PYLE Audio PLE730R User manual

power
4KHz 6KHz 1
5KH
ple730r
owner’s manual ple520p
equalizer with subwoofer crossover

i
congratulations...
for choosing Pyle Audio, and congratulations on
joining a select group of dedicated enthusiasts
committed to the very best in mobile sound
performance and dependability.
You are now the proud owner of one of the world’s
most sophisticated electronics components. This
Pyle product is the result of an extensive
engineering program with the sole purpose of
creating the finest mobile audio experience
imaginable. We’re confident that this product will
provide you with many years of outstanding
musical entertainment.
Ple730r

1
table of contents
owner’s manual
i
1
2
3
4-5
6-7
8
9
10-11
12
Ple520p
congratulations
table of contents
general features
specifications
features and controls
Ple730r
Ple520p
mounting and installation
electrical connections
system wiring
precautions and troubleshooting

2
general features
ple730r
ple520p
ple730r
ple520p
5 band graphic equalizer
5 band parametric controls
20 frequency band selectors
pre-amp line & aux input
via RCA jacks
output volume control
input gain adjustments frequency gain control
rotary fader
rotary band control
defeat switch
6 channels RCA outputs
remote power on/off
7 band graphic equalizer
pre-amp input via RCA jacks
output level control
LED power level meter
12 dB boost/cut
subwoofer frequency control
subwoofer boost control
front and rear fader control
6 channels RCA outputs
night illumination
remote power on/off
high impedance output
half-DIN size cabinet
to

3
ple730r
specifications
owner’s manual
ple520p
p
center frequencies 65 Hz ·150 Hz
400 Hz ·1.4 KHz
2.4 KHz ·6 KHz
15 KHz
sub band
25 ·50 ·65·80Hz
15 0 · 200 · 260 · 300 Hz
600 · 800 · 1000 · 1200 Hz
2.1 · 2.8 · 3.5 · 4.2 KHz
7·9.5·12·15KHz
low band
low mid band
high mid band
high band
cks
ntrol
rol
7-Band Equalizer 5-Band Equalizer
200 mV
10K Ohms
90 dB
50 dB
450 mA
ple730r ple520p
frequency response 15 Hz - 30 KHz (+/– 1 dB)
input level
(for 400mV output) 400 mV
total harmonic distortion (THD)
(at 400mV output) < 0.03%
output impedance
signal-to-noise ratio (S/N)
separation
current drain
power supply voltage 12V DC Neg. Ground
190x29x140
7 x 1.1 x 5.5
dimensions (WxHxL)
mm
inches

4
sub channel
outputs rear channel outputs front channel outputs stereo inputs auxiliary inputs
sub rear front line aux
OUTPUT INPUT
LRLRLRLRLR
rear
aux
def
left output level power
65Hz 150Hz 400Hz 1.4KHz 2.4KHz 6KHz 15KHz subwoofer 40 400 0 +18dB volume
fader
min max
right output level
front
rear
series
ple730r
front
LED level display
power indicator LED
equalizer controls subwoofer
frequency
control
subwoofer
boost
control
fader/volume control
defeat switch
aux input switch
s
features and controls
ple730r

5
aux input switch
LED level display
power indicator LED
fader control
volume control
defeat switch
equalizer controls
subwoofer frequency control
subwoofer boost control
power connections
subwoofer/rear/front
channel outputs
line and auxiliary inputs
the switch selects the aux or line inputs.
these rows of LEDs display the Preamp Output Levels. Left
and right channels are displayed independently at peak levels.
this LED is illuminated when the unit is properly powered,
grounded and the remote power has been turned on.
• in a 2 Amplifier, 4 Speaker system, rotating the knob to the
FRONT side increases the level of the front speakers; rotating
to the REAR side increase level of the rear speakers. At mid
position, both sets of speakers are at maximum level.
• in a 2 Speaker system, the fader control should be rotated
to the position which provides highest levels for both sets of
speakers.
allows adjustment of sound level for particular program material
or source.
when the “DEF” switch is in the position, the equalizer functions
are bypassed. Depressing the “DEF” switch again will restore
the equalizer’s operation.
this seven-band equalizer gives you control over the output
levels at various frequencies.
lets you adjust the subwoofer frequency and crossover point
from 40-400 Hz.
lets you adjust the subwoofer boost level froma0to+18dB
increase.
connect to power source as follows:
+12V: Connect a red wire of at least 12 gauge to the car
battery or other power source.
GROUND: Connect a black wire of at least 12 gauge to car
chassis for ground connection
REMOTE: Connect an orange wire to remote activating (12V
DC) wire of car stereo or other head unit.
RCA cables are used to connect the subwoofer channel outputs
to the subwoofer channel amplifier inputs, the rear channel
outputs to the rear channel amplifier inputs, and the front
channel outputs to the front channel amplifier inputs.
RCA cables are used to connect your car stereo head unit, CD
player, or other source to either the line or aux inputs.
features
owner’s manual

6
left output level power right output level
aux
def
sub low low mid hi mid high subwoofer
40 400 0 +18dB volume
min max
fader
front
rear
series
ple520p
front
LED level display
power indicator LED
equalizer controls subwoofer
frequency
control
subwoofer
boost
control
fader/volume control
defeat switch
aux input switch
sub channel
outputs rear channel outputs front channel outputs stereo inputs auxiliary inputs
sub rear front line aux
OUTPUT INPUT
LRLRLRLRLR
rear
top
s
input gain adjustment
aux line equalizer center frequency switches
25
50
65
80
15 0
200
260
300
600
800
1000
120 0
2.1k
2.8k
3.5k
4.2k
7k
9.5k
12 k
15 k
features and controls
ple520p

7
input gain adjustments
equalizer frequency controls
aux input switch
LED level display
power indicator LED
fader control
volume control
defeat switch
equalizer controls
subwoofer frequency control
subwoofer boost control
power connections
subwoofer/rear/front
channel outputs
line and auxiliary inputs
allows you to adjust the left and right channel input sensitivity to
match the output level from your line or auxiliary source.
these switches determine the frequencies the equalizer control
knobs on the front panel will affect. Setting a switch on one of the
5 bands on top of the equalizer permits the corresponding control
on the front panel to boost or cut the level.
the switch selects the aux or line inputs.
these rows of LEDs display the Preamp Output Levels. Left and right
channels are displayed independently at peak levels.
this LED is illuminated when the unit is properly powered, grounded
and the remote power has been turned on.
• in a 2 Amplifier, 4 Speaker system, rotating the knob to the FRONT
side increases the level of the front speakers; rotating to the REAR
side increase level of the rear speakers. At mid position, both sets
of speakers are at maximum level.
• in a 2 Speaker system, the fader control should be rotated to the
position which provides highest levels for both sets of speakers.
allows adjustment of sound level for particular program material
or source.
when the “DEF” switch is in the position, the equalizer functions
are bypassed. Depressing the “DEF” switch again will restore the
equalizer’s operation.
this seven-band equalizer gives you control over boost or cut at the
frequencies selected by the corresponding center frequency switches
on top of the unit.
lets you adjust the subwoofer frequency and crossover point from
40-400 Hz.
lets you adjust the subwoofer boost level froma0to+18dB
increase.
connect to power source as follows:
+12V: Connect a red wire of at least 12 gauge to the car battery
or other power source.
GROUND: Connect a black wire of at least 12 gauge to car chassis
for ground connection
REMOTE: Connect an orange wire to remote activating (12V DC)
wire of car stereo or other head unit.
RCA cables are used to connect the subwoofer channel outputs to
the subwoofer channel amplifier inputs, the rear channel outputs
to the rear channel amplifier inputs, and the front channel outputs
to the front channel amplifier inputs.
RCA cables are used to connect your car stereo head unit, CD
player, or other source to either the line or aux inputs.
features
owner’s manual

wiring tips
8
Signal Processor enclosure
Mounting Bracket
4 x 12 mm
self-tapping screw (2)
4 mm spring
washer (2)
4 mm plain
washer (2)
4 x 6 mm machine screw (4)
dashboard
When making electrical
connections to your amplifier,
please observe the following:
Connect 12V DC from a constant battery source to a +12V slip-on spade terminal and install
a one (1) amp fuse in line.
Connect the signal processor’s GROUND to a good chassis ground, near where the unit is
mounted, or to the case of the head unit.
Connect the signal processor’s REMOTE TURN-ON lead to the remote turn-on lead out of
the head unit, and install a 1/2 amp fuse in line. (A relay should be used if turning on more
than one component, such as EQ’s, crossovers or amplifiers.)
Connect stereo RCA cables from the head’s left and right front outputs to the left and right
inputs of the signal processor.
Connect stereo RCA cables from the left and right outputs, (and low, mid and high outputs
if applicable), of the signal processor to the left and right inputs of your amplifier(s) or
additional signal processor(s).
Turn the unit on, and adjust the input gain on the signal processor to match the output of
the head unit (1/2, or at center position, is about 1 V). Be careful not to overdrive the input
of your amplifier(s) or signal processor(s).
Adjust each of the crossover or equalizer controls to achieve the desired sound characteristics.
mounting
mounting and installation
ple730r
ple520p
Please take the time to install your
new Pyle Signal Processor
securely, according to this
diagram, using the hardware
provided.
This Half-DIN size unit can also
be installed in the dash adjacent
to the head unit, provided that
there is a slot available.
12V
RE

9
sub rear front line aux
OUTPUT INPUT
LRLRLRLRLR
electrical connections
owner’s manual
rear
to remote
turn-on
+12V head unit
ORANGE WIRE
12V battery
RED WIRE
Fuse 1A
BLACK WIRE
Fuse 0.5A
ple730r
ple520p

10
sub rear front line aux
OUTPUT INPUT
LRLRLRLRLR
system wiring
ple730r
ple520p
basic system application using
front,rear, and subwoofer amps
left and right
line outputs
from head unit
left and right
line inputs
FRONT CHANNEL
power amplifier
REAR CHANNEL
power amplifier
SUB CHANNEL
power amplifier
L
R
SUB CHANNEL
speakers
–
+
–
+
REAR CHANNEL
speakers
L
R
–
+
–
+
FRONT CHANNEL
speakers
L
R
–
+
–
+

11
sub rear front line aux
OUTPUT INPUT
LRLRLRLRLR
system wiring
owner’s manual
basic system application using
a4 channel amp and subwoofer amp
left and right
line outputs
from head unit
left and right
line inputs
4 CHANNEL
power amplifier
SUB CHANNEL
power amplifier
L/R FRONT
speakers
L/R REAR
speakers
ple730r
ple520p
L
R
SUB CHANNEL
speakers
–
+
–
+
–
+–
+
–
+
–
+

12
precautions
ple730r
ple520p
troubleshooting
• Never drive with the volume raised so high
you cannot hear what is occuring in traffic
around you.
• Be aware that repeated exposure to excessive
volume levels can permanently damage your
hearing!
• Keep all electronics away from moisture, dust,
extreme heat or extreme vibrations.
• Pyle Audio products are capable of sound
pressure levels in excess of 150 dB. Continuous
exposure to sound pressure levels over 100 dB
may cause permanent loss of hearing. Use
common sense and PRACTICE SAFE SOUND.
If you experience...
Signal Processor does not turn on. Check that:
• Remote Turn-On wire has 12V.
• 12V wire has 12V.
• Ground wire is properly connected.
Level of sound is low. Check that:
• Wiring is not loose or cables misconnected/disconnected.
• RCA cables are not faulty.
Background noise is too high. Check that:
• Wiring is not loose or cables misconnected/disconnected.
• RCA cables are not faulty.

13
notes
owner’s manual

All Pyle products are carefully constructed and thoroughly tested
before shipment. Products purchased in the USA are warranted
to be free of defects in material and workmanship for two (2)
years from the date of purchase. This warranty is limited to the
original retail purchaser.
Should the product fail due to factory defects in material or
workmanship, your unit will be repaired or replaced at the sole
discretion of Pyle.
To obtain warranty service you must first call our Consumer
Return Hotline number at [phone] to obtain a Return
Authorization number. This R.A.# must appear on the outside
of your package and on all paperwork relating to your return.
When returning a product to us for warranty service it must
be carefully packed and shipped prepaid to:
limited warranty policy
R.A.#
Pyle Service Center
1600 63rd Street
Brooklyn, NY 11204
You must also include the following items:
• A copy of your sales receipt or other proof of purchase
• A brief letter indicating the problem you are experiencing
• include in your letter your return address, daytime phone
number, and R.A. number
• also include a check or money order for $12.00 for return
shipping, handling, and insurance, or provide your Visa/MC
number with expiration date.
Our obligation under this warranty is limited to the
repair or replacement of the defective unit when it is
returned to us prepaid. This warranty will be considered
void if the unit was tampered with, improperly serviced,
or subject to misuse, neglect, or accidental damage.
