Pyle PSTMP95 User manual

USER MANUAL
PSTMP95
DigitalTableTopSteam Press

CONTENTS
Features of the Elite.....................................................1
Safety Reminders......................................................2
Part Identification...................................................3-4
Steam Press Operation
reparation for use.....................................................5
Filling the water tank..................................................5
Turning on the power..................................................5
Selecting the temperature...........................................6
Steam Control Notes...................................................7
Pressing....................................................................8
Finishing Pressing.......................................................9
Cleaning..................................................................10
Suggestion for Success..............................................11
Use of the Pressing Cushion.......................................12
Techniques for Pressing.........................................13-14
Troubleshooting...................................................15-16
P

Digital Table Top Stream Press
50% Faster Than Traditional Ironing
Safe for Nylon, Silk Rayon, Wool, Cotton, Linen, and more
Non-Stick and Anti-Shine Ironing Surface Coating
Even Pressure Ensures Sharp, Long-Lasting Creases
'Steam Burst' Function Blasts Away Wrinkles
Advanced Digital Control Center
Variable Temperature Selection
Quickly Steam Press and Remove Wrinkles
Multiple Dry-Heat & Steam Settings for Different Fabrics
Easy-to-Use and Safe One-Hand Operation
Extra Gentle Against Fabrics Like Silk
(7) Times the Size of Regular Irons
Iron Surface Size: 22'' x 10''
Ready Indicator Lights
Auto Shut-Off Safety Feature
10 oz. Refillable Water Tank
Accessories Included: Spray Bottle, Pressing Cushion & Water Fill Cup
1350 Watt Power
Dimensions: 26.7 x 10.2 x 22.0 inches
Weight: 26.4 Lbs.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
1

ØTo protect against the risk of electric shock, do not immerse the
appliance in water.
ØDo not let the cord hang over the edge of counters.
ØDo not allow the cord to touch hot surfaces.
ØAlways allow the appliance to cool for at least thirty minutes before
storing.
ØAlways put the appliance in a secure place on a table or counter when
using.
ØDo not move the appliance without unplugging it first.
ØThe appliance has very hot surfaces - Do not allow unsupervised children
to use the appliance.
ØAlways disconnect the appliance from the outlet before filling with or
removing water. Be careful to avoid spilling water on the appliance when
filling.
ØUse distilled water in the appliance. Do not use perfumed or products
containing alcohol in the appliance.
ØAlways disconnect the appliance when not in use.
ØDo not use the appliance if the cord gets damaged. Return the appliance
or have the cord repaired by the manufacturer, his service agent or a
similarly qualified person.
ØDo not operate the appliance if it has been dropped or damaged. Do not
disassemble the appliance. Incorrect reassembly can cause a risk of
electric shock. Send it to an authorized service center for repair.
ØDo not operate another high wattage appliance on the same circuit.
ØThis appliance must be grounded. Do not alter the plug or attempt to
defeat this feature.
ØBe careful. Burns can occur from touching hot metal parts, hot water or
steam.
ØThis appliance is not intended for use by young children or infirm
persons unless they have been adequately supervised by a responsible
person to ensure that they can use the appliance safely.
ØYoung children should be supervised to ensure that they do not play with
the appliance.
THIS UNIT IS FOR HOUSEHOLD USE ONLY.
SAVE THESE INSTRUCTIONS
WARNING
Read all of the instructions and then save them for future reference.
SAFETY REMINDERS
2

PART IDENTIFICATION
1. The Pressing Handle raises and lowers the Pressing Plate. By lowering the
Pressing Handle until it reaches the lowest point possible you automatically
obtain maximum pressure.
2. The Locking Knob will lock together the Pressing Plate and Ironing Board. Turn
the Locking Knob to the locked position to carry or store the Steam Press.
3. The Red Steam Burst Button on the handle grip produces a burst of steam
when pressed.
4. The Pressing plate is the temperature controlled surface that heats and presses
the fabric.
5. The Ironing Board is the padded surface that holds the fabric during pressing.
6. The Power Light (Red) is illuminated when the unit is on.
7. The Ready Light (Green) goes off when the Press has reached the selected
temperature.
8. The Steam Ready Light (yellow) goes on when the unit is ready to produce
bursts of steam.
9. The [ POWER ] button to turn ON/OFF the appliance.
10. Press the [ SELECT ] button arrows to set the desired temperature for each
fabric. NOTE: Steam will only be available on the three highest settings.
11. The Water Tank slides forward and is filled through holes in the top. The Water
Level can be seen through the front of the tank. Slide the tank forward for a
better view.
12. The Ironing Board Cover is removable and washable for extended use.
3
132
4
12
11
5
678910

4
13. The Pressing Cushion is a fabric covered pad used for pressing gathered
or contoured areas such as sleeves, darts, and yokes.
14. A plastic water Spray Bottle is used for dampening fabric before pressing.
15. A Water Container is used for filling the Water Tank.
The following information is provided for service by a qualified electrician only:
Rated voltage: 120V~, 60Hz, 1350W
WARNING:
This appliance must be grounded. Use only the proper type outlet when
plugging in the appliance. Do not attempt to override the ground wire feature.
13 14 15

STEAM PRESS OPERATION
STEP1 - PREPARATION FOR USE
Set the appliance on a sturdy work surface. Unlock the Locking Knob.
STEP 2 - FILLING THE WATER TANK
BEFORE PLUGGING IN THE APPLIANCE, fill the water tank;
a. Always make sure the appliance is unplugged before filling the tank.
b. Fill the Water Tank with the Pressing Plate lifted to the raised (up) position.
Slide the Water Tank towards the front of the unit. It will not come
completely out so do not force it to do so. Using the Water Container,
slowly pour the distilled water into the Water Tank Fill Holes(C).
c. Be careful to avoid spilling water onto the Steam Press when filling.
d. Slide the Water Tank back into its recessed position.
STEP 3 - TURNING ON THE POWER
a. Make sure the Locking Knob (D) is in the open position allowing free
movement of the Pressing Plate before plugging in the appliance.
b. Lift the Pressing plate to the fully raised (up) position.
c. Plug the appliance into an electric outlet.
d. Press the [ POWER ] button and the Red Power light will shine.
D
5
C

STEP 4 SELECTING THE TEMPERATURE
Press the [ SELECT ] arrow buttons to choose the kind of fabric you wish to
press. Press to move selection to higher setting and press to move
selection to lower setting.
a. Examine the garment label if unsure and look up the type on the chart.
IMPORTANT NOTE: If you can not determine the type of fabric, begin with
the lowest setting and increase the temperature as desired until you obtain
the proper results.
b. When the Green Ready Light goes off, the Pressing Plate has reached the
temperature for the desired setting.
c. When changing the setting from a higher selection to a lower setting allow
several minutes for the Pressing Plate to cool sufficiently after making the
change.
IMPORTANT NOTE: You may find it more efficient to arrange your fabrics
from those requiring the lowest setting to those requiring the highest setting
and proceed accordingly. This will avoid any unnecessary delay or wait for the
Pressing Plate to cool.
FABRIC COTTON LINENWOOLRAYONSILKNYLON
100 C
212 F
130 C
266 F
140 C
284 F
160 C
320 F
200 C
392 F
210 C
410 F
STEAM NO NO NO YES YES YES
6

STEP 5 - STEAM CONTROL
IMPORTANT NOTE: Steam is produced only when the Yellow Steam Ready
light is on.
The Green Ready Light goes off when the unit has reached the desired
temperature. The Yellow Steam Ready Light will come on when the unit is
ready to produce steam.
IMPORTANT NOTE: If this is the first time you are using the Steam Press
or you have been storing it for some time, lift the Pressing plate into the
raised position and press the Steam Burst Button several times until the
steam begins to flow.
IMPORTANT NOTE: The Steam Burst function can only be used when the
Steam Ready Light is on AND the steam press is in a slightly opened position.
Do not use the Steam Burst function when the steam press is closed, or you
may damage the unit.
IMPORTANT NOTE: Do not press the Steam Burst Button for more than 5
seconds or water may drip on your garment.
7

STEP 6 - PRESSING
a. Lift the Pressing Handle (A). The Pressing Plate (B) moves to the up
position.
b. Carefully arrange the garment to be pressed onto the Ironing Board (C).
c. Grasp the handle of the Pressing Plate(A) and lower it onto the Ironing
Board (C), capturing the garment between the two halves of the Steam
Press. For light duty Pressing, simply lowering the handle and allowing the
Pressing Plate to rest on the Ironing Board will be sufficient. Return to the
open position. For heavier duty pressing, continue to grasp the handle
and press downward until the Pressing Plate is pushed to its lowest
position, then open the press.
d. If the temperature is set high enough you may give the fabric a burst of
steam by pressing the Steam Burst Button (D) to remove stubborn
wrinkles. Lower the pressing plate until it is about two inches from the
garment. Press the Steam Burst Button for about 3-5 seconds. After
releasing the Steam Burst Button you may fully lower the pressing plate.
NOTE: Do not press the Steam Burst Button when the pressure
plate is in its lowest (closed) position.
e. After a few seconds, lift the handle and raise the Pressing Plate back to the
raised position.
IMPORTANT NOTE: If you forget to raise the Pressing Plate or become
distracted, the machine will give a warning beep and automatically shut-off
heating after approximately 10 seconds. The steam press will be completely
shut-off after 15 minutes of no activity with the press in the open position.
8
A
B
D
C

STEP 7 - FINISHING PRESSING/STORING THE UNIT
a. Water may be left in the reservoir, because it will not drip out if the
machine is stored in an upright position. However, it is recommended that
if the machine will be stored for some time, that all the water in the unit
should be drained by pressing the Steam Burst Button until all of the water
is pumped out.
b. Press the [ POWER ] button, the Red Power Light will go out. Disconnect
the plug from the outlet. Leave appliance in open position.
c. Wait for the Steam Press to cool completely (approximately 30 minutes).
d. When cool, lower the Pressing Plate onto the Ironing Board pushing the
handle to its lowest position.
e. Turn the Locking Knob to the locked position. This should prevent the
Steam Press from opening while being moved or stored.
f. Loosely wrap the electric cord and place it in the opening at the front of the
base of the Ironing Board. You are now ready to store the unit.
9

STEP 8 - CLEANING (As needed)
a. Cleaning the Pressing Plate:
Place the Pressing Cushion in the center of the Ironing Board. Place a clean
towel over the Pressing Cushion and the Ironing Board. Set the Steam
Control and Temperature Control to their maximum setting. When the Ready
Light comes on, gently lower the Pressing Plate onto the Pressing Cushion.
With water in the reservoir tank, press the Steam Burst Control 6 to 7 times.
Be careful to avoid touching the hot metal surfaces or leaving your hand in
the bursts of steam.
b. Once the Pressing Plate has cooled down you can clean the surface with a
damp cloth. DO NOT use any abrasives on the Pressing Plate. This Pressing
Plate has a non-stick coating that will assist in cleaning.
C. The Ironing Board Cover is removable for normal washing. You can rinse
the Ironing Board Cover with mild detergent and warm water.
10

SUGGESTIONS FOR SUCCESS --
USING PRESS CLOTH:
Placing a press cloth ( a piece of clean fabric) between the fabric and the
Pressing Plate may be desirable, especially for more delicate fabrics.
OLDER STYLE BUTTONS AND ZIPPERS:
While most modern buttons and zippers require no special attention, some
older types may be heat sensitive. Take care with items that could melt.
Lower the heat or steam settings, place the items FACE DOWN on the
ironing board, and cover the fabric with a press cloth BEFORE pressing. This
will help protect delicate accessories and fasteners.
SPRAY BOTTLE METHOD:
Using a Spray Bottle, lightly spray the garment before placing it on the
Ironing Board. This helps to distribute an even, fine mist over the fabric,
preparing it to be pressed, and removing all wrinkles.
DAMP CLOTH METHOD:
For the most stubborn or heavy gauge fabrics, place a damp cloth over the
area to be pressed. Press the garment normally for a few seconds, then raise
the Pressing Plate and allow the steam to escape. Repeat the procedure until
the fabric is dry.
11

USE OF THE PRESSING CUSHION --
Some garments have been constructed with details, such as darts,
curved Seams and shoulder pads, which are not intended to be pressed
flat. A Pressing Cushion is supplied with your Steam Press for use with
Theseareas.
a. Use the cushion whenever pressing areas where no creases are
desired or to shape tailored garments.
b. Place the area to be pressed onto the Ironing Board.
c. Place the Pressing Cushion under the dart, seam etc.
d. Make sure the area to be pressed is raised and lower the Pressing Plate.
The raised area is the only area the plate should contact.
IMPORTANT NOTE: Do not attempt to lower the Pressing Plate to its lowest
position or lock the Pressing Plate against the Ironing Board with the Pressing
Cushioninplace. YouMAY DAMAGE the Steam Press by doing so.
E.RaisethePressingPlateafterafewseconds.
12

TECHNIQUES FOR PRESSING --
LARGE PIECES OF FABRIC:
To press large pieces of fabric, place the entire piece in the storage area
behind the Ironing Board. The area you want to press first is on the top of
the pile.
Pull the fabric towards you, over the Ironing Board and lower the Pressing
Plate, pressing each section as you move the fabric forward. Allowing the
pressed fabric to drape in front of the Pressing Plate will Preserve the
Pressing and give you a complete job free of wrinkles.
SHIRTS AND BLOUSES:
a. Place the shoulder yoke on the Ironing Board first, face down and press.
b. Place the sleeves on the Ironing Board, next, with the fold parallel
to the long seam and press.
c. Place the cuffs on the end of the Ironing Board and press.
d. Place the body of the shirt into the storage area between the Pressing
Plate and Ironing Board, away from you. Press the side front of the shirt
including the placket or pocket.
e. Pull the shirt towards you and continue to press each area until complete.
f. Place the shoulder yoke flat on the Ironing Board. Press to remove the
crease.
G. Place the collar right side up on the Ironing Board and press.
13

PANTS:
a. Place the pressing Cushion under the waistband and press.
b. Reposition the waistband and continue around the pants until the entire
waistband is pressed.
c. To press the in seam, place the Pressing Cushion under the area to be
pressed. Press the entire in seam and repeat for the other leg.
d. Press the front and back pleats using the same method. Fold one leg along
the creased line. Place it on the Ironing Board so that the seams will not
be pressed. Press the crease.
PLEATED SKIRTS:
a. Place the Pressing Cushion under the waistband and press.
b. Reposition the waistband and continue around the skirt until the entire
waistband is pressed.
c. Place the pleated area on the Ironing Board. Fold the pleats carefully and
Press.
d. Continue with each pleated area until the garment is completed.
OTHER ITEMS:
a. EMBROIDERY should be placed FACE DOWN on the Ironing Board to
reduce wear and prevent damage to delicate work.
b. CURTAINS may be pressed running them from one end of the Ironing
Board to the other and pressing in sections until complete.
c. DRESSES with special needs should refer to the above sections on pleats,
shirts (bodices), etc., for proper use of the Pressing Cushion.
IMPORTANT NOTE: Many types of clothing are intricate and unique to their
owner. You may have to experiment with the best way to press challenging
garments. Remember, if you put in a crease you did not intend, you can
remove it just as simply with one of the methods contained in these
Instructions.
14

TROUBLE SHOOTING
Below is a chart detailing the most common problems, their causes and
solutions. Before shipping any appliance to a service center please check to
make sure that the solution is not listed here:
PROBLEM CAUSE SOLUTION
Steam Press cannot
be opened using
Pressing Handle.
Locking Knob is in
Locked position. Turn the Locking Knob to the unlocked
position.
Steam Press becomes
warm but Does not
remove wrinkles.
Temperature Setting
is not high enough for
the fabric attempted.
Gradually increase the
temperature until
obtaining the desired
results.
Press Does not get
warm. Temperature has not
been selected.
Press is not plugged
into an outlet.
Automatic Shut-Off
has engaged.
The Pressing Plate has
been raised for more
\than 15 minutes
without use.
Make a proper
selection.
Plug the appliance in.
Press the [ POWER ]
button again.
15

16
PROBLEM CAUSE SOLUTION
No Steam. Water Level is too low.
Controls have not been
properly set.
Fill the water tank.
If suitable for the fabric,
make a selection to a
higher temperature.
Wait for the Steam
Ready Light to come on.
If not use spray misting
bottle as directed.
Water drips from the
Pressing Plate. Steam Button has been
pressed too long.
The Pressing Handle
will not move into the
Automatic Maximum
pressure position.
Item on the Ironing
Board is too thick to
use this pressure.
Use lighter pressure on
thicker items.
Use added steam for
wrinkles.
Don t press the Steam
Button more than 5
seconds continuously.
,

Limited Warranty Policy
All Pyle products are carefully constructed and thoroughly tested before shipment.
Products purchased in the USA are warranted to be free of defects in material and
workmanship for one (1) year from the date of purchase. This warranty is limited
to the original retail purchaser.
Should the product fall due to factory defect in material or workmanship, your unit
will be repaired or replaced at the solo discretion of Sound Around Inc. You can
contact our customer service department at [phone].
To obtain warranty service, the unit must be carefully packed and shipped prepaid
to:
Sound Around Service Center
1600 63rd Street
Brooklyn, NY 11204
• You must also include the following items:
• A copy of your sales receipt or other proof of purchase.
• A brief letter indicating the problem you are experiencing.
• Include in your letter your return address, daytime phone number
• Must include a money order for $25.00 for return shipping, handling and
insurance or provide your Visa/ MC number with expiration date.
Our Obligation under this warranty is limited to the repair or replacement of the
defective unit when it is returned to us prepaid. This warranty will be considered
void if the unit was tampered with, improperly serviced or subject to misuse, ne-
glect or accidental damage.
Register Your Product Online
www.PyleAudio.com
How would you like to extend the warranty on your product for
three months? Simply write and post a review of the product
online. Then, register your product online at pyleaudio.com or
send an e-mail to warran[email protected] including your
name, address, and phone number, as well as a link to the review.

We want you listening for a lifetime
Introducing Pyle Rewards!
• Get points for registering your Pyle product, posting
text or video reviews online
• Redeem your points for cool items like Pyle-branded
t-shirts, pens, and Pyle products, including mini
speakers, sports watches, guitar pedals, iPod clock
radios, and more!
• Connect your Pyle Rewards account to your Facebook
and Twitter accounts to show o all the cool stu you
earned!
For more information, visit PyleAudio.com/rewards
Check us out on Facebook & Twitter:
www.facebook.com/pyleaudio
Twitter: @pyleaudio
