Pyle PMX44T User manual
PMX44T
Professional6-ChannelCompactAudioMixer
DC 5V Power Supply USB Interface Mixer
with Wireless BT and DSP Sound Effects
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]
www.PyleUSA.com
2
www.PyleUSA.com
3
For the best results and the satisfaction from your new unit, please read
this manual thoroughly, and retain it for future reference.
OPERATION AND MAINTENANCE
· Do not use the device in the vicinity of a TV, radio, stereo equipment, mobile
phone, or other electric devices. Otherwise, the device, TV, or radio may
generate noise.
· In order to prevent the possibility of panel disguration, unstable operation, or
damage to the internal components. Do not expose the device to excessive dust
or vibration, or extreme cold or heat (such as in direct sunlight, near a heater, or
in a car during the day).
· Do not place vinyl, plastic or rubber objects on the device, since this might
discolor the panel.
· When cleaning the device, use a dry and soft cloth. Do not use paint thinners,
solvents, cleaning uids, or chemical impregnated wiping cloths.
· Condensation can occur in the device due to rapid, drastic changes in ambient
temperature when the device is moved from one location to another, or air
conditioner is turned on or o. For example, using the device while condensation
is present can cause damage. If there is reason to believe that condensation
might have occurred, leave the device for several hours without turning on the
power until the condensation has completely dried out.
· Avoid setting all controls to their maximum. Depending on the condition of the
connected devices, doing so may cause feedback and may damage the speakers.
· When turning on the power in your audio system, always turn on the power
amplier LAST, to avoid speaker damage. When turning the power o, the power
amplier should be turned o FIRST for the same reason.
PRECAUTIONS WHEN USING THE USB 2.0 AND 5V DC TERMINALS
When connecting the USB2.0 connector to computer, please must abide by
following points. If not, it may cause computer crash, breakdown, or losing
data. If the computer or mixer crash, please restart the application software
or computer operating system, or disconnect the mixer, then power on again.
· Use an USB cable. USB 3.0 cable cannot be used.
· Before connecting the computer to the USB 2.0 terminal, exit from any power-
saving mode of the computer (such as suspend, sleep, standby).
FUNCTION AND INTRODUCTION
1. [MIC/LINE] Mono input, connect the microphone, musical instrument or audio
device (CD player and so on) to the device. The sockets are supporting both
XLR and UNBALANCED 1/4"PLUG.
2. [+48V PHANTOM] Button/LED, when the button is turned on, the LED light is
on, provide DC+48V phantom power to XLR plug on MIC mono input. Please
turn on this button when using the condenser microphone which is powered
by a phantom power.
3. [GAIN] Controller, determines the basic volume of each channel, adjust them
for the maximum volume performance, when the volume gets too loud, the
[PEAK] LED indicator light will keep ashing.
4. [HIGH] Treble tone controller, adjust the controller to enhance or attenuate
for 15dB at 12 KHz .
5. [LOW] Bass tone controller, adjust the controller to enhance or attenuate for
15dB at 80Hz.
6. [FX] Controller, adjust the signal level from the channel to the reverberation
line. Please note, the single level will vary with the dierent setting of the
channel attenuator. If using the stereo channel, will mix the signals from L and
R channels, then, send it to reverberation line.
7. [LEVEL] Controller, adjust to balance the volume of each channels.
8. Stereo channel input, if only connect to L/(MONO) socket, the mixer will send
out the same mono signal to L and R outputs.
4
5
6
24
8 8 9
10
14
15
17
1
2
3
20
25 21
77 23
18 19
16
25
4
5
6
24
8 8 9
10
14
15
17
1
2
3
20
21
77 23
22 19
16
UNBALANCED 1/4 " PLUG
www.PyleUSA.com
4
www.PyleUSA.com
5
9. [MAIN] Output, connect the active speaker or amplier.
10. [POWER] Power control switch.
11. Converting switch for “stereo channel” and “USB signal”.
12. [TAPE/CD ] TAPE/CD signal input.
13. [UNBAL5/6] Stereo input.
14. [PHONES] Connect an 3.5mm earphone, the socket is supporting stereo
phone plug.
15. [DSP Select] Press UP or DOWN button to select from 16 DSP.
16. [PEAK] LED indicator light, when the volume of input signal or volume after
adjusting equalizer is too High, the LED indicator light will keep ashing,
please rotate the [GAIN] CONTROLLER counterclockwise to turn down the
volume.
17. [Output Level Indicator] This is a stereo signal level indicator congured
with green LED lights (SIG) at the bottom and red LED lights (Peak)at the top
for both the left channel side and the right channel side. Flashing green LED
lights indicate normal input signals. When the red LED lights are ashing, the
MAIN output signal level may need to be lowered by adjusting the monitor
output level control knob.
18. [PARAMETER] Control the parameter of the sound eect.
19. [FX LEVEL] Eects return to level controller, adjust the volume of eect.
20. [PHONES LEVEL] Earphone controller, adjust the volume of earphone.
21. [MAIN LEVEL] Fader, adjust the overall volume from [MAIN] output signal.
22. [DELAY] Controller, adjust the depth of the reverberation.
23. [USB LEVEL] Controller, adjust the volume of USB channel.
24. [PAN Control] The PAN control determines the position of the channel signal
within the stereo image. When working with subgroups,you can use the PAN
control to assign the signal to just one output, which gives you additional
exibility in recording situations.
25. [CHANNEL FADER] Adjusts the level of the channal signal. Use these faders
to adjust the balance between the various channels.
MP3 OPERATING INSTRUCTIONS
1. WIRELESS BT CONNECTION
a. Press the "MODE " button in order to select the Wireless BT mode, after the
success of the selection, the Wireless BT icon on display is ashing, and
display BT.
b. Open the Wireless BT for pairing, after the success of the pairing, there will
be a sound prompt.
2. BUTTON FUNCTION
a. " /REC" button, press rst time to pause the playing song, press again to
continue playing.
b. " " button, short press to play the previous song, long press to reduce
the input volume.
c. " " button, short press to play the next song, long press to increase the
input volume.
d. [MODE] Selecting button, switching the functional model, select USB, REC,
BT in order.
3. USB RECORDING OPERATION
a. Press the "MODE" key to select the REC state.
b. Press the " /REC" button to start recording, the LED screen shows the
recording time, Press the " /REC" button again to pause the recording.
c. Press the "MODE" key back out the recording.
4. COMPUTER SOUND CARD
When connect the computer data cable, it will enter the PC playing states
automatically (The computer will install the driver automatically at the rst
connection, need to wait until the installation nish, to play or record)
USB FOR DATA TRANSFER, RECORD AND POWER SUPPLY
USB FOR POWER SUPPLY ONLY
Connected with PC USB port,
Power bank or power socket
to supply power to mixer.
It must meet the following
requirements:
Output voltage: 4. 8V to 5. 2V
Output current: 1A or even more
www.PyleUSA.com
6
www.PyleUSA.com
7
Features:
· Six-Channel Audio Mixer with Built-in USB Interface
· Combines Traditional Sound Card and Mixer Function
· Built-in Wireless BT for Music Streaming
· Built-in MP3 Player with LED Display
· Built-in DSP Sound Eects Processor
· Connects USB to PC to Play & Record Music
· Connects USB to PC or Power Bank for Power Supply
· Convenience for Mobile Audio Connection & Outdoor Guitar while Playing
& Singing
· Exquisite Plastic Chassis
· Mic/Stereo/MP3/USB Sound Card/Wireless BT Input Channels
· Main/Phones Output Channels
· Ultra-Low Noise Design with High Headroom
· Clipping LED Indicators for Left and Right Channel
· Smooth Rotary-Style Faders for Mic/USB/Line/Master Controls
· 1 XLR / 1/4'' Jack Combo Mic Input
· 2 RCA Stereo Inputs
What's in the Box:
· (1) Mixer Console
· (1) Power Adapter
Technical Specs:
· Power Output: +15V/0.3A -15V/0.2A +48V/0.05A
· Power Supply: 120-240V, (DC 5V/1A Power Adapter)
· Power Consumption: 5W
· Construction Material: Engineered ABS
· Phantom Power Voltage: +48V
· Frequency Response: 20Hz-20KHz
· Total Harmonic Distortion: <0.5%@+4dBu
· Product Dimension (L x W x H): 7.68'' x 7.09'' x 2.4'' -inches
