Qualcut 3300ST User manual

POWER PRODUCTS LLC.
GARDEN MASTER SERIES
OPERATING INSTRUCTIONS
3300ST BRUSHCUTTER
33CC
3300ST
BRUSHCUTTER

POWER PRODUCTS LLC.
3300ST
CONTENTS
Description of Symbols......................................................................................1
Machine Specifications .....................................................................................1
Unpacking..........................................................................................................1
Carton Contents...................................................................................................1
Parts Diagram....................................................................................................2
Applications..........................................................................................................3
Features................................................................................................................3
Recommended Cutting Attachments..................................................................4
Safety Instructions................................................................................................4
Effects of Vibration...............................................................................................6
Repetitive Strain Injury (RSI)...............................................................................6
Safe Operating Practises...............................................................................7
Thrown Debris......................................................................................................7
Blade Thrust (Kickback).......................................................................................7
Personal Protective Equipment.........................................................................4
Operating Tips.......................................................................................................8
Assembly................................................................................................................9
Fuel and Lubrication........................................................................................10
Starting Checklist....................................................................................................11
Starting the Brushcutter.........................................................................................12
Operating the Brushcutter......................................................................................14
Maintenance.....................................................................................................14
The Sparkplug.....................................................................................................15
The Air Filter.....................................................................................................15
The Nylon Head................................................................................................16
Storing Your Brushcutter....................................................................................17
Troubleshooting..............................................................................................18
Warranty...........................................................................................................19

!
+
POWER PRODUCTS LLC.
3300ST
UNPACKING
Due to modern mass production techniques, it is unlikely
that your Qualcut Brushcutter is faulty or that a part is
missing. If you find anything wrong, do not operate the
tool until the parts have been replaced or the fault has
been rectified. Failure to do so could result in serious
personal injury.
The packaging material is made of recyclable materials.
Please dipose of packaging materials in accordance with
regulations.
CARTON CONTENTS
The Qualcut Brushcutter is supplied with the following
accessories as standard.
• 33CC Engine
• Straight Shaft
• Grass Deflector Guard
• Fuel Mixing Bottle
• Bull-bar Handles
• Bump Feed Nylon Spool
• Brush Cutter Blade
• Shoulder Strap
• Operating Manual
1.
DESCRIPTION OF SYMBOLS
The rating plate on your tool may show symbols. These represent
important information about the product or instructions on its use.
Conforms to relevant safety standards.
Wear hearing protection.
Wear eye protection.
Wear head protection.
Read these instructions for use carefully. Failure to
follow operating instructions and safety precautions
can result in serious injury.
Wear safety footwear.
Wear safety gloves.
Wear protective clothing
Warning - Safety alert. Indicates danger, warning or
caution. Attention is required in order to avoid serious
personal injury.
Thrown objects can cause severe injury.
Keep all bystanders, especially children and pets at
least 15m from the operating area.
No naked flame - explosive material.
Extremely hot surface. Do not touch hot muffler,
gear box or cylinder, you may get burned. These
parts get extremely hot from operation and remain
hot for a short time after the unit is turned off.
Fuel inlet (Position: under the fuel tank cap)
On/Off (Position: on the on/off switch)
Setting the on/off switch to OFF stops the engine
immediately.
Do not remove safety guard. Operation without safety
guard can result in serious injury.
Z1085
HOT!
CAUTION!
SPECIFICATIONS
Engine Displacement: 33CC Full Crank
Max. Engine Power: 900W
Engine Type: Air cooled single cylinder,
two stroke cycle
Fuel Type: Unleaded petrol
- 2 stroke oil (40:1)
Fuel Tank Capacity: 900ml
Spark Plug: NGK LD L8RTF TORCH BM6A
CHAMPION CJ8
Weight: 7.0kg
Nylon Line Size: 2.0 - 2.5mm
Sound Power Level: 112dB(A)
Cutting Width: 430mm
Maximum RPM: 9800
Assembly Tools:
•Sparkplug Wrench /
Screwdriver
• Allan Key (x2)
• Spanner
• Backing Plates (x2)
• Screws / Washers

POWER PRODUCTS LLC.
3300ST
2.
1. Left Handle
2. Right Handle
3. Throttle Lever
4. Lock OFF Lever
5. Engine Switch
6. Safety Guard
7. Blade
8. Nylon Cutter
9. Safe Guard Bracket
10. Fuel Mixing Bottle
11. Inner Flange
12. Outer Flange
3300ST BRUSHCUTTER PARTS DIAGRAM
13. Shield
14. Nut
15. Sparkplug Cover
16. Engine
17. Choke Lever
18. Recoil Starter Handle
19. Shoulder Strap
20. Handle Bracket
21. Screwdriver
22. Wrench
23. Allan Key
24. Allan Key
1
2
21
13
15
4
5
16
14
22
17
20
18 19
9
8
11
7
12
10
6
3
23
24

!
!
POWER PRODUCTS LLC.
3300ST
3.
APPLICATIONS
Use this product for the following domestic / household
applications:
• Cutting grass, weeds and light undergrowth
• Edging along path and driveways
• Cutting pulpy weeds, vines and light brush
FEATURES
drive shaft and protects users from flying debris. The guard
includes a cutting blade that automatically trims the line to the
correct length.
Bump Feed Head
The bump feed head with dual line permits efficient cutting and
easy tap-and-go action for restoring broken line.
Ergonomic Loop Handle
The design of the product provides for easy handling. It is
designed for comfort and ease of grasp when operating in
different positions and at different angles. The barrier bar
restrains the operator in position and maintains a proper
distance between the operator and the line head.
Ezy Load Cutting Head
The Ezy Load Cutting Head is a simple alternative to the
traditional bump feed head, allowing replacement of new line
in just seconds.
Blade
The blade allows you to brush cut weeds, vines and light brush.
Shoulder Strap
The brushcutter includes a shoulder strap with anti-vibration
pad that helps support the product and reduce wearer fatigue.
Bull-bar Handles
For greater control or extended use, bull-bar handles provide
optimum comfort and manageability. The handle mounted
throttle and on-off switch means that engine power is at your
fingertips.
WARNING! Do not attempt to modify this product or
create accessories not recommended for use with
this product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to serious personal injury and will void your
guarantee.
Before using this product, familiarise yourself with all operating
features and safety requirements. However, do not let familiarity
with the productmake you careless.
WARNING! Exercise caution when using this product.
Careless actions, for even a fraction of a second can
result in serious personal injury.
Your new product is equipped with the following features.
Engine
The engine is powerful and easy to start. It is effectively counter-
balanced, which allows for less vibration and more durability.
Safety Guard
The safety guard keeps grass from getting wrapped around the

POWER PRODUCTS LLC.
3300ST
SAFETY INSTRUCTIONS
4.
Save these instructions.
1) Work Area
a) Clear the area to be cut before each use. Remove all
objects such as rocks, broken glass, nails, wire, string etc. that
can be thrown or become entangles in the cutting attachment.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the dust or
fumes.
c) Take extra care in dangerous environments. To avoid
falling, do not use the product in damp or wet locations.
2) Personal Safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power tool
while you are tired, ill or under the influence of drugs, alcohol,
or medication. Operate unit only if you are physically and
mentally well. A moment of inattention while operating power
tools may result in serious personal injury.
RECOMMENDED CUTTING
AT TAC H M E N T S
A variety of blades are available from your Qualcut Brushcutter
servicing dealer. Always use a debris shield designed for use
with a blade when attaching a blade to your machine. The blade
type debris shield does not have a cutoff knife.
Grass / Weed Blades
Grass / weed blades, which may be plastic or metal, are used
as an alternative to nylon monofilament line for cutting grass
and ordinary weeds.
However, blades should never be used for edging against solid
surfaces.
Weed / Brush Blades
These metal blades have chisel-shaped teeth that are used for
cutting through field grass, thick weeds, and light brush.
They are not designed for sawing woody material. The teeth
must be sharp for good results.
Brush / Wood Blades
These metal saw-tooth blades are used for sawing through
saplings, shrubs and woody brush.
The teeth must be sharp for good results. Brush/wood blades
will also cut grass and weeds, but they are not efficient for that
purpose.

POWER PRODUCTS LLC.
3300ST
into account the working conditions and the work to be performed.
Use of the power tool for operations different from intended
could result in a hazardous situation.
f) Beware of blade thrust . Blade thrust may occur when the
spinning blade contacts an object that it does not immediately
cut. A blade thrust can be violent enough to cause the product
and/or operator to be propelled in any direction and possibly
lose control of the product. Blade thrust can occur if the blade
snags, stalls or binds. This is more likely to occur in areas where
it is difficult to see the material being cut.
g) Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
h) Turn tool off completely before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power
tool accidentally.
i) Stopping the brushcutter. A coasting blade can cause injury
while it continues to spin after the engine is stopped or the
throttle is released. Maintain proper control until the blade has
completely stopped rotating.
j) Taking care with adjustments. During carburettor adjustments
the cutting attachment may spin. Therefore you should wear
protective equipment and observe all safety instructions when
adjusting the carburetor
k) Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools
are dangerous in the hands of untrained users.
l) Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are caused
by poorly maintained power tools.
m) Inspect the product before each use. Replace damaged
parts. Check for fuel leaks. Make sure all fasteners are in place
and secure. Replace cutting attachment parts that are cracked
chipped or damaged in any way. Make sure the cutting attach-
ment guard is properly installed and in the position recommended
by the manufacturer. NEVER use wire or wire rope which can
break off and become a dangerous projectile.
5.
b) Use safety equipment. Always wear eye protection.Safety
equipment such as non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal
injuries. Wear no-slip, heavy-duty work gloves to improve your
grip on the handle. Gloves also reduce the transmission of
machine vibration to your hands.
c) Always wear protective clothing - long heavy pants,
boots and gloves. Do not wear loose clothing, jewellery, short
pants, open toed shoes or go barefoot. Secure hair so that it
is above shoulder level to avoid entanglement in moving parts.
d) Choose the right time of day. Heavy protective clothing
can increase operator fatigue which may lead to heat stroke.
Schedule heavy work for early morning or late afternoon hours
when temperatures are cooler.
e) Do not over-reach. Keep proper footing and balance at
all times. This enables better control of the power tool in un-
expected situations.
f) Keep pets, children, and bystanders outside a 15m radius.
3) Power Tool Use And Care
a) Check condition of brushcutter before use. The brushcutter
should be assembled as per manufacturer’s instructions. Do
not attach any blade to a product without proper installation of
all required parts. Failure to use the proper parts can cause the
blade to fly off and seriously injure the operator and/or bystanders.
Discard blades that are bent, warped, cracked, broken or
damaged in any way.
b) Never start or run the product inside a closed room or
building. Breathing exhaust fumes can cause illness or death.
c) Mix and pour fuel outdoors where there are no sparks
or flames. Slowly remove the fuel cap only after stopping the
engine. Do not smoke while fuelling or mixing fuel. Wipe spilled
fuel from the product immediately. Move at least 9m from the
fuelling source and site before starting engine.
d) Keep the cutting attachment below waist level. Keep all
parts of your body away from the rotating cutting attachment
and hot surfaces.
e) Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at the rate for which it was designed, taking

POWER PRODUCTS LLC.
3300ST
Protecting your Body from Vibration
The following precautions are strongly recommended, because
the minimum exposure, which may trigger the ailment is unknown.
1. Always use the right tool for each job (to do the job more
quickly and expose you to less hand-arm vibration).
2. Check tools before using them to make sure they have been
properly maintained and repaired to avoid increased vibration
caused by faults or general wear.
3. Make sure cutting tools are kept sharp so that they remain
efficient.
4. Reduce the amount of time you use a tool in one go, by
doing other jobs in between. Try to fill each day with jobs
6.
4) Service
a) Have your power tool serviced by a qualified repair
personnel using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
EFFECTS OF VIBRATION
It is believed that a condition called Raynaud’s Phenomenen,
which affects the fingers of certain individuals, may be bought
about by exposure to vibration and cold - it may cause tingling
and burning sensations, followed by loss of colour and numbness
in the fingers.
If you continue to use high-vibration tools these symptoms will
probably get worse, for example:
• The numbness in your hands could become permanent
and you won’t be able to feel things at all;
• You will have difficulty picking up small objects such
as screws or nails;
• The vibration white finger could happen more frequently
and affect more of your fingers.
REPETITIVE STRESS
INJURIES (RSI)
It is believed that overusing the muscles and tendons of the
fingers, arms, hands and shoulders may cause swelling,
soreness, numbness, weakness or extreme pain in those areas.
Cerain repetitive hand activities may put you at a high risk for
developing a Repetitive Stress Injury (RSI).
An extreme RSI condition is Carpel Tunnel Syndrome (CTS)
which can occur when your wrist swells and squeezes a vital
nerve that runs through the area. It is believed that prolonged
exposure to vibration may contribute to CTS. CTS can cause
severe pain for months or even years.
To reduce the risks of RSI / CTS do the following:
• Avoid using your wrist in a bent, extended or twisted position.
Instead try to maintain a straight wrist position. Also, when
grasping, use your whole hand, not just the thumb and index
finger.
• Take periodic breaks to minimise repetition and rest your
hands.
• Reduce the speed and force with which you do the repetitive
movement.
• Do exercise to strengthen the hand and arm muscles.
n) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
o) Remove any adjusting key or wrench before turning the
tool on. A wrench or a key that is left attached to a rotating part
of the power tool may result in personal injury.
where operating the unit or other hand-held power equipment
is not required.
5. Avoid gripping or forcing a tool or workpiece more than you
have to.
6. Store tools so that they do not have very cold handles when
next used.
7. If you experience discomfort, redness, swelling of the fingers
followed by whitening and loss of feeling, consult your
physician before further exposing yourself to cold and
vibration.
8. Maintain good blood circulation by:
• Keeping your body warm, especially the head, neck,
feet, ankles, hands and wrists.
• Giving up or cutting down on smoking because smoking
reduces blood flow
• Performing vigorous arm exercises during frequent
work breaks.

POWER PRODUCTS LLC.
3300ST
7.
THROWN DEBRIS
The trimmer will throw debris in the direction of blade movement
at the point of contact.
The cutting line head or blade on the Qualcut 3300ST trimmer
rotates anti-clockwise as viewed from the operator’s position,
so tilting the cutting line head to the right will throw debris away
from you, and tilting to the left will throw debris towards you.
If the cutting line head or blade is held parallel to the ground,
debris will scatter in all directions, and there will be greater
friction which will wear out the cutting line or blade sooner.
When operating the trimmer near a hard surface such as a wall,
work from an angle where debris that strikes the hard surface
will ricochet away from you.
!
!
SAFE OPERATING
PRACTISES
Be very careful when operating the brushcutter over uneven or
rough ground, and when the ground is wet and slippery. Watch
out for hidden obstacles that could cause you to stumble.
Operate the brushcutter only under conditions with good visibility.
Do not operate the brushcutter where you cannot see what it
is cutting.
WARNING! Rotating cutting lines can cause serious
abrasions and cuts, and blades can cut deeply.
• Keep away from the cutting lines or blade whenever
the engine is running.
• Always stop the engine, and be sure the cutting
line head has stopped turning, before inspecting
or handling the cutting lines or blade.
• Immediately stop using all your power equipment and consult
a doctor if you feel tingling, numbness or pain in the fingers,
hands,wrists or arms. The sooner RSI / CTS is diagnosed,
the more likely permanent muscle damage can be prevented.
Gravel, loose stones, etc. can be picked up by the nylon cutting
lines or blade and thrown many feet with enough force to cause
serious personal injury and/or property damage. Before crossing
gravelled areas, release the throttle trigger to stop the cutting
line head or blade.
WARNING! Keep all bystanders, especially children
and pets at least 15m from the operating area.
Cut with the
right side to
throw debris
away from you
Debris
BLADE THRUST (KICKBACK)
Blade thrust (kickback) is the sudden, forceful, and uncontrolled
movement of a blade-equipped brushcutter that may occur if
the blade binds in the cut or strikes a solid object. It throws the
trimmer in the direction opposite blade rotation at the point of
contact, and the jolt received by the operator can result in further
loss of control.
To reduce the risk of loss of control:
• Replace or resharpen dull blades. Dull blades are more
likely to bind in the cut and cause blade thrust.
• Watch out for hidden obstacles, such as rocks, stumps,
roots, etc., that could cause the blade to kick back if struck.
Blade thrust is more likely to occur in areas where it is difficult
to see what is being cut.
• Understand the reaction forces of the blade.

POWER PRODUCTS LLC.
3300ST
8.
• When using a brush blade to saw through heavy brush
and small saplings, saw with the side of the brush blade that
is moving toward you and tends to pull the brushcutter away
from you.
• Blades on Qualcut brushcutters rotate counterclockwise, as
viewed from the operator’s position. Therefore, the left side
of the blade is moving toward you. Sawing with the left side
of a brush blade will give you better control and less risk of
kickback, though it will throw the sawdust toward you.
• Cut from the side of saplings that will cause them to fall
away from the brushcutter. This will help prevent the blade
from binding in the cut and kicking back.
• Accelerate the engine to maximum speed before starting
the cut, and saw through with uniform pressure.
OPERATING TIPS
Scything
• Swing the brushcutter in a level arc by rotating your body
with a smooth, easy motion, rather then moving the
brushcutter with your arms.
• Do not chop at tough weeds and brush; let the cutting line
or blade work through tough growths gradually.
• To direct thrown debris away from you, tilt the cutting
attachment to the right side, scythe from left to right, then
return without cutting.
Brush Clearing
• Clearing brush with a brush blade may require both scything
and sawing.
• Scything with the right side of the blade will direct thrown
debris away from you.
• Be especially careful to direct debris away from you if
recutting an area to shorten stumps. Short lengths of shrub
and sapling stumps may tear off and be thrown at high
speed.
• Sawing heavy brush and saplings with the left side of the
blade will reduce the risk of kickback.
Trimming & Edging
• Use nylon line for cutting against a hard surface. Work from
an angle where debris that strikes the hard surface will
ricochet away from you.
• Avoid contact with wires, wire fences, metal rods, etc. Over-
lapping a wire will cause the nylon line to wrap around the
wire and break off.

POWER PRODUCTS LLC.
3300ST
9.
• Accelerate the engine to maximum speed before starting
the cut, and saw through with uniform pressure.
• If shrubs or saplings bind the blade, stop the engine, and
while supporting the weight of the brushcutter, push the
shrub or sapling away to free the blade. Do not use the
blade as a lever.
Operation on Slopes
• Start on the low side of a slope, and work upward. This will
reduce your risk of slipping and falling, and it will give you
a cutting angle that will better enable you to direct debris
away from you.
• Do not let the cutting line or blade dig into the slope, because
that can cause stones and dirt to be thrown at you.
• Do not raise the cutting attachment above waist level during
operation, because that would increase the risk of thrown
objects striking your face.
• Avoid steep slopes that would require holding the cutting
attachment above waist level. Avoid slippery slopes that
might cause you to lose your balance.
ASSEMBLY
1. Fit the shoulder strap to the machine. (A)
2. Assemble the handle on the machine (B) . First release the
inner hex screws (C), then take right and left handle on the
centre of the handle holder (D). Assemble the handle
holder and tighten the inner screws.
3. Assemble the safety guard. Release the four nuts on sfaety
guard bracket (E). Ensure the nut is well tightened(F).
A
B
C
D
E
F
4. Release the nut. Line up the two holes of flange and shield.
Use screwdriver to hold the flange and turn the socket
wrench clockwise (G). The nut will be released.
G

!
POWER PRODUCTS LLC.
3300ST
10 .
WARNING: Please make sure the cutting head has
been assembled correctly before use.
1. To fit the nylon cutting head, remove the shield after releasing
the nut. Still holding the flange, place the nylon cutting head
on the shaft and rotate counterclockwise (H). The nylon
cutting head is now fitted.
Fitting the Nylon Cutting Head
2. To remove the nylon cutting head, use screwdriver to hold
flange and rotate clockwise.
H
1. To fit the blade, take the outer flange off after releasing the
main nut, then put the blade, outer flange shield and nut
according to priority (I). Note the blade rotation direction (J).
Use screwdriver to hold flange and tighten nut counter-
clockwise. Ensure the nut is well tightened.
Fitting the Blade
2. To release the blade, use screwdriver to hold flange and
release nut, the blade than then be removed.
I
J
PETROL OIL
1 litre 25ml
2 litres 50ml
3 litres 75ml
4 litres 100ml
5 litres 125ml
!
!
Mixing the fuel
FUEL & LUBRICATION
WARNING: Petrol is extremely flammable and
explosive. A fire or explosion from petrol will burn
you and others
This product is powered by a 2 stroke engine and requires pre-
mixing petrol and 2 stroke oil.
The oil mix should be 40:1. Never mix petrol and oil directly in
the engine tank.
Use unleaded petrol intended for motor vehicleuse with an
Octane rating of 87 ( [R + M] / 2) or higher. Purchase fuel from
a reputable fuel supplier.
Use the mixing container provided to mix the oil and petrol in
the correct quantities.
Mix only enough fuel for your immediate needs.
Fuel should not be stored for more than 30 days.
Follow these steps to mix the fuel:
1. Use the container provided for mixing fuel.
2. Mix the 2 stroke engine oil with unleaded petrol in the
container provided at the rate of 40 parts petrol to 1 part oil.
3. Mix the fuel thoroughly and also each time before re-fuelling.
4. Mix in small quantities. Do not mix more fuel than you expect
to use within a 30 day period.
5. Store fuel only in a clean, safe, approved container for petrol
- DO NOT store fuel in the fuel mixing bottle provided.
WARNING: Always stop the engine before filling
the tank. Never add fuel to a machine with a running
or hot engine.
+
= 40:1

!
POWER PRODUCTS LLC.
3300ST
Filling Fuel
11.
WARNING: Move at least 9m away from the
refuelling site before starting the engine. Do not
smoke while filling the tank. Do not add fuel to the
tank close to an open fire or sparks. Never add fuel
to the tank in a closed or non-ventilated area.
!WARNING: Check for fuel leaks. If you find any
leaks, correct the problem before using the product.
1. Clean the surface around the fuel tank to prevent
contamination.
K
3. Pour in the fuel carefully (L). Avoid spilling!
4. Screw the tank cap on firmly by hand.
2. Unscrew the tank cap and remove it (K).
Draining Fuel
1. Hold a collection container beneath the fuel drain bolt.
2. Unscrew the tank cap and remove it (M).
L
M
3. Allow the fuel to drain completely.
4. Screw the tank cap on.
STARTING CHECKLIST
MPORTANT: Do not start the unit until it has been completely
assembled. Before switching on the unit, always checking the
oil.
Check Machine Before Use
Check the safety condition of the device:
1. Check the machine for leaks.
2. Check the machine for visual defects.
3. Check that all parts of the machine have been securely fitted.
4. Check that all safety devices are in proper condition.
!WARNING: Do not operate this machine if you have
found any faults. To operate this machine with
faults could result in serious injury. Make sure to
replace faulty parts before using the machine again.
Adjusting the Harness
1. Adjust the harness so the quick-release latch is at your right
hip, as shown.

POWER PRODUCTS LLC.
3300ST
12 .
Balancing the Brushcutter on the
Shoulder Harness
1. Hang the machine on the harness hook, and see
how it balances.
2. Adjust the shoulder harness, the harness hanger on the
frame pipe, and the loop handle or U-type handlebar, so the
handle or handlebars are in a comfortable operating position,
and the trimmer hangs with its cutting attachment a few
inches above the ground.
!
STARTING THE
BRUSH CUTTER
Starting the product depends on whether the engine is cold or
warm.
WARNING: The recoil starter can be damaged by
abuse.
- Never pull the starter cord to its full length.
- Always engage the starter before cranking the
engine.
- Always rewind the starter cord slowly.
Once the machine has been set up properly, start the engine
as follows:
1. Press the fuel primer bulb 8 times.
2. Turn the engine switch to the ON position ( l ).
3. Put the choke lever into the CLOSED position (P).
4. Pull the recoil starter handle until it engages, then pull briskly
(Q). Repeat until the engine fires and is running.
N
O
l = ON
O = OFF
P
= Choke Closed

!
POWER PRODUCTS LLC.
3300ST
13 .
To Start a Warm Engine
Follow these steps to start a warm engine:
1. Lay the product on a flat, bare surface.
2. Slide the switch to the ON position.
3. Push the primer bulb up to eight times.
4. Pull the starter cord.
NOTE: If the product does not start, repeat the previous steps.
Check that fuel tank has sufficient fuel for the engine to start.
!WARNING: Incorrect sparkplug installation can
result in serious engine damage.
8. If you have any difficulties, press the engine switch to OFF
position, the machine will stop running. To stop the cutting
head working, release the throttle lever.
9. If the machine is hot, the throttle level can be adjusted to
the ON position directly when re-starting the machine and
no choke will be needed.
NOTE: Do not start the motor in tall grass
WARNING: When the engine has been switched off,
the cutter continues running for several seconds
therefore do not stand close to cutting head of brush
cutter until the cutter has come to a standstill!
To Start a Flooded Engine
1. Disconnect the spark plug boot and use the spark plug
wrench supplied to remove the plug in a counter-clockwise
direction.
2. If the spark plug is fouled or is soaked with fuel, clean or
replace the plug as required.
3. Turn the product so that the spark plug hole is aimed at the
ground.
4. Clear excess fuel from the combustion chamber by cranking
the engine several times while the spark plug is removed.
5. Install the spark plug and firmly tighten it with the spark plug
wrench supplied. DO NOT OVERTIGHTEN.
6. Reconnect the spark plug boot. Incorrect spark plug
installation can result in serious engine damage.
!WARNING: Before using brushcutter, always check
the ground and remove all obects which could be
thrown by the machine. Failure to do so could result
in serious injury.
5. Wait a few seconds and adjust the choke lever to the OPEN
position (R).
6. When the engine is running and idling the throttle lever on
handle is as below picture (S). First press the lock off lever
and then switch the throttle lever on, the machine will be
working (U).
7. If using the nylon cutter head, before cutting you will need
to bump to feed line on a hard surface to prepare the nylon
for cutting (V).
Q
ST
U
V
R
= Choke Open / Run

!
POWER PRODUCTS LLC.
3300ST
14 .
Stopping the Engine
1. Cool the engine by allowing it to run at idle for 2-3 minutes.
2. Slide the ON/OFF switch to the OFF position.
OPERATING THE
BRUSHCUTTER
Follow these steps to operate the brushcutter:
1. Remove blade guard from the blade.
2. Start the brushcutter.
3. Hold the brushcutter at waist level with your right hand (arm
extended) on the trigger handle and your left hand on the
front handle.
4. Place the product on the right side of your body with the
engine behind and away from your body.
5. Brushcut weeds and vines in a right-to-left motion with the
blade parallel to the ground. See page 8 for more information.
!WARNING: Do not touch these types of objects
with the blade.
!WARNING: Do not cut with a dull, cracked or
damaged metal blade. Before cutting growth, inspect
for obstructions such as rocks, metal stakes or
strands of wire from fences. If an obstruction cannot
be removed, mark its location so that you can avoid
it with the blade. Wires can catch on the blade head
and be thrown in the air.
MAINTENANCE
!WARNING: Before performing any maintenance on
this machine, stop the engine and disconnect the
sparkplug.
WARNING: When replacing parts other than engine
or emissions parts, use only Qualcut replacement
parts. Use of any other parts may create a hazard
or cause product damage.
Before Each Use
• Remove dirt and debris from the product exterior.
• Inspect the engine, tank and hoses for possible fuel leaks
and repair as necessary.
• Inspect the engine cooling fins for accumulation of debris
and clean as necessary.
• Inspect the entire machine for damage, loose and missing
components or fasteners and repair as necessary.
Cleaning the Product
• Stop the product before cleaning.
• Clean the exterior of the product with a damp cloth.
• Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
• Scrape debris away from air intake vents on both sides of
the motor housing.

!
POWER PRODUCTS LLC.
3300ST
15 .
The Qualcut 3300ST uses the following sparkplugs:
NGK LD L8RTF
Torch BM6A
Champion CJ8
Replacing the Sparkplug
NOTE: Before removing the spark plug, thoroughly clean the
spark plug and cylinder head area.
Follow these steps to replace the spark plug:
1. Ensure the engine is cool before servicing the spark plug.
2. Remove the spark plug boot.
3. Loosen the spark plug by turning it counter clockwise with
a socket.
4. Remove the spark plug.
5. Hand thread the new spark plug, turning it clockwise.
Do not over tighten.
CAUTION: Be careful not to cross-thread the spark plug. Cross
threading will seriously damage the product.
Follow these steps to clean the air filter:
1. Stop the engine.
2. Remove the spark plug boot.
3. Loosen the air cleaner cover by turning the knob counter
clockwise.
4. Remove the air filter cover.
5. Remove the air filter element.
6. Inspect the element. If the element is distorted or damaged
replace it with a new one.
7. Wash the element in clean fuel and squeeze or blow dry.
8. Wash the air cleaner in clean fuel and wipe or blow dry.
9. Rinse the air filter and let it dry completely.
10. Work two drops of oil into the air filter.
11. Replace the air filter (fits only one way).
12. Replace the air filter cover.
13. Tighten the air filter cover by turning the knob clockwise.
14. Replace the spark plug boot.
Cleaning the Air Filter
WARNING: Depending on the type of fuel used, the
type and amount of oil used and/or your operating
conditions, the exhaust port and muffler may
become blocked with carbon deposits. If you notice
a power loss with your petrol powered tool you may
need to remove these deposits to restore perfor-
mance. We highly recommend that only qualified
service technicians perform this service.
!WARNING: Keeping air intake vents free of grass
and debris prevents motor overheating and possible
failure.
THE SPARKPLUG THE AIR FILTER

!
POWER PRODUCTS LLC.
3300ST
16 .
THE NYLON HEAD
WARNING! Read and understand these operating
instructions, as well as the information supplied with
your machine, and follow all warnings and safety
instructions. Failure to do so can result in serious
injury to the operator and/or bystanders.
• To advance the nylon line, bump the downward protruding
button onto the ground while maintaining engine speed.
• Do not bump the head to attempt to feed line when operating
the machine above 4,500 revolutions per minute.
• Optimum cutting speed is approximately 6,000 revolutions
per minute.
• If the head does not properly extend nylon line, check the
head for damage and rewind cutting line.
Rewinding the Head
CAUTION!
1. Remove the cover by depressing the locking tabs located
180 degrees opposite of each other (Fig 1).
2. Remove the line spool from the housing.
3. Fold 18 ft. of cutting line in two halves, leaving one half 3
inches longer than the other, (the three additional inches
will make the line even on both sides of the head when
wound on the spool).
4. The spool is divided in the center and has a slot to
accommodate the folded portion of the nylon line (Fig 2).
5. Wind the line firmly with one strand on either side of the
center divider according to the directional arrow indicated
on the spool (Fig 3).
6. Hook the line strands to the line holding notches on one of
the outer flanges of the spool. This will help to hold the line
in place while the spool is installed in the body of the head
(Fig 4). Leave 4 - 6 inches of the lines protruding from the
notches.
7. The tension spring should stay in the housing hub. Put the
spool onto the housing, positioning it to move up and down
freely against the spring tension.
8. Put the lines into the respective eyelets (Fig 5 & 6).
9. Put the cover onto the housing, aligning the locking tabs on
the cover. Make sure the tabs are fully locked into place in
the cover (Fig 7).
Fig 1. Fig 2.
Fig 3. Fig 4.
Fig 5. Fig 6.
Fig 7.

POWER PRODUCTS LLC.
3300ST
17.
Storing the product differs depending on the amount of time it
will be in storage.
Follow these steps to store the product short term:
1. Clean all foreign material from the product.
2. Store in a well-ventilated place that is inaccessible to children.
If you do not intend to use the product for more than one month,
follow these steps to store the product long term:
1. Drain all fuel from tank into a container approved for petrol.
2. Run the engine until it stops.
3. Clean all foreign materials from the product.
4. Remove the spark plug boot, and then the sparkplug.
5. Pour approximately 5ml oil into the cylinder through the
sparkplug hole.
6. Pull the recoil starter 2 or 3 times to distribute the oil over
the cylinder walls.
7. Reinstall the spark plug. Follow the instructions for sparkplug
replacement.
8. Reconnect the spark plug boot.
9. Store the product in a well-ventilated place that is inaccessible`
to children.
CAUTION: Keep the product away from corrosive agents such
as garden chemicals.
IMPORTANT: Abide by all federal and local regulations for the
safe storage, handling and disposal of petrol. Never store this
product with any fuel remaining in the tank, fuel lines or
carburettor. Your warranty does not include coverage for damage
covered by stale or contaminated fuels.
STORING YOUR
BRUSHCUTTER

POWER PRODUCTS LLC.
3300ST
18 .
TROUBLESHOOTING
