Pyle PKBRD37RD User manual
Digital Musical Karaoke Keyboard
Portable Electronic Piano Keyboard
with Built-in Rechargeable Battery
and Wired Microphone, Red (37 Keys)
PKBRD37RD
www.PyleUSA.com
2
Please read this manual thoroughly prior to using the product in order
to benet fully from all features.
IMPORTANT SAFETY PRECAUTIONS
1. Please only use the power adaptor included in the product.
This unit may use a mobile phone adaptor with specication:
INPUT: 100-240V- 50/60Hz
OUTPUT:DC 5V, electricity should be 1000mA or above. The adaptor to be
used with this product should be regularly examined for potential hazard,
such as damage to the cable or cord, plug, enclosure of other parts.
Do not use the damaged products to avoid accidents.
2. The WHITE power ON/OFF button is also the charging indicator. The button
will light up in red color when the piano is charging. After the Li-ion battery is
fully charged, the red light will turn o. When the piano powered is ON, the
button will light up in blue.
3. Please charge the piano every two months when it is not in use, in order to
keep the performance and service life of the built-in Li-ion battery.
4. This product must be charged by adults.
5. The Li-ion battery is xed inside the toy, it is strictly forbidden to be removed
or put into the re or near the high-temperature environment as it will cause
explosion danger!
6. This product includes a USB cable. If you will use dierent USB cables, please
carefully check if there’s any damage to it. The mobile phone original adaptor
is recommended to use with this product. An inferior USB cable and adaptor
will bring noise and another potential hazard when you play this keyboard.
7. This product is not suitable for children under 3 years old.
8. Do not play the music aloud for a long time. Loud music may damage hearing.
9. Do not place this product in below locations; otherwise it may cause re or
electric shock.
• Humid or dusty place
• Kitchen or place that have lamp black
• Near air conditioner, electric blanket, exposed under the sunlight or any
other place would warm this keyboard up.
10. Do not put this product near TV, Radio or beside other electronic product
which may cause audio or video receiving interference.
11. Unplug the adaptor before cleaning this product or when you are not using
it for a long time.
www.PyleUSA.com 3
Illustration
1. Power on/o/Charging Indicator
2. Volume control knob
3. OKON
4. Tone
5. Rhythm
6. Demo all/ Demo select
POWER SUPPLY
DC Adaptor: Use DC adaptor with USB connector with voltage output DC 5V,
electricity should be 1000mA or above. It may cause malfunction if you use
another voltage adaptor.
TURN ON FOR PLAYING
Press the power ON/OFF button, blue light will light up in the button.
Play any white or black keys, if there’s a piano rings up, the keyboard works.
HOW TO PLAY
1. Volume Control: Turn this knob to raise or lower the master volume.
2. Tone: There’re 4 tones as below. The piano setting tone is piano. Press TONE
one time to play piano tone. Press TONE again to play the next tone: vibraphone.
Press TONE the third time to play the next tone and so on.
1. PIANO
2. VIBRAPHONE
3. SAXOPHONE
4. MUSIC BOX
1257 3
8
9
10 11
6
4
7. Stop
8. Audio input jack
9. Microphone jack
10. Headphone jack
11. DC 5V jack
www.PyleUSA.com
4
3. Rhythm: This Keyboard provides 4 rhythms. Press RHYTHM once to initiate
the Disco rhythm. Press RHYTHM again to initiate the next rhythm: blues.
1. DISCO
2. BLUES
3. MARCH
4. WALTZ
4. ALL/SEL: Press this button one time, it will enter the demo all mode and play
the demos in sequence. Press this button twice, you can select the demo.
There’re totally 10 demos list as below:
5. OKON (One key for one note): Under this mode, you can press any black or
white keys to play background music from the demos. Press ALL/SEL to select
the demo rst and then press OKON to play. Listen to the demo and get
familiar with the rhythm and song, then practice.
6. Stop: Under the RHYTHM, ALL/SEL mode, press STOP to exit.
7. Belt: The belt can be installed on the screw at the bottom of the piano to
carry and play the piano.
Operation notice:
1. This product should not be placed near the electric appliance, such as radio,
television, tuner to avoid interference when receiving audio or video signals.
2. Use the nearest power socket in order to unplug the adaptor immediately
when malfunctioning.
3. Unplug the adaptor when it is not in use.
4. The unit contains voltage carrying parts. Therefore DO NOT open the housing.
No. Name of Demo
1 Say Hello
2 Happy Birthday
3 Row, Row, Row Your Boat
4 Turkey March
5 Little Star
6 Scherzo
7 Old MacDonald Had a Farm
8 Les Preniers Sourires de Vanessa
9 Minuet
10 The Happy Farmer
www.PyleUSA.com 5
Features:
• 2-in-1 Karaoke Keyboard: Play & Sing-Along!
• Includes Wired Handheld Microphone
• Compact & Portable Musical Piano
• Simple Electronic Plug-in Operation
• Portable Piano, Built-in Rechargeable Battery
• Built-in Full Range Stereo Speaker
• Connect & Stream Audio from External Devices
• Multiple Preset Selectable Keyboard Sound, Tone & Rhythm Styles
• OKON Mode: Easy to Play the Preset Demo Song by Any Key
• Adjustable Volume Control
• Headphone Jack
• Light and Compact to Hang on the Shoulder Like a Guitar
• Perfect for Home Theater Living Room Performances
• Fun for Kids of All Ages: Children & Adults
What’s in the Box:
• Portable Piano Keyboard
• Wired Microphone (stored in the polyfoam inside the gift box)
• USB Charger Power Cable
• Audio Cable
• Belt
• UL Adapter
Technical Specs:
• (37) Keyboard Keys
• (4) Preset Selectable Tones
(• 4) Preset Selectable Audio Rhythms
• Belt: Black PP Webbing
• Audio Interface: Aux (3.5mm) Input Jack / Mic Input
• Max Sound Level: Up to 86 dB
• USB/Power Cable Length: 3.28’ ft.
• Construction Material: Engineered ABS
• Built-in Rechargeable Battery: 3.7V Li-ion
• Power Supply: 110/240V (DC 5V)
• Power Adapter: DC-5V/1000mA
• Piano Dimensions (L x W x H): 22.04’’ x 4.37’’ x 1.57’’ -inches
