QM DHM-2056 User manual
DHM-2056 “DUAL”
Quick start guide
4-step installation guide
The DHM-2056 can be programmed on the field using the following simple 3 steps*:
Step No 1
Power up the DHM-2056 by adding the external power supply (12VDC/1A) (#5).
The DHM-2056 will need 20-30secs to initialize itself.
The SSD (Seven Segment Display –#2) depicts the initialization status.
Step No 2
On power-up the DHM-2056 enters in “Chanel mode”and the “Channel LED” (#4) is on. By
pressing the “Channel/Profile”button (#1) the user is able to switch between “Channel” or
“Profile” mode. With the “Up/Down” buttons (#3) select the desired RF output channel
between VHF E05…E12 and UHF C21…C69. Wait 10secs for the PLL to lock.
Step No 3
Adjust the output RF level using the output 20dB attenuator (#6) from 70dBμV to 90dBμV.
Step No 4
Select the “Profile mode” and the Profile number beginning from No 1 and keep ascending
for each modulator in the same CATV installation.
For example:
Profile No 1 for the first modulator
Profile No2 for the second modulator
…
Profile No10 for the 10th modulator etc…
*The DHM-2056 offers advanced programming features from a PC software via a USB interface.
Mechanical drawing (mm)
More information
You can download DHM-2056’s full manual and software for advanced
programming from product’s page at www.kovanis.com/QM .
After 1min the DHM-2056’s keypad will be locked. To unlock, keep the
“Up/Down” buttons (#3) pressed simultaneously for 5sec. approximately.
This product complies with the relevant clauses of the European Directive 2002/96/EC.
The unit must be recycled or discarded according to applicable local and national
regulations.
Equipment intended for indoor usage only.
Conforms with the essential requirements of the EMC Directive 2004/108/EC the Safety
Directive 2006/95/EC and 2001/65/EU RoHS Directive, based on the following
specifications applied:
EU Harmonized Standards: ΕΝ 55103-1: 2009,ΕΝ 55013-2: 2009
ΕΝ 60950-1:2006 + Α12:2011,ΕΝ 62479: 2010
MAIN DISTRIBUTION / SERVICE
SAT-LUX S.A.
15 K. Samuel Str. Tel: +30 210 9968010
Ag. Dimitrios - Greece Fax: +30 210 9640127
www.satlux.gr Email: [email protected]
