Pulsar KRYPTON FXG50 User manual

Quick Start Guide
KRYPTON
FXG50 Thermal Imaging
Front Attachment

Quick Start Guide
EN Electromagnetic compatibility. This product complies with the requirements of
European standard EN 55032: 2015, Class A.
Caution: Operating this product in a residential area may cause radio interference.
Attention! A license is required for Thermal Imager Krypton FXG50 when exporting
outside your country.
This product is subject to change in line with improvements to its design.
The current version of the User’s Manual can be found on the website
www.pulsar-vision.com
FR Compatibilité électromagnétique. Ce produit est conforme aux exigences de la
norme européenne EN 55032: 2015, classe A.
Attention: L’utilisation de ce produit dans une zone résidentielle peut provoquer des
interférences radio.
Attention! Les modules d’imagerie thermiques Krypton FXG50 nécessitent
l’obtention d’une licence s’ils sont exportés hors de votre pays.
La conguration peut être modiée an d’améliorer l’utilisation de l’appareil.
La version actuelle du manuel d’utilisation est disponible sur le site
www.pulsar-vision.com
DE Elektromagnetische Verträglichkeit. Dieses Produkt entspricht den Anforderungen
der Europäischen Norm EN 55032:2015, Klasse A.
Achtung: Der Betrieb dieses Produktes in Wohngebieten kann Funkstörungen
verursachen.
Achtung! Die Wärmebildgeräte Krypton FXG50 erfordern eine Lizenz, wenn sie über
die Grenzen Ihres Landes exportiert werden.
Änderungen im Design zwecks höherer Gebrauchseigenschaften des Produktes
vorbehalten.
Die aktuelle Version der Bedienungsanleitung nden Sie unter www.pulsar-vision.com
ES Compatibilidad electromagnética. Este producto cumple con los requisitos de la
norma europea EN 55032:2015, Clase A.
Advertencia: el uso de este producto en la zona residencial puede provocar
interferencias de radiofrecuencia.
¡Atención! Los dispositivos de imagen térmica Krypton FXG50 requieren una licencia
si se exportan fuera de su país.
El diseño de este producto está sujeto a modicaciones con el n de mejorar sus
características de uso.
Encontrará la última edición del manual de usuario en el sitio web
www.pulsar-vision.com
IT Compatibilità elettromagnetica. Questo prodotto è conforme ai requisiti della
norma europea EN 55032:2015, Classe A.
Attenzione: l’uso di questo prodotto in un’area residenziale può causare dei
radiodisturbi.
Attenzione! I visori termici Krypton FXG50 necessitano di un certicato nel caso in
cui vengano esportati.
Per migliorare le proprietà del prodotto nella sua costruzione possono essere
apportate delle modiche.
La versione aggiornata delle istruzioni d’uso è disponibile sul sito
www.pulsar-vision.com
RU Электромагнитная совместимость. Данный продукт соответствует требованиям
европейского стандарта EN 55032:2015, Класс А.
Внимание: эксплуатация данного продукта в жилой зоне может создавать
радиопомехи.
Внимание! Тепловизоры Krypton FXG50 требуют лицензии, если они
экспортируются за пределы Вашей страны.
Для улучшения потребительских свойств изделия в его конструкцию могут
вноситься усовершенствования.
Актуальную версию инструкции по эксплуатации Вы можете найти на сайте
www.pulsar-vision.com
v.1220
KRYPTON FXG50
Thermal Imaging Front Attachment Krypton FXG50 1-8 ENGLISH
Module d’imagerie thermique Krypton FXG50 9-16 FRANÇAIS
Wärmebildvorsatzgerät Krypton FXG50 17-24 DEUTSCH
Visor acoplable de imagen térmica Krypton FXG50 25-32 ESPAÑOL
Dispositivo frontale a visione termica Krypton FXG50 33-40 ITALIANO
Тепловизионная насадка Krypton FXG50 41-48 РУССКИЙ

ENGLISH
ENGLISH ENGLISH
Package Contents
• Thermal Imaging Attachment
• Carrying Case
• IPS7 Battery Pack
• Battery Pack Charger
• Power Adapter
• USB Cable
• Quick Start Guide
• Lens-Cleaning Cloth
• Warranty Card
Description
Thermal Imaging Front Attachment Krypton FXG50 is a multipurpose device
that allows you to quickly and easily transform a daylight optical sight into
a thermal imaging one. The attachment is mounted on the lens of an optical
sight with the help of adapters designed for various lens diameters. The
attachment does not require any additional adjustment. The attachment is
intended for various applications, including hunting, sport shooting, night
photography & video recording, and surveillance.
Components and controls
1. Lens cover
2. Eyepiece cover
3. Battery compartment cover
4. Battery locking lever
5. Battery pack
6. REC button
7. MENU button
8. MODE button
9. ON button
10. Lens focus knob
11. USB port
12. Weaver rail
13. Optical sight lens
14. Insert
15. Adapter
16. Screws
17. Tightening screw
18. Screw
19. Adapter lever
20. Mount
Description of buttons function
BUTTON SHORT PRESS LONG PRESS
ON/OFF (9) Turn on device /
Turn on display /
Device calibration
Turn off device /
Turn off display
MODE (8) Switch observation modes /
Menu navigation down/left/
counterclockwise
Turn on / off the Black
Hot palette
MENU (7) Enter quick menu /
Switch between quick menu items /
Conrm selection
Exit quick menu /
Enter/exit main menu
REC (6) Start/pause/resume video recording
/ Photography /
Menu navigation up/right/clockwise
Toggle between photo
and video mode /
Stop video recording /
Charging battery pack
• Lift up the lever (4) of the Charger.
• Insert the Battery Pack (5) into the Charger until it stops; lock the Battery by
lowering the lever (4).
• Connect the microUSB plug of the USB cable (22) to the microUSB port (21) of
the charger.
• Connect the second plug of the USB Cable (22) to the Power Adapter (23).
• Plug the Power Adapter (23) into a 100-240 V socket (24).
• Disconnect the Power Adapter (23) from the mains after the Battery is fully
charged (green LED light stays on continuously).
Open
Close
5
18
2 20 6 11 12
4
3
19
7
1715
10 1
16
8 9
13
14
1 2

ENGLISH ENGLISH
21 24
4
5
23
22
LED Indicator Green LED light stays on
continuously – battery is full
Blinking red LED light –
battery is empty
Micro
USB port
Socket
Battery Locking Lever
USB cable
Battery Pack
Power adapter
Installing Battery Pack
• Lift the lever (4)
• Remove the protective cover of the battery compartment (3).
• Remove the Battery (5) from the Charger.
• Insert the Battery (5) into the slot on the device body specially designed for
it so that the element D(a ridge on the Battery body) is facing downwards.
• Lock the Battery (5) by lifting the lever (4). Lock the Battery (5) by lowering
the lever (4).
5
D
4
3
Operation
Mounting attachment on optical sight
• Remove the eyepiece cover (2).
• Select the Ring Adapter (15) (sold separately) with the insert (14) of the
required diameter depending on the outer diameter of the lens of your
optical sight (13) (see Table). The designation 42 mm / 50 mm / 56 mm in the
name of the adapter means the lens diameter of the optical sight.
Selection table for riescope inserts
Ring Adapter
model
The internal diameter of the insert needs to match the outer diameter of the
objective lens housing of the daylight riescope it is being installed on.
Insert internal diameter, mm Suitable for lens housing of daylight riescopes
with an outer diameter of, mm
PSP Ring
Adapter 42 mm
45.5 45.5
46 46
46.5 46.5
47 46.7-47.6
48 47.7- 48.6
49 48.7-49.6
50 49.7-50.6
PSP Ring
Adapter 50 mm
51.6 51.6
53.4 53.4
55 54.7-55.6
56 55.7-56.6
57 56.7-57.6
58 57.7-58.6
59 58.7-59.6
PSP Ring
Adapter 56 mm
60 59.7-60.6
61 60.7-61.6
62 61.7-62.6
63 62.7-63.6
64 63.7-64.6
65 64.7-65.6
• Screw together the Ring Adapter (15) and the attachment along the threads
of the mounting area (20) until it stops. Then untighten a little (no more than
one turn) so that the lever (19) is on the right side (see Figure).
• Evenly tighten the screws (16) until the ball joint grips in the Ring Adapter (15).
• Apply 2-3 strips of double-sided tape to the outer surface of the insert of
your choice (14).
• Push the insert (14) of your choice into the Ring Adapter (15) until it stops.
• Move the lever (19) to the OPEN position.
• Before installing the Ring Adapter (15) onto the optical sight, it is
recommended to degrease the lens body of the optical sight (13).
• Mount the Ring Adapter (15) with the insert (14) onto the lens of the optical
sight (13) as far as it will go.
• If the Ring Adaptor (15) with the insert (14) selected according to the table
cannot be mounted onto the lens (10), follow the steps below:
- Loosen the locking screw (17) with a 2mm Allen key.
- Untighten the screw (18) with a hex wrench (S = 4mm) until the Ring
Adaptor with the insert can be mounted onto the lens (13).
• Move the lever (19) from its initial OPEN position to the CLOSE position.
• Loosen the locking screw (17) with a 2mm Allen key, if it hasn’t been done before.
• Tighten the screw (18) using a 4mm Allen key. The clamping force should be
1.5-2 Nm (use a torque screwdriver) to ensure the lever is correctly tightened
(19), while the Ring Adapter with the attachment should not move relative
to the body of the optical sight (13). If necessary, tighten or loosen the screw
(18) to operate the lever (19) in the best way possible.
• Tighten the locking screw (17) as far as it will go.
• Turn on the attachment by briey pressing the ON button (9).
• Align the display center with the crosshairs of the reticle by tilting the
attachment.
3 4

ENGLISH ENGLISH
• Align top and bottom display boundaries parallel to the horizontal axis of the
optical sight by turning the attachment clockwise or counterclockwise.
• Having reached the best possible position of the attachment, tighten two
screws (16) until stop. The clamping force should be 6.5-7.5 N·m (use a
torque screwdriver to check).
Open
Close
18
14 19
1715 16
13
Display of attachment
Crosshair
Powering on and image setup
• Remove the lens cover (1) by turning it counterclockwise.
• Turn on the attachment by pressing the ON (9) button.
• If necessary, adjust the reticle sharpness according to the instructions for
your scope.
• Rotate the lens focus knob (10) to focus on the visual target.
• Enter the main menu with a long press of the MENU button (7) and select the
desired calibration mode: manual (M), semi-automatic (SA) or automatic (A).
• Calibrate the image by briey pressing the ON button (9). Close the lens
cover when calibrating manually.
• Select the desired observation mode (Forest, Rocks, Identication or User)
by briey pressing the MODE button (8) or in the main menu. User mode
allows you to congure and save custom brightness and contrast settings, as
well as one of three modes as a base.
• Select one of the two color palettes by a long press of the MODE button (8).
• Activate the quick menu by briey pressing the MENU button (7) to adjust the
brightness and contrast of the display (see the Quick Menu Functions section
of the full version manual for details).
• Upon completion of use turn the device off by a long press of the ON button (9).
Display Calibration
The attachment is congured so that after tting onto an optical sight that
had been properly zeroed, no adjustment of the aiming point is required. Yet if
point of impact change is observed after putting on the attachment, you can x
it with display calibration procedure.
• To enter display calibration mode,
rst press and hold the MENU
button (7) for 10 seconds.
• The display coordinates X=0; Y=0
will appear.
• Use the LEFT (8) and RIGHT (6)
buttons to move the display
horizontally (X axis) and vertically
(Y axis) so that the point of
impact moves to the centre of the
riescope reticle.
• Press the MENU button (7) to toggle
between the X and Y coordinates.
• The image offset range is +/- 30 pixels horizontally (X axis), +/- 30 pixels
vertically (Y axis).
• To exit the menu and save the settings, press and hold the MENU button (7)
for two seconds.
Stream Vision App
Download the Stream Vision app to stream the image (via Wi-Fi) from your
device to a smartphone or tablet, to view recorded les and update the
software on the device. A detailed user guide is available at pulsar-vision.com
Riescope reticle Display displacement
Impact pointDisplay coordinates
5 6

ENGLISH ENGLISH
Specications
MODEL KRYPTON FXG50
SKU 76655
MICROBOLOMETER
Type Uncooled
Resolution, Pixels 640x480
Pixel Pitch, µm 12
Frame Rate, Hz 50
OPTICAL CHARACTERISTICS
Magnication of attachment, x 1
Recommended daylight optics magnication, x 1.5-6
Lens F50/1.2
Field-of-view (Horizontal), deg/m per 100 m 8.7/15.4
Detection Range (animal height 1.7 m), m/y 2300/2515
Minimum Focusing Distance, m/y 5/5.47
DISPLAY
Type AMOLED
Resolution, Pixels 1746x1000
OPERATIONAL CHARACTERISTICS
Power Supply, V 3-4.2
Battery type/ Capacity/ Rated Output Voltage Li-Ion Battery Pack IPS 7 /
6400 mAh / DC 3.7 V
External Power Supply 5 V (USB)
Max. Battery Pack Life (at t = 22 °C), Hour 8
Degree of protection IP code (IEC60529) IPX7
Maximum Recoil Power when Used with a Ried
Weapon, Joules 6000
Maximum Shock-Resistance when Used with a
Slug Gun, Calibre 12
Operating temperature, °C -25 … +50
Overall Dimensions, mm/inch 143х93х76/5.63x3.66x2.99
Weight (without Battery), kg/oz 0.52/18.34
VIDEO RECORDER
Photo/Video Resolution, Pixels 960x720
Video/Photo Format .mp4/.jpg
Built-in Memory 16 GB
WI-FI CHANNEL
Frequency 2.4 GHz
Standard 802.11 b/g
Line-of-Sight Reception Range*, m/y up to 15/16.4
*Reception range may vary depending on various factors: the presence of obstacles, other
Wi-Fi networks.
The device repair is possible within ve years.
78
