q-Tech QDR User manual

QDR –QTech 900MHz Digital Radio
Owner’s Manual

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 2 of 16
Table of Contents
1.0 Document Revision History........................................................................................ 3
1.1 Change Control...................................................................................................... 3
1.2 Confidentiality and Copyright ................................................................................. 3
2.0 Introduction................................................................................................................ 4
3.0 Connections............................................................................................................... 5
3.1 Power Connector –2.1mm DC Socket................................................................... 5
3.2 Aerial Connector –SMA Socket............................................................................. 5
3.3 USB Port –Type B Socket..................................................................................... 5
3.4 RS232 Serial Port –DB9 Female Connector ......................................................... 5
3.5 RS485 Serial Port –RJ12 Socket.......................................................................... 5
4.0 Status Indicators........................................................................................................ 6
5.0 Applications............................................................................................................... 7
5.1 RS232 Mode.......................................................................................................... 7
5.2 RS485 –Half Duplex Mode.................................................................................... 7
5.3 RS485 - Full Duplex Mode..................................................................................... 9
6.0 Jumper Settings........................................................................................................10
7.0 Configuration Parameters.........................................................................................11
8.0 Important Notes and Warnings .................................................................................12
9.0 Troubleshooting........................................................................................................13
10.0 Specifications ...........................................................................................................14
User Notes...........................................................................................................................15

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 3 of 16
1.0 Document Revision History
Rev
Description
Date
Author
1.4
Added note to 5.1 relating to non-standard
installations
Oct 2014
RH
1.3
Added note for different RS485 cable
options (and pinouts) and updated wording
on power supply warning.
Aug 2012
IH
1.2
Added extra cable pin outs, address change
& corrected power plug to 2.1mm & PSU
warning
Mar 2012
AM
1.1
Amend for 256byte packets, v1.10 firmware
April 2011
TR
1.0
Original
Jan 2011
RH
1.1 Change Control
This document is maintained under change control. Any requests for change should
go to:
QTech Data Systems Limited
12 Midas Place
Middleton
Christchurch 8024
New Zealand
Ph [phone]
Fax [phone]
Email [email protected]
1.2 Confidentiality and Copyright
Copyright QTech Data Systems Limited 2012. All rights reserved.
This document is the property of QTech Data Systems Limited. It may not be copied,
distributed or recorded on any electronic or other medium without the express written
permission of QTech Data Systems Limited.
All material contained in this document which is not readily available in the public
domain is regarded as confidential to QTech Data Systems Limited and may not be
divulged to any third party without the express written permission of QTech Data
Systems Limited.

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 4 of 16
2.0 Introduction
The QDR is a Frequency Hopping Spread Spectrum (FHSS) digital radio operating in
the 921.5 –928.0MHz ISM band.
The QDR is used for connecting serial devices as a wireless link. It can be regarded
as a wireless alternative to RS232/RS485 cable connections.
Serial interface options are Full Duplex RS485, Half Duplex RS485, or RS232.
The radios can be supplied pre configured and with a suitable cable for these modes
of operation.
The radio can be configured to operate in Repeater Mode, whereby it stores and
retransmits any (RF) data packets it receives.
Each QDR (P/N PD9119-485) is supplied
with the following:
Qty 1x QDR Radio
Qty 1x Internal Stub aerial, 2dBi gain
Qty 1x 1m Power Cable
Qty 1x 1m Serial Cable RS485
Alternatively P/N PD9119-232 is the
RS232 version which is supplied with a
1m RS232 serial cable.
A range of quality external aerials are
also available:
PD9225 - 4 element Yagi, 9dBi gain with
5m coax and SMA connector
PD9218 - Whip aerial, 5dBi gain with 5m
coax, bracket and SMA connector
Note –The RS485 cable differs depending on whether connecting to a XL4
RTU (RJ12 to RJ12) or another device (RJ12 to RJ10), the respective P/N are
CB-QDR-RS485-XL4 & CB-QDR-RS485.

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 5 of 16
3.0 Connections
The connections of the QDR are identified below:
3.1 Power Connector –2.1mm DC Socket
Centre pin +V.
Spare power cables are available, P/N CB-QDR-PWR.
Warning –Do NOT use Switch Mode Power Supplies (SMPS) with this
product. The DC power supply used for this product MUST have a grounded
negative or be a “linear” transformer based plug pack. The reason is that the
aerial, programming port and external connections can provide exposed earth
points and the SMPS can impose an AC voltage on the DC ground, which can
lead to damage. Suitable cost effective plug packs are available from QTech
P/N PD5412.
3.2 Aerial Connector –SMA Socket
This is used to connect a suitable aerial with an SMA plug. Please refer to the notes
in Section 8 of this manual.
3.3 USB Port –Type B Socket
This is used for configuration via PC or upgrading the radio firmware.
3.4 RS232 Serial Port –DB9 Female Connector
This is used to connect to RS232 devices. Refer to applications.
Spare RS232 cables are available, P/N CB-QDR-RS232.
3.5 RS485 Serial Port –RJ12 Socket
This is used to connect to RS485 devices in either half or full duplex modes.

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 6 of 16
Refer to applications.
Spare RS485 cables are available, P/N CB-QDR-RS485.
Note –The RS485 cable differs depending on whether connecting to a XL4
RTU (RJ12 to RJ12) or another device (RJ12 to RJ10), the respective P/N are
CB-QDR-RS485-XL4 & CB-QDR-RS485.
4.0 Status Indicators
There are three status indicators on the QDR.
Colour
Meaning
Description
Green
Status
Indicates radio status
Yellow
RxD
Received valid (RF) data packet
Orange
TxD
Transmitted a packet
Notes
RxD LED blinks upon receiving a valid packet. A packet is valid if the Customer-ID
and Site-ID in the received packet are equal to the receiving radios Customer-ID and
Site-ID. The packets must also have a valid checksum.
Status LED issues 6 fast flashes to indicate that the QDR has been reset/repowered.
The Status LED flashes slowly to indicate the QDR processor is running correctly.

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 7 of 16
5.0 Applications
5.1 RS232 Mode
This is used for serial data communications.
A typical use of this mode would be:
The serial cable is connected from the RS232 port of the QDR to an RS232 port of
the RTU.
Pinout of RS232 Port and interface cable connections.
D9 Pin
Signal
Input/Output
Description
RJ45
Pin
1
DCD
Output
Data Carrier Detect
2
RxD
Output
Receive Data
2
3
TxD
Input
Transmit Data
6
4
DTR
Input
Data Terminal
Ready
5
GND
-
Ground
5
6
-
-
Not Connected
7
RTS
Input
Request To Send
8
CTS
Output
Clear To Send
9
RI
Input
Ring Indication
Please note: For non-standard installations please contact QTech for advice as
there can be variations in the pinout configuration.
5.2 RS485 –Half Duplex Mode
A typical use of this mode would be:
The serial cable is connected from the RS485 port of the QDR to the RS485/IPB port
of the RTU at a comms speed of 9600bps.
RS232
DATRAN Master RTU
Slave RTU
RS485-IPB
DATRAN RTU
Remote I/O
Q23 or Q26

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 8 of 16
Jumper Settings for Half Duplex RS485 (2-Wire)
Refer to Section 6 for further details on the jumpers
Jumper
Position
JP3
In
JP4
Out
JP5
In
JP6
In
Pinout of RS485 Port when in Half Duplex Mode
QDR
XL4
eXcel
Signal
Input/Output
Description
Pin
Pin
Pin
1
1
1 (NC)
GND
-
Ground
2
2
3
B
Input/Output
Inverting Input/Output
3
3
2
A
Input/Output
Non inverting Input/Output
4
4
4 (NC)
-
-
-
5
5
-
-
-
6
6
GND
-
Ground
Typical Half Duplex Connection
Note: Line termination resistors are inside the QDR
120 Ohm 
A
B
120 Ohm 
A
B

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 9 of 16
5.3 RS485 - Full Duplex Mode
This mode is used for serial data communications where all four signal lines are
required.
Jumper Settings for Full Duplex RS485 (4-Wire)
Refer to Section 6 for further details on the jumpers
Jumper
Position
JP3
In
JP4
In
JP5
Out
JP6
Out
Pinout of RS485 Port when in Full Duplex Mode
Pin
Signal
Input/Output
Description
1
GND
-
Ground
2
B
Input
Inverting Receiver Input
3
A
Input
Non inverting Receiver Input
4
Z
Output
Inverting Driver Output
5
Y
Output
Non inverting Driver Output
6
GND
-
Ground
Typical Full Duplex Connection
Note: Line termination resistors are inside the QDR
120 Ohm 
120 Ohm 
Y
Z
A
B
Y
A
B
Z
120 Ohm 
120 Ohm 

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 10 of 16
6.0 Jumper Settings
A list of all jumpers and their positions on the QDR has been provided for reference.
Jumper
Description
JP1
ISP Programming Enable
JP2
ISP Programming Enable
JP3
RS485 120 Ohm Line termination on A-B
JP4
RS485 120 Ohm Line termination on Y-Z
JP5
RS485 A-Y Link
JP6
RS485 B-Z Link
JP7
RF Power Amplifier Bias Disconnect
JP3
JP4
JP5
6
JP6
6
JP7
6
JP1
6
JP2
6

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 11 of 16
7.0 Configuration Parameters
The QDR is configured by QTech via the USB Port using a desktop application.
The available parameters are defined below:
Parameter
Options
Notes
Radio Type
2-wire RS485
4-wire RS485
RS232
Standalone Repeater
Repeater with 2-wire RS485
Repeater with 4-wire RS485
Repeater with RS232
Hopping Sequence
1-6
Power Level
1-8
1 = 1 mW
6 = 125 mW for Yagi
7 = 250 mW
8 = 500 mW for Collinear
Customer Number
1-255
Site Number
1-255
Radio Address
1-255
RSSI Mute Threshold
-128 –0 dBm
Background RSSI
-128 –0 dBm
Read only
Packet RSSI
-128 –0 dBm
Read only
Firmware Version
Read only
MAC Address
Read only

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 12 of 16
8.0 Important Notes and Warnings
Aerial Connection
The QDR should never be operated without an aerial connected. If the radio transmits
without an aerial, the RF power has nowhere to go but back into the radio, which can
damage it.
Transmitted RF Power Levels
The QDR must never be operated in violation of RSM license conditions. Ensure that the
Transmit Power Level and aerial system design do not exceed the limitation.
Please be considerate of other users of the ISM Band.
AS/NZS 4268:2008 specifies a maximum EIRP of 1 watt.
Warning –Do NOT use Switch Mode Power Supplies (SMPS) with this
product. The DC power supply used for this product MUST have a grounded
negative or be a “linear” transformer based plug pack. The reason is that the
aerial, programming port and external connections can provide exposed earth
points and the SMPS can impose an AC voltage on the DC ground, which can
lead to damage. Suitable cost effective plug packs are available from QTech
P/N PD5412.
Note –SMA Aerial Connectors
QDR. The aerial connector on the QDR
uses the standard/conventional polarity
SMA socket.
QTech supplies suitable aerials for the
QDR with a standard SMA plug, as
shown to the right.
QDR Type Aerial Cable
XTend Radio. If you are using QDRs to
upgrade an existing system, such as
from Digi XTend radios, this must be
stated at time of ordering.
The Digi XTend type radio uses a non
standard, reverse polarity SMA
connector, often referred to as RP-SMA,
as shown to the right.
XTend Type Aerial Cable

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 13 of 16
A QDR variant is available which has a reverse polarity RP-SMA aerial connector
which will allow you to use the existing aerials. Please order P/N PD9119-U/G.
Note –The RS485 cable differs depending on whether connecting to a XL4
RTU (RJ12 to RJ12) or another device (RJ12 to RJ10), the respective P/N are
CB-QDR-RS485-XL4 & CB-QDR-RS485.
Troubleshooting
Symptom
Cause
Solution
Green Status LED not
blinking when power
applied
Blown fuse
Replace fuse. Use 1 Amp
quick blow type.
Insufficient power supply
voltage
Check supply and provide
suitable power supply
No Communication
RS485 jumpers not
matching setup mode
Check settings and change
to suit
RS485 line termination
Check settings and change
to suit
Incorrect serial data rate
Check settings, ensure it is
9600 Baud, No Parity
Insufficient Rx signal
power
Use a directional antenna*
Use Workbench to measure
the RSSI. A value below -
95dbm is unlikely to be
reliable.
Incorrect configuration for
intended use
Options are point to point,
point to multipoint, repeater
* Be sure that the transmitted power from the antenna (EIRP) does not exceed the
licensed level.

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 14 of 16
9.0 Specifications
Performance
Indoor/Urban range (2.1dBi dipole antenna): Up to 500m
Outdoor line-of-site range (2.1dBi dipole antenna): Up to 5km
Outdoor line-of-site range (9dBi high gain yagi antenna): Up to 10km
Interface data rate: 9600bps
RF data rate: 9600bps
Receiver sensitivity: -110dBm
Power Requirements
Power supply voltage: 7 –28 volts (30 volts absolute max)
Standby supply current: 85mA @ 12 volts
Transmit supply current: 150mA @ 12 volts
Specification
Frequency: 921.5 –928.0MHz
RF Output: 1mW to 250mW
Technology: FHSS (Frequency Hopping Spread Spectrum)
Modulation: GFSK (Gaussian Frequency Shift Keying)
Hopping Channels: 6
Modes: point-to-point, point-to-multipoint, repeater
Maximum packet size: 256 bytes
Environmental
0º to 70º (non condensing)
Certification
AS/NZS 4268:2008
Network Configuration
Customer ID: 1 to 255
Site No.: 1 to 255
Radio Address: 1 to 255
Channel No: 1 to 6
RF Power Level: 1 to 8
Repeater Mode: ON/OFF
Serial Mode: None/RS232/RS485-2W/RS485-4W
Specifications may be subject to change.

QDR –QTech Digital Radio –Owner’s Manual – v1.4 –October 2014
www.qtech.co.nz Page 15 of 16
User Notes

QTech Data Systems Ltd
12 Midas Place, Middleton, Christchurch 8024
PO Box 9087, Tower Junction, Christchurch 8149
Ph: [phone]
Fx: [phone]
[email protected]
[e-mail]
www.qtech.co.nz
