Proxima LightBook 20 User manual

Your Proxima Lightbook Projector i-1
Introduction
Your Proxima Lightbook Projector
The Proxima® Lightbook™ projector makes sharing data and presenting
information as easy as connecting your computer to your monitor.
800
600
400
200
0
APR
MAY
JUN
JUL
Figure i-1 The Proxima Lightbook projector in use
This manual covers the Proxima Lightbook family of light, portable
projectors which provide images of unrivaled clarity and color accuracy.

i-2 Introduction
WHAT’S IN THE BOX?
After you’ve opened the box and removed the projector and accessory packs,
make sure you have all of the items shown in Figure i-2.
CAUTION! The Proxima Lightbook projector should be treated like any
other precision optical instrument. Handle it carefully.
Proxima 
Lightbook Projector Cyclops Remote  Control
080-01101-1
Power Cord
C1002-10
VGA Video Cable
C951-6
Mac – VGA
Adapter
C922
Also included but not shown:
• Cyclops F/X Diskettes
• (2) AAA Alkaline Batteries
• Product Registration Card

Composite
Video/Audio Cable
C497-6

S-Video Cable
C466-6 Computer  Audio Cable
C498-6
VGA – Mac
Monitor Adapter
C924
Serial Cable
C936-6 ADB Cable C4070-6
Mini Jack to RCA
Cable Adapter
C5105
PROG1 PROG2/
SOURCE SETUP
MUTE
–VOLUME+
MENU
/O
MAC
MAC
VGA
preview select
source
Cyclops Quick
Remote Control
A85
Figure i-2 Items included with the projector
Your projector also includes power cords for Europe, the United Kingdom,
and Italy.

Your Proxima Lightbook Projector i-3
OPENING THE PROJECTOR
1Press the gold buttons on both sides of the projector and pull the top
assembly up. It will click into place.
Figure i-3 Opening the projector
NOTE: The and indicators will both flash if the projector is not
completely open.
2Lift the gold front door latch to pop the lens open.
Figure i-4 Opening the lens

i-4 Introduction
YOUR LIGHTBOOK PROJECTOR
Before you begin, locate the main parts of the Lightbook projector.
Computer InSerial S. VHS Video In L
A
M
P
10
RIn–Audio–Out
Monitor Out
O
I

PROG 1 PROG 2/
SOURCE SETUP
MUTE
–VOLUME+
MENU
/O
910
12 11
11
3
8
2
3 4
5
6
7
4
3
preview select
source
13
Figure i-5 The Lightbook projector and Cyclops Remote Control
1Internal Speakers 8Cyclops Remote Control
2Control Panel 9Circuit Breaker
3Cooling Fans 10 Power Cord Receptacle
4Release Button 11 Main AC Power Switch
5Keystone Adjustment 12 Connector Panel
6Focus Ring 13 Cyclops Quick Remote
7Remote Control IR Lens

Your Proxima Lightbook Projector i-5
CONNECTOR PANEL
All connections between the projector and computer or video source are
made on the side connector panel.
Computer InSerial S-Video Video In L
A
M
P
10
RIn–Audio–Out
Monitor Out
O
I

11 9
10
1 2 3 4 5 6 7 8
Figure i-6 The Connector Panel
CONNECTOR DESCRIPTION
1SERIAL Connects to your computer so you can use
Cyclops F/X software.
2COMPUTER IN Connects computer video to the projector.
3MONITOR OUT Provides computer video output to a separate
monitor.
4S-VIDEO Allows S-Video video input.
5VIDEO IN Allows video input from an NTSC, PAL, or
SECAM source.
6L-AUDIO-R Allows stereo/mono audio input from an NTSC,
PAL, or SECAM source.
7AUDIO IN Allows stereo/mono audio input.
8AUDIO OUT Provides audio output to an external stereo
system.
9AC CIRCUIT BREAKER Restarts the system after a power failure.
10 AC PLUG Connects AC power.
11 AC POWER Turns the projector on or off.

i-6 Introduction
CONTROL PANEL
Use the Lightbook projector’s control panel keys to turn the projector on or
off, adjust the projected image, and display and hide the menu. The and
indicators provide status information about your projector.
Source
Setup
Menu
Over-Temperature
Replace Lamp
3
4
5
6
7
1
2
Figure i-7 The Control Panel
KEY FUNCTION
1Controls the menu and adjusts screen position.
2
Source
Switches the video inputs.
3
Setup
Activates the Setup menu.
4
Menu
Displays or hides the menu.
5Turns the lamp on or off.
6Adjusts the volume.
7

Your Proxima Lightbook Projector i-7
LIGHT FUNCTION
Glows red to warn of an over-temperature condition.
Flashes quickly if the projector is not fully opened.
Flashes slowly if the spare lamp burns out.
Glows red when the active lamp burns out.
Flashes quickly if the projector is not fully opened.
QUICK START
Follow the appropriate section below for the type of system that you have.
Be sure to observe the indicator lights when you power up the projector.
Connecting a Notebook
NOTE: If you are connecting to an Apple PowerBook, attach the Mac - VGA
cable adapter to the computer’s Video Out port (or video adapter cable).
1Plug the COMPUTER end of the supplied VGA Video cable into the
notebook’s VGA Out port or into the Mac - VGA cable adapter
(Macintosh only).
Serial Computer In Monitor Out S-Video Video In L R
In Audio Out
VIDEO/VGA
SERIAL
AUDIO
VIDEO/VGA
SERIAL
AUDIO

Figure i-8 Connecting a notebook
2Plug the end of the VGA Video cable with the large round collar into the
COMPUTER IN port on the projector.
3Connect your audio source to the AUDIO IN port on the projector.
4Turn the projector on.

i-8 Introduction
Connecting Desktop PCs
Serial Computer In Monitor Out S-Video Video In L R
In Audio Out
VIDEO/VGA
SERIAL
AUDIO
Figure i-9 Connecting a Desktop PC
1Turn the PC power off. Unplug the monitor cable from the computer.
2Plug the end of the supplied VGA cable with the large round collar into
the COMPUTER IN port on the projector. Plug the other end into the
computer’s Monitor Out port.
3Connect your audio source to the AUDIO IN port on the projector.
4You can project without using the PC monitor. If you want to also use the
monitor, plug the monitor cable into the MONITOR OUT port on the
projector.
5Turn the projector on.
6Turn the computer on.

Your Proxima Lightbook Projector i-9
Connecting Macintosh Computers
VIDEO/VGA
SERIAL
AUDIO
Serial Computer In Monitor Out S.Video Video In L R In Audio Out
Figure i-10 Connecting a Macintosh
1Unplug the existing monitor cable from your computer.
2Plug the end of the supplied VGA video cable with the large round collar
into the COMPUTER IN port on the projector. Attach the VGA end of the
Mac - VGA cable adapter to the other end of the VGA video cable.
3Plug the Mac end of the Mac - VGA cable adapter into your computer’s
video port.
4Connect your audio source to the AUDIO IN port on the projector.
5To project and view the monitor at the same time, plug the monitor cable
into the Mac end of the VGA - Mac monitor adapter.
NOTE: The Lightbook projector only supports Multi-sync monitors for
Macintosh computers.
6Plug the VGA end of the VGA - Mac monitor adapter into the MONITOR
OUT port on the projector.
7Turn the projector on.
NOTE: If you turn the projector off while the computer is on, your external
monitor will go blank. This is normal. Just turn the projector on again and the
monitor display will return.

i-10 Introduction
Connecting NTSC, PAL, SECAM, or S-Video
Use the supplied AV cable to connect an NTSC, PAL, or SECAM source to the
projector. Use the supplied S-Video cable to connect an S-Video source.
VideoOut
LR
Serial ComputerIn MonitorOut S.Video VideoIn L R
InñAudioñOut
4Head
VCR
S.Video
S-VideoCable
S-Video Cable
(Optional)
Figure i-11 Connecting video
Special Configurations
If your computer has an internal monitor but no external video capability
(such as the Macintosh Performa 575, PowerMac 5200, and certain
PowerBooks), you need a video adapter card to attach the Lightbook
projector.
Setup for a third-party adapter is identical to the procedures outlined in the
Quick Start section above. Contact your dealer, Proxima Customer Service, or
a third-party supplier for more information about an appropriate video
adapter.

Your Proxima Lightbook Projector i-11
CLOSING THE PROJECTOR
1Close the lens door latch.
Figure i-12 Closing the lens
2Press both gold buttons to release the top assembly
Figure i-13 Releasing the projector top
3Gently press down and pull back on the assembly until it clicks into
place.

Setting Up the Lightbook Projector 1-1
Chapter 1
Setting Up the Lightbook Projector
POSITIONING THE PROJECTOR
Place the projector on a solid, flat surface at a right angle (perpendicular) to
the projection screen and parallel to the floor. If you are using a media cart,
make sure the wheels are locked to prevent it from moving.
Perpendicular to the
projection screen
Parallel to the floor
Top View
Side View
Projection Screen
Figure 1-1 Positioning the projector

1-2 Chapter One
TRANSPORTING AND MOVING THE PROJECTOR
Always use the supplied carrying case to transport the projector. If you are
moving the projector a short distance, grasp it securely at the sides by the
lower parts of the housing to support the weight of the unit.
Figure 1-2 Moving the projector
Projector Cooling and Airflow
Locate the air intake grills under the front of the projector and in the left rear
corner, and the air exhaust grill in the right rear corner.
CAUTION! Never operate the projector if these grills are clogged or
obstructed, or if the electric fans are not running.
Computer InSerial S. VHS Video In L
A
M
P
10
RIn–Audio–Out
Monitor Out

Figure 1-3 Allow for proper air flow

Setting Up the Lightbook Projector 1-3
CONNECTOR PANEL
All connections between the projector and your computer or video source
are made on the side connector panel.
Computer InSerial S-Video Video In L
A
M
P
10
RIn–Audio–Out
Monitor Out
O
I

11 9
10
1 2 3 4 5 6 7 8
Figure 1-4 The Connector Panel
CONNECTOR DESCRIPTION
1SERIAL Connects to your computer so you can use
Cyclops F/X software. Use a serial connector
for a PC, ADB connector for a Macintosh.
2COMPUTER IN Connects computer video to the projector.
3MONITOR OUT Provides computer video output to a separate
monitor.
4S-VIDEO Allows S-Video video input.
5VIDEO IN Allows video input from an NTSC, PAL, or
SECAM source.
6L-AUDIO-R Allows stereo/mono audio input from an NTSC,
PAL, or SECAM source.
7AUDIO IN Allows stereo/mono audio input.
8AUDIO OUT Provides audio output to an external stereo
system.
9AC CIRCUIT BREAKER Restarts the system after a power failure.
10 AC PLUG Connects AC power.
11 AC POWER Turns the projector on or off.

1-4 Chapter One
CONNECTING POWER TO THE PROJECTOR
The power cord receptacle, AC POWER switch, and circuit breaker are
located below the connector panel of the projector.
Computer InSerial S-Video Video In L
A
M
P
10
RIn–Audio–Out
Monitor Out
O
I

Circuit Breaker
AC Power Switch
Power Receptacle
Figure 1-5 Power receptacle, AC Power switch, and circuit breaker reset switch
1Plug the appropriate power cord into the power receptacle on the side of
the projector.
2Connect the other end of the power cord to a properly-grounded wall
outlet.

Setting Up the Lightbook Projector 1-5
CONNECTING YOUR COMPUTER
Connecting Notebook Computers
Use the appropriate cable and adapter to connect your notebook computer
to the projector.
Computer InSerial S-Video Video In LRIn–Audio–Out
Monitor Out
MAC II
CPU
Video
Output
Port
MAC - VGA
Adapter
VGA Cable
Computer
In Port
Figure 1-6 Notebook connections
NOTE: If you are using an Apple PowerBook, attach the Mac - VGA cable
adapter to the computer’s Video Output port (or video adapter cable).
1Plug the end of the supplied VGA cable with the large round collar into
the computer’s VGA or Video Out port or into the Mac - VGA cable
adapter (Macintosh only).
2Plug the other end of the VGA cable into the COMPUTER IN port on the
projector.
3If you want audio, connect your audio source to the AUDIO IN port on
the projector.
4Turn the projector on.
NOTE: If your projector is unable to project an image at the same time your
laptop monitor displays an image, refer to your laptop documentation for
information on switching between the internal screen and the video port.

1-6 Chapter One
Connecting PCs
Use the included VGA video cable to connect your PC to the projector’s
COMPUTER IN port. If you want to use your monitor and Lightbook
projector at the same time, use your existing monitor cable to connect the
projector to the monitor.
VGA
VGA
VGA Connector Cable
To Projector To Computer
Figure 1-7 VGA Video cable
VGA Cable
To Computer In
From
Monitor Out
Computer InSerial S-Video Video In LRIn–Audio–Out
Monitor Out
Figure 1-8 Connecting a PC
1Unplug the monitor cable from the computer.
2Plug the end of the supplied VGA cable with the large round collar into
the projector’ COMPUTER IN port. Plug the other end of the VGA cable
into the computer’s Video Out (VGA) port.
3If you want audio, connect your audio source to the AUDIO IN port on
the projector.
4If you want to use an external monitor, connect the monitor cable to the
projector’s MONITOR OUT port.
5Turn the projector on.
NOTE: An external monitor is not required to use the Lightbook projector.

Setting Up the Lightbook Projector 1-7
Connecting Macintosh Computers
Use the video adapters shown below to connect a Macintosh computer and
monitor to the Lightbook projector.
VGA– Mac Monitor Adapter
Mac – VGA Cable Adapter
From
Mac CPU To VGA Cable
To Mac
Monitor Cable From Projector MONITOR OUT
MAC

MAC


Figure 1-9 The Macintosh adapters
Use the cable adapters and supplied VGA video cable to connect the
projector to your Macintosh computer.
Computer InSerial S-Video Video In LRIn–Audio–Out
Monitor Out
MAC II
CPU
VGA - Mac
Monitor Adapter
Mac - VGA
Cable Adapter
VGA Cable 
to 
Computer 1 
In Port
Macintosh
Monitor Cable To Monitor Out Port
Figure 1-10 Connecting a Macintosh

1-8 Chapter One
1Unplug the Macintosh monitor cable from the computer.
2Plug the end of the supplied VGA video cable with the large, round collar
into the COMPUTER IN port on the projector. Attach the VGA end of the
Mac - VGA cable adapter to the other end of the VGA video cable.
3Plug the Mac end of the Mac - VGA cable adapter into the Macintosh
video port.
4Connect the audio source to the AUDIO IN port.
Use the VGA - Mac monitor adapter and your existing monitor cable to
connect the projector to a separate computer monitor, so you can view
computer video on the projector screen and the monitor at the same
time.
5To project and view the monitor at the same time, plug the monitor cable
into the Mac end of the VGA - Mac monitor adapter.
6Plug the VGA end of the Mac - VGA monitor adapter into the MONITOR
OUT port on the projector.
7Turn the projector on.
NOTE: An external monitor is not required to use the Lightbook projector.
Special Configurations
If your computer has an internal monitor but no external video capability
(Macintosh Performa 575, PowerMac 5200, and certain PowerBooks), you
need a video adapter card in order to attach the projector.
Setup for a third-party adapter is identical to the procedures outlined in the
Quick Start section in the introduction chapter. Contact your dealer, Proxima
Customer Service, or a third-party supplier for more information about an
appropriate video adapter.

Setting Up the Lightbook Projector 1-9
CONNECTING COMPUTER AUDIO
Use the composite audio cable to connect your audio source to the AUDIO
IN port on the projector.
RIn–Audio–Out
Figure 1-11 Audio In port
1Insert one end of the computer audio cable into the Audio Out port of a
Macintosh or the sound card of a PC.
2Insert the other end into the projector’s AUDIO IN port.
NOTE: Although both AUDIO and AUDIO IN may be connected at the same
time, only one can be active. If computer video is selected, AUDIO IN is
active. If NTSC, PAL, SECAM, or S-Video is being viewed, AUDIO is active.
CONNECTING COMPOSITE VIDEO
You can display composite video (NTSC, PAL or SECAM) on the projector.
Video In LR
Figure 1-12 Video In port
Use the supplied composite Video/Audio cable (see page i-2) to connect an
NTSC, PAL, or SECAM source to your projector.
1Find the RCA connector on your video source marked Video Out or
something similar. This connector is typically yellow. Insert one of the
AV cable’s yellow connectors into the Video Out jack of the video source.
2Insert the other yellow connector into the projector’s VIDEO IN port.
