J. Insert the Female Lock Portion
(4) into the apertures of the lock
cradle on the wheel cover arm.
Insert the Male Lock Portion (3) into
the female lock portion and secure
with the key (9).
K. Remove the key and your wheel clamp is
now tted. Two keys are provided. Please
store your keys in a safe place and remember
to return your fully completed registration
card. Your key number is located on both of
the keys supplied and will be required in order
to purchase replacement keys.
Note: The male portion has a
notch that locates into a recess
on the female portion.
D. If necessary, unscrew (by turning anti-
clockwise) the Wheel Hub Arm Hex Bolt (7).
Do not fully remove.
E. The Wheel Hub Cover
Arm (2) has a ‘key hole’
slot that ts over the
hex bolt.
F. Feed the arm
over the hex bolt.
G. Slide the arm into
the slot.
I. Once in position, tighten the Wheel Hub
Arm Hex Bolt (7) by turning clockwise until
sufciently tight.
H. Hold the arm in position. The
round wheel cover has a slide and tilt
mechanism and should be adjusted to
be central to the face of the wheel as
much as possible. On larger wheels
where central location is not possible,
it must be ensured that at least one of
the wheel nuts is covered.
DE
F
G
HI
J
K
Note: With certain wheels
it is sometimes easier to
unscrew the hex bolt from
the ‘jaw’ section, locate
through the ‘key hole’
aperture (see 1a) in the arm
and then offer up the arm
to locate the end of the hex
bolt into the thread.
1a
