Pure Acoustics AMNESIA User manual

www.pure-acoustics.com
Model: AMNESIA
Powerful 1200w Double 10k Portable Karaoke
Party Speaker with 2 Wireless Microphones
User Manual

www.pure-acoustics.com
.
Thank you for choosing Pure Acoustics. We hope you enjoy using this product. We encourage
you to read this operating and safety instruction document before initial use in order to take
advantage of all the features and functions installed. The document should be stored in a safe
place for future reference and passed on to future owners.
Caution and Safety Guide:
Please turn off the speaker when not in use. If the unit is not used for extended periods of time
we recommend disconnecting the unit from the power source
To prevent speaker damage do not install in areas of high heat or in areas with direct exposure
to sunlight. Do not install the speaker near a place where it may come in contact with rain,
moisture, or other liquids.
Install the unit on a flat surface with good ventilation. Blocking these vents can damage the
speakers as a result of overheating.
To clean the unit, wipe it with a dry napkin or rag.
Warning:
Do not use detergents, gels, etc. to clean the speaker.
In the event of a malfunction, do not open the speaker yourself! Contact a qualified professional
for proper diagnosis and repair.
CAUTION:
Dismantling the unit yourself is dangerous and may damage you and the speaker and void your
warranty.

www.pure-acoustics.com
FEATURES
Powerful and powerful - 1200W watts of listening experience with deep bass and a strong and clear sound
Party lighting - Lighting panel with colored LED along the entire speaker with effects according to the rhythm
of the music
Easy operation - Turn on and sing! User-friendly and quick-to-operate speaker interface
Bluetooth - Streaming music wirelessly to the speaker, suitable for use with iPhone and Android and more
TWS - Connect 2 speakers to one audio source wirelessly, for a powerful surround sound experience. (Works
only in Bluetooth mode and must have a speaker of the same model)
USB / Micro SD input - For playing MP3 files straight from the memory card
FM radio - A digital tuner that includes automatic scanning and saving stations in the speaker memory
Digital recording - For recording karaoke directly on an on-key disk or memory card
Wireless microphones - Including 2 wireless microphones (where applicable) and wired microphone input
Wired microphone - Option to connect a wired microphones
Guitar input - 6.3 mm guitar input that includes a separate volume switch
Main audio selector - control of the volume of the speaker, treble, bass and microphones connected at once
AUX input - direct connection to smartphones, tablets and any music source with a 3.5 mm port
Display - shows the source of the music in which the speaker is turned on, such as: Bluetooth, AUX, USB for
easy and simple operation
Telescopic handle - Transport from place to place in an easy, convenient and safe way
IR remote control - Full control of all the functions of the remote speaker

www.pure-acoustics.com
בצמהטלקהליעפקריבצמבהקיזומAUX/BT
1. GUITAR / AUX / MICRO SD / USB inputs / Wired microphone 1 / Wired microphone 2
2. VOLUME - Main volume, guitar volume, microphone volume, echo volume.
3. REC / GUITAR / MIC buttons
MIC - Microphone: A. (short press 1 - to enter microphone mode and then you can change the
microphone volume using the volume selector (No. 2). B. (2 short presses - to enter the echo microphone control
mode and then you can change the echo volume of the microphone with the help of the volume selector (No. 2).
GUITAR - Guitar - short press 1 - To enter the guitar control mode and then you can change the volume of
the guitar with the volume selector (No. 2).
REC - Record key - the karaoke can be recorded on a USB or SD card (not included)
4. LIGHT SWITCH / MIC PRIORITY / EQ buttons
EQ - Equalizer - allows you to switch between built-in digital equalizer modes
MICROPHONE PRIORITY - The function of lowering the music when using a microphone. Pressing the
key will activate / deactivate the function. Microphone is made by one click - lowers the music when using the
microphone.
LIGHT SWITCH - Turn on / off the disco lighting
5. TREBLE / BASS - short press 1 - to enter TREBLE mode and then you can change the volume with the help of
the volume selector (No. 2), 2 presses to enter the BASS mode.
6. REPEAT - Repeat the previous song.
7. PREV - a short click on the previous song
8. PLAY / PAUSE - Play / pause song play
9. NEXT - A short click to the next song
10. MODE - Transfer between the various functions (BT / USB / AUX / SD / FM)
BUTTONS and FUNCTIONS
MAIN PANEL

www.pure-acoustics.com
11. DC power connection for charging
12. External Power Supply
13. Switch on and off the speaker
CONNECTIONS
Bluetooth Connection
1. Press the MODE button on the multimedia panel until you reach Bluetooth mode, then a sound
will sound and a Bluetooth mode will appear on the display.
2. Make sure that the distance between the speaker and your gland device is not more than a
meter.
3. Your Bluetooth device must be set to scan mode.
4. Select "AMNESIA" from the list of scanned devices
5. If prompted to enter a code press "0000" and select Yes / OK to complete the linking process.
FM radio with automatic scanning
1. Turn on the power switch with the on / off switch.
2. Press the MODE button on the panel until you reach FM mode to listen to the radio
3. To perform an automatic scan of the stations, press and hold the P / P button (No. 8) for 3-5
seconds.
4. Press buttons (No. 9 /No. 7) to switch between radio stations in the area at frequencies Mhz
87.5-108.0
AUX input
Allows analog connection between the speaker and the audio source such as: smartphones,
tablets, MP3 players and more.

www.pure-acoustics.com
TWS - Mode
1. Turn on both speakers and make sure both are in Bluetooth mode at no more than 3m
from each other.
2. Press and hold the button (3-5 seconds) on the next song (- in the next song).The
speakers to make a TWS link between the two.
3. At the end of the link, the main speaker will be called the "parent" speaker and the
second speaker will be called the "son" speaker.
4. Activate the Bluetooth scan on the music source (smartphone, tablet ...) and connect it
to the speaker "master", in the scan will be called "AMNESIA"
Disconnect TWS- Press and hold the next song button (# 7) to disconnect the speakers.
**Please note: The TWS function can be used only when two speakers are in Bluetooth
mode and of the same model.
USB input or MICRO SD Memory Card
You can play music from a USB Drive or a Micro SD memory card (limited to 32 GB).
A. Insert the USB Drive into the USB port and the speaker will play the stored music. If the
speaker does not start playing automatically Press the MODE button to enter USB mode.
-or-
B. Insert the MICRO SD memory card and the speaker will play the stored music. If by any
chance the speaker does not start playing automatically press the MODE button to enter SD
mode.
Recording
Digital recording - recording of speech directly on a USB or TF memory card (not
included) only. Use for lectures and conferences only, not recording audio and
speech together.
Press the record key - for 3-5 seconds for the recording mode to start recording and
another short press to stop the recording. Recording mode is active only in BT /
AUX music modes
Microphone Preference
When you press one, you hear the decibels in the entertainment automatically go down by
about 20 decibels for speaking into microphones.
Section Lighting On / Off Party Lighting
Party lighting will turn on automatically when the speaker is turned on. To switch off
lighting, use switch.
Indicator light on the back of the speaker
•Green light - the speaker is fully charged
•Blue light - the speaker is in charging mode
•Red light - weak battery, charge the speaker

www.pure-acoustics.com
1. Red key - MUTE - Mute / Unmute, MODE key - Switch
audio sources: BT / AUX / USB / SD and FM
2. Channel keys 1-9
3. ECHO + EQUILIZER + GUITAR- Volume control key
4. TREBLE - Volume control key
5. Multimedia control panel - volume + volume from
microphones
6. BASS - Volume control key
7. Previous song player key / Song pause song / Next song
player
8. Microphone preference / Repeat the previous song /
Record key
REMOTE CONTROL
TECH SPECS
Power: 1200W
Audio frequency: 48Hz-20 KHz +/- 3dB
Sensitivity: 88dB +/- 3dB
Battery: 12 V / 7.5A
Audio frequencies: 105 dB +/- 3dB
Impedance: 4
Power source 1: (DC 12V 7500A) Rechargeable battery
Power source 2: (DC 20V 4A) External power supply
Product dimensions: 30 * 33 * 86 cm

www.pure-acoustics.com
-
COMMON QUESTIONS
Why didn't my speaker turn on?
Check that the external transformer is connected to the back of the device.
Find out that the external transformer is connected to a power source.
Find out that the main circuit breaker is in the ON position.
Why is my microphone not working?
Make sure the microphone is in the ON position.
Make sure the switch on the back of the speaker is in the ON position and the transmission
light is on.
Make sure that the volume switch is turned to the on position
What is the ideal place to place my speaker?
The speaker should be placed on a smooth and safe surface or on a suitable stand (not included).
Make sure that the speaker is placed in a ventilated place.
Is there any action to extend the life of the speaker?
Yes! In the event that the speaker is not going to be used for an extended period of time, it should
be disconnected from the power source.
Fully charge the speaker once a week (4 hours charging time).
Batteries should be removed from the microphones at the end of each use.
Is it possible to clean the speaker occasionally?
Yes, it is possible to clean the speaker by wiping with a rag or dry paper towel only!
Warnings
•Do not cover the vents!
•Do not place other devices on top of the speaker such as: monitors, computers, amplifiers, etc ...!
•Do not place the speaker in a wet area or area where the speaker may get wet!
•Do not place the speaker in an area of high heat or a place with direct sun exposure!
•Do not use any kind of liquid to clean the speaker such as: water, detergent, soapy water etc ...
Using one of these may cause irreversible damage to the device.
Limited Warranty
Please note that the responsibility for the microphones and / or the rechargeable battery is for natural defects only! The warranty
does not include coverage for damages caused as a result of falls, fractures (external or internal) or contact with fluids.
Before confirming replacement or repair of the microphone and / or speaker under warranty, the product will undergo an internal
inspection to verify that the fault was not caused as a result of one of the faults mentioned above.
Overcharging! Do not charge the device for more than 4 hours in a row! Faults caused by overcharging are not included in the
warranty!
