Pycom WiPy 3.0 User manual

ESP
cont
Blue
RGB
heart beat RF
High
SM
8MB flash memory U.FL
WiPy 3.0
Introducing the WiPy 3.0. The tiny MicroPython enabled Wifi
&
Mechanical
Size: 42mm x 20mm x 3.5mm (excluding headers)
Bluetooth IoT development platform. With a 1KM WiFi range,
state of the art Espressif ESP32 chipset and dual processor,
the WiPy 3.0 is all about taking the Internet of Things to the
next level.
Create and connect your things everywhere. Fast.
WiPy Features
Operating temperature:
-20 to 85 degrees
celsius
3V3 ultra low
noise switching
regulator
32 dual core
micro- roller and
WiFi/ tooth 4.2
radio
performance
-Powerful CPU, BLE and state of the art WiFi
radio.
-1KM Wifi Range
-MicroPython enabled
Reset
Switch
D antenna
-Fits in a standard breadboard (with headers)
-Ultra-low power usage: a fraction compared to other
connected micro controllers
Processing
-Espressif ESP32 chipset
-Dual processor + WiFi radio System onChip
-Network processor handles the WiFi connectivity and the
IPv6
Interfaces
-2 x UART, 2 x SPI, I2C, I2S, micro SD card
-Analog channels: 8x12 bit ADCs
-Timers: 4x16 bit with PWM and inputcapture
-DMA on all peripherals
-GPIO: Up to 24
stack
-Main processor is entirely free to run the userapplication
-An extra ULP-coprocessor that can monitor GPIOs, the
ADC channels and control most of the internal peripherals
during deep-sleep mode while only consuming 25uA
Use the Pymakr IDE
Super easy code editor to write your Python scripts
Quick Verification
For easy and fast debugging use the interactive shell that is
acces- sible through telnet or one of the serialports
Hash / encryption
SHA, MD5, DES,
AES
WiFi
802.11b/g/n 16mbps
Bluetooth
Low energy and
classic
RTC
Running at 32KHz
Power
- 3.3V to 5.5V
3V3 output capable
of sourcing up to
500mA
Security & Certifications
-SSL/TLS support
-WPA Enterprise security
-FCC - 2AJMTWIPY3R
- CE 0700
Memory
-RAM: 4MB
-External flash: 8MB
-Hardware floating
point acceleration
-Pythonmulti-threading
Easy Upload
Upload your scripts, and any other files you want to theWiPy
3.0 via the FTP server
Locally or remotely
Reset the WiPy 3.0 (you can do it locally, or remotely via
Telnet)
With dozens of ready to use templates and libraries
soon to be available on the Pycom Exchange,
developing a new IoT solution is now easier and faster.
Additional support for Blynk: SMTP, MQTT, URLLIB,
ONEWIRE, Accelerometer, Event loop MicroPython
together with the universal hard-
ware API allow us to build a large set of powerful, robust,
and portable libraries across hardware platforms.
Distributed and manufactured by Pycom Ltd.
Registered office:
High Point, 9 Sydenham Road, Guildford, Surrey GU1 3RX, UK
Copyright © 2017 by Pycom Ltd. All rights reserved. No part of this
document may be reproduced, distributed, or transmitted in any form
or by any means, including photocopying, recording, or other electronicor

EU Regulatory Conformance
Hereby, Pycom Ltd declares that the radio equipment type Wipy
3.0 is in compliance with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available at the following internet
address:www.pycom.io
Federal Communication Commission Interference
Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1)This device may not cause harmfulinterference.
(2)This device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with
the instructions, may cause harmful interference to radio
communications.However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver isconnected.
-Consult the dealer or an experienced radio/TV technician for
help.
RF Warning Statement
To comply with FCC RF exposure compliance requirements,
the antennas used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction with any
other antenna or transmitter.
This device is intended only for OEM integrators under
the following conditions:
1)The antenna must be installed such that 20 cm is
maintained between the antenna and users,and
2)The transmitter module may not be co-located with any
other transmitter orantenna.
As long as two conditions above are met, further transmitter
test will not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional
compliance requirements required with this module installed.
Toensure compliance with all non-transmitter functions the
host manufacturer is responsible for ensuring compliance
with the
module(s) installed and fully operational. For example, if a host
was previously authorized as an unintentional radiator under the
Declaration of Conformity procedure without a transmitter
certified module and a module is added, the host manufacturer is
responsible for ensuring that the after the module is installed and
operational the host continues to be compliant with the Part 15B
unintentional radiator requirements.
The module is limited to OEM installation ONLY.
The module is limited to installation in mobile or fixed application.
We hereby acknowledge our responsibility to provide guidance
to the host manufacturer in the event that they require
assistance for ensuring compliance with the Part 15 Subpart B
requirements.
IMPORTANT NOTE: In the event that these conditions
cannot be met (for example certain laptop configurations or
co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID
cannot be used on the final product. In these circumstances,
the OEM integrator will be responsible for reevaluating the
end product(including the transmitter) and obtaining a
separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where
the antenna may be installed such that 20 cm may be maintained
between the antenna and users. The final end product must be
labeled in a visible area with the following: “Contains FCC ID:
2AJMTWIPY3R”. The grantee's FCC ID can be used only when all
FCC compliance requirements are met.
The following FCC part 15.19 statement has to also be
available on the label:
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions:
(1)this device may not cause harmful interferenceand
(2)this device must accept any interference received,
including interference that may cause undesired operation.
Manual Information to the End User
The OEM integrator has to be aware not to provide information
to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates
this module.
In the user manual of the end product, the end user has to be
informed that the equipment complies with FCC radio-frequency
exposure guidelines set forth for an uncontrolled environment.
The end user has to also be informed that any changes or
modifications not expressly approved by the manufacturer could
void the user's authority to operate this equipment.
The end user manual shall include all required
regulatory information/warning as show in this manual.
The maximum operating ambient temperature of the equipment
declared by the manufacturer is
-20~+85C

Regulatory statement
This device complies with Part 15 of the FCC Rules and with
RSS-247 of Industry Canada. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired
operation.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions
suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
RF Exposure Statement
This equipment complies with IC radiation exposure limits set
forth for an uncontrolled environment. This
equipment should be installed and operated with minimum
distance 20cm between the radiator & your
body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux
rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et
utilisé avec un minimum de 20 cm de
distance entre la source de rayonnement et votre corps.
Frequency Band
2400‐2483.5MHZ
EIRP For Internal antenna
Bluetooth: -5.24dBm
WiFi: 10.81dBm
EIRP For External antenna
Bluetooth: 2.93dBm
WiFi: 7.99dBm
