Pyle PDKRMX2M User manual

CompactKaraokeAudioMixer
PDKRMX2M
Built-in Mixer with Mic Level, Music Level,
and Echo Controls, with 3.5mmAudio Cord
and Two RCAAudio Cables
Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]

RECEIVER PARTS DESCRIPTION
Front
Rear
1. Power Indicator: The indicator will be illuminated when the receiver is powered ON.
2. Power Switch: Press to switch the receiver power to ON and OFF.
3. ECHO: Rotate the echo knob to your desired level.
4. MUSIC: Rotate to adjust volume of input music.
5. MIC1/MIC2: Rotate to adjust volume of wired dynamic MIC 1/2.
6. MIC 1/2: Insert the 6.3mm MIC plug of wired dynamic MIC (not provided) into MIC
1/2 jack.
7. Audio output jack (RCA type): Connect this set of RCA Jack to Active Speakers,
Hi Fi system, etc. to output the nal mix of music and microphone.
8. AF OUT: Connect this jack to MIC IN of your amplier to output the nal mix of
music and microphone.
9. Audio Input Jack (RCA type): Connect this set of RCA jacks to an audio source
with RCA output such as DVD, Streamer etc. to bring in the music.
10. Aux In (3.5mm stereo type): Connect this jack to an audio source with phone
out such as computer, iPad, mobile phone etc. to bring in the music.
11. DC IN jack: Connect DC jack of supplied AC/DC adapter to this jack.
OPERATION
1. Connect the mixer to Amplier (or Speaker) and Audio source
(Refer to CONNECTION).
2. Connect wired dynamic MIC (need to buy separately) into MIC 1/MIC 2 Jacks on
the front panel of the mixer.
3. Connect DC plug of supplied AC/DC adapter to DC IN jack on rear panel of the mixer.
Connect AC plug of AC/DC adapter to mains power socket.
4. Turn the mixer power on. Power indicator will be illuminated.
5. Turn on your Microphone, Amplier (or Speaker) and Audio source.
6. Adjust Echo, MIC volume and MUSIC volume to your desired level.
7. Now you are ready to sing!
CONNECTION
AUDIO INPUT
To bring in music, connect audio source to L/R RCA INPUT jack on the back of receiver
with the provided RCA cables (white and red) if your audio source has RCA output,
such as DVD, Streamer etc. or connect audio source to AUX IN jack on the back of
receiver with the provided 3.5mm/3.5mm cable if your audio source has 3.5mm
phone out, such as iPad, Smartphones, Tablets, Laptops, Computers, etc.
www.PyleUSA.com2 3www.PyleUSA.com
9 10 11
78
AUX IN
AF OUT
23 4 5 5 6
16
AUX IN
AF OUT
DVD, Streamer etc. RCA Output
L
R
Computers etc.
OR
Phone Out
L
R
RCA input
Active Speaker
OR
MIC IN
Passive Speaker
Audio
Input
Audio
Output

AUDIO OUTPUT
Both the ¼ inch AF OUT jack and the left/right RCA output jacks on the back of the
receiver output the nal mix of music and microphone. To output the sound you
need to have an additional audio device (speaker or amplier) .
Connect the left/right RCA output jacks on back of receiver to RCA input jacks on
active speaker with supplied RCA cables. Or connect the ¼ inch AF OUT jack on the
back of receiver to MIC input jack on amplier with supplied ¼ inch cable.
FEATURES:
• Level and Echo Control
• Includes Music Volume Control
• Two Individual MIC Volume Controls
• Two Wired MIC Inputs
• Stereo RCA Audio Input
• Stereo 3.5 AUX Input
• Stereo RCA Audio Output and 6.35 Mono Output
• With Cable for TV, PC, Smartphone, and Speaker
• Ideal for Karaoke and house parties
• Simple Menu-Free Operations
• Integrates with TV or Home Theater
• RCA Coaxial Audio Input Jacks for Connecting CD/DVD Players
• Designed to Provide Multi-Source Mixing for Solo Singers or Duets
WHAT’S IN THE BOX:
• Mixer
• Power Adapter
• (2) Audio (2RCA) Cable
• Audio (3.5mm) Cable
• Audio (6.35mm) Cable
TECHNICAL SPECS:
• Frequency Response: 80~18000Hz at ±3dB
• S/N ratio: > 95dB
• T.H.D: <0.5%
• LINE Input Sensitivity: 380mV/-8.5dB
• MIC Input Sensitivity: 5mV/-46dB
• LINE Input Impedance: 20KΩ
• MIC Input Impedance: 600Ω
• Power Supply: DC12V/200mA
• Construction Material: Engineered ABS
• Product Dimensions (L x W x H): 6.7" x 4.4" x 1.3" -inches
