Technical Guide
RDMS™ Access via Telnet
and
Serial Control Protocol
Quasonix, Inc.
6025 Schumacher Park Dr.
West Chester, OH 45069
27 May 2022
*** Revision 1.0.4***
**Note: Access to this serial control interface is provided primarily for debugging
purposes. Unlike the standard browser interface, the serial control interface
within the Telnet screen is not safeguarded from accidental or improper changes
to the receiver’s configuration.
It is strongly recommended that users contact Quasonix Technical Support
(Tel: [phone] or [email protected]) prior to using the Terminal serial
control interface.
Specifications subject to change without notice.
All Quasonix receiver products are under U.S. Department of Commerce jurisdiction categorized as
5A991; not covered by ITAR

Technical Guide: RDMS™Telnet and Serial Control
i
Quasonix, Inc.
Table of Contents
1Access via Telnet................................................................................................................................... 4
2RDMS™ Serial Control Protocol............................................................................................................ 8
2.1 Tier 0 (PCM/FM), Tier I (SOQPSK-TG), Tier II (Multi-h CPM) and PSK Commands ................. 9
2.1.1 Additional Command Set Details...........................................................................................14
2.1.1.1 Commands Used with AQPSK or AUQPSK Modes ......................................................... 14
2.1.1.2 Antenna Control Unit - ACU.............................................................................................. 15
2.1.1.3 Adaptive Equalizer Control - AEQ..................................................................................... 17
2.1.1.4 Automatic Frequency Control - AFC ................................................................................. 19
2.1.1.5 Automatic Gain Control - AGC.......................................................................................... 21
2.1.1.5.1 Automatic Gain Control Bulk Attenuation - AGC BA ............................................... 22
2.1.1.5.2 Automatic Gain Control Data Settings - AGC DATA ............................................... 23
2.1.1.5.3 Automatic Gain Control Mode - AGC M .................................................................. 23
2.1.1.5.4 Automatic Gain Control Loop Parameter - AGC L .................................................. 24
2.1.1.5.5 Automatic Gain Control Attenuator Look Up Table - AGC LUT .............................. 24
2.1.1.5.6 Automatic Gain Control Auto Zero - AGC AZ.......................................................... 25
2.1.1.5.7 Automatic Gain Control Zero - AGC Z..................................................................... 25
2.1.1.6 High Speed Output Mixer Settings - AHM ........................................................................ 26
2.1.1.7 High/Low Speed Outputs .................................................................................................. 27
2.1.1.7.1 Analog High Speed Output - AHO...........................................................................27
2.1.1.7.2 Analog Low Speed Output - ALO ............................................................................29
2.1.1.7.3 Digital High Speed Input –DHI................................................................................32
2.1.1.7.4 High Speed Digital Output - DHO............................................................................32
2.1.1.7.5 Low Speed Digital Input –DLI ................................................................................. 34
2.1.1.7.6 Low Speed Digital Output –DLO ............................................................................ 35
2.1.1.8 Low Speed Mixer Control - ALM ....................................................................................... 37
2.1.1.9 Lock Status Command - AL .............................................................................................. 37
2.1.1.10 Best Channel Selector –BCS ......................................................................................38
2.1.1.11 Bit Rate - BR................................................................................................................. 38
2.1.1.12 Combiner Control –CMB..............................................................................................39
2.1.1.13 Clock Polarity - CP........................................................................................................ 41
2.1.1.14 Downconverting Antenna - DA .....................................................................................41
2.1.1.15 Differential Decoding - DD............................................................................................ 42
2.1.1.16 Digital Output Muting - DOM......................................................................................... 42
2.1.1.17 Data Polarity - DP ......................................................................................................... 43

Technical Guide: RDMS™Telnet and Serial Control
ii
Quasonix, Inc.
2.1.1.18 Data Quality Encapsulation –DQ................................................................................. 43
2.1.1.19 Derandomizer State - DR ............................................................................................. 45
2.1.1.20 Digital Status Output - DSO.......................................................................................... 45
2.1.1.21 Forward Error Correction - FEC ...................................................................................47
2.1.1.21.1 FEC Settings for BPSK..........................................................................................47
2.1.1.21.2 FEC Settings for AQPSK....................................................................................... 47
2.1.1.21.3 FEC Settings for DPM ........................................................................................... 48
2.1.1.21.4 FEC Settings for SOQPSK/LDPC .........................................................................49
2.1.1.21.5 FEC Settings for STC/LDPC .................................................................................49
2.1.1.22 Force Lock Indication - FL ............................................................................................ 50
2.1.1.23 FM Demodulator Settings - FM .................................................................................... 50
2.1.1.23.1 FM Video Bandwidth Control - FM B .....................................................................51
2.1.1.24 Frequency - FR............................................................................................................. 51
2.1.1.25 Help Command –H ...................................................................................................... 52
2.1.1.26 Advanced Help Command - HA ................................................................................... 52
2.1.1.27 HyperTrack –HT .......................................................................................................... 53
2.1.1.28 IF Filter Control - IF....................................................................................................... 54
2.1.1.29 Low Density Parity Check –LDPC ............................................................................... 55
2.1.1.30 Modulation Index - MI ................................................................................................... 56
2.1.1.31 Modulation - MO ........................................................................................................... 57
2.1.1.32 Output Clock Measurement - OCM .............................................................................. 58
2.1.1.33 PCM Decoding - PDC................................................................................................... 58
2.1.1.34 PCM Deframing - PDF.................................................................................................. 59
2.1.1.35 Receiver Channel Parameters .....................................................................................61
2.1.1.35.1 Parameters Erase - PER ....................................................................................... 61
2.1.1.35.2 All Parameters Erase - PERA................................................................................ 61
2.1.1.35.3 Parameter Load - PLD........................................................................................... 61
2.1.1.35.4 Parameter Reset - PRS......................................................................................... 62
2.1.1.35.5 Parameters Save - PSV ........................................................................................62
2.1.1.35.6 RF Path Attenuation –RFA ...................................................................................62
2.1.1.35.7 Reset to Factory Defaults - RFD ........................................................................... 62
2.1.1.36 Power Level - PL ..........................................................................................................62
2.1.1.37 Phase Noise Compensation - PNC .............................................................................. 64
2.1.1.38 Query Temperature - QT ..............................................................................................64
2.1.1.39 Signal Degradation Information - SDI........................................................................... 64

Technical Guide: RDMS™Telnet and Serial Control
iii
Quasonix, Inc.
2.1.1.40 Spectrum Inversion - SI ................................................................................................ 67
2.1.1.41 Show Serial Number - SN............................................................................................. 67
2.1.1.42 Save Parameters - SV .................................................................................................. 67
2.1.1.43 Sync Detect –SYNC .................................................................................................... 67
2.1.1.44 System Status Tracking - SYS ..................................................................................... 69
2.1.1.45 Tape Out –TO.............................................................................................................. 71
2.1.1.46 Time of Day - TOD........................................................................................................ 72
2.1.1.47 Show Options - UP ....................................................................................................... 73
2.1.1.48 Version - VE.................................................................................................................. 74
List of Figures
Figure 1: Telnet Into Terminal ....................................................................................................................... 4
Figure 2: Channel Subscribed ...................................................................................................................... 4
Figure 3: Connected to Channel 2 in PCM/FM Mode ................................................................................... 5
Figure 4: Channel Subscribed-Method 2 ...................................................................................................... 5
Figure 5: RDMSIII Telnet Command Menu................................................................................................... 5
Figure 6: RDMSIII Telnet Command Menu-Unsubscribe All Channels ........................................................ 6
Figure 7: RDMSIII Telnet Command Menu-Subscribe to a Specific Channel .............................................. 7
Figure 8: RDMS™ Welcome Message Example .......................................................................................... 8
List of Tables
Table 1: Standard and Optional User Commands ...................................................................................... 10

Technical Guide: RDMS Telnet and Serial Control
4
Quasonix, Inc.
1 Access via Telnet
Telnet provides access to the individual receiver channel’s underlying serial control interface. The serial control
interface is not recommended for typical RDMS usage. The Telnet interface should only be accessed by advanced
users. Contact Quasonix customer support before using these options.
Note: Access to this serial control interface is provided primarily for debugging purposes. Unlike the
standard browser interface, the serial control interface within the Telnet screen is not safeguarded from
accidental or improper changes to the receiver’s configuration.
It is strongly recommended that users contact Quasonix Technical Support (Tel: [phone]) prior to using
the Terminal serial control interface.
1. In a command window, type: telnet open {IP address of the receiver to connect to} 8888.
2. Press the Enter key on the keyboard.
Figure 1: Telnet Into Terminal
The next screen (Figure 2) shows the RDMS channel subscribed to by Telnet.
Method 1-Use the Subscribed Channel
3. At this point, the user may ignore the instructions on the screen and press the Enter key again.
Figure 2: Channel Subscribed
The command prompt for the mode in the subscribed channel displays immediately, as shown in Figure 3. This is a
portal to the receiver’s serial control interface and allows the user to communicate to the individual receiver “brick”
using its basic command protocol.

Technical Guide: RDMS Telnet and Serial Control
5
Quasonix, Inc.
Figure 3: Connected to Channel 2 in PCM/FM Mode
Method 2-Unsubscribe and use a different channel
Look at the second Telnet screen again (Figure 4).
4. Follow the on-screen instruction and press the ` key. This is the very first key on the left side of the
keyboard under the tilde (~).
Figure 4: Channel Subscribed-Method 2
5. The RDMSIII Telnet Command Menu is shown in Figure 5.
Figure 5: RDMSIII Telnet Command Menu

Technical Guide: RDMS Telnet and Serial Control
6
Quasonix, Inc.
The command menu is used to unsubscribe from connections and reconnect to a specific channel. Figure 6 shows all
connections being unsubscribed.
Figure 6: RDMSIII Telnet Command Menu-Unsubscribe All Channels
In Figure 7, the user typed a 1 to subscribe (connect) to channel 1. At this point, the user may press the Enter key to
continue, as described in Method 1.

Technical Guide: RDMS Telnet and Serial Control
7
Quasonix, Inc.
Figure 7: RDMSIII Telnet Command Menu-Subscribe to a Specific Channel
All Quasonix serial commands are alphabetic characters, followed by 0, 1, or 2 arguments. If the command is issued
with arguments, there must be a space after the alphabetic characters. The commands are not case sensitive.
All commands generate a response of one or more lines. The length of the response depends on the verbosity level.
The last response line is always the currently selected mode (PCMFM, SOQPSK, CPM, or PSK), followed by the
character “+” or “>”, depending on the version of the firmware. This prompt signifies that the RDMS™ is ready to
accept new characters.
A complete list of available serial commands can be found in section 2 or by typing HA.

Technical Guide: RDMS Telnet and Serial Control
8
Quasonix, Inc.
2 RDMS™Serial Control Protocol
The RDMS is controlled via a simple three-wire serial interface (transmit, receive, and ground). Configure your
controller’s serial port to the following settings:
•Baud rate of 115,200
•8 bits
•No parity
•1 stop bit
For setup and configuration via a standard Windows-based PC, Quasonix recommends the application called
Terminal, a flexible, full-featured control interface that is included in the RDMS Product CD. Otherwise, one can
use other terminal emulators, such as PuTTY or TeraTerm.
When power is applied to the receiver, a welcome message, shown in Figure 5, displays. After the welcome
message, the mode status displays (in this example, PCM/FM). This varies depending on the modes and versions
loaded into the RDMS. Additional status information about RDMS initialization displays last. This also varies
depending on RDMS settings and options.
Quasonix, Inc
6025 Schumacher Park Dr
West Chester, OH 45069
[phone]
www.quasonix.com
CAGE CODE: 3CJA9
IRIG-106 Release 07
PCMFM App Rev: 1.0.10.166 Dec 3 2015 09:42:16
PCMFM FPGA Rev: 0000102E Nov 12 2015 02:34:51
AGC tables loaded
RF attenuator calibration loaded
IF attenuator calibration loaded
Gain calibration data loaded
RF filter tune data loaded
Synthesizer data loaded
Saved parameters DEFAULTED
Warm start>
Figure 8: RDMS™ Welcome Message Example
The base command syntax is “a command followed by zero or more command parameters.”If the command is
issued with arguments, there must be a space after the alphabetic characters. The commands are not case sensitive.
All commands generate a response of one or more lines. The length of the response depends on the verbosity level.
The last response line is always the currently selected mode (PCM/FM, SOQPSK, CPM, or PSK), followed by the
character “+” or “>”, depending on the version of the firmware. This prompt signifies that the RDMS is ready to
accept new characters.

Technical Guide: RDMS Telnet and Serial Control
9
Quasonix, Inc.
2.1 Tier 0 (PCM/FM), Tier I (SOQPSK-TG), Tier II (Multi-h CPM) and PSK
Commands
The following table describes all receiver user commands. Listed are the command code, name, description of the
command, whether specific options must be ordered or the command is standard on all receivers, basic or advanced
command, and whether the command is restricted to specific waveform modes.
Multiple commands may be typed on a command line if they are separated by a semicolon “;”. There is a limit of
256 characters per command line, including semicolons. Commands with no parameters request status only.
Refer to command HA in section 2.1.1.25 for specific help in reading the command sets.
Refer to section 2.1.1 for additional command set detail and examples. This information is also available in the
command Help.
For example:
PCM/FM>FR 2200.5; BR 6.000; AGC
results in the following:
Frequency set to 2200.5 MHz
Bit Rate set to 6.000 Mbps
and status for all AGC parameters are displayed as:
AGC control enabled
AGC control mode RF
AGC automatic mode select enabled
AGC zero mode Auto
AGC zeroed at -110.22 dBm (13.38 dB attenuation)
AGC auto zero hold threshold 0.000 dB
AGC auto zero time constant 0.250 seconds
AGC loop total power 13.375 dB
Bulk attenuator AGC control enabled, switched out
Ctrl Y repeats the command sequence without having to retype the commands.

Technical Guide: RDMS Telnet and Serial Control
10
Quasonix, Inc.
Table 1: Standard and Optional User Commands
Mnemonic
Name
Description
Option (s)
Required
Mode
Restriction
?
Help Message
Displays abbreviated list of
available Help commands
Standard
None
ACU
Antenna Control
Unit
Report or set antenna control
unit automatic gain control
(AGC) settings
-37
None
AEQ
Adaptive
Equalizer
Report equalizer status and
control adaptive equalizer
settings
-EQ
None
AFC
Automatic
Frequency
Control
Report or set a variety of
automatic frequency control
parameters
Standard
None
AGC
Automatic Gain
Control
Reports or set a variety of
AGC parameters
Standard
None
AHM
Analog High
Speed Mixer
Displays and controls high
speed (video) output mixer
settings
-37
None
AHO
Analog High
Speed Output
(Tape Output)
Displays and controls high
speed (video) output settings
-37
None
ALM
Analog Low
Speed Mixer
Displays and controls low
speed (video) output mixer
settings
-37
None
ALO
Analog Low
Speed Output
Displays and controls low
speed (ACU) output settings
-37
None
AL
Lock Status
Command
Reports system lock status
Standard
None
BCS
Best Channel
Selector
Displays and controls best
channel selector settings
Standard
None
BER
Bit Error Rate
For Bit Error Rate commands
and information, refer to
Appendix A, Bit Error Rate
Testing
Standard
None
BR
Bit Rate
Report or set baseband bit
rate
Standard
For Asynch
PSK (legacy)
modes, BR A
and BR B must
be specified
separately
CLH
Command Line
History
Reports last 25 commands
issued
Standard
None

Technical Guide: RDMS Telnet and Serial Control
11
Quasonix, Inc.
Mnemonic
Name
Description
Option (s)
Required
Mode
Restriction
CMB
Combiner
Control
Displays and controls
combiner settings
Standard
None
CP
Clock Polarity
Report or set clock polarity
inversion state
Standard
For Asynch
PSK (legacy)
modes, CP A
and CP B must
be specified
separately
DA
Downconverting
Antenna
Displays and controls
receiver C band to P band
downconverting antenna
P band
enabled
receiver
None
DD
Differential
Decoding
Enable or disable differential
decoding
Standard
SOQPSK
DHI
High Speed
Digital Input
Displays and controls high
speed digital input settings
Standard
None
DHO
High Speed
Digital Output
Displays and controls high
speed digital output settings
Standard
None
DLI
Low Speed
Digital Input
Displays and controls low
speed digital input settings
Standard
None
DLO
Low Speed
Digital Output
Displays and controls low
speed digital output settings
Standard
None
DOM
Digital Output
Muting
Control shut down of clock
and data outputs
Standard
None
DP
Data Polarity
Report or set data polarity
inversion state
Standard
For Asynch
PSK (legacy)
modes, DP A
and DP B must
be specified
separately
DQ
Data Quality
Encapsulation
and Metrics
Display and control data
quality encapsulation and
DQ metrics
Standard
ARTM modes
DR
Derandomizer
State
Report or set the
derandomizer state
Standard
None
DSO
Digital Status
Output
Controls the source, polarity,
and override states
Standard
None
FEC
Forward Error
Correction Mode
Report FEC status for
enabled modes
-K7
Legacy PSK
FL
Force Lock
Indication
Diagnostic tool to force the
system to indicate locked or
unlocked
Standard
None

Technical Guide: RDMS Telnet and Serial Control
12
Quasonix, Inc.
Mnemonic
Name
Description
Option (s)
Required
Mode
Restriction
FM
FM Demodulator
Settings
Displays and controls FM
demodulator settings
Standard
PCM/FM
FR
Frequency
Report or set receiver center
frequency
Standard
None
HA
Advanced Help
Command
Displays Help commands not
frequently used or with more
complex construction than
the basic two character Help
commands
Standard
None
HT
HyperTrack
Displays and controls
HyperTrack settings
Standard
None
IF
IF Filter Control
Display and control IF filter
settings
Standard
None
LDPC
Low Density
Parity Check
Display and control Forward
Error Correction settings
Standard
SOQPSKLDPC
or STCLDPC
MI
Modulation Index
Report or Set Modulation
Index Tracking or Acquire
Standard
PCM/FM
MO
Modulation
Report or set modulation
setting
Standard
Limited to
modes installed
OCM
Output Clock
Measurement
Displays measured output
clock frequency
Standard
None
PDC
PCM Decoding
Controls digital decoding
such as NRZ-L, NRZ-M, and
bi-phase
Standard
None
PDF
PCM Deframing
Displays and controls PCM
deframing settings
Standard
None
PER
Parameters
Erase
Erases the stored parameter
set for the current mode;
Upon power cycle, resets
current operating parameter
set to factory default values
Standard
None
PERA
All Parameters
Erase
Reset all modes to factory
default values
Standard
None
PL
Input Power
Level
Reports or sets the current
input power level setting
Standard
None
PLD
Parameters
Load
Loads the stored parameter
set into the current operating
parameter set
Standard
None
PNC
Phase Noise
Compensation
Report or set phase noise
compensation state
Standard
PCM/FM

Technical Guide: RDMS Telnet and Serial Control
13
Quasonix, Inc.
Mnemonic
Name
Description
Option (s)
Required
Mode
Restriction
PRS
Reset Defaults
Restores factory default
parameters for the unit
Default is currently the
lowest number modulation
supported by the transmitter
with the selected band and
frequency limits
Standard
None
PSV
Parameters
Save
Writes the current operating
parameter set into a
(previously erased) stored
parameter set
Standard
None
QT
Query
Temperature
Report the temperature in
degrees Celsius
Standard
None
RFD
Reset Defaults
Reset all parameters to
factory default values
Erases all parameter data
Resets to default Mode
Standard
None
SDI
Signal
Degradation
Information
Sets signal degradation
information enable or disable
parameters
Standard
SOQPSK
SI
Spectrum
Inversion
Accounts for downconverting
antenna spectral inversion
Standard
None
SN
Show Serial
Number
Report the serial number for
the unit
Standard
None
SV
Save
Parameters
Saves the current
parameters in non-volatile
memory, including
frequency, modulation, bit
rate, data polarity, clock
polarity, AGC state, verbosity
level, etc.
Standard
None
SYS
System Status
Tracking
Displays the system status of
the receiver
Standard
None
TO
Tape Out
Displays and controls tape
output settings
Standard
None
TOD
Time of Day
Sets the current calendar
date and time of day
Standard
None
UP
Show Options
Displays the current
hardware configuration and
options on the receiver
Standard
None

Technical Guide: RDMS Telnet and Serial Control
14
Quasonix, Inc.
Mnemonic
Name
Description
Option (s)
Required
Mode
Restriction
VE
Version
Report the current Firmware
(software) version
information for the receiver;
displays the current
application, FPGA, and
adaptive equalizer versions
Standard
None
2.1.1 Additional Command Set Details
2.1.1.1 Commands Used with AQPSK or AUQPSK Modes
The commands detailed below generally operate on a single data stream. AQPSK and AUQPSK modulation,
however, contain two data streams that require different bit rate settings and may require other independent settings.
As a result, when using AQPSK or AUQPSK modes, some command components require a datapath parameter to
distinguish which stream is being configured. These commands include: Best Channel Selector (BCS), Clock and
Data Polarity (CP, DP), Derandomizer (DR), Data Quality (DQ), Forward Error Correction (FEC), and PCM
Decoding (PDC).
Refer to the receiver Help for the syntax specific to each command.
For example:
BCS in AQPSK mode
Displays and controls best channel selector settings
BCS [<d><e>] –Sets best channel selection enable for data <d> to <e>
where:
<d> - Datapath component
A –Data A
B –Data B
<e> - Enable
0 –Disabled
1 –Enabled
All of the commands follow a similar pattern, however, not all components of a particular command contain the
datapath parameter. In the following BCS example, the BCS Source controls the enables for both BCS channels:
BCS [S<s><e>] - Sets best channel selector source <s> enable to <e>
where:
<s> Sources
CH0 –Channel 0

Technical Guide: RDMS Telnet and Serial Control
15
Quasonix, Inc.
CH1 –Channel 1
INT –Internal
where:
<e> Enable
0 –Disabled
1 –Enabled
BCS NOT in AQPSK mode
Displays and controls best channel selector settings
BCS [<e>] –Sets best channel selection enable for data <e>
where:
<e> - Enable
0 –Disabled
1 –Enabled
2.1.1.2 Antenna Control Unit - ACU
The ACU command displays and controls the antenna control unit settings.
ACU [M <m>|C <e>|O <s>]
M <m> - Sets antenna control mode to <m>
where: <m> - Control mode
M - AGC time constant and AM bandwidth set manually
S - AGC time constant and AM bandwidth set based on antenna scan
C <e> - Sets AGC compensated AM enable to <e>
where: <e> - Enable
0 - Disabled
1 - Enabled
O <s> - Sets antenna control output to <s>
where: <s> - Signal source
0 - Channel 0
1 - Channel 1
C - Combiner
ACU [S [T <t>|R <r>]] - Antenna scan settings

Technical Guide: RDMS Telnet and Serial Control
16
Quasonix, Inc.
T <t> - Sets antenna mode scan type to <t>
where: <t> - Scan type
C - Conical scan
E - E-scan
R <r> - Sets antenna mode scan rate to <r>, 10.00 to 50.00 Hz
ACU [AM [<p>|S <s>|B <b>]] - Antenna control unit AM settings
<p> - Sets AM output polarity to <p>
where: <p> - Polarity
{0|+} - Normal
{1|-} - Inverted
S <s> - Sets AM output scale to <s>, -128.0 to 128.0
B <b> - Sets manual mode AM detector bandwidth to <b>, 5.00 to 50000.00 Hz
ACU [AGC [<p>|S <s>|T <n>]] - Antenna control unit AGC settings
<p> - Sets AGC output polarity to <p>
where: <p> - Polarity
{0|+} - Normal
{1|-} - Inverted
S <s> - Sets AGC output scale to <s>, 1.0 to 50.0 dB/V
T <n> - Sets manual mode AGC time constant to <n>, 0.1 to 1000.0 ms
Examples:
ACU Report ACU related status
PCMFM$acu
ACU mode manual
AGC compensated AM on
Antenna scan type conical
Antenna scan rate 30.0 Hz
Manual AM bandwidth 100.0 Hz
Manual AGC time constant 100.0 ms
AM output polarity +
AGC output polarity +
AGC output scale 10.0 dB/V
AM scale 1.0

Technical Guide: RDMS Telnet and Serial Control
17
Quasonix, Inc.
ACU AGC 0 Set polarity to Normal
ACU AGC 1 Set polarity to Inverted
ACU AGC S 42.0 Set AGC output scale to 42.0 dB/V
Valid range is 1.0 to 50.0 dB/V
ACU AGC T 222.0 Set manual mode AGC time constant to 222.0 ms
Valid range is 0.1 to 1000.0 ms
2.1.1.3 Adaptive Equalizer Control - AEQ
The AEQ command displays and controls adaptive equalizer settings.
AEQ [<e>| H {E|Q}|HE<t>|HQ <t>|HD <t>]
<e> - Sets adaptive equalizer enable to <e>
where: <e> - Enable
0 –Disabled
1 –Enabled
AEQ H <e> - Sets equalizer auto hold enable to <e>
<e> - Sets adaptive equalizer enable to <e>
where: <e> - Enable
0 - Disabled
1 - Enabled
H E –Sets equalizer hold reference to Eb/N0
H Q –Sets equalizer hold reference to DQM BEP
HE <t> - Sets EQ hold below Eb/N0 <t>, -20.000 to 30.000 dB or -100.000 is Off
HQ <t> - Sets EQ hold below DQM BEP <t>, 1.00042e-12 to 0.5 or 1.0 is Off
HD <t> - Sets EQ hold/run delay <t>, 10 to 60000 ms or 0 is Off
AEQ T [<e> [-h][<f>][<r>]] - Sets equalizer tracking display enable to <e> in format <f> at rate <r>
where: <e> - Enable
0 - Disabled
1 - Enabled
<f> - Format (last used, if not specified)
N - Normal
C - CSV
<r> - Display rate <r>, 100 to 60000 ms (500 ms if not specified)

Technical Guide: RDMS Telnet and Serial Control
18
Quasonix, Inc.
Options:
-h - Do not display header
AEQ [M {CMA|DD} <k>]
M CMA <k> - Sets EQ CMA Mu to <k>, 0.000 to 0.003906
M DD <k> - Sets EQ CMA Mu to <k>, 0.000 to 0.003906
AEQ [K {FF|FB} <k>]
K FF <k> - Sets EQ feed forward proportional constant to <k>, 0.000 to 0.999985
K FB <k> - Sets EQ feedback proportional constant to <k>, 0.000 to 0.999985
AEQ [MT {CMA|DD} <t>]
MT CMA <k> - Sets CMA MSE threshold to <k>, 0.000 to 0.999985
MT DD <k> - Sets DD MSE threshold to <k>, 0.000 to 0.999985
AEQ [CT <t>] - Sets confidence threshold to <t>, 0.000 to 3.999939
AEQ [AR <e>|C <e>|R <r>|DD <e>]
AR <e> - Sets auto reset enable to <e>
C <e> - Sets power centering enable to <e>
R <e> - Sets reset <r>
where: <r> - Reset
0 - Run
1 - Reset
DD <e> - Sets decision directed enable to <e>
where: <e> - Enable
0 - Disabled
1 –Enabled
AEQ TAPS [DFT][ <f>][ <o>]] - Display equalizer source <s> in format <f> with options <o>
where: <f> - Format
N - Display using normal format - default
C - Display using CSV format
where: <o> - Options
IQ - Display complex values using CSV format - default
POL - Display polar values using CSV format

Technical Guide: RDMS Telnet and Serial Control
19
Quasonix, Inc.
G - Display as graphic only
Examples:
AEQ Report equalizer status
PCMFM$aeq
Adaptive equalizer enabled
EQ auto hold disabled
Decision directed error is NOT in use
Decision directed enabled
Reg enabled
Mean squared error (CMA) 0.014893
Mean squared error (DD) 0.855225
Average confidence 0.040588
Equalizer filters not reset
Equalizer IS in auto reset
Auto reset enabled
AEQ 0 Disable adaptive equalizer
AEQ 1 Enable adaptive equalizer
AEQ H x Set equalizer hold below Eb/N0 to a value between -20.000 and 30.000 dB;
-100.000 sets equalizer hold to Off
AEQ T 0 Disable equalizer information tracking display
AEQ T 1 Enable equalizer information tracking display
2.1.1.4 Automatic Frequency Control - AFC
The Automatic Frequency Control command reports or sets various AFC parameters.
AFC [M <m>|H <t>|C {A|<c>}|L <m>|T {L|H} <t>|R <e> or AFC SYS <d>
M <m> - Sets AFC mode to <m>
where: <m> - mode
O - Off
H - Hold
T - Track
A - Acquire
H <t> - Sets AFC hold below Eb/N0 <t>, -20.000 to 30.000 dB or -100.000 is off
C A - Sets AFC coefficient to be automatically set based on bit rate
C <c> - Sets AFC coefficient to <c>, 0.0003511 to 46.018 seconds
