purchaser.
To make a warranty claim the consumer must deliver the product at their cost to the
original place of purchase or to any other place which may be nominated by either BWI or
the retailer from where the product was bought in order that a warranty assessment may
be performed. The consumer must also deliver the original invoice evidencing the date and
place of purchase together with an explanation in writing as to the nature of the claim.
In the event that the claim is determined to be for a minor failure of the product then
BWI reserves the right to repair or replace it at its discretion. In the event that a major
failure is determined the consumer will be entitled to a replacement or a refund as well as
compensation for any other reasonably foreseeable loss or damage.
This warranty is in addition to any other rights or remedies that the consumer may have
under State or Federal legislation.
IMPORTANT NOTE
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
