PURE 18V Impact Driver User manual

18V Li-Ion
Impact Driver
(PUREIMPACTDRIVER18V)
Original
Instructions

2
PURE 18V Impact Driver
TABLE OF CONTENTS
EC - Declaration of Conformity
Important Information
12 Month Limited Warranty
General Safety Rules
Additional Specic Safety Rules
Labels and Symbols
Driver Overview
Specication
Operating Instructions
Maintenance
Environmental Protection
EC - DECLARATION OF CONFORMITY
We, the importer
Evolution Power Tools Ltd.
Venture One
Longacre Close
Shefeld
S20 3FR
Declare that the product
Part numbers: PUREIMPACTDRIVER18
Evolution: Pure Battery Drill/Driver
Complies with the essential requirements
of the following European Directives:
2006/42/EC – Machine Directive
2006/95/EC – Low Voltage Directive
2004/108/EC – EMC Directive
2002/95/EC – Restriction of the use of
Certain Hazardous Substances in Electrical
and Electric Equipment
Standards and Technical specications
referred to:-
EN 5 5014 -1/A1:2 0 0 9
EN 55014-2/A2:2008
EN 6 074 5 -1/A11:2 010
EN 60745-2-2:2010
All documentation is held on le at the
above address and is available, on request
for review.
Authorized Signatory
Date: 20/12/11
Name: Mr Matthew J Gavins
Position: Managing Director
02
03
03
03
05
06
06
07
07
09
09

3
IMPORTANT
Please read these operating and safety
instructions carefully and completely.
For your own safety, before using this
equipment check that the voltage is correct
and that all handles and parts are rmly
secured. If you are uncertain about any
aspect of using this equipment, please
contact our Technical Helpline.
UK 0870 609 2297
PURE COMPACT 18V IMPACT DRIVER
Congratulations on your purchase of an
Evolution Power Tools Pure 18V Impact
Driver. Please complete your product
registration on line to validate your
machine’s warranty period and ensure
prompt service if needed. We sincerely
thank you for selecting a product from
Evolution Power Tools.
12 MONTH LIMITED WARRANTY.
Evolution power tools reserves the right
to make improvements and modications
to design without prior notice.
Evolution Power Tools will, within twelve (12)
months from the original date of purchase,
repair or replace any goods found to be
defective in materials or workmanship. This
warranty is void if the tool being returned has
been used beyond the recommendations
in the Instruction Manual or if the driver has
been damaged by accident, neglect, or
improper service. This warranty does not
apply to machines and / or components which
have been altered, changed, or modied
in any way, or subjected to use beyond
recommended capacities and specications.
Electrical components are subject to
respective manufacturers’ warranties. All
goods returned defective shall be returned
prepaid freight to Evolution Power Tools.
Evolution Power Tools reserves the right to
optionally repair or replace it with the same
or equivalent item. There is no warranty –
written or verbal – for bits. In no event shall
Evolution Power Tools be liable for loss or
damage resulting directly or indirectly from
the use of our merchandise or from any
other cause. Evolution Power Tools is not
liable for any costs incurred on such goods
or consequential damages. No ofcer,
employee or agent of Evolution Power Tools
is authorized to make oral representations of
tness or to waive any of the foregoing terms
of sale and none shall be binding on Evolution
Power Tools. Questions relating to this limited
warranty should be directed to the company’s
head ofce, or call the appropriate Helpline
number.
GENERAL SAFETY RULES
WARNING: When using electric tools,
basic safety precautions should always be
followed to reduce the risk of re, electric
shock and personal injury.
Please read all of these instructions before
attempting to operate this machine.
Save this manual for future reference.
1. Keep work area clear. Cluttered work
areas invite accidents.
2. Consider work area environment. Do
not expose tools to rain. Do not use tools
in damp or wet locations. Keep work area
well lit. Do not use tools in the presence of
ammable liquids or gases.
3. Guard against electric shock. Avoid
body contact with earthed or grounded
surfaces (e.g. pipes, radiators, ranges,
refrigerators).
4. Keep other people away. Do not let
others, especially children, come close to
the work, and touch the tool or the extension
lead. Keep them away from the work area.
18V Li-Ion
Impact Driver

4
5. Store idle tools. When not in use, tools
should be stored in a dry locked-up place,
out of reach of children.
6. Do not force the tool. It will do the job
better and safer at the rate for which it was
intended
7. Use the right tool. Do not force small
tools to do the job of a heavy duty tool. Do
not use tools for purposes not intended; for
example do not use circular saws to cut tree
limbs or logs.
8. Dress properly. Do not wear loose
clothing or jewellery, they can be caught
in moving parts. Non-skid footwear is
recommended when working outdoors.
Wear protective hair covering to contain
long hair.
9. Use protective equipment. Use safety
glasses. Use face or dust mask if working
operations create dust.
10. Connect dust extraction equipment.
If the tool is provided for the connection of
dust extraction and collection equipment,
ensure these are connected and properly
used.
11. Do not abuse the cord. Never yank
the cord to disconnect it from the socket.
Keep the cord away from heat, oil and sharp
edges.
12. Secure work. Where possible, use
clamps or a vice to hold the work. It’s much
safer than using your hand.
13. Don’t over reach. Keep proper footing
and balance at all times.
14. Maintain tools with care. Keep
cutting tools sharp and clean for better
and safer performance. Follow instructions
for lubricating and changing accessories.
Inspect tool cords periodically and, if
damaged, have them repaired by an
authorised service facility. Inspect extension
cord periodically and replace immediately if
damaged. Keep handles dry, clean and free
from oil and grease.
15. Disconnect tools. When not in use,
before any servicing and when changing
accessories such as blades, bits, cutters,
disconnect tool from the power source
16. Remove adjusting keys and
spanners. Form the habit of checking to
see the keys and adjusting spanners are
removed from the tool before turning it on.
17. Avoid unintentional starting. Ensure
switch is in “off” position when plugging in.
18. Use outdoor extension leads.
When the tool is used outdoors, use only
extension cords intended for outdoor use
and so marked.
19. Stay alert. Watch what you are doing,
use common sense and do not operate the
tool when you are tired.
20. Check damaged parts. Before further
use of tool, it should be carefully checked
to determine that it will operate properly
and perform the intended function. Check
for alignment of moving parts, mountings
and any other components that may affect
its operation. A guard or other part that is
damaged should be properly repaired or
replaced by an authorised service centre
unless otherwise indicated in this instruction
manual. Have defective switches replaced
by an authorised service centre. Do not use
the tool if the switch does not turn it on and
off.
21. WARNING. The use of any accessory or
attachment other than one recommended in
this instruction manual may present a risk of
personal injury.
22. Have your tool repaired by a qualied
person. This electric tool complies with
relevant safety rules. Repairs should only
be carried out by qualied persons using
original spare parts. Otherwise this may
result in considerable danger to the user.
HEALTH ADVICE
WARNING: When drilling, sanding, sawing
or grinding, dust particles will be produced.
In some instances, depending on the
materials you are working with, this dust can
be particularly harmful to you (e.g. lead from
old gloss paint).You are advised to consider
the risks associated with the materials you
are working with and to reduce the risk of
exposure.

5
You should:
• Work in a well-ventilated area.
• Work with approved safety equipment,
such as dust masks that are specially
designed to lter microscopic particles.
ADDITIONAL SAFETY RULES FOR YOUR
IMPACT DRIVER
1. Do not expose to rain or water.
2. Do not drop, shake or strike the battery.
3. Wear hearing protection when necessary.
Exposure to noise can cause hearing loss.
4. Cutting blades and accessories can
become very hot. Take care when changing
or handling any bits or accessories.
3. Recharge the battery only with the
charger specied by the manufacturer.
A charger that is suitable for one type of
battery pack may create a risk of re when
used with another battery pack.
4. Use this power tool only with specially
designated battery packs. Use of any other
battery packs may create a risk of injury and
re.
5. When the battery pack is not in use,
keep it away from other metal objects like
paper clips, coins, keys, nails, screws or
other small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a re.
6. Under extreme conditions electrolyte
may be leak from the battery. If contact
accidentally occurs, ush your skin with
water. If electrolyte contacts your eyes,
additionally seek medical help. Electrolyte
from the battery may cause irritation or
burns.
7. Hold the tool by the insulated gripping
surfaces, especially when performing an
operation where the driving bit may contact
hidden wiring. If the driving bit contacts
a ‘live’ wire, exposed metal parts of the
power tool could become ‘live’ and give the
operator an electric shock.
8. If possible, use clamps or a vice to hold
your work.
9. When screw driving into walls, oors or
similar areas, make sure, as far as possible,
that there are no services (gas or water
pipes, electric cables etc) in the path of
the screw. Striking hidden services could
cause injury to the user and damage to the
property.
10. Always hold the tool with both hands for
maximum control. Keep proper footing at
all times.
11. Keep hands away from the driving area.
Do not reach under material being drilled.
12. Always wear appropriate safety glasses
when using this machine. Every day glasses
are NOT safety glasses.
WARNING: This machine is not intended
for use by persons (including children)
with reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
the safe use of the machine by a person
responsible for their safety.
Children should be supervised to ensure
that they do not have access to, and are not
allowed to play with, this machine.
18V Li-Ion
Impact Driver

6
LABELS & SYMBOLS
WARNING: Do not operate machine if
warning and/or instruction labels are
missing or damaged. Contact Evolution
Power Tools for replacement labels.
PHOTOGRAPH OF IMPACT DRIVER
3
1
4
2
5
6
Symbol Description
V Volts
A Amperes
Hz Hertz
Min-1 Speed
~ Alternating Current
noNo Load Speed
Double Insulated
Wear Safety Goggles
Wear Ear Protection
1. KEYLESS COLLECT CHUCK
2. FORWARD/REVERSE SELECTION LEVER
3. SOFT GRIP HANDLE
4. ON/OFF TRIGGER SWITCH
5.INSERTED BATTERY PACK
6. BATTERY PACK LOCKING TAB

7
SPECIFICATION
PURE IMPACT DRIVER
Voltage: 18V-DC
No Load Speed: 0-2300 min-1
Impact Speed: 0-2800 BPM
Max torque: 140 N.m
Items Supplied
Instruction Manual: 1pc
OPERATING INSTRUCTIONS
Note: Before using this tool, read the
Instruction Manual carefully.
BEFORE USE
A Battery Pack must be inserted into the
tool as detailed below. It is important that
the Battery Pack is of the designated type
recommended for this machine.
Newly purchased Battery Packs do not
come fully charged. Please refer to the PURE
CHARGER MANUAL for full details on how to
charge the Battery Pack for
this machine.
1. INSTALLING OR REMOVING THE
BATTERY PACK
Check that the Battery Pack is of the
designated type for this machine. We
recommend that the ‘On/Off’ trigger switch
is locked in the ‘Off’ position when removing
or inserting the Battery Pack. Refer to
section 3 below.
a. Slide the Battery Pack into the end of the
machines body. The Battery can only t one
way round.
b. Gently slide the Battery Pack fully into
the machines body to engage the locking
tabs. The electrical connections between
the battery and the machine will be made
automatically.
c. To remove the Battery Pack, simply press
the two locking tabs with your nger and
thumb and slide the Battery Pack from the
machine.
18V Li-Ion
Impact Driver

8
2. On/Off TRIGGER SWITCH
This tool is tted with a variable speed Trigger
Switch that delivers higher speed and torque
as the trigger pressure is increased. The
Trigger Switch is also tted with a brake
function which stops the chuck immediately
when you quickly release the trigger.
3. TRIGGER SWITCH LOCK
To lock the Trigger Switch in the ‘Off’
position, slide the Forward/Reverse
Selection Lever to its central position.
4. FORWARD/REVERSE SELECTION
For screw driving use the forward rotation
marked on the Selection Lever. Push the
lever fully to the left.
For reverse rotation, necessary when
removing screws etc. push the Selection
Lever fully to the right, marked on the
Selection Lever.
Only operate the Selection Lever when the
drill is at a complete stop.
5. CHUCK OPERATION
Note: This Impact Driver is equipped
with a keyless Collet chuck. This chuck is
optimized for use with single ended 50 mm x
6 mm AF impact quality bits/adaptors. Other
bits/adaptors may t, but may not locate
positively within the chuck. Only use impact
quality bits/adaptors with this machine.
a. To open the chuck pull the Collet sleeve
forwards and insert the desired bit or
adaptor into the chuck.
b. Release the Collet sleeve.
c. Pull the bit/adaptor forward slightly until
the Collet sleeve springs backwards and the
bit/adaptor is locked in place.
d. To release the bit/adaptor, pull the Collet
sleeve forwards and pull the bit/adaptor
from the chuck.
6. LOOSENING A SCREW
• Insert a suitable bit into the Collet chuck.
• Select reverse rotation by pushing the
Selection Lever fully to the right.
• Locate the bit into the screw.
• Push the bit forcefully into the screw.
• Operate the trigger switch.
• Allow the impacts to loosen and begin to
withdraw the screw.
• Adjust the speed of rotation for best
working efciency.
7. LOOSENING A NUT OR BOLT.
• Insert a suitable adaptor into the Collet
chuck.
• Select a suitable impact quality socket,
which is a good t over the nut/bolt head.
• Push the socket over the nut/bolt head.
• Operate the trigger switch.
• Allow the impacts to loosen and begin to
withdraw the nut or bolt.
• Adjust the speed of rotation for best
working efciency.
8. TIGHTENING
This impact driver is capable of delivering
substantial amounts of torque (turning
power). The operator must use due care and
diligence to ensure that fastenings are not
over-tightened and damaged.

9
18V Li-ION
Impact Driver
9. MAINTENANCE
Your Impact Driver requires no additional
lubrication or maintenance. There are no
user serviceable parts in your power tool.
Keep the tool clean, but do not use
chemical cleaners which may damage the
plastic parts. Clean with a dry cloth. Ensure
that the motor ventilation slots are kept
clean.
