PT CPC5565 User manual

CPC5565
Intel Core 2 Duo Processor Single Board Computer
User’s Guide
www.pt.com
205 Indigo Creek Drive Rochester, NY 14626 Phone [phone] support @ pt.com
RTM

2
Document Revision History
Copyright Notice
© Copyright 2010 Performance Technologies, Inc. All Rights Reserved.
The PT logo is a registered trademark of Performance Technologies, Inc.
All product and brand names may be trademarks or registered trademarks of their respective owners.
This document is the sole property of Performance Technologies, Inc.
Errors and Omissions
Although diligent efforts are made to supply accurate technical information to the user, occasionally
errors and omissions occur in manuals of this type. Refer to the PT Web site to obtain manual revisions
or current customer information:
http://www.pt.com.
Performance Technologies, Inc., reserves its right to change product specifications without notice.
Symbol Conventions in This Manual
The following symbols appear in this document:
Caution:
There is risk of equipment damage. Follow the instructions.
Warning:
Hazardous voltages are present. To reduce the risk of electrical shock and danger to
personal health, follow the instructions.
Date Explanation of changes
December 2, 2009 Initial Production Release
December 10, 2009 Updated default setting in the topic “SW2-4: Console Redirection” on page 38.
January 21, 2010 Updated Table 4-4, “IPMC Sensors,” on page 66
March 24, 2010 Updated Table 4-4, “IPMC Sensors,” on page 66. Updated the command code for
the Get Geographic Address command in Table 4-5, “PPS Extension Commands
Supported by the IPMC,” on page 70, and in “Get Geographic Address Command” on
page 76. Updated “Get Status Command” on page 71. Added link to the Intel
82571EB NIC in the topic “Ethernet” on page 115.
July 8, 2010 Rebranded and reformatted. Removed reference to hot swap kit for the CPC5565.
August 18, 2010 Updated “Ethernet Interface” on page 41 for CPC5565 BIOS version P05.
September 24, 2010 Updated topic “SATA Interface” on page 28. Removed all references to SATA drives
on the SODIMM sockets. Updated all references from RTM4810 to RTM4811. Added
Table 3-1, “Default Ethernet Routing,” on page 43. Added the topic “Older Operating
Systems” on page 52. Added driver information to the topic “Ethernet” on page 115.

3
Caution:
Electronic components on printed circuit boards are extremely sensitive to static electricity.
Ordinary amounts of static electricity generated by your clothing or work environment can
damage the electronic equipment. It is recommended that anti-static ground straps and anti-
static mats are used when installing the board in a system to help prevent damage due to
electrostatic discharge.
Additional safety information is available throughout this guide and in the topic “Product Safety
Information” on page 113.

4

5
Chapter 1: About This Guide 15
Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Customer Support and Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Customer Support Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Other Web Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Return Merchandise Authorization (RMA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Product Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Chapter 2: Introduction 19
Product Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
CPC5565 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
CPC5565 Functional Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Chipset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CompactPCI Bus Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Intelligent Platform Management Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Universal Serial Bus (USB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
AMD/ATI Radeon E2400 Video Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Video Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
SMARTSHADER 4.0 - Advanced Shader Technology . . . . . . . . . . . . . . . . . . . . . . . . . . .26
SMOOTHVISION 2.0 - Flexible Anti-Aliasing and Anisotropic Filtering . . . . . . . . . . . . . .26
Avivo™ Display Support - Two Fully Functional Displays . . . . . . . . . . . . . . . . . . . . . . . . .26
Video Acceleration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Serial I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SATA Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Rear Transition Module (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
PTMC Interface (Build Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Drone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Contents

Contents
6
Real-Time Clock, CMOS RAM and Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Two-Stage Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
User LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Front Panel Ethernet (RJ-45 Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Hot Swap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Status/Health . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Rear-Panel I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Operating Systems Supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
IPMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Chapter 3: Getting Started 33
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Electrical and Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Memory Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
I/O Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Switch Pack 1 (SW1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
SW1-1: PCIXCAP Override on Local PCI Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
SW1-2: COM Port Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SW1-3: IPMC JTAG Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SW1-4: Drone Reset Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Switch Pack 2 (SW2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SW2-1: Clear CMOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SW2-2, SW2-3: User Switch Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SW2-4: Console Redirection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Switch Pack 3 (SW3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
SW3-1 Port 80 Post Codes Out Serial Port (Front Panel) . . . . . . . . . . . . . . . . . . . . . . . . 39
SW3-2 Reserved . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
SW3-3 Force Drone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
SW3-4 Reserved . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Push-Button Reset (SW4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Contents
7
Hot-Swap Switch (SW5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
BIOS Configuration Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Ethernet Switch BIOS Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
VLAN Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
VLAN Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Jumbo Frames Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Port Trunking Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
MAC Address Handling Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Network Architecture Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Avoiding Loops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Console Redirection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Older Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Custom Default Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Behavior of the BIOS if a Corrupted CMOS Checksum is Detected . . . . . . . . . . . . . . . . .53
Installing a PMC Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Installing the Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
USB CD/DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
PXE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Operating Systems Supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Programming the LEDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Installing the Display Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Windows XP (32- and 64-Bit Editions) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Solaris . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Chapter 4: System Monitoring and Alarms 61
IPMC Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Summary of Supported Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Device Locator Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Device ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Interpreting Sensor Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Serial Interface Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Terminal Mode Messages and Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Terminal Mode Message Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

Contents
8
Raw IPMI Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Terminal Mode Text Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Pigeon Point Systems (PPS) Extension Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Terminal Mode Line Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Supported PPS Extension Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Get Status Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Serial Line Properties Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Get Serial Interface Properties Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Set Serial Interface Properties Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Debug/Verbosity Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Get Debug Level Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Set Debug Level Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Payload Communication Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Get Payload Communication Timeout Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Set Payload Communication Timeout Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Graceful Payload Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Payload Diagnostic Interrupt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Payload Shutdown Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Get Payload Shutdown Timeout Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Set Payload Shutdown Timeout Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Get Geographic Address Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Firmware Upgrade Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
HPM.1 Boot Loader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
HPM.1 Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Upgrade Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Detailed HPM.1 Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
IPMI Communication Utility (ipmitool) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Building the ipmitool Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Accessing an IPMC with ipmitool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Accessing an IPMC via a Shelf Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Accessing an IPMC via a Serial Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Using ipmitool for HPM.1 Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
HPM.1 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
targetcap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
compprop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
activate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
rollback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
rollbackstatus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

Contents
9
Chapter 5: Connectors 85
Backplane Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
J1 (IPMB/Power Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
J2 (V(I/O) Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
J3 (Rear-Panel Gigabit Ethernet Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
J5 (Rear-Panel User I/O Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Front Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
DVI-I Connector (J6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
RS-232 RJ-45 Console Port (J7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Ethernet Connectors (J8 and J9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
USB Connectors (J10, J15) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Internal Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
PTMC Connectors (J11, J12, J13, and J14) (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
DDR2 SDRAM Connectors (P1, P2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Hot-Swap Ejector Switch Connector (P3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
SATA Hard Disk Connector (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Serial Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Chapter 6: Reset 101
Reset Types and Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
General Reset Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Push-Button Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
NMI\SMI\SERIRQ Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Chapter 7: Specifications 103
Electrical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
CPC5565 Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
DC Operating Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Power Consumption with 2.2 GHz Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Maximum Available Current for PMC Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Battery Backup Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

Contents
10
CPC5565 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Mechanical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
CPC5565 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Chapter 8: Thermal Considerations 109
Thermal Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Temperature Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Intel Thermal Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Chapter 9: Agency Approvals 111
CE Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Emissions Test Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
EN 50081-1 Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
EN 55024 Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
FCC (USA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Industry Canada (Canada) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Product Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Compliance with RoHS and WEEE Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Chapter 10: Data Sheet Reference 115
AMD/ATI Radeon E2400 Video Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Chipset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Intelligent Platform Management Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
I/O Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
PICMG Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

11
Table 3-1: Default Ethernet Routing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 4-1: IPMI/PICMG Command Subset Supported by the IPMC Firmware . . . . . . . . . . . . . . . . . 62
Table 4-2: IPMB Management Controller Device Locator Record. . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Table 4-3: IPMC Device ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Table 4-4: IPMC Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Table 4-5: PPS Extension Commands Supported by the IPMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Table 4-6: IPMC Status Bits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Table 4-7: The <interface ID> Parameter Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Table 4-8: The <interface properties> Parameter Bit Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Table 4-9: IPMC Debug Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Table 5-1: Connector Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Table 5-2: J1 CompactPCI Bus Connector Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Table 5-3: J2 V(I/O) Connector Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Table 5-4: J3 Rear-Panel Gigabit Ethernet Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Table 5-5: J5 Rear-Panel User I/O Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Table 5-6: DVI-I Connector J6 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Table 5-7: RJ-45 Console Port J7 Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Table 5-8: Ethernet Connectors J8 and J9 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Table 5-9: USB Connectors J10, J15 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Table 5-10: PTMC Connector J11 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Table 5-11: PTMC Connector Pin Map (J12). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Table 5-12: PTMC Connector Pin Map (J13). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Tables

Tables
12
Table 5-13: PTMC Connector Pin Map (J14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Table 5-14: P3 Hot-Swap Ejector Switch Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Table 5-15: Management Cable Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Table 7-1: Power Consumption with 2.2 GHz Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

13
Figure 2-1: CPC5565 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 2-2: CPC5565 Functional Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 3-1: Memory Address Map Example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 3-2: I/O Address Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 3-3: Switch Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 3-4: Setup Screen Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 3-5: Switch Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 3-6: VLAN Configuration Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Figure 3-7: Jumbo Frames Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Figure 3-8: Port Trunking Configuration Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Figure 3-9: MAC Address Handling Configuration Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Figure 3-10: Inter-Switch Link Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Figure 3-11: Separate Switching Domains. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Figure 3-12: ISL Segregation and MAC Address Learning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Figure 3-13: Spanning Tree Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Figure 3-14: Saving Custom Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Figure 3-15: Solder-Side Shield. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Figure 3-16: PMC Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Figure 4-1: PPS Extension Command Request. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Figure 4-2: PPS Extension Command Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Figure 5-1: Connector Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Figure 5-2: Backplane Connectors Pin Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Figures

Figures
14
Figure 7-1: Battery Socket Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Figure 7-2: CPC5565 Board Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

15
Chapter 1
About This Guide
This manual describes the operation and use of the CPC5565 Intel® Core™ 2 Duo Single
Board Computer (referred to as the CPC5565 in this guide). The following outline describes the
focus of each chapter.
Chapter 2, “Introduction,” on page 19 provides an overview of the CPC5565 and includes
information such as product features, a functional block diagram with a brief description of each
block, and descriptions of software such as the BIOS, supported operating systems, and IPMI.
Chapter 3, “Getting Started,” on page 33 provides setup information such as unpacking the
product, system requirements, and installation procedures.
Chapter 4, “System Monitoring and Alarms,” on page 61 describes the commands supported
by the on-board Intelligent Platform Management Controller.
Chapter 5, “Connectors,” on page 85 provides connector location, description, and pinout
information for the CPC5565’s CompactPCI connectors, front panel, and internal connectors. It
also includes a description of the serial cable recommended for use with the front panel RJ11
serial connector.
Chapter 6, “Reset,” on page 101 describes the CPC5565 reset types with their respective
sources.
Chapter 7, “Specifications,” on page 103 contains mechanical, electrical, and environmental
specifications as well as product reliability specifications.
Chapter 8, “Thermal Considerations,” on page 109 describes the thermal requirements to
reliably operate a CPC5565 processor board.
Chapter 9, “Agency Approvals,” on page 111 presents agency approval and certification
information.
Chapter 10, “Data Sheet Reference,” on page 115 provides information on data sheets,
standards, and specifications for the technology designed into the CPC5565.
The CPC5565 assembly should be used in conjunction with the PT software package that you
have chosen, for example NexusWare®Core.
The most current documentation to support any additional components that you purchased
from PT is available at www.pt.com under the product you are inquiring about.
For additional documentation references see Chapter 10, “Data Sheet Reference,” on
page 115.

Chapter 1: About This Guide
16
Text Conventions
Conventions in This Guide describes the text conventions that are used in this guide.
Customer Support and Services
PT offers a variety of standard and custom support packages to ensure customers have access
to the critical resources that they need to protect and maximize hardware and software
investments throughout the development, integration, and deployment phases of the product
life cycle.
If you encounter difficulty in using this PT product, you may contact our support personnel by:
1. EMAIL (Preferred Method) – Email us at the addresses listed below or use our online email support
form. Outline your problem in detail. Please include your return email address and a telephone
number.
2. TELEPHONE – Contact us via telephone at the number listed below, and request Technical Support.
Our offices are open Monday to Friday, 8:00 a.m. to 8:00 p.m. (Eastern Time).
If you are located outside North America, we encourage you to contact the local PT distributor
or agent for support. Many of our distributors or agents maintain technical support staffs.
Conventions in This Guide
Convention Used For
Monospace
font Monospace font represents sample code.
Bold font Bold font represents:
• paths
• file names
• UNIX commands
•userinput.
Italic font Italic font represents:
• notes that supply useful advice
• supplemental information
• referenced documents.
PT Support Contact Information
Embedded Systems and Software
(Includes Platforms, Blades, and Servers) SS7 Systems (Includes SEGway™)
Email [email protected] [e-mail]
Phone [phone]
(Monday to Friday, 8 a.m. to 8 p.m.
Eastern Time)
[phone]
(Monday to Friday, 8 a.m. to 8 p.m.
Eastern Time)

Product Warranty
17
Customer Support Packages
Our configurable development and integration support packages help customers maximize
engineering results and achieve time-to-market goals. To find out more about our Customer
Support packages, visit http://www.pt.com/page/support/.
Other Web Support
Support for existing products including manuals, release notes, and drivers can be found on
specific product pages at http://www.pt.com. Use the product search to locate the information
you need.
Return Merchandise Authorization (RMA)
To submit a return merchandise authorization (RMA) request, complete the online RMA form
available at http://pt.com/assets/lib/files/rma-request-form.doc and follow the instructions on
the form. You will be notified with an RMA number once your return request is approved.
Shipping information for returning the unit to PT will be provided once the RMA is issued.
Product Warranty
Performance Technologies, Incorporated, warrants that its products sold hereunder will at the
time of shipment be free from defects in material and workmanship and will conform to
Performance Technologies’ applicable specifications or, if appropriate, to Buyer’s specifications
accepted by Performance Technologies in writing. If products sold hereunder are not as
warranted, Performance Technologies shall, at its option, refund the purchase price, repair, or
replace the product provided proof of purchase and written notice of nonconformance are
received by Performance Technologies within 12 months of shipment, or in the case of
software and integrated circuits within ninety (90) days of shipment and provided said
nonconforming products are returned F.O.B. to Performance Technologies’s facility no later
than thirty days after the warranty period expires. Products returned under warranty claims
must be accompanied by an approved Return Material Authorization number issued by
Performance Technologies and a statement of the reason for the return. Please contact
Performance Technologies, or its agent, with the product serial number to obtain an RMA
number. If Performance Technologies determines that the products are not defective, Buyer
shall pay Performance Technologies all costs of handling and transportation. This warranty
shall not apply to any products Performance Technologies determines to have been subject to
testing for other than specified electrical characteristics or to operating and/or environmental
conditions in excess of the maximum values established in applicable specifications, or have
been subject to mishandling, misuse, static discharge, neglect, improper testing, repair,
alteration, parts removal, damage, assembly or processing that alters the physical or electrical
properties. This warranty excludes all cost of shipping, customs clearance and related charges
outside the United States. Products containing batteries are warranted as above excluding
batteries.

Chapter 1: About This Guide
18
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS,
IMPLIED OR STATUTORY INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS. IN NO EVENT SHALL PERFORMANCE TECHNOLOGIES BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES DUE TO BREACH OF THIS WARRANTY
OR ANY OTHER OBLIGATION UNDER THIS ORDER OR CONTRACT.

19
Chapter 2
Introduction
This chapter provides a brief introduction to the CPC5565 64-bit Intel Core 2 Duo™ Single
Board Computer. It includes a product definition, a list of product features, a figure showing the
CPC5565 front panel, a functional block diagram, and a description of each block. Unpacking,
initial board configuration, and other setup information are provided in Chapter 3, “Getting
Started.”
Key topics in this chapter include:
•“Product Definition” on page 19
•“CPC5565 Features” on page 20
•“CPC5565 Functional Blocks” on page 22
•“Software” on page 31
Product Definition
The CPC5565 is a CompactPCI® 64-bit, single-slot, single board computer, featuring the Intel
Core 2 Duo dual core 2.2 GHz processor, designed for high-performance embedded
applications. The board incorporates the Intel 3100 integrated northbridge/southbridge chipset,
supporting an 800 MHz front-side bus interface, 400 MHz 64-bit PC2-3200 DDR2 memory
interface. 64-bit PC2-3200 DDR SDRAM up to 8 GB is supported.
The CPC5565 includes support for high-performance video, audio, and storage, featuring the
Advanced Micro Devices (AMD)/ATI Radeon™ E2400 video processor and Serial Advanced
Technology Attachment (SATA) hard disk drive (HDD) interface. It is designed to deliver
exceptional 2D, 3D, and multimedia graphics performance for embedded systems that may
require video/audio, hard disk drive storage, or both.
Figure 2-1: CPC5565 Front Panel
CompactPCI
CPC5565
P
M
C
R
PMC Site
USB
Ethernet
AEthernet
B
RS-232
RJ-45
Console
Port
DVI-I
Push-
Button
Reset
Health
LED
User
LED Hot-
Swap
LED

Chapter 2: Introduction
20
CPC5565 Features
• Single Slot 6U PICMG 2.16 compute blade
•CompactPCI Hot Swap Specification, PICMG 2.1, R 2.0 compliant
•CompactPCI PTMC Specification, PICMG 2.15 R1 compliant
•CompactPCI Packet Switched Backplane Specification, PICMG 2.16, R 1.0 compliant
•CompactPCI System Management Specification, PICMG 2.9, R 1.0 compliant
•IPMI v1.5 Specification compliant
• 2.2 GHz dual core Intel Core 2 Duo processor (T7500)
• Intel 64 architecture
• Supports Intel Architecture with Dynamic Execution
• PC2-3200 DDR2 400 MHz memory controller interface
• 32 KB Level 1 instruction cache (per core)
• 32 KB Level 1 data cache (per core)
• Up to 4 MB Level 2 shared cache with Advanced Transfer Cache Architecture
• 800 MHz, Source-Synchronous front-side bus
• Intel Virtualization Technology
• Execute Disable Bit support for enhanced security
• System management bus
• Card edge interface contains two SATA channels, eight-lane PCI Express bus, and dual SERDES
1Gb/2.5 Gb Ethernet channels
• Intel 3100 Chipset
• Dual 10/100/1000 Mb/s Ethernet links are available on the front panel via RJ45 connectors
• AMD/ATI Radeon™ E2400 Video Processor
– Internal 128 MB GDDR3 memory
– High-performance 2D, 3D, and multimedia graphics
– QXGA resolution up to 2048 x 1536
– HDMI output for 480p, 720p, and 1080i
– 32 bits per pixel
– DirectX 10 and OpenGL 2.0 support
– Video acceleration
- Advanced de-interlacing algorithms
- Programmable, independent gamma control for video overlay
– SMARTSHADER™ 4.0
– SMOOTHVISION™ 2.0
– Dual-display mode
– Integrated HD audio codec supports PCM and Dolby® Digital 5.1 audio formats
