1. General Description
The PS100 is a Passive speaker with 2 meter long wire, which designed specifically
for GVXXX-series.
The Hands-free kit (include speaker and MIC) enables a Voice Call between
GVXXX-series device and Control Center (or other Voice communications
equipment). Used for both fleet management purposes, or for personal security (in
case of kidnapping, for example, the Control Center can connect to the kit and hear
what happens inside the vehicle).
ACCEPS100UG001 -4-
Queclink
Confidential
PassiveSpeakerUserGuide
2. Product Specification
2.1. Basic Specification
NO. ITEM SPECIFICATION
1 Box Size 74.5mm*68.5mm*33mm
2 Impedance 8ohm±15%
3 Frequency Range F0-6000Hz
4 Rated Power 2W
5 Max Power 3W
6 Sensitivity 85±3dB/W/M
7 Resonance Frequency 450Hz±20%
8 Operating Temperature -20℃～+60℃
9 Storage Temperature -20℃～+60℃
10 Wire 200±3cm; Red, White;
11 Terminal NO
2.2. Frequency Response
