Pyle PBMSPG120CM User manual

Portable Bluetooth Boombox
User Manual
PBMSPG120CM

Instruction Manual
PBMSPG Series
Please read this manual carefully before operating and save it for future
reference.

1
Location of controls

2
Location of controls
1. POWER SWITCH
2. DC IN JACK
3. USB PORT
4. AUX IN JACK
5. BATTERY INDICATOR
6. BLUETOOTH INDICATOR
7. GUITAR INPUT JACK
8. MICROPHONE INPUT JACK
9. MODE BUTTON
10. EQ/FD (BASS / TREBLE CONTROL / FOLDER)
11. LIGHT BUTTON
12. / -
13. / FM SCAN
14. / +
15. VOLUME LEVEL CONTROL
16. ECHO LEVEL CONTROL
17. MICROPHONE INPUT LEVEL CONTROL
18. BATTERY COMPARTMENT
19. NFC AREA

3
Getting started
Charge the battery
Before using the speaker, you must charge the battery. When the battery is charging, the
BATTERY INDICATOR lights solidly. After the battery has fully charged, the light
switches off.
1. Connect the AC adaptor to the DC IN JACK of the speaker firmly, and plug it into a
wall outlet.
2. When the battery is fully charged, first disconnect the AC adaptor from the speaker,
then from the wall outlet.
Power source
1. Press the POWER SWITCH to turn on the speaker.
2. Press the POWER SWITCH again to turn off the speaker, and pull the AC adaptor
out of the wall outlet if you want to switch off completely.
Bluetooth function
Pair the bluetooth device
Before using your speaker with a Bluetooth device for the first time, you must pair and
connect it to the Bluetooth device. Press the POWER SWITCH to turn on the speaker.
The display shows “HI”. Then press the MODE button to select the Bluetooth mode (F1).
The "BLUETOOTH INDICATOR starts to flash, and the speaker is now in pairing mode.
F1
Pair the speaker using NFC
1. With Near Field Communication (NFC), you can easily pair and connect the speaker
to Android device with NFC.
2. If the Android device supports NFC, activate its NFC feature, and touch the NFC
area of the speaker with the NFC area of your Android device (F2). The speaker
pairs and connects to the Android device automatically. For details on NFC, see the
user guide of the Android device.
F2
3. For other Bluetooth device, pair the speaker manually.

4
Pair the speaker manually
1. Verify that the Bluetooth function of Bluetooth device is enabled.
2. Choose the Bluetooth menu in your Bluetooth device, and from the found devices,
select the “Pyle Audio”. If you are prompted to enter the PIN code, please enter
"0000" (four zeros).
3. For more information, see the user manual of Bluetooth device.
4. After a successful pairing, play the music from the Bluetooth device.
Note:
1. Only one Bluetooth device can be connected to the speaker. If the speaker is
already connected to another Bluetooth device, the speaker will not appear in the
Bluetooth menu of your Bluetooth device.
2. When you turn off/on the speaker or the Bluetooth device, the speaker will connect
to the last Bluetooth device it was used with automatically within 10 seconds.
Otherwise, you need to connect it manually on the Bluetooth menu in your Bluetooth
device.
3. Depending on the device manufacturer, some Bluetooth devices need to perform the
pairing again.
Aux in function
1. When the speaker is in Bluetooth mode, press the MODE button to select the Aux in
mode (F3).
F3
2. Connect an audio cable (not included) to the AUX IN JACK of the speaker and to
the audio output socket on the external audio devices such as MP3 player, discman,
etc.
3. Play from an external audio device.

5
Listening to FM radio
1. When the speaker is in Aux in mode, press the MODE button to select FM radio (F4)
F4
2. Press / FM SCAN button to search all the FM stations.
3. When it stops searching FM stations, all the FM stations have been found and
stored automatically.
4. Press / -or / + button to explore the found stations (F5).
F5
Playing audio via USB port
1. When the speaker is in FM radio mode, press the MODE button to select USB
mode (F6).
F6
2. Plug the USB device into USB Port, then it will play the music file automatically.
3. For interruption while the music is playing, press the / FM SCAN button once.
Playback is now paused. To re-start playback, press the / FM SCAN button
again. The music will start from the exact position where it was interrupted.
4. When / -or / + button is pressed once, it will return to the previous track or
advance to the next track.
5. During play mode, when / -or / + button is pressed and held, it will search the
track with audible high-speed backward or forward playback.
6. Press and hold EQ/FD button will advance to the next folder (F7).
F7

6
Connecting a microphone/guitar
Using a microphone or a guitar, you can mix its sound with a source sound.
CAUTION
DO NOT connect a bass guitar to the MICROPHONE / GUITAR INPUT JACK, as it may
damage the speaker.
1. Turn the MICROPHONE INPUT LEVEL CONTROL fully counterwise.
2. Connect a microphone or a guitar to the MICROPHONE / GUITAR INPUT JACK of
the speaker.
3. Select the Bluetooth, Aux in, FM radio or USB as the source.
4. Start playback of the sound source.
5. Turn the MICROPHONE INPUT LEVEL CONTROL to adjust the microphone
volume.
6. Turn the GUITAR OUTPUT LEVEL CONTROL of your guitar to adjust the guitar
volume.
Party Light
The party light effect pluse to music. Press LIGHT button on the unit, the colour of party
light effect changes as below:

7
AdAjust volume level and sound effect
To adjust the volume
Turn the VOLUME LEVEL CONTROL to adjust the volume of the speaker.
Control the echo
Turn the ECHO LEVEL CONTROL to adjust the echo effect.
Control the bass and treble effect
1. Press the EQ/FD button to select the bass effect, then press / + to increase bass
effect (F9).
F9
2. Press / -to decrease bass effect (F10).
F10
3. Press the EQ/FD button again to select the treble effect, then press / + to
increase treble effect (F11).
F11
4. Press / -to decrease treble effect (F12).
F12

8
MAX Power: 100 Watt
Sound System: (2) x 5.25'' Subwoofers, (2) x 2.5'' Speakers
Housing Construction Material: Engineered ABS
Pulsing LED Light Colors: Red, Blue, Green
Radio Station Memory Presets: 30
Maximum USB Flash Size Support: 32GB
Power: 120/240V
Dimensions (L x W x H): 19.8'' x 7.9'' x 8.3''
Weight: 12 lbs.
Specification
