Prolon T1000 Series User manual

T1000
User Guide
Introduction
The T1000 digital thermostats are designed for operation in conjunction with
the ProLon VC1000 VAV zone controllers, to which they provide zone
temperature, setpoint and occupancy status override information. They also
provide an access point from which to visualize and configure any parameter on
the connected VC1000 through an on-screen menu system. The T1000 features
a circular capacitive touch pad, graphic LCD screen with backlighting and an
auxiliary analog input suitable for temperature averaging.
Installation
1. Open casing to remove back cover by
pushing on the tab located underneath the
thermostat. (Figure 1)
2. Pull wire(s) through central hole of back
cover.
3. Screw in the back cover to the wall.
4. Connect wires:
oIf using twisted pair wires:
Pull out the screw terminal
blocks.
Remove 1 cm insulation from the
end of each wire.
Connect the wires to the terminal
blocks and re-connect the
terminal blocks. (Figure 2)
Reinstall terminal blocks.
oIf using CAT5 cable:
Plug the cable into the RJ45 jack
5. Reconnect top cover
Figure 1
Figure 2
Important: Do not install the thermostat under the following conditions:
xAny location exposed to direct sunlight
xOn an outside wall
xNear an air discharge grill
xIn a location where vertical air circulation is restricted
xNear a dimmer switch
1

Operation
The T1000 is controlled using the
circular touch pad on the bottom half
of the thermostat. The touch pad
uses capacitive sensing technology
to detect finger proximity. There are
no moving parts to push or rotate.
The T1000 is controlled using simple
scrolling, tapping or holding motions,
performed around the circle of the
touch pad. The center of the circle is
unused.
Tap here to
go BACK Tap here to ENTER
Scroll clockwise or
counterclockwise
to adjust or navigate
FEEDBACK
The black
arc follows
your finger
22.8 ºC
Hint Display
At the bottom of the screen, a circle
representing the touch pad is
displayed, with hints on how to
navigate and modify settings, as well
as providing feedback as you
manipulate the touch pad. Hints are
context-sensitive and will only
display where logical. HINTS
Hold your finger over
highlighted areas to use
special features
Changing the setpoint
2

Schedule Override
Navigating Menus
3

Specifications
Supply: 24 VAC ±10%, 50/60 Hz
Power consumption: 5 VA max
Inputs: 1 analog input (Thermistor 10K type3 /
dry contact), 10 bit resolution (1024 segments)
Outputs: None
Screen: LCD 80x130 pixels with back lighting
Interface: Circular capacitive touch pad
Audible feedback: Yes
Processor: Atmel 32 bits, 60 MHz, 256K bytes Flash
Connection: Screw-type terminal blocks (16 AWG max)
and RJ45 modular jack
Dimensions: 82 mm x 126 mm ( 3.23" x 4.96" )
Weight: 0.1 kg (0.22 lb)
Environment: 0-50 ºC (32-122 ºF)
Mounting: Standard electrical box 2" x 4"
Dimensions
