PYROD C3448 User manual

0090506892
34" COLOUR TV RECEIVER
C3448
Please read this manual carefully
before using this TV set and keep
it for future reference.
OWNER'S MANUAL
Telefix Help Line Number:
1300 366 144

CONTENTS
WARNING AND CAUTIONS...............................................................................................................1
BASIC FEATURE..................................................................................................................................2
TECHNICAL SPECIFICATION............................................................................................................2
FUNCTION BUTTONS AND EXTERNAL SOCKETS.......................................................................3
REMOTE CONTROLLER BOARD......................................................................................................5
OPERATION MENU..............................................................................................................................6
MULTI FUNCTION TIMER.................................................................................................................10
PROGRAM NUMBER EXCHANGE...................................................................................................11
GENERAL OPERATION.......................................................................................................................12
EXTERNAL CONNECTIONS...............................................................................................................13
TROUBLESHOOTING GUIDE.............................................................................................................14
WARRANTY
Congratulations on you purchase of a new Electronics Australia Product!
This product has a one year warranty from the date of purchase. Please NOTE: This Warranty is
valid with a proof of purchase. Subject to the conditions of this warranty an authorized service
centre will perform the necessary repairs on this product without charge for the period of 1 year from
date of purchase.
This warranty only applies to products sold by Certified Electronics Australia P/L dealerships. The
warranty will void if service performed by an unauthorized service agent or dealership. Proof of
purchase must be presented when warranty service is requested.
This warranty is valid only if the product has been installed and maintained according to the
manufacturers manual and recommendations pertaining to normal use and reasonable care.
This product warranty covers this product for normal domestic use ONLY and does NOT cover or
accept warranty claims for accidents, misuse, neglect, alteration, unauthorized repair, fire, floods or any
damage caused by natural disasters. The authorized service centre reserves the right to determine
whether the fault has been caused by manufacturing defects or failure of any component or material in
this product.
WARRANTY SERVICE
Telefix Help Line Number:
1300 366 144
Send or bring the product to your local authorized service centre.
Please Note: You are responsible for all freight charges to & from your
nearest authorized service centre.
NO WARRANTY SERVICE WILL BE PERFORMED WITHOUT PROOF OF PURCHASE

WARNING AND CAUTIONS
1. When you clean the TV set, please pull
out the power plug from AC outlet.
Or may result in electric shock, fire or
damage to the TV set. Don't clean the
cabinet and the screen with benzene,
petrol and other chemicals.
4. Do not place the TV set near rain
or moisture as it may cause an electric
shock, or the TV set to catch fire. The TV
set must only be used
in dry indoor location.
2. In order to prolong the using life of the
TV set, please place it in a well ventilated
location.
5. The back cover must only be removed
by a registered electrical service person.
Removing the back cover may result in
electric shock, fire or damage to
the TV set.
3. Don't place the TV
set in direct sunlight or
near heat source.
6. If the TV set is not going to be used for
long time, or there is a severe thunder &
lightening storm, it is recommended that
the TV set be disconnected from the AC
power outlet and the aerial plug
removed.
Explanation on the display tube
When the picture tube requires cleaning, please disconnect the power and use
a dry soft cotton cloth. Do not use any cleaner or abrasive cloth.
1
BASIC FEATURE
TECHNICAL SPECIFICATION
●218 programs stored
●Auto-correcting black balance
●Surround stereo
●Blue extension, green improvement
●Multi-picture modes and multi-sound modes
●Audio/Video input, S-Video input
●DVD component input
2
POWER SUPPLY: See rating plate
TV SYSTEM: B/G
COLOUR SYSTEM: PAL NTSC3.58/4.43 (AV)
CRT: 34"
AERIAL INPUT IMPEDANCE: 75Ωunbalanced
VIDEO INPUT: 1.0VP-P(75Ω)
AUDIO INPUT: 436mVrms(40KΩ)
VIDEO OUTPUT: 1.0VP-P(75Ω)
AUDIO OUTPUT: 436mVrms(>600Ω)
AUDIO MAX OUTPUT POWER: 5W+5W
POWER CONSUMPTION: See rating plate
NET WEIGHT(kg): 60.5
NET SIZE(mm): 895×565×670
Supplied accessories:
Infrared remote control handset 1
Battery(AA) 2
Operating instructions 1
Design and specifications are subject to change without notice.

43
MARK FUNCTION DESCRIPTION
MUTE
STANDBY
ONE DIGIT SELECTION
ONE OR TWO OR THREE DIGITS PRE-SELECTION
TV/VIDEO SELECTION
MENU DISPLAY
SWAP PROGRAM BETWEEN THE PRESENT AND THE LAST
VOLUME CONTROL
CHANNEL NUMBER UP/DOWN
0-9
-/--
TV/AV
MENU
SWAP
-VOL+
-CH+
PICTURE MENU
SOUND MENU
SOUND
TIME MENU
TIME
FUNCTION MENU
FUNCTION
NOTE：
The function of selecting menu button on the remote controller is
the same as that of program up/down button on the TV set.
The function of identifying menu button on the remote controller
is the same as that of volume up/down button on the TV set.
T
MU
E
A
SC N
PROGRAM SCAN
ZOOM
V
ALI
ID
BU TON
N T
CALL DS AY
I PL
IEXT
I
I-I
TD
PS.
T
S.SD
E
T N
U
CHILD LOCK
PICTURE MODE SELECTION
SOUND MODE SELECTION
TUNE MENU SELECTION
EXIT MENU DISPLAY
REMOTE CONTROLLER BOARD
123
4 5
X
EIT
.ST
PD
S.STD
CA
S N
LOCK
PCTUI RE
VOL-
+C H
+
VOL
-
CH
M
UTE
6
IME NU
SUN U CTN TE
OD T FIO N
7 8 9
/
V A
T V
-
-/-
ZOOM
CALL
0
-I
II
P
.
P
M N
E U
W
S AP
C
LO K
NICAM BUTTON
FUNCTION BUTTONS AND EXTERNAL SOCKETS
(1) S-VIDEO input
(2) AUDIO/VIDEO input
(3) YUV-DVD component input
(4) Antenna input
(5) AUDIO/VIDEO output
(1) (2) (3)
(4)
S-VIDEO
3
Y
Cb
Cr
OUT
IN
VIDEO
AUDIO
L
R
IN
(5)
2. Audio and video rear connections
1. Front panel
(1)Remote sensor: let the remote
controller aim here, the TV set
can receive remote control signal.
(2)Power switch: press the button to turn
on the TV set ,press the button again to
turn off the TV set.
(3)Power indicator: the indicator lights
in standby status .The indicator glints
when you use remote controller.
(4)Menu button
(5) Program up/down button
(6)Volume up/down button
(7)TV/AV switch button
( 2)
( 3)
( 1)
MENU TV/AV P
- +
- +
(4) ( 5)( 6)( 7 )
AUDIO
VIDEO
AUDIO2-R
AUDIO2-L
VIDEO2
L
R
S-VIDEOS-VIDEO
YY
CCbb
CCrr
OUTOUT
ININ
VIDEOVIDEO
AUDIOAUDIO
LL
RR
ININ

1.Entering and exiting menu
Press MENU button on the remote controller once (or directly
press PICTURE button on the remote controller),PICTURE
menu displays on the screen; press MENU button
twice (or directly press SOUND button on the remote
controller), SOUND menu displays on the screen.
Press the menu button again (3 times, or directly press
TIME button on the remote controller), TIME menu displays
on the screen. Press the menu button again (4 times, or directly press FUNCTION button on the
remote controller), FUNCTION menu displays on the screen. Press the menu button again (5
times or directly press TUNE button on the remote controller), TUNE menu displays on the
screen. Press the menu button again (6 times), EXCHANGE menu displays on the screen .To
turn off the on-screen menu display, either press the EXIT button or allow the TV set to
automatically turn off the menu by not pressing any button for a few seconds.
2.Auto search
A. Press MENU button five times continually (or directly press TUNE button on the remote
controller), e
Press MENU button five times continually (or directly press TUNE button), ensure that the
TUNE menu is displayed. Press the CH+/- buttons to select SEARCH. Then press the VOL+
button to search up or VOL- button to search down to the next TV station.(It is much faster to
search up.) If the wrong station is found, press the search button again. You may need to
repeat this until the correct station is located. To store the new program, press the EXIT
button.
4.Fine tune
If the picture or sound is poor, try to use the "FINE TUNE" feature. Select the
FINE TUNE by using the CH +/- buttons. Use the VOL +/- buttons to fine tune the
sound and picture for optimum results. Then press the EXIT button to store the
results. Do not use this feature unless reception is poor.
nsure that the TUNE menu is displayed. Press the CH+/- buttons to select
AUTO SEARCH. Then press the VOL+ button, the TV set will begin to search programs
from present programme No..
B. After the search has finished, the TV set will return to the first program that is stored.
3.Search
TUNING
COLOR SYSTEM AUTO
BAND VHFL
SKIP OFF
PROG NO. 19
SEARCH
FINE TUNE
AUTO SEARCH
OPERATION MENU
5.Selecting color system
Usually this should be set in the auto position. However if the colors displayed on the screen
are incorrect you can manually select the correct color system. When you have finished
remember to turn it back to auto again so that other programs will still work correctly.
Use the CH+/- buttons to select COLOR SYSTEM then the VOL+/- buttons to select a
color system you need. Press the EXIT button to save the setting.
Setting Channel
5 6
Press the menu button once or press the PICTURE button
on the remote controller to display the picture setting
menu.
1.Contrast (adds depth to the picture)
Press the CH+/- buttons to select CONTRAST, then
press the VOL+/- buttons to adjust the contrast level.
2.Brightness (adds sparkle and shine to the picture)
Press the CH+/- buttons to select BRIGHTNESS, then press the VOL+/- buttons
to adjust the brightness level.
3.Colour (adds colour depth)
Press the CH+/- buttons to select COLOUR, then press the VOL+/- buttons to
adjust the colour level.
4.Sharpness (adds fine detail)
Press the CH+/- buttons to select SHARPNESS, then press the VOL+/- buttons to
adjust the sharpness level.
Note: Do not turn the sharpness up to high if the reception is poor or has lots of
noise as it will enhance the fine grain details.
5.Coring
Press the CH+/- buttons to select CORING, then press the VOL+/- buttons to turn
this feature on/off.
6.Picture boost
Press the CH+/- buttons to select PICTURE BOOST, then press the VOL+/-
buttons to turn this feature on/off.
7.Program skip
The program skip feature enables you to skip/hide programs that you do not
wish to be displayed when using the CH+/- buttons. These channels will still
be displayed by directly using the channel number buttons on the remote
controller. To skip , press the CH+/- buttons to select the SKIP menu, press the
VOL+/- buttons to tune the skip feature on/off. Press the EXIT button to save
the setting.
8.Program number
The program number is the remote control channel number. You can change the
program number to see channels stored without exiting this main menu. Press the
CH+/- buttons to select PROGR No., press the VOL+/- buttons to change the
program number that you are adjusting.
9.Band switching (Note: This is a new item.)
If you already know what band the channel is on, tuning can speed up by selecting
the correct band before going into the search menu. This feature should only be
used if you understand the channels in your local area.
Picture Adjustments
CONTRAST 89
BRIGHTNESS 66
COLOR 50
SHARPNESS 50
CORING OFF
PICTURE BOOST OFF
IIIIIIIIIIIIIIIIIIIIIIIII..........
OPERATION MENU

Sound Adjustments
Press the MENU button twice or press the SOUND button on the remote controller,
to display the sound setting menu.
2.Bass (add low frequency depth)
Press the CH+/- buttons to select BASS, then
press the VOL+/- buttons to adjust the bass level.
3.Treble (add high frequency clarity)
Press the CH+/- buttons to select TREBLE, then
press the VOL+/- buttons to adjust the treble
level.
4.Balance (selects between the left and right
stereo channel levels)
Press the CH+/- buttons to select BALANCE,
then press the VOL+/- buttons to adjust the
balance level.
5.Surround (enhances the stereo effect by
making the sound appear wider)
Press the CH+/- buttons to select SURROUND,
then press the VOL+/- buttons to turn this feature
on/off.
1.Volume (adjust the loudness level)
Press the CH+/- buttons to select VOLUME,
then press the VOL+/- buttons to adjust the
volume level.
SOUND
VOLUME 50
BASS 50
TREBLE 50
BALANCE 0
IIIIIIIIIIIIIIIIIIIIIIIII..........
SURROUND OFF
OPERATION MENU
8
7
FUNCTION
BACKGROUND OFF
BLACK STRETCH OFF
2.Background (If the signal is very poor or there is no
input signal the picture will mute to black.)
Press the CH+/- buttons to select BACKGROUND,
then press the VOL+/- buttons to turn this feature
on/off.
OPERATION MENU
1.Black stretch (adds deeper blacks and increases the
contrast range)
Press the CH+/- buttons to select BLACK STRETCH,
then press the VOL+/- buttons to turn this feature
on/off.
Function Menu

TIME
CLOCK --:--
ON TIME --:--
ON PROG 1
OFF TIME --:--
SLEEP TIME --:--
REMIND TIME
--:--
REMIND PROG 1
Multi Function Timer
The TV set has in built a comprehensive timer
that has five basic functions.
1.Clock
2.On time so that the TV set can be programmed
to turn on at a certain time.
3.Off time to allow the TV set to turn off at the
preset time.
4.Sleep timer to allow the TV set to turn off after
10 ~ 180 minutes.
5.Program remind timer, that displays an on-
screen reminder prompt, when a program on a
different channel is due to start.
Selecting the clock menu
Press the MENU button four times until the CLOCK menu is displayed or press
the yellow time button on the remote controller.
1.Clock (master timer clock)
Press the CH+/- buttons to select CLOCK, then press the VOL+/- buttons to
adjust the hour. Press the CH- button to select minute and the VOL +/- buttons to
adjust the minute.
2.On time
Press the CH+/- buttons to select ON TIME, then press the VOL+/- buttons to
adjust the hour. Press the CH- button to select minutes and the VOL+/- buttons to
adjust the minutes. Press the CH- button to select ON PROG and the VOL+/-
buttons to select the TV channel that the TV set will automatically turn on to.
3.Off time
Press the CH+/- buttons to select OFF TIME, then press the VOL+/- buttons to
adjust the hour. Press the CH- button to select minute and the VOL+/- buttons to
adjust the minute.
4.Sleep time
Press the CH+/- buttons to select SLEEP TIME, then press the VOL+ button
Note: When the set is disconnected from the power supply or is turned off by the
main power switch on the front panel, the clock looses power and will need
to be reset when the power is reconnected.
MULTI FUNCTION TIMER
910
to adjust the amount of time before the TV set will automatically turn off. Each
time the VOL+ button is pressed the sleep time will increase by 10 minutes. The
maximum sleep time is 180 minutes.
5.Remind time
Press the CH+/- buttons to select REMIND TIME, then press the VOL+/- buttons
to adjust the hour.
Press the CH- button to select minute and the VOL +/- buttons to adjust the minute.
Press the CH- button to select REMIND PROG and the VOL +/- buttons to select
the TV channel that the TV set will automatically remind you to turn to while
watching another channel.
Program Number Exchange
This feature enables TV programs that
may be on a wrong TV channel number
to be swapped/exchanged. This feature
is very useful when Automatic Search
Tuning has been used, to reallocate the
found programs to the correct channel
numbers.
Press the MENU button 6 times until the
exchange menu is displayed.
Press the CH+/- buttons until program 1 is
selected. Use the VOL+/- buttons to
select the channel number to be swapped.
(I.E If you wish to exchange channel 2
and 4 PROG1 should = 2.)
Press the CH+/- buttons until program 2 is
selected. Use the VOL+/- buttons to
select the channel number to be swapped.
(I.E If you wish to exchange channel 2
and 4 PROG 2 should = 4.)
Press the CH+/- buttons until EXCHANGE is
selected. Press the VOL+ button to
enable the exchange.
EXCHANGE
PROG 1 1
PROG 2 1
EXCHANGE
MULTI FUNCTION TIMER
PROGRAM NUMBER EXCHANGE

1.Channel changing (218 possible channels)
Use either the CH+/- buttons on the remote controller or the front panel of the TV set
to change the channels. Or directly enter the channel number with the numeric button
on the remote controller.
To select channel numbers from 10 ~ 99, press [-/--] button and enter the two digits
channel number. To select channel numbers from 100 ~ 217, press [-/--] button and
enter the 3 digits channel number.
2.Volume adjustment
Press the VOL+/- buttons on the remote controller or the front of the TV set to adjust
the volume level. The range is 0~100. When the volume buttons are pressed, the
volume level is displayed automatically on the TV screen.
3.Standby
Using the remote controller the TV set can be placed into standby mode. Standby
mode must be used when the timer features is be operated correctly. A red standby
light will glow on the TV front panel when the TV set is placed into standby. To turn
the TV set back on again, press standby button on the remote controller again. It will
take a few seconds before a picture will be displayed.
4.Mute
Press the MUTE button on the remote controller to mute the TV sets sound. Pressing
the MUTE button again will turn the sound back on again.
5.Preset picture modes
Our engineers have designed in 5 commonly used picture settings to allow fast
picture level selection depending on what type of TV program is showing. Each
mode is selected in turn by pressing the "P. STD" button on the remote controller.
The 5 modes are:
Listen- This is a new feature that blacks out the TV screen when listening to
music only channels.
Soft - Designed for night time low light viewing.
Standard - Designed for rooms that have good all round lighting.
Rich - Designed for rooms with high ambient lighting such as daytime sport.
User- A spare setting that can be adjusted to personal tastes.
All the 5 modes can be independently adjusted by using the PICTURE
adjustment menu.
GENERAL OPERATION
11 12
6.Preset sound modes
Our engineers have designed in 4 commonly used sound modes to allow the
best possible sound to be selected quickly. Each mode is selected in turn by
pressing the "S.STD" button on the remote controller.
The 4 modes are:
Speech- Designed to reduce the bass and treble which enhances the voice for
News programs.
Theatre- Enables extra bass and treble to enhance the movie experience.
Music- Adjust the sound to best suit music programs.
User - A spare setting that can be adjust to personal tastes.
All the 5 modes can be independently adjusted by using the PICTURE
adjustment menu.
7.Recall (On-screen Display)
The CALL button on the remote controller allows the on screen menu to be
displayed, showing the channel numbers and colour system and sound system.
8.Program scan (Automatically increments/scans the channels and displays
each channel for a short time.)The SCAN button on the remote controller
turns on/off the scan feature.
Enlarged - Zooms the picture in to magnify smaller images.
9.Channel swap (toggles between the last channel view and the current
channel)
Each time the SWAP button is pressed, the last channel view is displayed.
GENERAL OPERATION
10.AV input selection
Each time the TV/AV button is pressed, the input selection will cycle among
TV- AV1- AV2- SVHS- DVD- TV.
Notes: I.AV1 & SVHS share the same AV1 audio input.
Ⅱ.In AV modes the RECALL status display will only display the colour
system.
11.Lock
Press the LOCK button to select Child Lock on/off.

S-VIDEOS-VIDEO
YY
CCbb
CCrr
OUTOUT
ININ
VIDEOVIDEO
AUDIOAUDIO
LL
RR
ININ
EXTERNAL CONNECTIONS
13 14
W
RB
G R
DVD(with DVD component)
W
R
G
B
Direction of signal
white（left audio）
red（C /right audio ）
blue（C ）
green
（video）
（Y）
yellow
r
b
Y
VCR (without S-VIDEO terminal)
YW R
To adio ut
uo
VCR (with S-VIDEO terminal)
W R
et
To s-vid o outpu
o
To vide output
o mp e t u
Tcoon n ot
Note:
1.When receives s-video signal, you must remove video signal; when receive
video signal, you must remove s-video signal.
2.When receive front video signal, you must remove back video signal; when
receive back video signal, you must remove front video signal.
S-VIDEO
3
Y
Cb
Cr
OUT
IN
VIDEO
AUDIO
L
R
IN
To assist in location possible faults use help guide below:
BREAKDOWN PHENOMENON
PICTURE SOUND CHECKING
the aerial direction and connection
volume、sound mute
Ensure that the power supply is connected to
the TV set and turned on. Also ensure that the
TV set is not in "Listen Mode" or that the
brightness and contrast are not turned down.
adjust color control
adjust channel again
Colour purity fault which can be caused by moving
the TV set, placing magnets near the TV screen or
turning on/off house hold appliances such as
vacuum cleaners near the TV set. Turn the TV off
with the mains power switch for 15 minutes.
When the power is turn on again the TV set will
automatically degauss the picture. In server cases
leave the TV set turned off over night.
Picture with Snow Noise
Color Spot Normal Volume
Scramble Normal or Weak Volume
No Color Normal Volume
No Picture No Sound
No Sound
Normal
Normal
Disturb Noise
Double or Triple Image
Note:
1.If the fault can not be repaired by using above guide consult with your local authorized service center.
2.The TV set must only be repaired by a qualified registered service person. Never attempt to remove
the back cover as the TV set has dangerous voltages in side that may cause a fatality or fire.
3.The cabinet may produce the occasional "snapping sound" This is normal and caused by the
materials in the cabinet expanding with room temperature changes.
TROUBLESHOOTING GUIDE
Electrical interference which can be caused by
cars, motorbikes etc, fluorescent lamps and
dirty insulators on overhead power cables.
This is called ghosting which can be minimized
with an outside aerial, and good quality cable
and terminations. Altering the aerial direction
can also minimize this effect.
