Quasar VV-1301 User manual

Please read these instructions carefully before attempting to connect,
operate, or adjust this product. Please save this manual.
Spanish Quick Use Guide is included.
(Guíapararápidaconsultaenespañolestáincluida.)
CombinationVCR
Operating Instructions
ModelsNo. VV-1301/VV-1311W/VV-13F1/VV-2001
LSQT0502A
Basic Operation
Initial Setup TV Operation
Timer Operation
Advanced Operation
For Your Information
• Initial Setup and Connection Procedures are on pages 8 to 13.
• SELF-DEMO Procedure is on page 4.
As an ENERGY STAR®Partner,
Matsushita Electric Corporation of America has
determined that this product or product model meets
the ENERGY STAR®guidelines for energy efficiency.
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:371

2Forassistance,pleasecall:1-800-211-PANA(7262)orsende-mailto:[email protected]
Important Safeguards and Precautions
INSTALLATION
1 POWER SOURCE CAUTION
Operate only from power source indicated on unit
or in this manual.If uncertain, have your Electric
Utility Service Company or Video Products Dealer
verify your home power source.
2 POWER CORD PLUG
For safety, this unit has a polarized type plug (one
wide blade), or a three-wire grounding type plug.
Always hold the plug firmly and make sure your
hands are dry when plugging in or unplugging the
AC power cord.Regularly remove dust, dirt, etc.
on the plug.
POLARIZEDPLUG CAUTION:
The plug fits into outlet one way.If it cannot be fully
inserted, try reversing it. If it still will not fit, have an
electrician install the proper wall outlet.Do not
tamper with the plug.
GROUNDING PLUG CAUTION:
The plug requires a three-hole grounding outlet.
If necessary, have an electrician install the proper
outlet. Do not tamper with the plug.
3 POWER CORD
To avoid unit malfunction, and to protect against
electrical shock, fire or personal injury:
-Keep power cord away from heating appliances
and walking traffic. Do not rest heavy objects on,
or roll such objects over the power cord.
-Do not tamper with the cord in any way.
-An extension cord should have the same type
plug (polarized or grounding) and must be
securely connected.
-Overloaded wall outlets or extension cords is a
fire hazard.
-Frayed cords, damaged plugs, and damaged or
cracked wire insulation are hazardous and
should be replaced by a qualified electrician.
4 DO NOT BLOCKVENTILATION HOLES
Ventilation openings in the cabinet release heat
generated during operation.If blocked, heat
build-up may result in a fire hazard or heat
damage to cassettes.
For your protection:
a.Never cover ventilation slots while unit is ON,
or operate unit while placed on a bed, sofa,
rug, or other soft surface.
b. Avoid built-in installation, such as a book case
or rack, unless properly ventilated.
5
AVOIDEXTREMELYHOTLOCATIONS OR
SUDDENTEMPERATURE CHANGES
Do not place unit over or near a heater or
regulator, in direct sunlight, etc. If unit is suddenly
moved from a cold place to a warm place,
moisture may condense in unit and on the tape
causing damage.
6TO AVOID PERSONAL INJURY
• Never place unit on support or
stand that is not firm, level,
andadequatelystrong.
The unit could fall causing
serious injury to a child or
adult and damage to the unit.
• Move any appliance and cart
combination with care.Quick
stops, excessive force, and uneven
surfaces may cause objects to overturn.
• Carefully follow all operating instructions.
USING THE UNIT
Before unit is brought out of storage or moved to a new location,
refer again to the INSTALLATION section of these safeguards.
1 KEEP UNITWELL AWAY FROMWATER OR
MOISTURE, such as vases, sinks, tubs, etc.
2 IF EXPOSEDTO RAIN,MOISTURE, OR STRONG
IMPACT, unplug unit and have it inspected by a qualified
service technician before use.
3 ELECTRICAL STORMS
During a lightning storm, or before leaving unit unused for
extended periods of time, disconnect all equipment from the
power source as well as the antenna and cable system.
4 WHEN UNIT IS PLUGGED IN
• DO NOT OPERATE IF:
- liquid has spilled into unit.
- unit was dropped or otherwise damaged.
- unit emits smoke, malodors, or noises.
Immediately unplug unit, and have it inspected by a service
technician to avoid potential fire and shock hazards.
• Neverdrop orpushanyobject throughopeningsinunit.
Touching internal partsmaycause electricshockor fire hazard.
• Keep magnetic objects, such as speakers, away from unit
to avoid electrical interference.
5 USING ACCESSORIES
Use only accessories recommended by the manufacturer to
avoid risk of fire, shock, or other hazards.
6 CLEANING UNIT
Unplugunit.Use aclean,dry, chemicallyuntreatedcloth to gently
remove dust or debris.DO NOT USE cleaning fluids, aerosols, or
forced air that could over-spray, or seep into unit and cause
electrical shock.Any substance, such as wax, adhesive tape, etc.
may mar the cabinet surface.Exposure to greasy, humid, or dusty
areas may adversely affect internal parts.
READANDRETAINALLSAFETYAND
OPERATINGINSTRUCTIONS.HEEDALL
WARNINGSINTHEMANUALANDONUNIT
SERVICE
1 DO NOT SERVICE PRODUCTYOURSELF
If,after carefully followingdetailed operatinginstructions,the
unit does not operate properly, do not attempt to open or
remove covers, or make any adjustments not described in the
manual.Unplug unit and contact a qualified service technician.
2 REPLACEMENT OF PARTS
Make sure the service technician uses only parts specified
by the manufacturer, or have equal safety characteristics as
original parts.The use of unauthorized substitutes may
result in fire, electric shock, or other hazards.
3 SAFETY CHECK AFTER SERVICING
After unit is serviced or repaired, request that a through safety
check be done as described in the manufacturer’s service
literature to insure video unit is in safe operating condition.
OUTDOOR ANTENNA INSTALLATION
1 SAFE ANTENNA AND CABLE CONNECTION
An outside antenna or cable system must be properly
grounded to provide some protection
against built up static charges
and voltage. Section 810 of
the National Electrical Code,
ANSI/NFPA 70 (in Canada,
part 1 of the Canadian
Electrical Code) provides
information regarding proper
grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements for
thegroundingelectrode.
2 KEEP ANTENNA CLEAR OF HIGHVOLTAGE
POWER LINES OR CIRCUITS
Locate an outside antenna system well away from power
lines and electric light or power circuits so it will never touch
these power sources should it ever fall.When installing
antenna, absolutely never touch power lines, circuits or
other power sources as this could be fatal.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA LEAD
IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE
GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL
ELECTRICAL CODE
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:372

3
Safety Precautions/Mesures de sécurité
Warning : To prevent fire or shock hazard, do not expose this equipment to rain or moisture.
Caution : To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Avertissement :Afin de prévenir tout risque d’incendie ou de chocs électriques, ne
pas exposer cet appareil à la pluie ou à une humidité excessive.
Attention :Pour éviter les chocs électriques, introduire la lame la plus large de la fiche
dans la borne correspondante de la prise et pousser jusqu’au fond.
This video recorder, equipped with the HQ (High Quality) System, is compatible
with existing VHS equipment.
Only use those tapes with the mark. It is recommended that only cassette
tapes that have been tested and inspected for use in 2, 4, 6, and 8 hour VCR
machines be used.
This television receiver provides display of television closed captioning in
accordance with §15.119 of the FCC rules.
FCCWARNING : Any unauthorized changes or modifications to this
equipment would void the user’s authority to operate.
This symbol warns the user that uninsulated
voltage within the unit may have sufficient
magnitude to cause electric shock. Therefore,
it is dangerous to make any kind of contact
with any inside part of this unit.
This symbol alerts the user that important
literature concerning the operation and
maintenance of this unit has been included.
Therefore, it should be read carefully in order
to avoid any problems.
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS
INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:373

4Forassistance,pleasecall:1-800-211-PANA(7262)orsende-mailto:[email protected]
Before Using
Congratulations
on your purchase of one of the most sophisticated
andreliable products onthe market today.Used
properly, it will bring you and your family years of
enjoyment.Pleasefillintheinformationbelow.The
serial number is on the tag located on the back of
yourunit.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
Batteries
2 “AA”
Loading the Batteries
Accessories
Battery replacement caution
3) Close the cover.
Prevent Accidental Tape Erasure
Break off the tab to protect.
Record Tab
Screw driver
Cover the hole
with cellophane tape.
To record again.
2) Insert batteries as marked.
1) Open the
cover.
To order accessories,
call toll free 1-800-332-5368.
• Do not mix old and new batteries.
• Do not mix alkaline with manganese batteries.
With Power ON, press
PLAY/REPEAT on the
unit for 7 seconds to
deactivate the SELF-
DEMO Mode.
Repeat this to display
demo screen.
SELF-DEMO Mode
Remote Control
LSSQ0283
(VV-1301/VV-13F1/
VV-2001)
LSSQ0284
(VV-1311W)
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:374

5
Table of Contents
Important Safeguards and Precautions / Safety Precautions ........ 2
Before Using......................................................................................... 4
Table of Contents ................................................................................ 5
Location of Controls............................................................................ 6
Initial Setup for ANT. / Cable Connection ......................................... 8
Initial Setup for DSS / Cable box Connection..................................10
Reset Language, Channels, Clock, Time Zone Adjust...................12
Playback a Tape..................................................................................14
Record On a Tape ...............................................................................14
Copy Your Tapes (Dubbing) ..............................................................15
Tape Operation....................................................................................24
Special VCR Features ........................................................................27
V-Chip Control Feature ......................................................................30
On-Screen Display (OSD) ..................................................................33
Unit Information ..................................................................................34
Before Requesting Service................................................................35
Service Center List .............................................................................36
Limited Warranty ................................................................................37
Spanish Quick Use Guide / Guía para rápida consulta..................38
Index.....................................................................................................BC
TV Operation .......................................................................................16
Picture Adjustment.............................................................................17
TV Timer Features ..............................................................................18
Closed Caption System......................................................................20
Timer Recording .................................................................................22
Basic Operation
TV Operation
TimerOperation AdvancedOperation
For Your Information
Initial Setup
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:375

6Forassistance,pleasecall:1-800-211-PANA(7262)orsende-mailto:[email protected]
Location of Controls
Remote Control Buttons
EJECT button:
When EJECT is pressed, the tape is ejected from Cassette Compartment.
If EJECT is pressed during recording, the unit will not respond to the command.
ADD/DELETE
Page 13.
NITE
Page 16.
SLEEP
Page 19.
TRACKING UP/DOWN
Page 34.
NUMBER keys
Page 16.
SEARCH
Page 24.
VOLUME UP/DOWN
Page 16.
SET/BACKSPACE
Page 13.
PROGRAM
Page 22.
FAST FORWARD/SEARCH
Page 14.
PLAY
Page 14.
CM/ZERO
Page 26.
SPEED
Page 14.
PAUSE/SLOW
Page 14.
EJECT
Page 14.
POWER
Page 8.
DISPLAY
Page 33.
TAPE POSITION
Page 25.
COUNTER RESET
Page 26.
RAPID TUNE
Page 16.
MUTE
Page 16.
CHANNEL UP/DOWN
Page 16.
SET/BACKSPACE
Page 13.
ACTION
Page 12.
STOP
Page 14.
REC
Page 14.
REWIND/SEARCH
Page 14.
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:376

7
Initial Setup
VHF/UHF
Front View of the unit and Indicators on the Front Panel
AC Power Plug
When plugged into
an AC outlet, the unit
consumes 4.0 W of
electric power in OFF
condition.
VHF/UHF Antenna
Input Terminal
In from your Antenna
or Cable.
Pages 8, 10
Rear View of the unit
<Models VV-1301/VV-1311W/VV-13F1 unit shown>
Easy-Grip-Handle
<ModelsVV-1301/VV-1311W/
VV-13F1>
Use when transporting
the unit.
<Model VV-2001 unit shown>
REC
REC
ON TIMER
ON TIMER
PROG TIMER
PROG TIMER
VIDEOIN
VIDEOIN
AUDIOIN
AUDIOIN
POWER
POWER
VOL
VOL
CH
CH
STOP/EJECT
STOP/EJECT
REW/
REW/
PLAY/REPEAT
PLAY/REPEAT
FF/
FF/
REC
REC
TIMER
TIMER
ACTION
ACTION
REC
REC
ON TIMER
ON TIMER
PROG TIMER
PROG TIMER
REWIND/SEARCH Page14
ACTION Page13
STOP/EJECT Page14
ACTION Page13
CHANNELUP/DOWN Page16
TRACKINGUP/DOWN Page34
SELECTUP/DOWN Page13
VOLUME UP/DOWNPage16
SET/BACKSPACE Page13
POWER Page8
Audio/VideoInJackPage15
<ModelsVV-1301/
VV-1311W/VV-13F1>
CassetteCompartment Page14
PLAY/REPEAT Page14
FASTFORWARD/
SEARCH Page14
REC Page14
TIMER Page19
Buit-InSpeaker
PhonesJack Page16
REC Indicator
Lightsduringrecording.
In Rec Pause or OTR
Pausemode,the
indicatorflashes.
Page14
ON TIMER Indicator
Lightswhen the OnTimer
isset.
Page18
PROG TIMER Indicator
Lights when the unit is set for
TimerRecording.Itflashes
whenaTimer Recordinghas
beenset with notape inserted,
the clock is not set, or the tape
isin motion.
Page22
Remote Sensor
VIDEOIN
VIDEOIN
AUDIOIN
AUDIOIN
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:377


9
Initial Setup
Reset all unit Memory Functions
Whenmoving unitto anewlocation,or if a
mistakewasmadeintheInitialSetupsection.
•Make sure atape is not insertedin the unit.
Manual Clock Set
If AUTO CLOCK SET was incomplete, manually
set the clock as follows.
SET
:
SE
L
E
C
T
:
END
:
ACT
I
O
N
SET
C
L
OC
K
DST
:
O
N
SE
SE
L
E
C
T
M
O
N
TH
1 / / :
1
2
Press ACTION on the Remote to
display SET CLOCK Menu screen.
Press to select the month
and press to set. In the same
manner, select and set the date,
year, time, and DST. (Daylight
Saving Time)
SET
:
END
:
ACT
I
O
N
SET
C
L
OC
K
DST
:
O
N
SE
SE
L
E
C
T
COMPLETED
COMPLETED
2 / 7/ :
2001 WED 12 00
PM
3Press ACTION twice to start
CLOCK and exit.
3
1
2
Turn the unit
Power on.
Do “Initial Setup” on page 8.
Press and hold both PLAY and
FF on the unit for more than 5
seconds.
• The power will shut off.
• Please ignore “NO CASSETTE”
warning.
<Model VV-2001 unit shown>
VIDEO IN AUDIO IN
POWER VOL CH
STOP/EJECT REW/ PLAY/REPEAT FF/ REC TIMER
ACTION
REC ON TIMER PROG TIMER
POWER
ACTION
SELECT/SET
:CH UP
:CH DOWN
:VOL UP
:VOL DOWN
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:379


11
Initial Setup
4Press CH to start
CHANNEL /CLOCK AUTO
SET operation. Settings are
performed automatically.
If the setup is completed, the
following screen is displayed.
If AUTO CLOCK SET IS
INCOMPLETE screen appears,
set the clock using MANUAL
CLOCK SET procedure on page 9.
Note to CABLE System Installer
This reminder is provided to call the CABLE (Cable TV) System Installers attention to
Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
POWER
ACTION
SELECT/SET
:CH UP
:CH DOWN
:VOL UP
:VOL DOWN
2
/
7
/
2001
W
ED
12
:
00
P
M
DST
:
O
N
A
UTO
C
L
OCK SET
CO
M
P
L
ETED
SETT
I
N
G
:
CH
1
0
END
:
P
RESS
CH
UP
KEY
SET
:
END
:
ACT
I
O
N
SET
C
L
OC
K
DST
:
O
N
SE
L
E
C
T
COMPLETED
2 / 7/2 / 7/ :
20012001 WEDWED 1212 0000
PM
PM
VV13F1 P01-11 Initial Setup.p65 01/09/19, 10:3711

12 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Reset Language, Channels, Clock, Time
4)Press and
press to select
and set the month,
date, year, time,
and DST (Daylight
Saving Time).
5) Press ACTION
twice to start the
clock and exit this
mode.
3) Press to select
“ANTENNA,”then
press to set your
antennasystem
(“TV”or“CABLE”).
4) Press to select
“AUTOSET,” then
press .
• After Channel Auto Set is
finished, Clock Auto Set
will be performed.
(“TIME ZONE ADJUST”
appearsonlywhenauto
clock is set.)
M
A
I
N
M
EN
U
T
VVCR LANGUAGE
SET
:
ACT
I
O
N
SE
L
E
C
T
:
T
V
EX I T
C
L
OC
K
C
H
T
VVCR
IDIOMA
T
V
MENU
PR
I
NC
I
PAL
C
A
N
A
L
R
E
L
O
J
SA
L
I
R
H
O
L
A
F
I
J
AR
:
ACT
I
O
N
E
L
E
G
I
R
:
BONJOUR
LAN
GU
E
M
EN
U
T
ELE
M
A
GN
ET
.
SORT I E
HORLOGECANAL
REGLER
:
ACT
I
O
N
SEL.
:
1) Press to
selectlanguage
icon.
2) Press ACTION
repeatedly.
For English
M
A
I
N
M
EN
U
T
VVCR
H
ELL
O
LANGUAGE
SET
:
ACT
I
O
N
SE
L
E
C
T
:
T
V
EX I T
C
L
OC
K
C
H
For Spanish
For French
Language
M
A
I
N
M
EN
U
T
VVCR
EX I T
C
L
OC
K
C
H
LANGUAGE
SET
:
ACT
I
O
N
SE
L
E
C
T
:
Channels Clock
Press ACTION
to display MAIN MENU.
3) Press to
select “EXIT.”
Press ACTION to
exit.
1) Press to
select “CH.”
M
A
I
N
M
EN
U
C
L
OC
K
C
H
SET
:
ACT
I
O
N
SE
L
E
C
T
:
VCR
T
V
EX I T
LANGUAGE
ANTANT
ENN
ENN
A
:
C
ABLEABLE
A
U
T
O
S
E
T
C
H
A
NNE
L
CAP
T
I
ON
W
EAK S
I
GNAL
D
I
SPLAY
:
OFF
SELE
C
T
:
SET
:
END
:
ACT
I
O
N
SET UP
CH
A
NNE
L
2) Press ACTION.
M
A
I
N
M
EN
U
VCR
C
L
OC
K
C
H
SET
:
ACT
I
O
N
SE
L
E
C
T
:
T
V
EX I T
C
H
LANGUAGE
1) Press to
select “CLOCK.”
AUT
O
C
L
OC
K SET
M
A
NU
NU
ALAL
T
I
M
E
ZO
N
E
A
D
JUS
T
:
0
SELE
C
T
:
SET
:
END
:
ACT
I
O
N
SET
C
L
OC
K
2) Press ACTION.
1
2
3)Press to select
“MANUAL” or
“AUTO CLOCK
SET” and press .
• For Auto Clock Set,
select “AUTO CLOCK
SET,” then press CH .
SET
:
END
:
ACT
I
O
N
SET
C
L
OC
K
DST
:
O
N
2 / 7/2 / 7/ :
20012001 WEDWED 1212 0000
PM
SESE
L
E
C
T
HOURHOUR
SE
L
E
C
T
:
VV13F1 P12-21 Basic-TV.p65 01/09/19, 10:4512

13
Basic Operation
Clock, Time Zone Adjust
3) Press to
select TIME ZONE
ADJUSTand
press or to
subtractoradd
hour(s)as
necessary.
4)Press ACTION
twice to exit.
(Only when Auto Clock is set.)
Add or Delete a Channel
Time Zone Adjust
1) Press to
select “CLOCK.”
M
A
I
N
M
EN
U
VCR
C
L
OC
K
C
H
SET
:
ACT
I
O
N
SE
L
E
C
T
:
T
V
EX I T
C
H
LANGUAGE
2) Press ACTION.
AUT
O
C
L
OC
K SET
M
A
NU
AL
T
I
M
E
ZO
ZO
N
E
A
D
JUS
T
T
:
0
SELE
C
T
:
SET
:
END
:
ACT
I
O
N
SET
C
L
OC
K
AUT
O
C
L
OC
K SET
M
A
NU
AL
T
I
M
E
ZO
ZO
N
E
A
D
JUS
T
T
:
+1
+1
SELE
C
T
:
SET
:
END
:
ACT
I
O
N
SET
C
L
OC
K
C
HANNEL
08
ADDED
Toaddchannel:
Select channel with
number keys and
press ADD/DLT.
C
HANNEL
08
DE
L
E
T
ED
Todeletechannel:
Select channel with
CH or number keys
and press ADD/DLT.
ACTION key on
the unit Using keys
: CH UP
:CH DOWN
:VOLUME UP
:VOLUME DOWN
Whenever the menu or
program screen is displayed,
CHANNEL UP/DOWN function
as and VOLUME UP/
DOWN function as only.
On Remote On Unit
On Unit
You can operate the
menu screen using
unit buttons.To display
the menu, press STOP/
EJECT and REW
together with no tape
inserted.To exit the
menu, repeat above
with or without tape
inserted until normal
screen appears.
STOP/EJECT
STOP/EJECT
REW/
REW/
ACTION
ACTION
VOL
VOL
CH
CH
POWER
ACTION
ADD/DLT
NUMBER Keys
SELECT/SET
:CH UP
:CH DOWN
:VOL UP
:VOL DOWN
VV13F1 P12-21 Basic-TV.p65 01/09/19, 10:4513





18 Forassistance,pleasecall:1-800-211-PANA(7262)orsende-mailto:[email protected]
1
ON-TIMER with Alarm
TV Timer Features
Ready Check List
The clock is set to correct time.
This unit can be set to automatically power on in one of 2
modes(TV, Playback).
Youcan also combine the On-Timerwith a one minute alarm
thatgraduallyincreasesinvolume.
•If no button on the remote or unit
(includinga button used toturn off
the alarm) is pressed within 60
minutesafter unit turns itselfon,
it will turn itself back off.
Press PROG to display SET PROGRAM
screen.
Note
2
31)Press to select
desired settings.
2)Press to set the
ON-TIMER TIME or
ON-TIMER mode.
• Make sure a tape is
inserted if Playback
mode is selected.
• ON-TIMERmode
selectionorder
4Press to select
ALARM “ON” or
“OFF.”
When “ON” is selected,
an alarm will gradually increase in volume for one
minute or until canceled by pressing any button
(including VOL + -).
To Make Corrections,
use and to move back and correct.
5Press PROG to set ON TIMER.
• “ON TIMER SET” is displayed.
• ON TIMER Indicator lights on the unit.
To Cancel ON-TIMER set,
Repeat steps 1and 2. Then, press ADD/DLT to
clear the time in step 3. Now, press PROG to end.
“ON TIMER END” briefly appears on-screen.
ON TIMER
indicator
CH
TIMER
<ModelVV-2001unit shown>
1)Press to select
“ON TIMER.”
2)Press to display
ON TIMER screen.
SET
:
SE
L
E
C
T
:
END
:
PROG
SET PROGRAM
T I MER PR
OGRAMMING
ON TIMER
ON TIMER
O
N T
I
M
E
R
SE
SE
L
E
C
T
H
OU
OU
R
6
:--
AM CH
AM CH
--
SET
:
SE
L
E
C
T
:
END
:
PROG
ALAR
M
:
O
N
C
H
01
C
H
125
PLAY
C
H
02
C
H
03
O
N T
I
M
E
R
SE
SE
L
E
C
T
ALARM
ALARM
6
:
0000
AM
AM
CH
CH
0808
SET
:
SE
L
E
C
T
:
END
:
PROG
ALAR
M
:
O
N
C
ANCEL
:
ADD / DLT
ABC
VIDEOIN AUDIO IN
POWER VOL CH
STOP/EJECT REW/ PLAY/REPEAT FF/ REC TIMER
ACTION
REC ON TIMER PROG TIMER
VV13F1 P12-21 Basic-TV.p65 01/09/19, 10:4618

19
TV Operation
Press SLEEP repeatedly
to set SLEEP TIMER.
•PressingDISPLAYwith
sleep timer set displays
remainingtime.
Press SLEEP repeatedly
until “SLEEP TIMER 00”
appears to cancel.
Sleep Timer
This unit can be set for auto power off.
kList
rrect time.
SLEEP TIMER 30
SLEEP TIMER 60
SLEEP TIMER 90
SLEEP TIMER 00
Instant Alarm
You can set a timer alarm up to 60 min. Useful when you are
cooking,etc.
1
2
3
To cancel, press TIMER then press ADD/DLT on
the remote while CANCEL/SET screen is displayed.
To increase timer in progress, repeat step 2. Time
will be rounded up to next 1, 5, or 10 minute interval.
(See chart left.)
<Example>
• If current time remaining is 12:15, countdown will
restart from 15:00.
• If current time remaining is 9:15, countdown will
restart from 10:00.
Press CH on the
unit with CANCEL/SET
screen displayed to set
alarm. (Time changes in
the order shown left.)
Alarm will sound at 0: 00.
Press any button to stop
• The volume of the alarm gradually increases
for one minute and then continues to beep
until any button is pressed.
• Pressing TIMER repeatedly on the unit
willchange display as follows.
Press TIMER on the unit to display the
instant alarm CANCEL/SET screen.
5
:
20
PM
CANCEL : ADD
/
DLT
02
:
00
SET
:
CH
KEY ON UN
I
T
• Whiletimer function is inprogress,
you can change channels on the unit
with CH while “CANCEL/SET”
screen is not displayed.
Note
1:00
(one minute)
2:00
3:00
9:00
10:00
15:00
20:00
25:00
30:00
40:00
50:00
60:00 (Max)
one-minute
increase
until10:00
five-minute
increase
until30:00
ten-minute
increase
until60:00
RemainingTime
SELECT/SET
:CH UP
:CH DOWN
:VOL UP
:VOL DOWN
DISPLAY
SLEEP
ADD/DLT
SLEEP
VV13F1 P12-21 Basic-TV.p65 01/09/19, 10:4619

20 Forassistance,pleasecall:1-800-211-PANA(7262)orsende-mailto:[email protected]
OFF CAP C1
TEXT C1
CAP C2
TEXT C2
M
A
I
N
M
EN
U
T
VVCR
EX I T
C
L
OC
K
C
H
LANGUAGE
SET
:
ACT
I
O
N
SE
L
E
C
T
:
Closed Caption Mode Feature
1
2
3
4
5
Closed Caption System
Closed Caption is ...
This multi-use system not only allows the hearing impaired to enjoy selected programs,
but also makes useful information from TV stations available to everyone.
Press ACTION
to display MAIN MENU.
1)Press to
select “TV.”
2)Press ACTION to
display SET UP
TV screen.
1)Press to
select “CAPTION”.
2)Press to display
CAPTION screen.
Press ACTION three times to return
to the normal screen.
1)Press to
select CAPTION
MODE.
2)Press
repeatedly to
select mode.
(See left.)
CAPT
I
ON
CA
CA
PT
PT
I
O
N
MODE
MODE
:
CAP C1
CAP C1
CC ON MUTE
:
CAP C1
SET
:
SE
L
E
C
T
:
END
:
ACT
I
O
N
Closed Caption Mode
Selections
Caption Mode: CAP C1 or C2
A narration of selected TV
programs is displayed.
Check TV program listings for
CC(Closed Caption)
broadcasts.
Caption Mode: TEXT C1 or
C2
The lower half of the screen
will be blocked out. When the
TV station broadcasts
information, such as program
listings, it will appear in this
space.
Caption Mode: OFF
Closed Caption / Text narration
will not be displayed.
NOTE :
The closed caption or text
signal may be broadcast over
C1, C2, or both. Also, text
contents can vary so you may
wish to try different settings.
Recording and Playing Back a Closed Caption/Text Program
Record: Record normally.
Closed Caption/ Text signal, if present, is recorded automatically.
Playback: Start playback. Do above steps to select desired caption mode.
LOCK
CA
CA
PT
PT
I
O
N
N
I
NP
U
T
SELE
C
T
:
T
UNER
V
I
D
E
O
A
D
J
U
ST
SELE
C
T
:
SET
:
END
:
ACT
I
O
N
SET
UP TV
VV13F1 P12-21 Basic-TV.p65 01/09/19, 10:4620
This manual suits for next models
8
Table of contents
Other Quasar TV VCR Combo manuals

Quasar
Quasar VV-8213 User manual

Quasar
Quasar VV-1307 User manual

Quasar
Quasar Omnivision VHS VV-1330S User manual

Quasar
Quasar VV-1302 User manual

Quasar
Quasar VV1319W MONITOR/VCR User manual

Quasar
Quasar Omnivision VV-1303 User manual

Quasar
Quasar VV-1300 User manual

Quasar
Quasar V V-1303A User manual

Quasar
Quasar V V-1303A User manual

Quasar
Quasar VV-1330 User manual
Popular TV VCR Combo manuals by other brands

Philips/Magnavox
Philips/Magnavox CCW135AT owner's manual

Symphonic
Symphonic CSC313E Service manual

CHIEF
CHIEF AVR1 installation instructions

Panasonic
Panasonic PV-C1323-K operating instructions

Philips
Philips 25PV808 operating instructions

Panasonic
Panasonic Omnivision VHS PV-C1324 operating instructions
