Pyle Nutrichef PKSTIND48 User manual

by
by
PKSTIND48
Dual Induction Cooktop
Double Countertop Burner with Digital Display

www.NutriChefKitchen.com www.NutriChefKitchen.com
2 3
PRODUCT CONFIGURATION
CONTROL PANEL:
1. SAFETY CAUTIONS:
WARNING:
SWITCH OFF THE INDUCTION COOKER IN CASE OF ANY CRACK ON
THE COOK-TOP PANEL
1. Do not place the unit in any place that is near gas or hot environment
in order to avoid damages or malfunction.
2. To reduce the risk and damage, this plug should be fit into and
individual outlet. The rated electrical current is not less than 15A.
3. Place the unit on a level surface, the distance between the unit and
background surrounding must be not less than 10cm.
4. Do not immerse the appliance and electric cord in water liquid, or
allow liquid to go into the cabinet and get short/contact inner
electrical parts, the power cord must be plugged out before cleaning.
5. Do not cover gas vent with anything during cooking, otherwise it will
cause danger.
6. To avoid danger, please uncap the cover before heating tinned food.
7. If it is still not working after inspection, please immediately contact
our service center and do not open the unit to avoid any danger.
8. Do not operate any appliance with a damaged cord or plug, or after
appliance malfunctions or has been damaged in any manner
9. It would get dangerous when the metal gets heated directly or
indirectly.
10. Do not place any metal on the plate and also to the nonmetal pad
within 10cm.
11. Do not cook with an empty pot to avoid malfunction or danger.
12. Always clean the unit and avoid any dirt that may go into the fan to
effect normal working.
13. Do not touch the plate while the unit is working to avoid getting
burned.
Black Crystal Plate
Heating Area
Control Board
Lock Button Timer Button Lock Button Timer Button
Menu Choice Menu Choice

www.NutriChefKitchen.com www.NutriChefKitchen.com
4 5
14. To avoid injuries such as scalding, do not let children operate the
appliance alone.
15. If you have a pacemaker, you should consult with your doctor
before you take advantage of any induction cooking device
16. Do not place on or near a hot gas , electric burner, or in a heated
oven
17. To avoid danger, do not place paper, aluminium foil, cloth or other
unsuitable articles onto the induction cooker heating plate for
indirect heating.
18. Do not place the unit on the cloth or carpet to avoid blocking the
rear exhaust vent.
19. Please kindly avoid hitting the plate of the unit, in case of getting
cracked, should turn off the unit and plug out immediately and
then contact with service points of our company.
20. Do not touch the control panel with any sharp objects.
21. Do not place any metal on the unit while operating.
2. PRODUCT OPERATING INSTRUCTIONS
1. Place suitable cooking utensils in the center of the top plate.
2. Insert the plug in to AC 120V, 60Hz Socket, Press ON/OFF to switch
on, after pressing Function, The default “Fry” will auto select.
Different cooking functions, setting and adjustments.
3. To switch off, Press ON/OFF again, then plug out to shut off power.
2.1 COOKING MODE:
1. Right Side/Left Size:
1. Manual Control Function: Fry, Steam, Water, Fry Function:
• Press the [Function] key until the indicator of [Fry] remain light up,
display will show [900] representing that the default power is 900W.
It can be adjusted by pressing the [+] or [-] key to set the desired
Power level. • There are 8 Power levels in total
(140-210-260-300-350-390-430-460°F, Default 300°F)
• To Cancel this mode, press to Function mode or [On/Off] key to stop
the operation.
• Time: 4 Hours Timer
Steam Function:
• Press the [Function] key until the indicator of [Steam] remain light
up, display will show[1300] representing that the default power is
1300W. It can be adjusted by pressing the [+] or [-] key to set the
desired Power level.
• There are 8 Power levels in total
(140-210-260-300-350-390-430-460°F, Default 390°F)
• To Cancel this mode,press to Function mode or [On/Off] key to stop
the operation.
• Time:23:59 Hou rs Preset
Water Function:
• Press the [Function] key until the indicator of [Water] remain light up,
display will show[1800] representing that the default power is 1800W.
It can be adjusted by pressing the [+] or [-] key to set the desired Power
level.
• There are 8 Power levels in total
(140-210-260-300-350-390-430-460°F, Default 460°F)
• To Cancel this mode,press to Function mode or [On/Off] key to stop
the operation.
• Time:4 Hours Timer

www.NutriChefKitchen.com www.NutriChefKitchen.com
6 7
2. Automatic Control Function: Warm
Warm Function:
• Press the [Function] key directly until the indicator of [Warm] remain
lit up, display will show [140] representing that the default
Temperature is 140°F.
• To Cancel this mode, press Function Mode or [On/Off] key to stop the
operation.
• Time: 23:59 Hours Preset
2.2 TIMER OR PRESET FUNCTION: (4 HOURS TIMER & 23:59 PRESET)
1. User can set the cooking time when cooking mode is selected.
2. Press the [Timer] or [Preset] key until the indicator of [Time] or
[Preset] lights up.
3. Display will show the default time [0], user can press [+] or [-] key to
set the desired time.
4. Press [+] or [-] key once to increase or decrease a minute.
5. Press and hold for 3 second to access quick adjustment, the time can
be adjusted from 0 minutes to 4 hours/23:59 Hours.
6. After setting, user can press Cooking key once to confirm or wait
until the display stop.
7. To Cancel this mode, press Cooking Key or [Timer] Key or [On/Off]
key to stop the operation.
2.3 LOCK FUNCTION:
• Press the [Lock] key and hold for 3 seconds the display will show
[Loc] indicates that the appliance is locked.
• To Cancel this mode, press [Lock] key and hold for 3 seconds or
[On/Off] key to stop the operation.
3. SELECTION OF COOKWARE:
1. Material required: • Steel, cast iron, enameled iron, stainless steel, flat-bottom pans/pots
with diameter from 12 to 26cm.
• It is suggested to use the required pot. Do not attempt to use other
pot instead (especially pressure sensors vessels).
2. Please kindly check according to the below requirements if its
necessary to use the vessel.
• Pan/Pot must be suitable for induction cooker.• Pan/pot should be tried out if it's bought by self to see if compatible with the induction cooker
• Pan/Pot should be at and comes with cover and gas vent.4. MAINTENANCE AND DAILY CARE
1. Remove the power plug prior to clean the unit. Do not clean it until
the surface cools down.
2. Glass Plate, Panel and Shell:
• Soft Cloth for slight stain.
• For greasy, dirt, blot by using a clean damp cloth with neutral
detergent.
3. While the radiator-fan is working, dust and dirt would remain on the
gas vent, please clean it by brush or cotton stick regularly.
4. Do not wash the unit by water directly to avoid damage.
5. To protect the induction cooker, be sure to have a good contact
between plug and socket before use.
6. Do not pull out the power cord directly during operation. To extend
the appliance’s life, press the “On/Off” button first to power off then
pull out the power cord.

www.NutriChefKitchen.com www.NutriChefKitchen.com
8 9
7. In order to make operating time longer, the fan will still work for
cooling the plate, it is better to plug out after the fan stops working.
8. If the appliance is not be used for a long period of time, pull out the
power plug.
9. Some models have structural design against cockroaches, if needed,
you can put something like mothball to expel the cockroaches.
5. TROUBLESHOOTING AND TREATMENT
During operations, if any errors occurred, please check the following
table before calling for service. Below are common errors and solutions.
If the above solutions can’t fix the problem, unplug the appliance
immediately, contact service center for inspection and repairing, note
the error code and report it to service center ltd. To avoid any danger and
damage to the appliance, do not disassemble or repair it by yourself.
PROBLEM CHECK POINTS SOLUTION
After connecting
the power and
pressing the
“Power” key, the
appliance has no
response
Power outage?
Is the plug connected
firmly?
Is the fuse broken down?
Use when electricity
resumes
Check the root causes
carefully. If the problem
can’t be fixed,please
contact service center for
checking and repairing.
Induction Cooker
send out “Beep”
Sound
Incompatible cookware or
no cookware is used?
Is the cookware not
considerable placed from
the center of the heating zone?
Is the cookware bigger
than 12cm?
Replace compatible
cookware for the
induction cooker
Replace the cookware at
the center of the defined
heating zone
Change the diameter
of cookware bigger
than 12
No operation during
the heating being
in use
Is the cookware empty or the
temperature too high?
Is the air intake/exhaust vent
clogged or dirt has
accumulated
Is the cooker working over
2 hours without any external
instruction?
Please check whether
the appliance is being
misused
Remove the stuff clogging
the air intake/exhaust vent.
Operate the appliance
again after cooling down.
Reset cooking modes
or use timer function
PHENOMENON CHECK POINTS SOLUTION
No Cookware or
Incompatible cookware used
Low-Voltage
High-Voltage
If error signal E0, E3,
E5 shows, please
check whether the
cookware is not
suitable or switch on
the appliance again
after it cooled down
naturally.
If error signal E1, E2,
E4, E6, E7, occurs
please contact service
center for checking
and repairing
Top Plate Overheat
Top Plate Sensor Open Circuit
IGBT Overheat
Top Plate Sensor Short Circuit
Internal Circuit Error
Error Codes Occur E0
Error Codes Occur E1
Error Codes Occur E2
Error Codes Occur E3
Error Codes Occur E4
Error Codes Occur E5
Error Codes Occur E6
Error Codes Occur E7
