PYD Life iSmart User manual

www.pydlife.com
Ofce
Rm 4409, No. 372, Huanshi
Dong Road, Yuexiu District,
Guangzhou, 510060, China
Wesite:
www.pydlife.com
Tel: [phone] E-mail: sales01@pydlife.
com
iSmart
Sublimation
Oven

iSmart Sublimation OveniSmart Sublimation Oven
www.pydlife.com
1
www.pydlife.com
2
iSmart
Sublimation
Oven
Technical Description
Control Panel
Temp. Knob: Turn to adjust printing temperature.
Upper Tube: Press to enter upper tube heating mode.
Lower Tube: Press to enter lower tube heating mode.
Time Knob: Turn to adjust printing time.
Start/Stop: Press to start or stop heating.
Low Temp./Dry: Press to enter low temperature heating mode.
Hot Air: Press to turn on or turn off the hot air circulation inside.
Light: Press to turn on or turn off the oven light.
Upper Tube Temp.
Lower Tube Temp.
Time
Function Indicator
Preheat Indicator
Item Number KX40LB
Capacity 40L
Size 460×360×380(mm)
Voltage AC 110V/220V 50/60 Hz
Power 1600W/2000W
Temp. Range 60-230oC
Temp. Adjusting Upper and lower heating tubes can be
adjusted together or separately
Part 3 upper tubes, 3 lower tube, 1 back
tube, 1 fan, 1 oven light
1 4
5
12
32
6 7 89
13 10 11
1 8
2 9
310
411
512
613
7

iSmart Sublimation OveniSmart Sublimation Oven
www.pydlife.com
3
www.pydlife.com
4
Operation
1. Mode
2. Upper & Lower Heating Tube
Starting : When turned on rst, screen ashes on for 1 sec
and displays default time and temperature.
Preheating: Screen displays “ ” indicator, no time countdown.
Working: Screen display the set temperature, time is counting down.
Finishing: Screen displays the set temperature and ashing 00:00,
machine beeps for 3 times. Press any button to turn back to
standby mode, screen displays the set values.
The default mode setting is upper and lower tube heating mode. Oven enters this heating mode
automatically once turned on;
1. Press “Upper Tube” button and turn the temp. knob to adjust the temperature of upper tube;
2. Press “Lower Tube” button and turn the temp. knob to adjust the temperature of lower tube;
3. Press “Upper Tube” and “Lower Tube” buttons at the same time and turn the temp. knob to adjust
the temperature of both tubes;
4. Press “Start/Stop” button to start heating.
3. Low Temperature
4. Hot Air
Low temperature mode is for drying transfer paper or sublimating items that need low
temperature printing.
1. Press “Low Temperature” button to enter low temperature heating mode;
2. Turn the time temp. knob to adjust temperature and time knob to adjust time.
The fan inside the oven can circulate the hot air and make temperature inside more
uniform.
1. Press “Hot Air” button after turning on the oven;
2. Turn the time temp. knob to adjust temperature and time knob to adjust time;
3. Press “Start/Stop” button to start or stop the hot air fan during working.

iSmart Sublimation OveniSmart Sublimation Oven
www.pydlife.com
5
www.pydlife.com
6
5. Printing Parameter
6. Note
Item Preheat Temp. Time
Mug
7-10 mins
195oC
12 mins for 1 mug
15 mins for 4 mugs
20 mins for 6 mugs
Stainless Steel Bottle 195oC 5 mins for 1 bottle
Enamel Mug 195oC 7 mins for 2 mugs
Aluminum Bottle 160oC 7 min for 1 bottle
Ceramic Tile 195oC 20 mins for 1 piece
1. When the oven is working, working mode cannot be changed.
2. When the oven is working, press “Start/Stop” to stop working, and turn the knob to adjust the printing time.
3. The printing temperature can be adjusted even during working.
4. Make sure to press the "Hot Air" button after turning on the oven to achieve the best printing result.
Heating Mode Default Temp. (oC) Temp. Range Default Time
(min) Time Range
Upper Tube Lower Tube Back Tube Hot Air Fan Oven Light
800W 700W 300W 20W 15W
Upper & Lower Tubes 180
Double Tube:
60-230oC
Single Tube:
60-200oC
30 1min-2h √ √ √
Low Temperature 35 28-50oC60 10min-12h √ √
Hot Air 180 60-230oC30 1min-2h √ √ √ √ √
7. Error Alarm
8. Important Safeguard
During working or self-checking, the oven can detect if the thermal sensor functions properly in 5 seconds. If the screen displays
“E1”: The upper temperature sensor has an open circuit or a short circuit;
“E2”: The lower temperature sensor has an open circuit or a short circuit;
“E3”: The temperature inside reaches over 280oC,
When errors above happen, the load current will cut off immediately, and the oven will beep for 10 times. The oven will be back to good
working condition until the error is repaired and the circuit is reconnected.
1. The oven body surface becomes very hot during working, be careful not to burn yourself during or after using. Wear heat-resistant gloves
and use the door handle to open and close the oven door;
2. To avoid electric shock, do not immerse cord, plug or any parts of the oven in the water, always unplug after use;
4. Never leave the oven unattended during operation;
5. Do not put any of the following materials in or on the top of the oven: cardboard, plastic, paper, candle or other ammable materials;
6. The oven needs at least 10cm clearance space on all sides and at least 30cm above for adequate air circulation;
