ProSoft Technology MVI56E-MNETC User manual

MVI56E-MNETC/MNETCXT
ControlLogix Platform
Modbus TCP/IP Client Enhanced
Communication Module - Client/Server
September 20, 2018
USER MANUAL

Your Feedback Please
We always want you to feel that you made the right decision to use our products. If you have suggestions, comments,
compliments or complaints about our products, documentation, or support, please write or call us.
How to Contact Us
ProSoft Technology, Inc.
[phone]
[phone] (Fax)
www.prosoft-technology.com
[email protected]
MVI56E-MNETC/MNETCXT User Manual
September 20, 2018
ProSoft Technology®, is a registered copyright of ProSoft Technology, Inc. All other brand or product names are or
may be trademarks of, and are used to identify products and services of, their respective owners.
In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments.
User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided at our website:
www.prosoft-technology.com
Content Disclaimer
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of
these products for specific user applications. It is the duty of any such user or integrator to perform the appropriate
and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or
use thereof. Neither ProSoft Technology nor any of its affiliates or subsidiaries shall be responsible or liable for
misuse of the information contained herein. Information in this document including illustrations, specifications and
dimensions may contain technical inaccuracies or typographical errors. ProSoft Technology makes no warranty or
representation as to its accuracy and assumes no liability for and reserves the right to correct such inaccuracies or
errors at any time without notice. If you have any suggestions for improvements or amendments or have found errors
in this publication, please notify us.
No part of this document may be reproduced in any form or by any means, electronic or mechanical, including
photocopying, without express written permission of ProSoft Technology. All pertinent state, regional, and local safety
regulations must be observed when installing and using this product. For reasons of safety and to help ensure
compliance with documented system data, only the manufacturer should perform repairs to components. When
devices are used for applications with technical safety requirements, the relevant instructions must be followed.
Failure to use ProSoft Technology software or approved software with our hardware products may result in injury,
harm, or improper operating results. Failure to observe this information can result in injury or equipment damage.
Copyright © 2018 ProSoft Technology, Inc. All Rights Reserved.
Printed documentation is available for purchase. Contact ProSoft Technology for pricing and availability.
North America: [phone]
Asia Pacific: +603.7724.2080
Europe, Middle East, Africa: +33 (0) 5.3436.87.20
Latin America: +1.281.298.9109

Important Safety Information
North America Warnings
A This Equipment is Suitable For Use in Class I, Division 2, Groups A, B, C, D or Non-Hazardous Locations Only.
B Warning –Explosion Hazard –Substitution of Any Components May Impair Suitability for Class I, Division 2.
C Warning –Explosion Hazard –Do Not Disconnect Equipment Unless Power Has Been Switched Off Or The
Area is Known To Be Non-Hazardous.
D The subject devices are powered by a Switch Model Power Supply (SMPS) that has regulated output voltage of
5 VDC.
ATEX/IECEx Warnings and Conditions of Safe Usage:
Power, Input, and Output (I/O) wiring must be in accordance with the authority having jurisdiction.
A Warning - Explosion Hazard - When in hazardous locations, turn off power before replacing or wiring modules.
B Warning - Explosion Hazard - Do not disconnect equipment unless power has been switched off or the area is
known to be non-hazardous.
C These products are intended to be mounted in an ATEX/IECEx Certified, tool-secured, IP54 enclosure. The
devices shall provide external means to prevent the rated voltage being exceeded by transient disturbances of
more than 40%. This device must be used only with ATEX certified backplanes.
D Before operating the reset switch, be sure the area is known to be non-hazardous.
E If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment
may be impaired.
Agency Approvals & Certifications
Please visit our website: www.prosoft-technology.com
<Ex>
II 3 G
Ex nA IIC T4 Gc
0°C <= Ta <= 60°C
-25°C <= Ta <= 70°C (XT models only)
II –Equipment intended for above ground use (not for use in mines).
3 –Category 3 equipment, investigated for normal operation only.
G –Equipment protected against explosive gasses.
For professional users in the European Union
If you wish to discard electrical and electronic equipment (EEE), please contact your dealer or supplier
for further information.
Warning –Cancer and Reproductive Harm –www.P65Warnings.ca.gov

Battery Life Advisory
Note: Modules manufactured after April 1st, 2011 do not contain a battery. For modules manufactured before that
date the following applies:
The module uses a rechargeable Lithium Vanadium Pentoxide battery to back up the real-time clock and CMOS
settings. The battery itself should last for the life of the module. However, if left in an unpowered state for 14 to 21
days, the battery may become fully discharged and require recharging by being placed in a powered-up ControlLogix
chassis. The time required to fully recharge the battery may be as long as 24 hours.
Once it is fully charged, the battery provides backup power for the CMOS setup and the real-time clock for
approximately 21 days. Before you remove a module from its power source, ensure that the battery within the module
is fully charged (the BATT LED on the front of the module goes OFF when the battery is fully charged). If the battery
is allowed to become fully discharged, the module will revert to the default BIOS and clock settings.
Note: The battery is not user-replaceable or serviceable.
Electrical Ratings:
Backplane current load: 800mA @ 5 VDC; 3mA @ 24 VDC
Markings:
DC Voltage symbol
Caution symbol

MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform Contents
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 5 of 172
September 20, 2018
Contents
Your Feedback Please........................................................................................................................2
How to Contact Us..............................................................................................................................2
Content Disclaimer..............................................................................................................................2
Important Safety Information...............................................................................................................3
Battery Life Advisory...........................................................................................................................4
1Start Here 9
1.1 System Requirements.............................................................................................10
1.2 Setting Jumpers ......................................................................................................11
1.3 Installing the Module in the Rack ............................................................................12
1.4 Creating a New RSLogix 5000 Project....................................................................13
1.4.1 Before You Import the Add-On Instruction..............................................................14
1.4.2 Creating the Module................................................................................................15
1.4.3 Importing the Add-On Instruction ............................................................................18
1.4.4 Adding Multiple Modules (Optional) ........................................................................21
1.5 Connecting Your PC to the ControlLogix Processor...............................................27
1.6 Downloading the Sample Program to the Processor..............................................28
2MVI56E-MNETC/MNETCXT Configuration 29
2.1 Using ProSoft Configuration Builder Software........................................................29
2.1.1 Installing ProSoft Configuration Builder ..................................................................29
2.1.2 Upgrading from MVI56-MNETC in ProSoft Configuration Builder ..........................30
2.1.3 Setting Up the Project .............................................................................................30
2.1.4 Setting Module Parameters.....................................................................................33
2.1.5 Module.....................................................................................................................34
2.1.6 MNET Servers.........................................................................................................39
2.1.7 MNET Client x .........................................................................................................42
2.1.8 MNET Client x Commands......................................................................................44
2.1.9 Static ARP Table.....................................................................................................51
2.1.10 Ethernet Configuration ............................................................................................53
2.2 Connecting Your PC to the Module.........................................................................54
2.2.1 Using CIPconnect to Connect to the Module ..........................................................54
2.2.2 Using RSWho to Connect to the Module ................................................................64
2.2.3 Connecting Your PC to the Module's Ethernet Port................................................65
2.3 Downloading the Project to the Module ..................................................................68
3Using Controller Tags 71
3.1 Controller Tags........................................................................................................71
3.1.1 MVI56E-MNETC Controller Tags............................................................................72
3.2 User-Defined Data Types (UDTs)...........................................................................73
3.2.1 MVI56E-MNETC User-Defined Data Types............................................................73
3.3 Controller Tag Overview..........................................................................................74
3.3.1 MNETC.DATA.........................................................................................................74
3.3.2 MNETC.CONTROL.................................................................................................77
3.3.3 MNETC.STATUS ....................................................................................................78
3.3.4 MNETC.UTIL...........................................................................................................78

Contents MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
User Manual Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Page 6 of 172 ProSoft Technology, Inc.
September 20, 2018
4Diagnostics and Troubleshooting 81
4.1 Ethernet LED Indicators.......................................................................................... 81
4.1.1 Scrolling LED Status Indicators.............................................................................. 82
4.1.2 Non-Scrolling LED Status Indicators ...................................................................... 83
4.2 Clearing a Fault Condition ...................................................................................... 83
4.3 Troubleshooting the LEDs...................................................................................... 84
4.4 Using the Diagnostics Menu in ProSoft Configuration Builder ............................... 85
4.4.1 The Diagnostics Menu............................................................................................ 88
4.4.2 Monitoring Module Information............................................................................... 89
4.4.3 Monitoring Backplane Information.......................................................................... 90
4.4.4 Monitoring Database Information............................................................................ 90
4.4.5 Monitoring MNETC Server Information .................................................................. 91
4.4.6 Monitoring MNET Client Information....................................................................... 92
4.5 Reading Status Data from the Module ................................................................... 92
4.5.1 Status Data Definition............................................................................................. 93
4.5.2 Configuration Error Word........................................................................................ 96
4.5.3 Client Command Errors.......................................................................................... 96
4.6 Connecting to the Module's Web Page .................................................................. 98
5Reference 101
5.1 Product Specifications .......................................................................................... 101
5.1.1 General Specifications.......................................................................................... 101
5.1.2 Functional Specifications...................................................................................... 102
5.1.3 Hardware Specifications....................................................................................... 102
5.2 Functional Overview ............................................................................................. 103
5.2.1 Backplane Data Transfer...................................................................................... 103
5.2.2 Normal Data Transfer Blocks................................................................................ 106
5.2.3 Special Function Blocks........................................................................................ 110
5.2.4 Data Flow between MVI56E-MNETC/MNETCXT Module and Processor ........... 129
5.3 Ethernet Cable Specifications............................................................................... 134
5.3.1 Ethernet Cable Configuration ............................................................................... 134
5.3.2 Ethernet Performance........................................................................................... 134
5.4 Modbus Protocol Specification ............................................................................. 135
5.4.1 About the Modbus Protocol .................................................................................. 135
5.4.2 Read Coil Status (Function Code 01)................................................................... 136
5.4.3 Read Input Status (Function Code 02)................................................................. 137
5.4.4 Read Holding Registers (Function Code 03)........................................................ 138
5.4.5 Read Input Registers (Function Code 04)............................................................ 139
5.4.6 Force Single Coil (Function Code 05) .................................................................. 140
5.4.7 Preset Single Register (Function Code 06).......................................................... 141
5.4.8 Read Exception Status (Function Code 07) ......................................................... 142
5.4.9 Diagnostics (Function Code 08) ........................................................................... 142
5.4.10 Force Multiple Coils (Function Code 15) .............................................................. 144
5.4.11 Preset Multiple Registers (Function Code 16)...................................................... 145
5.4.12 Modbus Exception Responses............................................................................. 145
5.5 Using the Optional Add-On Instruction................................................................. 148
5.5.1 Before You Begin.................................................................................................. 148
5.5.2 Overview............................................................................................................... 148
5.5.3 Importing the Optional Add-On Instruction ........................................................... 150
5.5.4 Reading the Ethernet Settings from the Module................................................... 154
5.5.5 Writing the Ethernet Settings to the Module......................................................... 156

MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform Contents
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 7 of 172
September 20, 2018
5.5.6 Reading the Clock Value from the Module............................................................157
5.5.7 Writing the Clock Value to the Module..................................................................158
5.6 Adding the Module to an Existing Project .............................................................159
5.7 Using the Sample Program...................................................................................162
5.7.1 Opening the Sample Program in RSLogix............................................................162
5.7.2 Choosing the Controller Type ...............................................................................164
5.7.3 Selecting the Slot Number for the Module ............................................................165
5.7.4 Downloading the Sample Program to the Processor............................................166
5.7.5 Adding the Sample Ladder to an Existing Application ..........................................166
6Support, Service & Warranty 167
6.1 Contacting Technical Support...............................................................................167
6.2 Warranty Information.............................................................................................169
Index 170

MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 8 of 172
September 20, 2018

MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform Start Here
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 9 of 172
September 20, 2018
1 Start Here
In This Chapter
System Requirements...........................................................................10
Setting Jumpers ....................................................................................10
Installing the Module in the Rack...........................................................12
Creating a New RSLogix 5000 Project..................................................13
Connecting Your PC to the ControlLogix Processor..............................27
Downloading the Sample Program to the Processor.............................28
To get the most benefit from this User Manual, you should have the following
skills:
Rockwell Automation®RSLogix™ software: launch the program, configure
ladder logic, and transfer the ladder logic to the processor
Microsoft Windows®:install and launch programs, execute menu
commands, navigate dialog boxes, and enter data
Hardware installation and wiring: install the module, and safely connect
Modbus TCP/IP and ControlLogix devices to a power source and to the
MVI56E-MNETC/MNETCXT module’s application port(s)

Start Here MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
User Manual Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Page 10 of 172 ProSoft Technology, Inc.
September 20, 2018
1.1 System Requirements
The MVI56E-MNETC/MNETCXT module requires the following minimum
hardware and software components:
Rockwell Automation ControlLogix®processor (firmware version 10 or higher)
with compatible limited voltage power supply and one free slot in the rack for
the MVI56E-MNETC/MNETCXT module. The module requires 800mA of
available 5 VDC and 3 mA of available 24 VDC power.
Rockwell Automation RSLogix 5000 programming software
oVersion 16 or higher required for Add-On Instruction
oVersion 15 or lower must use Sample Ladder, available from
www.prosoft-technology.com
Rockwell Automation RSLinx®communication software version 2.51 or higher
ProSoft Configuration Builder (PCB) (included)
Pentium®II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
Supported operating systems:
oMicrosoft Windows®Vista
oMicrosoft Windows XP Professional with Service Pack 1 or 2
oMicrosoft Windows 7 Professional (32-or 64-bit)
oMicrosoft Windows 2000 Professional with Service Pack 1, 2, or 3
oMicrosoft Windows Server 2003
128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 768 recommended)
Note: The Hardware and Operating System requirements in this list are the minimum
recommended to install and run software provided by ProSoft Technology®. Other third party
applications may have different minimum requirements. Refer to the documentation for any third
party applications for system requirements.
Note: You can install the module in a local or remote rack. For remote rack installation, the module
requires EtherNet/IP or ControlNet communication with the processor.
